Uplift Desk UPL940 Quick setup guide

90.014.01.0146v.D
DIRECTIONS FOR ASSEMBLY AND USE
UPLIFT 4-Leg Height Adjustable Standing Desk
®
SAVE THESE INSTRUCTIONS:
Any user or installer of desk base must study this manual carefully. If this desk is sold,
please provide the manual to the buyer, installers, or support personnel operating the product.
TABLE OF CONTENTS PAGE
1 Safety and Warnings 2
2 Usage 2
3 Parts List 3
4 Assembly Instructions 4
5 Desk Placement 7
6 Programming 7
7 Troubleshooting 8
8 TechnicalSpecications 9
UPL940/R01
© UPLIFT Desk•1-800-349-3839•[email protected]•www.upliftdesk.com

© UPLIFT Desk • 1-800-349-3839 • [email protected] • www.upliftdesk.com
2
2. USAGE
Thisheightadjustabledeskhasanelectricmotorandisdesignedforuseindryworkareasonly.Thedesk
height is adjustable so that it can be positioned at the most ergonomically suitable height. These desks are
designedonlyforthepurposesincludedinthismanual.Theyshouldnotbeusedinenvironmentswithhigh
humidity or dampness. Any other use is at user’s risk.
Donotmovearound,crawl,orlieunderthedeskframe.Donotsitorstandonthedeskframe.
Children should never use the desk unless they are supervised by adults.
Liability: Undernocircumstancesdoesthemanufactureracceptwarrantyclaimsorliabilityclaimsfordam-
agescausedfromimproperuseorhandlingofthedeskframeotherthanthatwhichisdescribedinthis
operation manual.
1. SAFETY AND WARNINGS
Whenusinganelectricalfurnishing,basicprecautionsshouldalwaysbefollowed,includingthefollowing:
Read all instructions before using the desk.
FAILURE TO COMPLY WITH OR OBSERVE ALL INSTRUCTIONS AND WARNINGS REGARDING THE
USE OF THIS PRODUCT MAY RESULT IN SERIOUS PROPERTY DAMAGE OR BODILY INJURY.
DANGER - Toreducetheriskofelectricshock,alwaysunplugthisfurnishingfromtheelectricaloutlet
before cleaning, or before putting on or taking off parts.
WARNING - Toreducetheriskofburns,re,electricshock,orinjurytopersons:
• Closesupervisionisnecessarywhenthisfurnishingisusedby,ornearchildren,invalids,ordisabled
persons.Keepchildrenawayfromelectricheight-adjustabledesks,controlunits,andkeypads.
There is a risk of injury and electric shock.
• Use this table only for its intended use as described in these instructions. Do not use attachments
not recommended by the manufacturer.
• Keepthetableclosetothepowersocket/outlettobeeasilyaccessible.
• Neveroperatethistableifithasadamagedcordorplug,ifitisnotworkingproperly,ifithasbeen
droppedordamaged,ordroppedintowater.
• Keepthecordawayfromheatedsurfaces.
• Donotopenanyofthecomponents:legs,controlbox,orkeypad.Thereisadangerofelectric
shock. Do not insert anything into any seam or opening.
• Keepallelectricalcomponentsawayfromliquids.
•
Donotoperatewhereaerosol(spray)productsarebeingusedorwhereoxygenisbeingadministered.
• Do not use outdoors.
• Inappropriate use of this product may cause property or bodily injury.
• Check surroundings on all sides before using the desk. Body parts and property can be crushed if
trappedbetweenanimmobileobstacleandthedesk’srangeofmotion.
• Ensurethelengthofpowercordsareaccountedforwhenoperatingthedesk.Monitors,comput-
ers,speakers,anythingwithacordthatisnotlongenoughforthedesk’srangeofmotioncouldbe
pulleddownorhaveitswiresbroken.Itemspulledoffthedeskmaycauseotheritemstofall.
• Please provide this manual to any users, installers, or support personnel operating the product.
MAKE SURE NO OBSTACLES ARE IN THE DESK’S PATH AND ALL CORDS ARE
OF APPROPRIATE LENGTH FOR DESK TRAVEL. FAILURE TO COMPLY WITH
OR OBSERVE ALL ASSEMBLY, SAFETY, AND OPERATION INSTRUCTIONS AND
WARNINGS REGARDING THE USE OF THIS PRODUCT MAY RESULT IN SERIOUS
PROPERTY DAMAGE OR BODILY INJURY.
!

© UPLIFT Desk • 1-800-349-3839 • [email protected] • www.upliftdesk.com 3
6
Part # Description Qty
4
4
4
16
1
1
4
5
32
28
Leg
Small Foot
Zero Crossbar Bracket
Adhesive Pads
Control Box
Keypad
Leveling Studs
Cables (power&connectorcables)
M6x14 Screw
M5x16 Wood Screw Cable
Clips 15
1
1
2
2
3
34
4
5
6
7
8
9
10
10
11
or
5
Foot
(qty4)
Leg
(qty4)
Control box
(qty1)
Adhesive
pads
(qty20)
Leveling stud
(qty4.pre-installed)
1 2 4
36
M5x16
wood screw
(qty28)
Cable clip
(qty15)
11
10
5
M6x14 screw
(qty32)
Keypad
oneoftwotypes(qty1)
8
79
or
Zero crossbar
bracket
(qty4)
Components
Tools Required
3. PARTS LIST
Please count all pieces before disposing of any carton or packing material. Use a padded or carpeted
area for assembly to avoid damage. For ease and safety, we recommend two people for assembly.
PhilipsHeadScrewdriver
and/orPowerDrill
Tape
Measure
Allenwrench
(included)
9
Connectorcables qty 4
Powercable qty 1
Cables

© UPLIFT Desk • 1-800-349-3839 • [email protected] • www.upliftdesk.com
4
4. ASSEMBLY INSTRUCTIONS
A. Layoutallcomponentsandhardware
to ensure that you have all the components
andhardwarelistedonthepartspage.
Placeve(5)self-adhesiveAdhesivePads
(part4)oneachofthefour(4)Zero
CrossbarBrackets(part3)asshown.
B. PlaceeachZeroCrossbarBracket(part3)ontheundersideofthedesktop.Carefullymeasure
fromallsidesandattachtheZeroCrossbarBrackets(part3)totheundersideofthedesktopwith
twenty-four(24)PanHeadScrews(part10),six(6)perbracket.
Double-checkthatthewoodscrews
are not too long for the desktop
andwon’tpuncturethesurface
whenscrewedallthewayin.
Ifyourdesktopisnotpre-drilled,werecommend
that you pre-drill the holes for connecting the
Brackets(part3)tothedesktop.Drill1/2’’deep
(max)witha1/8’’drillbit.
Neverusecountersunkscrews.
i
!
10
3
3
4

© UPLIFT Desk • 1-800-349-3839 • [email protected] • www.upliftdesk.com 5
D. Attachthefour(4)SmallFeet(part2)
tothefour(4)Legs(part1),eachwith
four(4)MachineScrews(part9).
9
2
E. Usingthecables,connecttheLegs(part1)
totheControlbox(part5)andtheKeypad
(part6)asperthediagrambelow.
Do this so you can place the Keypad
andControlBoxinsuchawaysothat
the cables can reach them.
C. Usingthesuppliedallenwrench,
insertfour(4)MachineScrews(part9)
throughtheholesineachZeroCrossbar
Bracket(part3)goingintotheLeg(part1)
androtateeachscrewjustafewturns.
Whenallmachinescrewsarethreaded,
gobackandtightenallfour(4).
1
3
9
1
5
6
8

© UPLIFT Desk • 1-800-349-3839 • [email protected] • www.upliftdesk.com
6
G. Turntheassembleddeskright-side-up.Withtwopeople,grabthedeskbythelegsanddesktop
and turn the desk right-side up. Adjust the Leveling studs on the Feet as needed.
MAKE SURE NO OBSTACLES ARE IN THE DESK’S PATH.
MAKE SURE ALL CORDS ARE OF A LENGTH THAT WILL
ACCOMMODATE THE CHANGE IN HEIGHT.
H. PlugthePowerCordintoa110voutlet.
IMPORTANT!
You must RESET the desk prior to use!
Press and hold the DOWN button on the Keypad until the desk reaches
itslowestheight.ReleasetheDOWNbutton.PressandholdtheDOWN
buttonagainuntiltheLEDdisplayreads“RST”orabout10secondson
non-LED handset models. Release the DOWN button. Press and hold
theDOWNbuttonagainuntilthedesklowersalittlebitmore,slightly
risesandstops.ReleasetheDOWNbutton.Yourdeskisnowreadytouse.
Toprogramuptofourpresets:
Usetheup/downbuttonstondadesiredheight,thenpress“M”followedbyanumber1–4.
8
F. AttachtheControlBox
(part5)totheundersideof
thedesktopusingtwo(2)M5x16
Screws(part10).Ensureitisplaced
close to the center of the desktop
so the cables can reach it.
PlacetheKeypad(part6)sothat
thefrontoftheKeypadisushwith
thefrontdesktopedge(orrecessed
upto1/8”).TheKeypadmaybeplaced
anywherealongthefrontedgeofthe
desktopbutwerecommendplacingit
towardanendsoitdoesnotinterfere
withthechairswhenseated.Usetwo
(2)M5x16Screws(part10)tothedesktop.
Usetheadhesive-backedCableClips(part11)
to secure the Connecting Wires, so they don’t sag.
Double-checkthatthewoodscrews
are not too long for the desktop
andwon’tpuncturethesurface
whenscrewedallthewayin.
Donotovertightenscrewsinthis
step. Overtightening could cause
damage to the components.
5
6
! !
!
Ifyourdesktopisnotpre-drilled,werecommendthat
youpre-drilltheholesforconnectingtheControlbox
(part5)andKeypad(part6)tothedesktop.
Drill1/2’’deep(max)witha1/8’’drillbit.
Neverusecountersunkscrews.
i

© UPLIFT Desk • 1-800-349-3839 • [email protected] • www.upliftdesk.com 7
5. DESK PLACEMENT
Followingdeskassembly,adjusttheLevelingstudsorcasters(soldseparately)onthefeetsothatthedesk
is level and does not shift its position.
Whenmovingthedesk,ifcastersarenotinstalled,useatwo-personliftandliftthedesksothatitcanbe
movedwithoutdragging.Draggingthedeskmaycausetheframeandscrewstopullloosefromthedesktop.
When moving the desk, DO NOT lift the desk by the desktop alone, or the frame, alone. Support both the
frameandthedesktopequally.Favoringoneovertheothercanstressthefastenersconnectingthedesk
frametothedesktop.Lowerthedeskcompletelyandliftthedeskbygraspingtheframe.
Chooseaplacementforthedeskthat’sasafedistancefromwindowframes,radiators,furniture,etc.,so
that people do not get stuck or trapped by the desk.
Checkcordclearance,sothattheydon’tgetjammed.Thenconnectthedesktothe120voutletandthe
desk is ready for use.
Donotplaceanyobjectsunderneaththedeskthataretallerthan20’’.
6. PROGRAMMING:
If you’ve purchased an UPLIFT Desk and the Advanced 1-touch digital keypad, press the DOWN button
ontheKeypaduntiltheframereachesitslowestposition.Measuretheheightoftheframefromtheoor
to the underside of the desktop and if the number on the LED display does NOT match your measure-
ment,followthesesteps:
Press and hold the DOWN button again until the LED display reads “RST”
Pressandholdthe“M”button(about5seconds)untiltheLEDdisplaystheashingstartingheight.
(Ifthedisplayreturnsto“RST”beforethenextstepistaken,repeatthisstep.)
To change the value of the starting height:
By0.1s:
Increase:presstheUPbutton
Decrease:presstheDOWNbutton
Oncethenewvalueisdisplayed,waitabout5secondsandthedisplaywillreturnto“RST”.Finish
theresetprocessbypressingandholdingtheDOWNbuttonagainuntilthedesklowersalittlebit
more,slightlyrisesandstops.ReleasetheDOWNbutton.Thenewstartingheightvalueissaved
andyourdeskisnowreadytouse.
Note:theLEDdisplayhasa0.1tolerance.
+
-
By1.0s:
Increase:pressthe“l”button
Decrease:pressthe“2”button
By10.0s:
Increase:pressthe“3”button
Decrease:pressthe“4”button
SETTING THE LED RETRACTED HEIGHT

© UPLIFT Desk • 1-800-349-3839 • [email protected] • www.upliftdesk.com 8
6. PROGRAMMING (continued):
Thisframeisdesignedtogotoitsminimumandmaximumheights,allowingforthewidestpos-
siblerange.Ifyouprefertochangethesettingstoamorenarrowrange,followthesesteps:
MakesurethepowerisONandanumberreadsintheLEDdisplay(ifnonumberappears,please
followtheResetproceduredescribedintheTROUBLESHOOTINGsectionbelow).
To Set the Upper-Limit Position:
UsetheUP/DOWNbuttonstomovetheframetothedesiredmaximumheightposition.
MakesuretheUPbuttonwasthelastbuttonyoupushed.Pressandholdthe“M”button
untiltheLEDdisplayashes“S-”onceandletgoofthebuttonThenpressandrelease
thebutton2moretimesinquicksuccession.TheLEDdisplaywillchangeto“999”onthe
thirdpush,andthenautomaticallyreturntotheselectedheight.Thenewupperlimitis
nowset.
To Set the Lower-Limit Position:
UsetheUP/DOWNbuttonstomovetheframetothedesiredminimumheightposition.
MakesuretheDOWNbuttonwasthelastbuttonyoupushed.Pressandholdthe“M”but-
tonuntiltheLEDdisplayashes“S-”onceandletgoofthebutton.Thenpressandre-
leasethebutton2moretimesinquicksuccession.TheLEDdisplaywillchangeto“000”
onthethirdpush,andthenautomaticallyreturntotheselectedheight.Thenewlower
limitisnowset.
To Remove the Upper/Lower Limit Positions:
UsetheUPorDOWNbuttontomovethedesktoanynewposition.Pressandholdthe
“M”buttonuntiltheLEDdisplayashes“S-”onceandletofthebutton.Thenpressand
releasethebuttoninsuccessionuntilthedisplaychangesto“555”(ignoreanyinterim
readings).Afterafewseconds,thedisplaywillautomaticallychangebacktothenum-
beredheightposition.Theupperandlowerlimitsarenowremoved.
ARESETprocedurerequiresthedeskframetofullyretract(beyond
anylowerlimitset).Pleaseensurethatyouhavetheproperclear-
ancebelowthedeskframe.
Aftertheupperandlowerlimitsareset,thepreviousmemorypositions(l,2,3,4)maybeoutside
thenewrangeofmovement.Ifso,simplyresetthememorypositions.
Ifyouattempttoreviseapreviouslysetupperorlowerlimitanditisoutsideoftheexistingrange,
youwillneedtoremovethepreviouslysetupper/lowerlimitsrst.
! !
SETTING THE UPPER & LOWER LIMITS (Advanced 1-touch digital keypad only)
7. TROUBLESHOOTING
--Reset Instructions--
IfexperiencingerrormessagesshowingontheKeypadornoresponsewhentryingtoraiseorlower:
• UnplugthepowercordandholdtheDOWNbuttonfor30seconds.
• Plugthepowercordbackin.
• PressandholdtheDOWNbuttonontheKeypaduntilthedeskreachesitslowestheight.Releasethe
DOWNbutton.PressandholdtheDOWNbuttonagainuntiltheLEDdisplayreads“RST”orabout10
seconds on non-LED keypad models. Release the DOWN button. Press and hold the DOWN button
againuntilthedesklowersalittlebitmore,slightlyrisesandstops.ReleasetheDOWNbutton.Your
deskisnowreadytouse.
• TheKeypadwillthendisplaythecurrentheight,andyoushouldbeabletooperateitnow.
• Youmayneedtodothisifthedesktopiseverunpluggedorlosespower.
IftheLeypaddisplayserrormessages“Er1”through“Er13”,conrmthatallwiredconnectionsaresecure
(legstocables,cablestocontrolbox).Thenperformtheresetprocedureabove.Iftheerrormessageper-
sistsaftertheresetprocedureoriftheheightbetweenthelegsexceeds1.5’’stoptheresetprocedureand
contactTheHumanSolution(800.531.3746or[email protected]).
IftheKeypaddisplays“Hot”,letthebasecooldownfor20minutes.
Ifthedeskseemstobeuneven,trytheresetinstructionsabove.Ifthatdoesnotworkyoumayneedto
adjust the levelers at the bottom of the foot.

© UPLIFT Desk • 1-800-349-3839 • [email protected] • www.upliftdesk.com 9
KeepChildrenawayfromelectricheight-adjustabledesks,controlunitsand
handsets. There is a risk of injury and electric shock
Thisproductisdesignedwithadutycycleof10%
(2min.on,18min.off)
Intheeventofapoweroutageorifthepowercordisunplugged,
amanualresetmaybenecessary(seeResetInstructionsabove)
Donotopenanyofthecomponents:liftingcolumns,controlbox,orhandset.
There is a danger of electric shock
Keepallelectricalcomponentsawayfromliquids
i
i
8. TECHNICAL SPECIFICATIONS
Height Range 23.5”-49.5”(withoutdesktop)
Travel Speed 1.5”persecond(varies,slowestw/maximumload)
Weight Capacity 710lbs.
Duty Cycle 10%,Max.2minson,18minsoff
   SoftStart/Stop
Adjustable leveling studs
   4Memorypresets(somemodels)
!
!
!
Ifcastersarenotinstalled,useatwo-personliftandliftthedesksothatitcanbe
movedwithoutdragging.Draggingthedeskmaycausetheframeandscrews
to pull loose from the desktop.
!
Copyright Notice: This guide is a component of the UPLIFT Desk™. This guide is a part of the scope of delivery, even if the item is resold. This guide is also
availableontheUPLIFTDeskwebsite:upliftdesk.com.Excerptsorcopiesmaynotbeforwardedtothirdpartiesorusedinanyotherpublishedformwithout
thepriorwrittenconsentofUPLIFTDesk.
TheseinstructionsaresubjecttoUnitedStatescopyrightlaw.
©
