Simpli Home brooklyn+max WyndenHall AXCERN-07 User manual

Erina / Cecilia / Larny
Low TV Media Stand
Model # AXCERN-07
TM
TM
1

2
It's time to register your product warranty.
It's quick and easy. And you'll be happy you did.
simpli-home.com/product-registration
Great quality is a right.
Thank you for shopping with Simpli Home,
America's top brand for high-value furniture.
Activate your 1-year warranty
Automatic entry to win a $500 gift certificate
Earn instant rewards and save
ü
ü
ü

3
Review your product and collect rewards!
Thank you for your purchase! We hope you enjoy it. We’d love
your feedback. Please share a review and get instant rewards!
simpli-home.com/product-review
Share photos and get your cash back!
Send us images or share them on social and qualify for instant
rewards. You may even receive store credit on your entire purchase!
simpli-home.com/share-images

4
For Fastest Customer Service:
1. Open your phone’s camera.
2. Point your phone’s camera at the QR code to scan.
3. Click on the pop up.
4. You’ll be taken to our customer service page.
5. Fill the form with your order information and issue.
6. Submit form.
7. A customer service associate will contact you.
Other ways to contact us…
Visit Us
Visit our site directly at
www.simpli-home.com
Email Us
[email protected]
Call Us
1-866-518-0120
Monday to Friday
9am to 5pm EST
*If you’ve purchased from a retailer and you wish to return the product, please
contact the retailer directly.

CAUTION: Injuries and damage can occur from furniture tip over if product is
not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint
provided with the product. Consult our assembly instructions for help.
If the Furniture Anti-Tipping Restraint kit is not in the box, please contact our
customer service department in order to obtain another kit before using the
furniture.
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required.
Hardware package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly
of this product. Keep this manual for future reference.
5

This furniture is designed for indoor use.
Damage to furniture can come from temperature changes in relative humidity (RH)
in our homes. Humid air oxidizes metal which results in rusting, corrosion, tarnishing
and roughness. Wood absorbs water as relative humidity rises and falls, and in doing
so it swells and shrinks.
To protect against the humidity effect, the metal is powder coated. The powder coat
layer protects the metal from oxidizing, corrosion, tarnishing and scratching and
keeps it looking good for years to come. The wood is sealed and lacquered to
protect against humidity.
To help protect your furniture, follow these steps:
·Use a humidifier, preferably one with an automatic control system that can
sense the humidity level and adjust itself accordingly
·Dust with soft dry cloth
·Wipe up spills promptly
·Clean with a dry cloth
·Do not use abrasive cleaners, chemical solvents, strong detergents, cleaners
with bleach, and furniture polish
·Use soft felt base coasters, placemats to help prevent scratches
·Keep furniture out of direct sunlight, which can cause cracking or roughness
on the protective layer
·If it can be avoided, do not put furniture near heating vents
·Keep the furniture 3 to 4 inches away from the wall, giving heat and air space to
circulate.
Care & Maintenance
6

WARNING Do not place toys, food, etc. on the top shelves or upper drawers.
Serious injury or death may occur when children climb on furniture. A remote
control or items placed on the furniture may encourage a child to climb on the
furniture and as a result make it top-heavy and cause it to tip over on the child.
WARNING Do not place a TV that exceeds the weight limits or size guidelines
shown in the instructions specified for the furniture. Do not overload shelves
or place heavy items on top shelves or drawers.
Improper use of furniture to support TVs may result in serious injury or death.
WARNING Do not relocate audio and/or video equipment to furniture not
specifically designed to support audio and/or video equipment. Do not move
furniture without shelves or drawers unloaded. Furniture can collapse or tip
over onto a child and cause physical injury or death.
This TV Stand does not come with legible instructions pertaining to the risk of
fire and electric shock that is associated with the use of electrical components
such as operation, user-maintenance, loading, storage and as applicable
electrical issues including grounding or double-insulation.
Any use of this item other than that recommended by the manufacturer in this
manual may cause fire, burns, electric shock and/or serious injuries or death.
WARNING
The maximum diagonal CRT television screen size is 25 inch to 27 inch (63.50 cm to
68.58 cm). For use with televisions weighing 220 lbs or less.
Using larger or heavier televisions may cause instability or tip over which can lead to
serious injury or even death.
The recommended maximum width of the television intended for use is 72 inch
(182.88 cm).
MAXIMUM LOAD 220 LBS MAXIMUM LOAD 25 LBS
7

.C
.
L
B
.
R
B
.A
SHELF
QTY 2 LEFT SIDE QTY 1
RIGHT SIDE
QTY 1 UPPER BAR
QTY 2
LOWER BAR
QTY 1
.D
Front / Avant
UpSide/Vertical
Up Side / Vertical
UpSide/Vertical
Up Side / Vertical
Part Description
8
Model # AXCERN-07Pre-Assembly Information

Required -
Flathead screwdriver
Phillips screwdriver
Not Included
.1.3 .2
.4.5
ALLEN KEY BOLT
M6 X 20mm
QTY 12
LOCK WASHER
Ø10 / Ø6 x 1.5 mm
QTY 12
WASHER
Ø16 / Ø6 x 1 mm
QTY 34
ALLEN KEY
QTY 1
PHILLIPS SCREW ROUND HEAD
M4 X 15mm
QTY 22
a. M4 X 25mm - QTY 2
( 1 is extra )
b. M4 X 15mm - QTY 1
c. M4 X 25mm - QTY 1
FURNITURE TIP OVER RESTRAINT
QTY 2 SETS
.6
Hardware Description
9
Model # AXCERN-07Pre-Assembly Information

C
BL
BR
A
A
C
D
Front /
Avant
Front /
Avant
Up Side / Vertical
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
10
Model # AXCERN-07Components - Key Diagram

Step 1
1. Align Upper Bars C and Lower Bar D to Right Side BR .
2. Use two Bolts 1 , two Lock Washers 2 and two Washers 3 to secure
each part C , D with BR .
3. Use Allen Key 5 to tighten Bolts. Do not over-tighten.
C
BR
D
C
BR
D
3
2
1
5
Up Side / Vertical
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
11
Model # AXCERN-07Assembly

Step 2
1. Repeat Step-1 for Left Side BL .
C
BR
D
BL
C
C
D
BL
BR
3
2
1
5
UpSide/Vertical
Up Side / Vertical
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
UpSide/Vertical
12
Model # AXCERN-07Assembly

Step 3
1. Attach top Shelf A to assembled metal frame.
2. Use eleven Phillips Screws Round Head 4 and eleven Washers 3 to secure Shelf A
and metal frame.
3. Use Phillips screwdriver to snugly tighten Screws.
A
A
3
4
UpSide/Vertical
UpSide/Vertical
Up Side / Vertical
Front / Avant
UpSide/Vertical
UpSide/Vertical
Front /
Avant
UpSide/Vertical
UpSide/Vertical
13
Model # AXCERN-07Assembly

Step 4
1. Repeat Step-3 for the second Shelf A .
3
4
A
A
A
A
UpSide/Vertical
Front /
Avant
Front / Avant
UpSide/Vertical
UpSide/Vertical
Front /
Avant
14
Model # AXCERN-07Assembly

Step 5
Note: Levelers on bottom of legs can be adjusted if floor is uneven.
15
Model # AXCERN-07Assembly

Step 6
Furniture Tip Over Restraint Assembly
NOTE: The screwdriver is not
included in the hardware pack.
WARNING
Serious or fatal crushing injuries can occur from furniture tip-over.
If the furniture tip over restraint kit is not in the box, please contact our customer
service department in order to obtain another kit before using the furniture.
6
6
16

1. Attach one of the mounting brackets securely to the back edge of
the furniture. Use the shorter screw.
2. Determine where furniture is to be placed and mark location on
the wall for mounting bracket screw hole approximately 2 inches
below the bracket mounted to the furniture.
3. Drill a 3/16 inch hole in the wall. Press the plastic anchor into the
hole and gently tap until the flange on the anchor is against the
wall surface.
4. Position the bracket over the anchor and use the longer screw to
securely attach the bracket to the wall.
5. Place the furniture so the back edge is in line with the bracket on
the wall.
6. Lace an end of the nylon zip-tie strap down through each bracket.
Bring both ends together and slide the smooth side upright
through the square-shaped end and pull through to create the
“locked” position.
7. Check to make sure the strap is securely laced and locked to the
brackets.
·DO NOT place heavy objects in top drawers or on top shelves
·DO NOT let children climb or hang on drawers, doors or shelves
Px
P
P
x
x
Furniture Anti-Tipping Restraint Instructions
17
