Mocka Eclipse Four Drawer User manual

Eclipse Four Drawer
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
Wall Strap
x2
washer
Z
Y
wall
anchor
x1
X
safety
strap x1
WV
screw
x1
wall
screw
x1
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
bolt
x35
x8
A B C D E F G H
JKL M
I
Hardware Supplied
dowel
x14
screw
x40
slide
rail x4
slide
rail x4
slide
rail x4
slide
rail x4
locking
nut x35
screw
x7
wedge
x8
screw
Phillips & Flathead screwdrivers
bolt
x8
handle
x4
N
handle
screw
x8
screw
x26
Allen Key
x1
O P

Eclipse Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
2
12
Insert 5x bolts (C) into panel [1] and tighten with a screwdriver. Attach 4x slide rails (F) and 4x slide rails (G) to panels [3] and
[4] as shown and secure with 24x screws (E). Tighten with
a screwdriver. .
G
CR
E
F
CL
E
1
3
4
G
G
G
G
F
F
F
F
C
C
C
C
C
E
E
E
E
E
E
E
E

Eclipse Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
3
3 4
Insert 10x bolts (C) into panels [3] and [4]. Tighten with a screwdriver. Attach panels [5], [6], [7] and [8] to panel [3] with 2x dowels (A) and
secure with 5x locking nuts (D). Tighten with a screwdriver.
3
3
4
5
7
8
C
C
C
CC
C
CC
C
C
AD
D
D
DD
3
6
D
D

Eclipse Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
4
65
Slide panel [9] down along the grooves between the panels [7]
and [8] to form the back of the unit as shown.
Attach panel [4] to panels [5], [6], [7] and [8] with 2x dowels (A) and
secure with 5x locking nuts (D). Tighten with a screwdriver.
4
5
7
7
9
8
8
A
A
D
D
D
D
3
6

Eclipse Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
5
7 8
Attach panel [1] to panels [3], [4], [5] and [7] with 6x dowels (A) and
secure with 5x locking nuts (D) and 3x screws (B). Tighten with a
screwdriver.
Slide panel [9] down along the grooves between the panels [3]
and [4] to form the back of the unit as shown.
1
3
3
4
4
7
9
A
A
D
D
D
D
D
B
B
B
A
A
AA
3
5

Eclipse Four Drawer
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
6
910
Assembly Instructions
10
10
11
11
12
12
Attach panel [2] to the unit with 4x dowels (A) and secure with 4x
screws (B). Tighten with a screwdriver.
Attach panels [10] to panels [11] and panels [12] and secure
with 8x bolt (L). Tighten with an Allen Key (P).
B
B
A
A
B
B
A
L
L
L
L
L
L
L
L
3
2
4
LP

11
Attach panels [11] to panel [2] as shown using 6x screws (O).
Tighten with a screwdriver.
Insert 20x bolts (C) into panels [13] and [14]. Tighten with a screwdriver.
Eclipse Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
7
12Drawers x411
O
O
O
O
O
O
CC
C
C
C
CC
C
C
C
2
3
11
3
13
3
14
x2
x2
O

Slide panels [18] along the grooves between the side
panels [15] and [16] as shown.
Eclipse Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
8
14 Drawers x413 Drawers x4
Attach panels [15], [16] and panel [17] to panels [13] and [14]
and secure with 20x locking nuts (D). Tighten with a screwdriver.
DD
D
D
D
3
15
3
15
3
17
3
16
3
16
3
18
x2 / x2
3
13 3 14
x2 / x2
3
13 3 14

Attach slide rail (I) and slide rail (H) to the underside of the side
panels [15] and [16] as shown. Secure with 16x screws (E) and
tighten with a screwdriver.
Eclipse Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
9
16 Drawers x415 Drawers x4
Attach panels [15], [16], [17] and [19] together as shown using 20x screws (O).
Tighten with a screwdriver.
OO
O
OOH
E
E
E
E
I
3
15
3
15
3
16
3
16
3
19
x2 / x2
3
13 3 14
x2 / x2
3
13 3 14

Insert the assembled drawers into the corresponding compartments
as shown. Ensure the drawers slide easily along the rails.
Eclipse Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
10
1817Drawers x4
Attach 4x handles (M) to panels [13] and [14] and secure with 8x
handle screws (N). Tighten with a screwdriver.
M
M
N
N
N
N
3
13
3
13
3
14
3
14
3
13
3
14
x2
x2
Tighten the
screws 90%..
Tighten the
screws 90%..

9
9
Once assembled lift furniture into place, do not drag. Use a drill to
create a small hole lining up with the top of the safety strap (V).
Fasten to the wall using 1x washers (Z), 1x wall anchor (X) and
1x wall screw (Y). Ensure unit is balanced and steady before use.
You’re done, enjoy!
Eclipse Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
11
2019
Attach 8x wedges (J) into the corners of the back of the
unit and secure with 8x screws (K). Tighten with a screwdriver.
Attach 1x safety straps (V) to the top of the back side of the unit as
shown using 1x washers (Z) and 1x screws (W). Tighten with a
screwdriver.
V
Z
W
J
K
V
Z
W
X
Y
Z
wall
anchor
screw
strap
washer

Eclipse Four Drawer
Assembly Instructions
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
12
21
After installation, if the two handles are not aligned, loosen the screws
in the back, adjust the two handles to align them, and then tighten the
screws back up.
M
M
M
M
M
M
