SingTel Optical Network Router User manual

OPTICAL NETWORK ROUTER
Quick Installation Guide
Power adapter input - 100–240 V AC, 50/60 Hz
System power supply - 12V DC, 2A
Operating temperature - 5°C to 45°C
Operating humidity - 5% to 95% RH (non-condensing)
Weight - About 205g
System power consumption - < 12W
| Product Overview
Optical Network Router (ONR) has 4 Ethernet ports
& 2 POTS ports.

1. What’s in the box?
ONR
LAN network cable
Power adapter
Phone cable
This installation guide is also included in the box.
ONR should be placed horizontally in an open area, such as on
your desk. Ports at the back of the ONR should be unobstructed.
Do not install the ONR outdoors/cabinets which may be exposed
to sun or rain.
2. Suggested placement of the ONR

1. Power port
2. Two telephone ports
3. Four ethernet ports
4. Fiber port
5. Power switch
6. Reset button
3. Connecting cables and devices to ONR
6
15 4
2
3

Step 1: Connect the LAN network cable from the Ethernet
port of your device to a LAN port, e.g. Computer.
Step 2: Connect the phone cable from your phone to the
assigned TEL port.
Step 3: Connect the power adapter to the ONR’s Power
port and your home electrical outlet. The Power
indicator on the ONR should be green.
FTTH ID (section 4.2).
Please connect fiber cable to the ONR only after configuring the
Your session will automatically timeout after 5 minutes of inactivity
and you will be required to log in again. Replace your default
password with a personal one to avoid unauthorised access.
Step 1: Connect your PC to the ONR through the Ethernet port.
Step 2: Enter http://192.168.1.254 in the address bar of your
Internet Browser and press Enter. When the login
window is displayed, enter username (admin by default)
and password (printed on the nameplate of the device).
Step 3: Click Login.
4. Configuring the ONR

4.3 Connecting Fiber Cable to the ONR.
sharply and ensure the bending diameter is larger than 30mm.
As the fiber optic cables are made of glass, please do not bend
on the back of the ONR, and
secure the optical fiber by fitting
Connect one end of the fiber
patch cord to the fiber port
it on the holders. Follow the
arrows in the diagram for the
positions of the holders.
Connect the other end of the
patch cord to the fiber
termination point (FTP).
1. 2.
Verify your service later. Refer to section 5 on how to verify your
service.
3.
Step 2: Input the FTTH ID (Use FTTH ID provided by Singtel).
Step 1: Choose Maintenance > FTTH ID Configuration.
Step 3: Click Save.
a
b
c

5. Verify if connection is successful
LED indicators on the ONR provide status information of
each service connection. Each light indicator indicates the
success of the connection listed previously in sections 3
and 4:
section 4.
If the PON indicator is flashing, check your fiber
connection and FTTH ID configuration as stated in
Refer to section 7 for the other indicator statuses.
• Fiber connection is up if PON indicator is steady green.
• Each of these services are functioning normally if LAN/TEL/
INTERNET/IPTV indicators are steady green.

6. Resetting to Factory Default
What does it do?
How do I reset it?
When should I perform a factory reset?
Resets all settings except the FTTH ID.
Press the Reset button by using a needle-like object and hold for
more than 10 seconds. If the LED indicator turns off and on, your
ONR has been successfully restored to factory default.
To reset all the settings except the FTTH ID.
Perform the reset operation if you want to erase all the data
on the ONR. Please note that this operation may cause the loss
of your ONR configuration information and lead to Internet
connection failure. If this problem occurs, please contact your
service provider for help.

7. Indicator Descriptions
Indicator
POWER
Status
LED Description
Green ONR is powered on. The LED displays amber first,
then green flashing and turns steady green
Off ONR is powered off
Amber flashing New firmware downloading
ONR start up has failedRed
Green flashing ONR is booting up
PON
Green ONR has ranged successfully
Green flashing ONR is ranging
Off No light source is detected
TEL 1 - TEL 2
Green Call account is registered
Green flashing Phone call in progress;
Call account registration in progress
Off Call account is not registered
LAN 1 - LAN 4
Green Ethernet connected/powered device
connected to LAN port
Green flashing Data activity present (traffic in either direction)
Off Power off or Ethernet not connected
IPTV
Green IPTV IP address and STB detected and operational
Green flashing No IP address obtained in IPTV interface
Off No STB detected
INTERNET
Green Internet service is OK
Green flashing Active Internet traffic
Internet service is downOff
AUTH
Green ONR is authorized/authenticated
Green flashing ONR is ranging or synchronizing
Off ONR is not authorized/authenticated
USB
Green Device connected to USB port
Green flashing Traffic activity on the USB connection
Off No device connected to USB port
