Simpli Home Sidney AXCSDY-01 User manual

Sidney / Fleming / Dressler
54 Inch Tall TV Stand
Model # AXCSDY-01
TM
TM
1

2
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
simpli-home.com/product-registration
Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
Activate your 1-year warranty
Automatic entry to win a $500 gift certificate
Earn instant rewards and save
ü
ü
ü

3
Review your product and collect rewards!
Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Share photos and get your cash back!
Send us images or share them on social and qualify for instant
rewards. You may even receive store credit on your entire purchase!
simpli-home.com/share-images

4
For Fastest Customer Service:
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order information and issue.
6. Submit form.
7. A customer service associate will contact you.
Other ways to contact us…
Visit Us
Visit our site directly at
www.simpli-home.com
Email Us
[email protected]
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.

CAUTION: Injuries and damage can occur from furniture tip over if product is
not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint
provided with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly
of this product. Keep this manual for future reference.
5

This furniture is designed for indoor use.
Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity
rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and
contracts unequally along different grain directions. As humidity changes, the components
of wooden objects are continually pushing and pulling against each other. This pressure
often results in parts of furniture no longer fitting together closely or becoming distorted
or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by keeping
furniture containing spaces cooler in the winter or most importantly, have a good working
humidifier for your home. A humidistat automatically works to balance the humidity in
your home so it is constant. Dry indoor air can suck enough moisture from its surroundings
to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger but lose moisture more slowly
than other finishes.
To help protect your wood furniture, take these steps:
·Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly
·Don't over-humidify; that can damage wood by causing it to expand and contract
·Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp
·If you can avoid it, don't put furniture near heating vents; if you can’t, keep the
item 3 to 4 inches away from the wall, giving the heat and air space to circulate
·Dust with soft dry cloth
·Do not use liquid or aerosol products
·To avoid marking, do not place rubber on surface (foot pads, etc.)
·For soil build-up, wipe with damp cloth & dry
·Do not use abrasive cleaners
Care & Maintenance
6

WARNING Do not place toys, food, etc. on the top shelves or upper drawers.
Serious injury or death may occur when children climb on furniture. A remote
control or items placed on the furniture may encourage a child to climb on the
furniture and as a result make it top-heavy and cause it to tip over on the child.
WARNING Do not place a TV that exceeds the weight limits or size guidelines
shown in the instructions specified for the furniture. Do not overload shelves
or place heavy items on top shelves or drawers.
Improper use of furniture to support TVs may result in serious injury or death.
WARNING Do not relocate audio and/or video equipment to furniture not
specifically designed to support audio and/or video equipment. Do not move
furniture without shelves or drawers unloaded. Furniture can collapse or tip
over onto a child and cause physical injury or death.
This TV Stand does not come with legible instructions pertaining to the risk of
fire and electric shock that is associated with the use of electrical components
such as operation, user-maintenance, loading, storage and as applicable
electrical issues including grounding or double-insulation.
Any use of this item other than that recommended by the manufacturer in this
manual may cause fire, burns, electric shock and/or serious injuries or death.
WARNING
The maximum diagonal CRT television screen size is 25 inch to 27 inch (63.50 cm to
68.58 cm). For use with televisions weighing 200 lbs or less. Using larger or heavier
televisions may cause instability or tip over which can lead to serious injury or even
death.
The recommended maximum width of the television intended for use is 60 inch
(152.4 cm).
MAXIMUM LOAD 200 LBS
MAXIMUM LOAD 25 LBS
7

BC
D E F
GH I
TOP
QTY 1 RIGHT SIDE QTY 1 LEFT SIDE
QTY 1
LEFT DIVIDER
QTY 1 RIGHT DIVIDER
QTY 1 TOP FRAME
QTY 1
CENTRE SHELF
QTY 1 BOTTOM SHELF QTY 1 SIDE SHELF
QTY 2
A
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
J KL
CENTRE SHELF
QTY 1 LEFT DOOR QTY 1
KR
RIGHT DOOR
QTY 1
Part Description
Model # AXCSDY-01Pre-Assembly Information
8

LL
L2
LEFT BACK PANEL
QTY 1
M NL
OP
Q
DRAWER FRONT
QTY 2 LEFT DRAWER SIDE
QTY 2
DRAWER BACK
QTY 2 DRAWER BOTTOM
QTY 2
DRAWER BOTTOM SUPPORT
QTY 4
LR
NR
RIGHT DRAWER SIDE
QTY 2
RIGHT BACK PANEL
QTY 1 TOP & BOTTOM BACK PANEL
QTY 2
L1
CENTRE BACK PANEL
QTY 1
Warning
Label
Part Description
Model # AXCSDY-01Pre-Assembly Information
9

MAGNET
QTY 2
ADJUSTABLE HINGE
QTY 4
ALLEN KEY
QTY 1
ALLEN KEY SCREW
M6 X 30mm
QTY 26
PHILLIPS SCREW
ROUND HEAD
M4 X 15mm
QTY 38
CAM LOCK PIN
CAM LOCK
QTY 32 SETS
WOOD DOWEL
M8 X 30mm
QTY 18
12 3 4
5678
9 10 11
PHILLIPS SCREW
M4 X 15mm
QTY 24
SHELF SUPPORT
QTY 18
PHILLIPS SCREW
M3 X 15mm
QTY 8
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
a. M4 X 25mm - QTY 2
( 1 is extra )
b. M4 X 15mm - QTY 1
c. M4 X 25mm - QTY 1
FURNITURE TIP OVER RESTRAINT
QTY 1 SET
Hardware Description
Model # AXCSDY-01Pre-Assembly Information
10

A
C
G
DE
IJI
B
F
H
O
Q
P
M
Q
L1
L2
K L
K
R
N R
N
L
L
R
L
L
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant
Model # AXCSDY-01Components - Key Diagram
11

Step 1
Step 2
Q
Q
2
M
P
M
1. Attach 6 Cam Lock Pins 2 to pre-drilled holes at back of Drawer Front M .
2. Align Cam Lock Pins with pre-drilled holes and attach Drawer Sides NL , NR and
Drawer Bottom Supports Q .
3. Insert 6 Cam Locks 2 into pre-drilled holes on Drawer Sides NL , NR and
Drawer Bottom Supports Q (2 Cam Locks on each Drawer Side, 1 Cam Lock
on each Drawer Bottom Support).
4. Use flathead screwdriver secure Cam Locks.
1. Slide Drawer Bottom P firmly into slots on Drawer Sides NL , NR and
Drawer Front M .
N
L
N R
N
L
N
R
Model # AXCSDY-01Assembly
12

Step 3
Step 4
2O
P
M
1
4
P
M
O
1. Attach 2 Cam Lock Pins 2 to pre-drilled holes at Drawer Back O .
Q
Q
Repeat Step 1 - 4 for the second drawer.
1. Align Cam Lock Pins on Drawer Back O with pre-drilled holes on Drawer
Bottom Supports Q .
2. Align Drawer Back O with Drawer Bottom P and press firmly into slot.
3. Attach Drawer Back O using 2 Allen Key Screws 1 throung pre-drilled holes on
each Side NL , NR .
4. Use Allen Key 4 to tighten screws. Do not over-tighten.
5. Insert 1 Cam Lock 2 into pre-drilled hole on each Drawer Bottom Support Q .
6. Use flathead screwdriver secure Cam Locks.
N
L
N R
N
L
N
R
Model # AXCSDY-01Assembly
13

Step 5
F
D
3
2
1. Insert 2 Dowels 3 into pre-drilled holes on Left Divider D .
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach 2 Cam Lock Pins 2 to Left Divider D using guide holes.
4. Align Cam Lock Pins with pre-drilled holes on Top Frame F .
5. Insert 2 Cam Locks 2 into pre-drilled holes on Top Frame F .
6. Use flathead screwdriver secure Cam Locks.
Front / Avant
Model # AXCSDY-01Assembly
14

Step 6
G
E
2
1. Attach 3 Cam Lock Pins 3 to Right Divider E using guide holes.
2. Align Cam Lock Pins with pre-drilled holes on Centre Shelf G .
3. Insert 3 Cam Locks 2 into pre-drilled holes on Centre Shelf G .
4. Use flathead screwdriver secure Cam Locks.
Front /
Avant
Model # AXCSDY-01Assembly
15

Step 7
41
3
3
D
F
1
4
GE
1. Insert 2 Dowels 3 into pre-drilled holes on each Left Divider D and
Right Divider E .
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach Left Divider D to Centre Shelf G using 3 Allen Key Screws 1 .
4. Attach Right Divider E to Top Frame F using 3 Allen Key Screws 1 .
5. Use Allen Key 4 to tighten screws. Do not over-tighten.
Front / Avant
Front / Avant
Model # AXCSDY-01Assembly
16

Step 8
H
G
D
F
E
4
1
3
1. Insert 2 Dowels 3 into pre-drilled holes on Right Divider E .
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach Right Divider E to Bottom Shelf H using 3 Allen Key Screws 1 .
4. Use Allen Key 4 to tighten screws. Do not over-tighten.
Front /
Avant
Front / Avant
Front / Avant
Model # AXCSDY-01Assembly
17

Step 9
H
G
D
E
B
2
2
3
3
1. Insert 4 Dowels 3 into pre-drilled holes on Bottom Shelf H and Top Frame F
(2 Dowels on each part).
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach 5 Cam Lock Pins 2 to Right Side B using guide holes.
4. Align Cam Lock Pins with pre-drilled holes on Top Frame F and Bottom Shelf H .
5. Insert 5 Cam Locks 2 into pre-drilled holes on Top Frame F and Bottom Shelf H .
6. Use flathead screwdriver secure Cam Locks.
F
Front / Avant
Front / Avant
Front /
Avant
Front / Avant
Model # AXCSDY-01Assembly
18

Step 10
C
H
G
D
EB
F
1. Insert 2 Dowels 3 into pre-drilled holes on Bottom Shelf H .
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach 6 Cam Lock Pins 2 to Left Side C using guide holes.
4. Align Cam Lock Pins with pre-drilled holes on Centre Shelf G and Bottom Shelf H .
5. Insert 6 Cam Locks 2 into pre-drilled holes on Centre Shelf G and Bottom Shelf H .
6. Use flathead screwdriver secure Cam Locks.
22
3
Front / Avant
Front /
Avant
Front / Avant
Front / Avant
Front / Avant
Model # AXCSDY-01Assembly
19

Step 11
3
1
4
H
G
C
D
E
F
B
A
4
1
1. Insert 4 Dowels 3 into pre-drilled holes on Right Side B and Left Side C .
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Align pre-drilled holes bottom corners of Top A with Dowels 3 in Right Side B
and Left Side C .
4. Attach Top A to Right Side B , Left Side C and Left Divider D using 9
Allen Key Screws 1 .
5. Use Allen Key 4 to tighten Screws. Do not over-tighten.
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front /
Avant
Model # AXCSDY-01Assembly
20
