Simpli Home WyndenHall brooklyn+max INT-AXCADR-BNCH-EB User manual

1/15
ADRIEN / NOLAN / REMINGTON
MODEL # INT-AXCADR-BNCH-EB
ENTRYWAY STORAGE BENCH
SI
M
P
I
I
HOME
L I F E B Y D E S I G N

2/15
SI
M
P
I
I
HOME
L I F E B Y D E S I G N
Questions, problems, assembly help, missing parts?
No need to return the product, we will gladly help and ship your
replacement parts free of charge
Please call Customer Service at 1-866-518-0120 ext. 262
Monday to Friday between 9 am – 4 pm EST
or go to
www.simpli-home.com/parts request
In order to assist you in a timely manner, please have the following information ready:
Model # _______________________ Part Number or Letter_______________________
Purchased at ___________________Date of Purchase ___________________________
If you wish to return the product, please contact the retailer where the
product was purchased.

3/15
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.
SAFETY INFORMATION
Identify all the parts and hardware. Do not discard of the packaging until you
have checked that you have all of the parts and hardware required. Hardware
package may have spare parts.
WARNING: This item contains small parts which can be swallowed by
children and pets. Keep children and pets away during assembly. To avoid
danger of suffocation, always keep plastic bags away from children and pets.
We recommend that you assemble this unit on a carpeted floor to avoid
scratches. If using power tools, set the tool to low torque to avoid damage.
May require 2 people for ease of assembly.

4/15
CARE and MAINTENANCE
Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative
humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls,
and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally
along different grain directions. As humidity changes, the components of wooden objects are
continually pushing and pulling against each other. This pressure often results in parts of furniture
no longer fitting together closely or becoming distorted or breaking from their own internal
stresses.
The response to relative humidity changes begins with determining the annual average RH for
your particular space. Then try to keep the RH in the space where your furniture is as close to that
average as possible, generally within about 10% up or down. De-humidify in the summer and
humidify in the winter.
Be aware that raising the temperature lowers the humidity and vice versa. Thus, modern heating
systems, which can drive down interior RH in the winter, almost invariably cause problems for
furniture. To counteract their effect, you can either modify the RH by keeping furniture containing
spaces cooler in the winter or most importantly, have a good working humidifier for your home. A
humidistat automatically works to balance the humidity in your home so it is constant. Dry indoor
air can suck enough moisture from its surroundings to do permanent damage to wood, causing it
to crack or split.
Remember, that not all woods are created equal. Two factors that help determine how rapidly a
wood will lose moisture are pore size and surface hardness. A piece made from a dense and hard
wood will dry less rapidly than pieces made from softer woods.
Furniture that is sealed and lacquered will lose moisture more slowly than an unfinished piece
while pieces with veneer finishes are not only stronger, but lose moisture more slowly than other
finishes.
To help protect your wood furniture, take these steps:
• Use a humidifier, preferably one with an automatic control system that can sense the humidity
level and adjust itself accordingly. Don't over-humidify; that can damage wood by causing it to
expand and contract.
• Keep furniture out of direct sunlight, which can cause it to dry out, crack and warp.
• If you can avoid it, don't put furniture near heating vents. If you must, keep the piece 3 to 4
inches away from the wall, giving the heat and air space to circulate.
• Dust with soft dry cloth.
• Do not use liquid or aerosol products.
• To avoid marking, do not place rubber on surface (foot pads, etc.)
• For soil build-up, wipe with damp cloth & dry.
• Do not use abrasive cleaners.
IMPORTANT : Please read this manual carefully before beginning
assembly of this product. Keep this manual for future reference.

NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
PRE-ASSEMBLY INFORMATION
5/15
AL
PARTS DESCRIPTION
LEFT SIDE
QTY 1
D
E
BACK PANEL
QTY 1
G
H
BOTTOM SUPPORT LEG
QTY 1
BOTTOM SHELF
QTY 1
B
F
CL
SEAT
QTY 1
LEFT DIVIDER
QTY 1
BACKREST
QTY 1
BASKET
QTY 3
MODEL # INT-AXCADR-BNCH-EB
CR
RIGHT DIVIDER
QTY 1
AR
RIGHT SIDE
QTY 1
Front / Avant
Front Side
Front Side
Front / Avant
Front
/
Avant
Front
/
Avant

1
PRE-ASSEMBLY INFORMATION
HARDWARE DESCRIPTION
23
4 5
NEED HELP? For help with assembly or if you are missing a part,
Please call customer service at 1-866-518-0120 ext. 262 (9 am to 4 pm EST)
6/15
WOOD BOLT CAP
QTY 4
ALLEN KEY
QTY 1
ALLEN KEY SCREW
M6 x 30 mm
QTY 16
6
PHILLIPS SCREW ROUND HEAD
M4 x 15 mm
QTY 16
ALLEN KEY BOLT
M6 x 50 mm
QTY 4
WOOD DOWEL
8 X 30 mm
QTY 8
MODEL # INT-AXCADR-BNCH-EB
Required -
Phillips screwdriver
Rubber mallet
Not Included

COMPONENTS – KEY DIAGRAM
7/15
B
CL
CR
D
E
F
G
H
MODEL # INT-AXCADR-BNCH-EB
AL
AR
Front
/ Avant
Front
/
Avant
Front
/ Avant
Front / Avant

8/15
ASSEMBLY
STEP 1
1. Insert 4 Wood Dowels 3 into Dividers CL & CR ( 2 Dowels per each Divider ).
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of
dowels should be exposed.
3. Hold Bottom Shelf D upright and attach Dividers CL & CR by inserting exposed dowel
ends into matching pre-drilled holes on Bottom Shelf D .
4. Insert 4 Allen Key Screws 1 into pre-drilled holes through centre of Bottom Shelf D
into Dividers CL & CR .
5. Use Allen Key 2 to snugly tighten. Do not over-tighten.
CL
CR
3
3
D
1
2
3
MODEL # INT-AXCADR-BNCH-EB
Front /
Avant
Front /
Avant
Front /
Avant
Front /
Avant

ASSEMBLY
STEP 2
1. Attach Seat B to Dividers CL & CR using 4 Allen Key Screws 1 .
2. Use Allen Key 2 to tighten Screws. Do not over-tighten.
D
2
1
B
CL
CR
MODEL # INT-AXCADR-BNCH-EB
9/15
Front
/
Avant
Front / Avant
Front
/ Avant
Front
/
Avant
Front
/
Avant
Front
/
Avant

ASSEMBLY
STEP 3
1. Insert 2 Dowels 3 into Bottom Shelf D .
2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. ½ length of
dowels should be exposed.
3. Attach Left Side AL to Bottom Shelf D and Seat B using 4 Allen Key Scews 1 .
4. Use Allen Key 2 to tighten Bolts. Do not over-tighten.
3
2
1
2
1
D
B
CL
CR
10/15
MODEL # INT-AXCADR-BNCH-EB
AL
Front /
Avant
Front / Avant
Front
/
Avant

ASSEMBLY
STEP 4
11/15
1. Attach Backrest E to Left Side AL using 2 Allen Key Bolts 5 .
2. Use Allen Key 2 to tighten Bolts. Do not over-tighten.
MODEL # INT-AXCADR-BNCH-EB
5
2
E
AL
Front / Avant
Front
/ Avant
Front
/ Avant
Front / Avant

ASSEMBLY
STEP 5
12/15
1. Repeat Step-3 for the Right Side AR .
2
1
3
2
1
MODEL # INT-AXCADR-BNCH-EB
AL
AR
Front
/ Avant
Front
/
Avant
Front
/ Avant
Front
/ Avant

ASSEMBLY
STEP 6
13/15
2
5
1. Attach Backrest E to Right Side AR using 2 Allen Key Bolts 5 .
2. Use Allen Key 2 to tighten Bolts. Do not over-tighten.
1. Attach Bottom Support Leg G to Bottom Shelf D .
STEP 7
G
D
MODEL # INT-AXCADR-BNCH-EB
AL
AR
Front
/ Avant
Front
/ Avant
Front /
Avant
Front
/ Avant
Front / Avant
Front
/
Avant
Front /
Avant
Front /
Avant

ASSEMBLY
STEP 8
1. Attach Back F to back frame using 16 Phillips Screw Round Heads 4 .
2. Use Phillips screwdriver to snugly tighten screws.
3. Insert 4 Wood Bolt Caps 6 into exposed bolt holes on side of bench.
14/15
STEP 9
F
4
6
H
MODEL # INT-AXCADR-BNCH-EB

15/15
Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max
product. These products have been made to demanding, high-quality
standards and are guaranteed for domestic use against manufacturing
faults for a period of 12 months from the date of purchase. This warranty
does not affect your statutory rights.
In case of any malfunction of your product (failure, missing parts, etc.)
please contact us at our toll free service line at 1-866-518-0120 ext. 262
from 9 am to 4 pm, Monday to Friday, Eastern Standard Time or by email at
cust[email protected].
We reserve the right to repair or replace the defective product, at its
discretion.
This product is guaranteed for 12 months if used for normal purposes.
Any warranty is invalid if the product has been overloaded or subject to
neglect, improper use or an attempted repair by other than an authorized
agent. Heavy-duty or daily professional/commercial usage are not
guaranteed.
Due to continuous product improvement, we reserve the right to change
the product specifications without prior notice.
