METALUX®F-BAY I5 & I8 DOORFRAMES & WIREGUARDS
For maximum light outputBlank= No Guard
OPEN
Visit our web site at www.cooperlighting.com
Customer First Center 1121 Highway 74 South Peachtree City, GA 30269 770.486.4800 FAX [phone] ADF060835
DESIGNATION DESCRIPTION
In white doorframe w/”Herringbone”
patterned end rail
I5-FRM/FL= Frosted Acrylic Lens & Frame (use
with general distribution reflector, I5 only)
I5-FRM/CL= Clear Acrylic Lens & Frame (use
with general distribution reflector, I5 only)
FROSTED ACRYLIC LENS
DESIGNATION DESCRIPTION
Finished in white. Can be used alone
or in combination with other shielding
I5/WG= Heavy Duty Wireguard
HEAVY DUTY WIREGUARD
DESIGNATION DESCRIPTION
Thin Blade White Baffle w/23˚
longitudinal shielding
I5/TBW=Thin White Baffle (for I5)
I8/TBW=Thin White Baffle (for I8)
TBW
DESIGNATION DESCRIPTION
Can be oriented in either direction for
flexibility
I5/ASY= Asymmetric Directional Louver (use with
general distribution reflector)
ASYMMETRIC LOUVER
DESIGNATION DESCRIPTION
Items listed are the major options and accessories available on Metalux Recessed (Parabolic and Recessed) and Surface Fixtures. Additional options and accessories are available.
Consult Pre SalesTechnical Support for additional information.

METALUX®F-BAY HB DOORFRAMES & WIREGUARDS
For maximum light outputBlank= No Guard
OPEN
Visit our web site at www.cooperlighting.com
Customer First Center 1121 Highway 74 South Peachtree City, GA 30269 770.486.4800 FAX [phone] ADF060835
DESIGNATION DESCRIPTION
Finished in whiteSWG/2HB-4FT-B= Heavy Duty Wireguard for
field installation.
SWG/HB-4FT-B= Heavy Duty Wireguard for
field installation.
DESIGNATION DESCRIPTION
Awide choice of acrylic lenses in a
white extruded aluminum doorframe
(G1 & G2 optional)
HB-FRM/WG= Frame and Wireguard for HB
2HB-FRM/WG= Frame and Wireguard for 2HB
HB-FRM/LENS/WG= Frame and Prismatic
Acrylic Lens with Wireguard
2HB-FRM/CL/WG= Frame and Clear Lens with
Wireguard
HB-FRM/DROP WG= Frame and Drop Wireguard
for HB
2HB-FRM/DROP WG= Frame and Drop Wireguard
for 2HB
WIREGUARD
DESIGNATION DESCRIPTION
Items listed are the major options and accessories available on Metalux Recessed (Parabolic and Recessed) and Surface Fixtures. Additional options and accessories are available.
Consult Pre SalesTechnical Support for additional information.
HB-FRM/LENS= Prismatic Acrylic Lens & Doorframe
for HB (use with general distribution reflector)
2HB-FRM/LENS= Prismatic Acrylic Lens & Doorframe
for 2HB (use with general distribution reflector)
HB-FRM/CL= Clear Acrylic Lens & Doorframe for HB
2HB-FRM/CL= Clear Acrylic Lens & Doorframe for 2HB
DESIGNATION DESCRIPTION
PRISMATIC & CLEAR ACRYLIC
LENS & ALUMINUM DOORFRAME
HEAVY DUTY STOCK WIREGUARD
