Simpli Home WyndenHall Brooklyn + Max AXCHAR-06 User manual

1/15
TV MEDIA STAND
MODEL # AXCHAR-06
HARDING / BARRIE / DIXON
TM
TM
SI
M P
HOME
TM

2/15
TM
TM
SI
M P
HOME
TM
Questions, problems, assembly help, missing parts?
o nee to return the prouct, we will glaly help an ship your
replacement parts ree o charge
lease call ustomer erice at --- et. 
onay to riay between  am  pm 
or go to
www.simpli-home.com/parts request
n orer to assist you in a timely manner, please hae the ollowing
inormation reay
oel  art umber or etter
urchase at ate o urchase 
If you wish to return the product, please contact the retailer where the
product was purchased.

3/15
IMPORTANT : for Please read this manual carefully before beginning
assembly of this product. keep this manual for future reference.
SAFETY INFORMATION
Identify all the parts and hardware. Do not discard of the packaging until you have
checked that you have all of the parts and hardware required. hardware package
may have spare parts.
WARNING: This item contains small parts which can be swallowed by children
and pets. keep children and pets away during assembly. to avoid danger of
suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid scratches.
If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.

4/15
CARE and MAINTENANCE
Perhaps the greatest environmental damage to wood furniture comes from wide swings in
relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative
humidity rises and falls, and in doing so it swells and shrinks. Making matters worse, it
expands and contracts unequally along different grain directions. As humidity changes,
the components of wooden objects are continually pushing and pulling against each
other. This pressure often results in parts of furniture no longer fitting together closely or
becoming distorted or breaking from their own internal stresses.
The response to relative humidity changes begins with determining the annual average RH
for your particular space. Then try to keep the RH in the space where your furniture is as
close to that average as possible, generally within about 10% up or down. De-humidify in
the summer and humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern
heating systems, which can drive down interior RH in the winter, almost invariably cause
problems for furniture. To counteract their effect, you can either modify the RH by
keeping furniture containing spaces cooler in the winter or most importantly, have a good
working humidifier for your home. A humidistat automatically works to balance the
humidity in your home so it is constant. Dry indoor air can suck enough moisture from its
surroundings to do permanent damage to wood, causing it to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how
rapidly a wood will lose moisture are pore size and surface hardness. A piece made from a
dense and hard wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished
piece while pieces with veneer finishes are not only stronger, but lose moisture more
slowly than other finishes.
To help protect your wood furniture, take these steps:
·Use a humidifier, preferably one with an automatic control system that can sense the
humidity level and adjust itself accordingly. Don't over-humidify; that can damage
wood by causing it to expand and contract.
·Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp.
·If you can avoid it, don't put furniture near heating vents. If you must, keep the piece 3
to 4 inches away from the wall, giving the heat and air space to circulate.
·Dust with soft dry cloth.
·Do not use liquid or aerosol products.
·To avoid marking, do not place rubber on surface (foot pads, etc.)
·For soil build-up, wipe with damp cloth & dry.
·Do not use abrasive cleaners.
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.

5/15
NEED HELP? for help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm est)
PARTS DESCRIPTION
HARDWARE DESCRIPTION
PRE-ASSEMBLY INFORMATION MODEL #
AXCHAR-06
PRE-ASSEMBLY INFORMATION MODEL #
AXCHAR-06
A
C
B
D
TOP
QTY 1
LEG
QTY 2
E
BOTTOM
QTY 1
CASTER WHEELS
QTY 4
ALLEN KEY BOLT
M8 X 50 mm
QTY 12
ALLEN KEY BOLT
M8 X 20 mm
QTY 8
WASHER
Ø 22.5 / Ø 8.5 X 1.2 mm
QTY 20
ALLEN KEY
QTY 1
12
35
SHELF
QTY 1
4
LOCK WASHER
Ø 12 / Ø 8.5 X 2 mm
QTY 20

A
C
D
6/15
COMPONENTS - KEY DIAGRAM MODEL #
AXCHAR-06
E
B
B

7/15
ASSEMBLY MODEL #
AXCHAR-06
STEP 1
A
A
B
B
5
1
3
4
1. Place Top A upside down on a smooth, flat surface and place Leg B on Top A .
2. Use four Allen Key Bolts 1 , four Washers 4 , and four Lock Washers 3
to attach Leg B to Top A .
3. Use Allen Key 5 to tighten Bolts. Do not over tighten.

8/15
ASSEMBLY MODEL #
AXCHAR-06
STEP 2
3
1
4
B
B
A
B
B
A
4
1. Repeat Step #1 to attach the second Leg B to Top A .

9/15
ASSEMBLY MODEL #
AXCHAR-06
STEP 3
D
2
1
3
B
B
C
D
C
B
B
3
4
4
1. Align Bottom C and four
Caster Wheels
D to Legs B by matching Holes.
2. Use one Allen Key Bolt 1 , one Lock Washer 3 and one Washer 4
on each corner of the TV Stand to attach the Caster Wheels D .
Use one Allen Key Bolt 2 , one Lock Washer 3 and one Washer 4
on the other side of the Caster Wheel D facing inward to complete attaching the
Caster Wheels. Refer to the diagram for exact location of the Bolts.
3. Use Allen Key 5 to tighten Bolts. Do not over tighten.

10/15
ASSEMBLY MODEL #
AXCHAR-06
STEP 4
4
2
5
E
E
3
1. Insert the Shelf E on center of TV Media Stand.
2. Use four Allen Key Bolts 2 , four Washers 4 and four Lock Washers 3 .
3. Use Allen Key 5 to tighten Bolts. Do not over tighten.

11/15
ASSEMBLY MODEL #
AXCHAR-06
STEP 5
Note: Insert the pin in the Caster Wheel to lock in place .

12/15
TO MOVE THE TV MEDIA STAND
REMOVE THE PIN FROM THE CASTER WHEEL

13/15
TO KEEP THE TV MEDIA STAND IN A PERMANENT PLACE
5
1. Remove the Caster Wheels on the long side of the TV Media Stand.
(pick one side).
Use Allen Key 5 to remove Allen Key Bolt 2 , Washer 4
and Lock Washer 3 facing inward on both Caster Wheels.
234
C
1
3
4
STEP (A)

14/15
90°
C
D
Rotate Caster Wheels 90° .
1. Use Allen Key Bolt 2 , Lock Washer 3 and Washer 4
to complete attaching the two Caster Wheels to the Bottom C .
Refer to the diagram for placement of the Caster Wheels.
2. Use Allen Key 5 to tighten Bolts. Do not over tighten.
5 2 3 4
1
3
4
STEP (B)
TO KEEP THE TV MEDIA STAND IN A PERMANENT PLACE

15/15
WARRANTY
TM
TM
SI
M P
HOME
TM
Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max
product. These products have been made to demanding, high-quality
standards and are guaranteed for domestic use against manufacturing faults
for a period of 12 months from the date of purchase. This warranty does not
affect your statutory rights.
In case of any malfunction of your product (failure, missing parts, etc.) please
contact us at our toll free service line at 1-866-518-0120 ext. 262 from 9 am
to 4 pm, Monday to Friday, Eastern Standard Time or by email at
[email protected]
We reserve the right to repair or replace the defective product, at its
discretion.
This product is guaranteed for 12 months if used for normal purposes.
Any warranty is invalid if the product has been overloaded or subject to
neglect, improper use or an attempted repair by other than an authorized
agent. Heavy-duty or daily professional/commercial usage are not
guaranteed.
Due to continuous product improvement, we reserve the right to change the
product specifications without prior notice.
