Sine Systems AFS-1 User manual

Nashville,Tennessee
Audio Failsafe
– Instruction Book –
This documentation is valid for
Audio Failsafe hardware version 2.00
Model AFS-1

Table of Contents
Section 1 — Warranty/Product Registration
Paragraph Title Page Number
1.1 Warranty 1.1
1.2 Suitability For Use 1.1
1.3 Product Registration 1.1
Section 2 — Safety Information
Paragraph Title Page Number
2.1 Safety Information 2.1
Section 3 — Specifications
Paragraph Title Page Number
3.1 General 3.1
3.2 Audio Input 3.1
3.3 Relay Output 3.1
Section 4 — Equipment Description
Paragraph Title Page Number
4.1 Functional Description 4.1
4.2 Physical Description 4.1
Section 5 — Installation
Paragraph Title Page Number
5.1 Unpacking 5.1
5.2 Mechanical Installation 5.1
5.3 Electrical Installation 5.1
5.4 Power Connection 5.1
5.5 Relay Connection 5.1
5.6 Audio Connections 5.2
5.7 Loss of Power to AFS-1 5.2
5.8 Safety Considerations 5.2
5.9 Modifying Operating Parameters 5.3
Version 2.00 Table of Contents

Section 6 — Circuit Description
Paragraph Title Page Number
6.1 Audio Section 6.1
6.2 Power Supply 6.1
Section 7 — Illustrations and Diagrams
Paragraph Title Page Number
7.1 List of Illustrations and Diagrams 7.1
7.2 AFS-1 Schematic Diagram 7.2
7.3 AFS-1 Component Locations 7.3
Section 8 — Parts List
Paragraph Title Page Number
8.1 AFS-1 Audio Failsafe Parts List 8.1
Version 2.00 Table of Contents

Section 1 — Warranty/Product Registration
1.1 Warranty
Sine Systems, Inc. agrees to repair or replace the AFS-1 Audio Failsafe at no cost, if the
unit fails in normal use, during the first year of original ownership. This Warranty does
not include damage caused by improper installation or use nor does it include damage
caused by any other external means.
1.2 Suitability For Use
The purchaser and user of the Sine Systems AFS-1 Audio Failsafe bears the sole
responsibility for determining suitability of this equipment for their intended use.
Because this equipment can, as can any electronic equipment, fail in an unpredictable or
unexpected way, even in normal use, Sine Systems, Inc. cannot be held responsible for
damages, either direct or indirect, resulting from use of this equipment. Under no
circumstances should this equipment be used or relied upon in a situation where a life-
threatening condition could result if the equipment were to fail.
1.3 Product Registration
To help us know our customers and to keep them informed of future engineering, product,
and safety information, please fill out the following form and send a copy to Sine Systems
at the address below. It is not necessary to return this form to validate the warranty but
it is necessary if you wish to receive engineering bulletins.
If you did not purchase the equipment new, we still encourage you to register as an owner
so that you will automatically receive all pertinent safety and product information.
Record the following information and return a copy to the address shown on the front
cover of this book:
AFS-1 Serial Number (stamped on front panel) ___________________________________
Name of purchaser (company or call sign): _______________________________________
Mailing address: ____________________________________________________________
Contact Name: ______________________________________________________________
Telephone: _________________________________________________________________
Purchased from: ____________________________________________________________
Date delivered: ______________________________________________________________
Version 2.00 Warranty/Registration page 1.1

Section 2 — Safety Information
2.1
The AFS-1 Audio Failsafe should be installed only by qualified technical personnel.
Incorrect or inappropriate installation could result in a hazardous condition.
Service of the AFS-1 Audio Failsafe should be performed only by qualified technical
personnel. Even though the AFS-1 is powered by 12 volts AC from a "wall plug"
transformer, failure of this transformer could cause dangerous and potentially lethal
voltages to become present. Only the supplied transformer should be used.
Because of exposed terminals, high voltage (greater than 25 volts) should not be connected
to the relay terminals, or any other terminals on the AFS-1.
If the AFS-1 is connected so that loss of audio turns a transmitter off, the return of audio
could turn a transmitter back on. Operating and maintenance personnel should be
mindful of this possibility and be sure the transmitter is rendered inoperable before
maintenance is begun on the transmitter, antenna, or associated equipment.
The AFS-1 is designed for indoor use in a dry location. Installation and operation in other
locations could be hazardous.
Version 2.00 Safety Information page 2.1

Section 3 — Specifications
3.1 General
Output Relay Operation Output relay contact closes within one second after
audio becomes present and remains closed as long
as audio is present. Output relay contact opens at the
end of an adjustable delay period after audio
becomes absent.
Delay Range 7 seconds to approximately 4.5 minutes.
(factory adjusted to approximately 4.5 minutes)
Indicators 1. Audio Present (Green LED)
2. Relay Closed (Green LED)
3.2 Audio Input
Number Of Audio Inputs 2
Input Type Actively Balanced
Input Impedance 60 K Ohms
Sensitivity (For Relay Closure) -16 DBv
3.3 Relay Output
Output Type 1 Form "A" (SPST) Contact, Floating
Contact Ratings 120 Volts AC, 5 Amps Resistive/2 Amps Inductive
Version 2.00 Specifications page 3.1

Section 4 — Equipment Description
4.1 Functional Description
The AFS-1 is designed to monitor one or two audio signals and provide a relay contact
closure as long as at least one of the audio signals is present. When neither audio signal
is present for an adjustable delay period (7 seconds to 4.5 minutes), the relay contact
opens and remains open until one or both of the audio signals return. The AFS-1 was
designed to provide a means to turn a device off (or on) remotely by discontinuance of an
audio signal.
A typical application of the AFS-1 is to provide an alternate control means for a remotely
controlled broadcast transmitter. When appropriately installed, the AFS-1 can be used to
turn off a transmitter by discontinuing the audio feed to the transmitter. This procedure
would normally be used only when the normal remote control means had failed.
4.2 Physical Description
The AFS-1 is contained in a small "modem-sized" case (5.5" x 5.5" x 1.75") and can be
mounted in any convenient location such as on a wall, inside an equipment rack, or it
may be rack mounted with an optional kit. A 12 volt AC "wall plug" transformer (supplied)
is connected to the AFS-1 and provides power. Audio and relay connections are made on
"pluggable" screw-terminal connectors on the front panel. LED's are also included to
show when audio is present and when the relay contact is closed. A switch is provided to
force closure of the relay contacts and defeat operation of the AFS-1.
The audio sensitivity and relay timing of the AFS-1 are factory set to values which will be
satisfactory for most applications. These values can easily be changed, however.
Instructions on how to accomplish this are located in the "Modifying Operating
Parameters" paragraph in Section 5 of this manual.
Version 2.00 Equipment Description page 4.1

Section 5 — Installation
Installation of the AFS-1 Audio Failsafe should be
performed only by a qualified technician. Installation is not difficult; however,
an attempted installation by a person who is not technically qualified could
result in danger to operating or maintenance personnel, or damage to the unit.
5.1 Unpacking
When the AFS-1 is unpacked, it should be inspected for obvious signs of mechanical
damage or loose parts. Loose parts should be tightened before installation. If damage is
found, save the packing material and report it to the shipping company and the dealer
from which it was purchased. Do not install the unit.
5.2 Mechanical
The AFS-1 generates little heat and can be mounted in just about any convenient location.
It can be mounted in the bottom of an equipment rack, it can be wall mounted, or it can
be rack mounted with the optional RK-3 rack mount kit.
5.3 Electrical
Electrical connections are made to the AFS-1 through two screw-terminal connectors
located on the front panel. Note that these can be removed from the panel by pulling
them straight out. This makes wiring to these connectors considerably easier.
5.4 Power Connection
Power to operate the AFS-1 is supplied by a 12 volt AC "wall plug" transformer supplied
with the AFS-1. The leads of this transformer should be stripped and connected to the
terminals marked "12 VAC" on the front panel of the AFS-1. If the supplied transformer is
of the type that has a connector on the end of the cord, simply cut the connector off and
discard it.
5.5 Relay Connection
The contacts of the internal relay are accessed by the terminals marked "RELAY." This
connection is closed when audio is present and opens after an adjustable period of time
without audio (7 seconds to 4.5 minutes).
Version 2.00 Installation page 5.1

Although the relay contacts are rated at 120 volts AC,
it is not recommended that 120 volts AC be connected to the AFS-1. The screw-
terminal connectors have several exposed points that could produce a
dangerous or even lethal shock if they were contacted. Low voltage AC or DC is
much safer and eliminates the potential for a shock hazard.
The "G" terminal next to the "RELAY" terminals is a connection to the internal circuit
ground but it is not connected to the case.
5.6 Audio Connections
Audio connections are made to the AFS-1 through the screw-terminal connector on the
left hand side of the front panel. There is an "A" channel input and a "B" channel input.
Either one or both channels may be used. If two stereo channels are fed to the inputs,
note the polarity of the audio connections or cancellation of the signals will result in the
AFS-1. If only one audio source is used, connect it to either input and leave the other
input disconnected. The "G" terminal is connected to the internal circuit ground and its
use is optional.
Generally, the most desirable location to "tap" the audio signal for use by the AFS-1 is a
point where the signal level is somewhere between 0 dBm and +10 dBm. This could be the
output of a discrete STL, the output of audio processing equipment, or the transmitter's
audio input terminals. Note should be made of installations using telephone lines for
program audio sources. Since the audio level of incoming telephone lines is generally in
the range of -30 dBm, the output of a processing device would be a good monitoring point
in such installations. The audio input impedance of the AFS-1 is approximately 60 KΩso
bridging the AFS-1 across a program source usually has no significant effect.
After installing the AFS-1 be sure to test that the "AUDIO" LED does in fact go off if audio
is lost. Otherwise the timing interval will never begin and the AFS-1 will not work as
intended.
5.7 Loss of Power to AFS-1
It should be noted that if power is lost to the AFS-1, the control relay will open. If it is
necessary to disconnect power to the AFS-1 without opening the relay contacts, place the
switch on the front panel in the "DEFEAT" position before disconnecting power.
5.8 Safety Considerations
If the AFS-1 is connected so that loss of audio turns a transmitter off, the return of audio
could turn a transmitter back on. Operating and maintenance personnel should be
mindful of this possibility and be sure the transmitter is rendered inoperable before
maintenance is begun on the transmitter, antenna, or associated equipment.
Version 2.00 Installation page 5.2

5.9 Modifying Operating Parameters
The AFS-1 operating parameters can easily be modified to suit special applications. The
period of time required after the loss of audio before the relay contact opens is set at the
factory to approximately 4.5 minutes. This can be adjusted with the 22 turn
potentiometer located on the AFS-1 main board. The adjustment range is approximately
7 seconds to 4.5 minutes.
Version 2.00 Installation page 5.3

Section 6 — Circuit Description
6.1 Audio Section
The first two sections of U1 are balanced audio input stages of the "A" and "B" audio
inputs. Overall, these have a gain of 0.33 (loss). The next stage combines the two
channels and has a gain of 10. Capacitors C1 through C12 provide high frequency roll-off
and RFI immunity. A rectifier, short term integrator (about 1 second), and comparator
follow. When audio is present, the "AUDIO" LED is turned on by this comparator. R8 and
C14 form the network which determines the timing interval. The following comparator
drives the output relay and the "RELAY" LED.
6.2 Power Supply
The 12VAC input is rectified and filtered by BR1, VR1, and C15 to produce 18VDC
unregulated output. R9 provides a low impedance "mid-point" connection for the various
circuit elements.
Version 2.00 Circuit Description page 6.1
