IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
SAFETY INFORMATION
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required. Hardware
package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.
3/13

4/13
CARE and MAINTENANCE
Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative
humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls,
and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally
along different grain directions. As humidity changes, the components of wooden objects are
continually pushing and pulling against each other. This pressure often results in parts of furniture
no longer fitting together closely or becoming distorted or breaking from their own internal
stresses.
The response to relative humidity changes begins with determining the annual average RH for
your particular space. Then try to keep the RH in the space where your furniture is as close to that
average as possible, generally within about 10% up or down. De-humidify in the summer and
humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern heating
systems, which can drive down interior RH in the winter, almost invariably cause problems for
furniture. To counteract their effect, you can either modify the RH by keeping furniture containing
spaces cooler in the winter or most importantly, have a good working humidifier for your home. A
humidistat automatically works to balance the humidity in your home so it is constant. Dry indoor
air can suck enough moisture from its surroundings to do permanent damage to wood, causing it
to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how rapidly a
wood will lose moisture are pore size and surface hardness. A piece made from a dense and hard
wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished piece
while pieces with veneer finishes are not only stronger, but lose moisture more slowly than other
finishes.
To help protect your wood furniture, take these steps:
• Use a humidifier, preferably one with an automatic control system that can sense the humidity
level and adjust itself accordingly. Don't over-humidify; that can damage wood by causing it to
expand and contract.
• Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp.
• If you can avoid it, don't put furniture near heating vents. If you must, keep the piece 3 to 4
inches away from the wall, giving the heat and air space to circulate.
• Dust with soft dry cloth.
• Do not use liquid or aerosol products.
• To avoid marking, do not place rubber on surface (foot pads, etc.)
• For soil build-up, wipe with damp cloth & dry.
• Do not use abrasive cleaners.
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.

NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
PRE-ASSEMBLY INFORMATION
MODEL # AXCKIT06-WH
PARTS DESCRIPTION
5/13
A
TOP
QTY 1
LEFT SIDE
QTY 1
BLBR
RIGHT SIDE
QTY 1
BACK PANEL
QTY 1
C
BOTTOM SHELF
QTY 1
D
DIVIDER
QTY 1
E
FRONT BAR
QTY 1
F G
DRAWER FRONT
QTY 2
HL
LEFT DRAWER SIDE
QTY 2
HR
RIGHT DRAWER SIDE
QTY 2
I
DRAWER BACK
QTY 2
J
DRAWER BOTTOM
QTY 2
Front /
Avant
Front / Avant
Front
/
Avant
Front / Avant
Front /
Avant
Front
/
Avant
Up S
i
de
/ V
e
rt
ic
a
l
U
p
S
id
e
/ V
er
ti
c
a
l

PRE-ASSEMBLY INFORMATION
HARDWARE DESCRIPTION
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
6/13
MODEL # AXCKIT06-WH
123
4 5
HANDLE
M4 X 25 mm
QTY 2 SETS
ALLEN KEY
QTY 1
CAM LOCK PIN
CAM LOCK
QTY 14 SETS
ALLEN KEY SCREW
M6 X 30 mm
QTY 15
Required -
Flathead screwdriver
Phillips screwdriver
Rubber mallet
Not Included
WOOD DOWEL
Ø8 X 30 mm
QTY 18

COMPONENTS – KEY DIAGRAM
7/13
MODEL # AXCKIT06-WH
A
BL
CE
F
D
I
JG
BR
HL
HR
Fr
ont /
Av
ant
Front /
A
v
ant
Up Side / Vert
i
c
a
l
Front
/
Av
an
t
Front
/
A
v
an
t

ASSEMBLY
STEP 1
8/13
MODEL # AXCKIT06-WH
1. Slide Drawer Bottom J firmly into slots on Drawer Sides HL , HR and
Drawer Front G .
STEP 2
1. Attach 4 Cam Lock Pins 2 to back of Drawer Front G .
2. Align Cam Lock Pins with guide holes and attach Drawer Sides HL , HR .
3. Insert 2 Cam Lock 2 into guide holes on each Drawer Side HL , HR .
4. Use flathead screwdriver to secure Cam Locks.
G
2
HL
G
J
HR
HL
HR

ASSEMBLY
STEP 3
9/13
MODEL # AXCKIT06-WH
STEP 4
1. Use Phillips Screwdriver to attach Handle 4 to Drawer Front G .
Repeat Step 1-4 for the second drawer.
1. Align Drawer Back I with Drawer Bottom J and press firmly into slot .
2. Attach back using 2 Allen Key Screws 1 through guide holes on each side.
3. Use Allen key 3 to tighten. Do not over-tighten.
NOTE: The screwdriver is not
included in the hardware pack.
1
3
G
J
I
G
4
HL
HR

ASSEMBLY
STEP 5
10/13
MODEL # AXCKIT06-WH
1. Insert 4 wood Dowel 5 into of each Back Panel C , Front Bar F and Bottom Shelf D .
2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Attach 3 Cam Lock Pins 2 to into each Side BL , BR .
4. Align wood Dowel 5 on C , F , D with guide holes of Side BL , BR .
5. Align Cam Lock Pins with guide holes and attach Bottom Shelf D .
6. Insert 6 Cam Locks 2 into guide holes on Bottom Shelf D .
7. Use flathead screwdriver to secure Cam Locks.
D
F
C
5
52
BL
BR
Up
Sid
e / Ver
tic
al
U
p
S
ide
/
Ver
t
i
cal
Front
/ Avant

ASSEMBLY
STEP 6
11/13
MODEL # AXCKIT06-WH
1. Insert 2 Dowels 5 into Divider E .
2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Align Wood Dowels 5 on Divider E with guide holes on Back panel C .
4. Use Allen Key Screw 1 attach Front bar F to Divider E .
5. Use Allen key 3 to tighten Allenkey Screw. Do not over-tighten .
D
C
F
E
5
1
3
BL
BR
U
p S
ide / V
ert
ica
l
Front / A
van
t
Fron
t / A
v
ant
Fr
ont / A
v
ant

ASSEMBLY
STEP 7
12/13
MODEL # AXCKIT06-WH
1. Insert assembled drawers into slots on assembled table.
2. Drawers can be inserted into either side of table opening.
STEP 8
1. Insert 2 Dowels 5 into top corners of each Side BL , BR .
2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. 1/2 length of
Dowels should be exposed.
3. Align guide holes on bottom corners of Top A with Dowels 5 in Sides BL , BR .
4. Use Allen Key Screw 1 attach Top A to Sides BL , BR and to Divider E .
5. Use Allen key 3 to tighten Allen key Screw. Do not over-tighten .
A
E
D
BL
BR
5
3
1
1
3
Fron
t
/
Av
an
t
Front /
Avant
