Sirius Satellite Radio switle SWT-JT500 Instruction Manual

★ If there is no information in the column, the warranty is invalid, so please be sure to confirm it.
This warranty is subject to free repair based on the contents of the document.
During the above warranty period from the date of purchase, follow the instructions for use, the
product logo and other precautions to use it properly, and have the store to repair it.
SIRIUS CO., LTD
Postcode：110-0015
3/F Nakajima bld.,1-14-9, Ueno, Taito, Tokyo
Japan
Product
name
Hydro-cleaning connector
for vacuum cleaners
Model
number
SWT-JT500
Term of
service
1 year from the date of purchase
★
Date of
purchase
D M Y
★
Purchaser
Full name
Address Zip code Tel. （ ）
★
Store
Address/store name
Tel. （）
Operating instruction manual
Hydro-cleaning connector for vacuum cleaners
MODEL :SWT-JT500
Franshise: Sh a n gh a i Bi K u T r ad i ng Co . , Lt d
Te l: 02 1- 34 1850 0 0
Add: 4F , Bl o ck- B , 39 1 Gu ip i ng Road , Sh a ngha i , 20 0 23 3
Place of origin: Japan
●
Repair records
INDEX
SWL302020300 1804-0
●
Please read the manual carefully and use the product properly.
●
Please read “Safety instructions” on pages 2~3 before using it.
●
Please confirm that the information filled in a warranty is correct and keep it with the manual.

2
3
Product features
Use the power of water for cleaning.
It is a connector for a vacuum cleaner used with a water for
cleaning, which is being sprayed and absorbed at the same
time.
The power of a used water.
Safe and reliable cleaning method.
Use approx. 500mL of
water for a sectional
cleaning
Safety instructions Please comply with the following
To avoid injury and a material damage caused to the users and others, please follow this guidelines.
Airflow
Clear water flow
Dirty water flow
Air*dirty air flow
Description of tokens(indicates the degree of
damage that also occurs when it used
incorrectly)
The icon description
A pattern or a similar icon indicates the need in
complying with a matter.
A pattern or a similar icon indicates a prohibited item.
Turbo fan
water
Do not open the upper cover
when the machine started
absorbing
（easy to sustain an injury）
After stopping the machine, the fan
continues to rotate.Make sure it
stopped rotating and then open the
top cover.
The water tank is not installed
and the fan should not be
turned on if it is outside
（easy to sustain an injury）
Do not use it to clean the stains of
ash, vomit, etc. that might have
suspicions of being infected
（easily causes an infection）
Do not use benzine or
diluentto clean the machine.
Do not spray insecticides on
the product surface
（easy to cause cracks and fires）
Perform a maintenance before
storing it
（ the stains left in the machine are
able to multiply molds and bacterias
in it that may create a bad odor ）
Do not drop it while moving,
otherwise it may affect you
（easy to be injured and cause failure）
If the nozzle is clogged up,
shut down the machine
immediately
（easy to cause a malfunction）
Keep away from fire
（ Easy to cause deformation and
breakage of the product）
Shut down the vacuum cleaner
immediately if a foreign objects
are being absorbed （ easy to get
hurt and cause malfunction）
A high-speed rotation and foreign objects
sucked inside the machine may cause
damage and malfunction when starting it.
Do not use it on a greasy spots
（ the machine will crack due to
oiliness, which will cause
malfunctions and damage ）
Do not pull the vacuum cleaner
with the plugged machine
Please remove the water from the
machine in advance in case the iced
over circumstanceswill take place
(easy to cause cracks and malfunctions)
(easy to cause a malfunction of a counterflow
valve, extension pipe, interconnecting piece)
Warning
Indicates 【 the the possibility of death
and serious injury】.
Attention
Indicates 【 the possibility of causing
minor injuries and property loss】
No modifications should be made
without permission, and personnel
outside the technical staff should not
disassemble the machine for repair
Do not inhale flammable or
combustible substances
（ easy to cause an explosion and fire ）
Kerosene, gasoline, essential oil,
thinner, toner, cigarette butts,
incense, etc.
（easy to sustain an injury）
Please contact the store or customer service
when you need a repair.

4
5
Prevent WI
吸
Cleaning precautions
If the water in a tank for wastewater exceeds a ‘FULL’ waterline, or the main body of the machine
is substantially tilted, the product will not be able to perform its original functions, and it will easily
lead to water entering the used vaccum cleaner, which will cause a mulfunction.
Pre-exploitation
Before using this product, please read the following precautions carefully and use this product on
an understanding basis.
Usually, the stains that could not be removed after washing, for example, the highly colored
stains of coffee, ketchup, red wine, greasy or dry stains, etc., probably will be difficult to clear away.
Before cleanig, apply the detergent or related beforehand on a dirty spot for effective results ( p.15)
Depending on the type of rug, in special circumstances it can be drenched while being cleaned.
Carpets made from a special material, even with a tap water, can cause a color changing and fading.
Be sure to try it on the edge to confirm that there are no problems before using.
※ Be careful when using detergents or anything related.
For details, please read the chapter “effective cleaning methods” of the manual （ p.15）
The vacuum cleaner may shut down itself while running it
Depending on the vacuum cleaner used, in case of overload, etc., it is possible that the
protection (temperature detection) of the machine will be activated and the machine will
stop working. (Normally after turning off the vacuum cleaner, it resumes
operation after about 1-3 hours of cooling)
In this case, you can reduce the vacuum suction by one step or adjust the
“air-in regulating switch”.
※For details about the switch, please read the definition of it （p.8）
Water flowing out of the drain is not a leakage from the water tank.
To prevent accumulation of water in the upper cover, please
drain the water that overflows when water is pumped and the
water that penetrates during cleaning.
Precautions for using a vacuum cleaner
Since the vacuum cleaner’s pipe diameters are different and sometimes they cannot fit together, you
may contact a customer service for a help (p. 19) .
To use it, please connect it to the vacuum cleaner with the power of 170W or above.
Remark ･･･ThesuctioncapacityisfoolowedthetermsofJIS.
During the processing, the vacuum cleaner becomes very loud and extension pipe starts pulling back.
Depending on functions of the vacuum cleaner and the dust accumulation degree , the cleaning
functions of the current product probably will not be brought into a full play.Before using the product,
please read the manual carefully. If the body of the vacuum cleaner is clogged with debris, it will cause
decrease of the power, for this reason please renew a dust absorbtion bag and others, keep the body of
the vacuum cleaner in a clogging free condition for its proper use.
This is due to the fact that the countercurrent fan and the turbofan are exposed to water, which
causes a decrease in the rotational force. Do not allow the vortex fan to touch the water surface.
Please put the lid of the water tank back to correct position
Please make sure that the lid was tighted in a horizontal position. It will be difficult to twist it off if the lid was
tighted under heeling condition.
When the product falls or being shaked the safety valve prevents ingress of water into the vacuum
cleaner.
Cross section valve
Horizontal rotation Do not force it under the heeling position
suction
Vacuum cleaner direction
M. section
BC
W
WH
WH
W
The main body is tilted
Excess use of water line (-FULL)
normal
Air-in reg. switch

6
7
Issues requiring attention during exploitation
For safe and proper use of this product, please read the following precautions carefully.
This is a household product, and if it is used for commercial purposes, it will shorten its life.
It is specially designed for cleaning rugs, and if it is used for another cleaning, it will not fully perform its functions.
It can’t be used for artcrafts, not suitable for water fibers (silk, silk fiber, viscose, regenerated fiber,
etc.), not suitable for water materials (fur, leather, clothes, white wooden furniture, lackuering
woodworks, lackerwares, etc.), products easily damaged by scratching (floorboard, tabletop, etc.)
Stopping the spraying of water with prolonged use will not lead to the achievement of the same
characteristics as that of household vacuum cleaners, and excessive absorption of dry dirt will
cause a drop in inlet capacity.
It cannot be used for absorbing the following items.
A great quantity of fine powder, sandy soil, cobblestones, etc.
Sharp materials, such a glass fragments, iron plates, needles, etc.
Do not inject more than 40 degrees hot water into the water tank, as this may cause the product’s breakdown.
When the vacuum cleaner is shut down, please make sure that the sucker mouth is not
touching a ground to prevent leaking of a dirty water.
Matters needing attention before exploitation
Place the bottom of the machine to the objected plane that you are going to clean, the noozle of it
should gently come into contact with the spot to proceed the cleaning, if the machine will be arosen
while processing, it won’t be able to achieve an optimal result.
The names of each part
The main part
Top cover
※
refer top.16
Cover
Connection status
VC
MP
※Connected mode
Inlet scoop
※
Knob
Turbo fan
Fixed nut
clip(4)
Nozzle
（ p.8）
The mounting
port preventing
backflow
Wastewater tank
(outside water tank)
CW switch
p.8
）
Clear water tank
(Inside water tank)
suction inlet
tank cap
Suction inlet
Water jet
dextrorotation
anticlockwise
Air end
※Avoid clogging of the water jet, if it
happened please do not spray a water.

8
9
The names of each part (continued)
Setting up before exploitation (pour a clear water)
Open an upper cover
Pull the clip (4) and detach the upper cover
During the fan rotation do not open the clips to
open the lid
Follow（OPEN）to
twist off the bottom cap.
Pour 500 ml of pure water to the water
tank no further than the ‘Full” line 「▼」.
Follow (CLOSE )to turn
the bottom cup tightly.
※Please turn it tightly.
Attention
To prevent a moulds and a bad smell in a residual water left after cleaning, please drain the water out the machine after usingit and keep it clean.
Use the clean water in an inner section of a machine only, do not load any detergents.
Do not tilt the machine if it’s full of water, it ,might cause a water leakage.
Installation of a top cover※According to a contrary order (1) proceed an installation
Align the mark / on the top
cap and the nooszle
The main body of a machine has
a recess inserted in a bottom of
an upper covers ledge.
When pressing the clips (4)
you may hear the noise
Accessories
Extension pipe
Japanese brand of a particular universal tube, can connect
a nozzle to a round valve with a diameter of 34~42 mm
When the product falls down, a
safety valve prevents water from
entering the vacuum cleaner.
Vacuun cleaner’s side
（long plug）
Joint pipe
Vacuum
cleaner
Noise
Clip（4）
※Inside there might be a collision sound,
which is not a malfunction, but a valve’
s motion.
「 」 Up to
waterline
Clip （4）
Left-handed
The switch
Stop a water spraying
※
Pay attention
A water spraying
If the suction power of the conected vacuum cleaner
went down while using it, adjust an air-intake switch (p.12)
※In a normal use mode, please press down the air intake switch （shut down completely）.
※If the absorbtion level of the connceted vacuum cleaner went down (when ligt indicates that the bag is full of dust),
intensively push down a switch of the vacuum cleaner to position 1, or lift up a ‘regulating switch of the intake
port’ (so it will be in a half-open position) to be able to use it.
Full-gear
※
Adjustment notch
ledge
recess
Attention
Be careful not to twist or tilt the product, it might cause a water leakage.

10
11
逆流防止阀
34mm～42mm
When installing the backflow prevention valve,
please note that the lug of the safety valve is inserted
directly into the body of the machine.
When the extension pipe (short side) is connected to
the backflow prevention valve, insert it while rotating.
Attention
※ Please do not pull on
the hose connection.
Over 27mm
Completed
Attention
The current product can be connected to a canister-type vacuum cleaner using an extension hose hat,
it cannot be connected manually or vertically.
Setting up before exploitation (attachment)
Insert the backflow prevention valve into the main body of the product and connect
it to the extension pipe (short side)
Use a joint pipe connection (when the vacuum cleaner cannot be connected to extension pipe directly)
If the vacuum cleaner you have in the house cannot be connected directly to the extension tube, use a connecting tube to connect. It is
also possible to connect a vacuum cleaner with a small pipe diameter (27 mm or more) and a vacuum cleaner nozzle.
Vacuum cleaner
Extension pipe Joint tube
Extension pipe (long side of the mouth) is connected to a vacuum cleaner used at home
Pull out the pipe’s brush head and insert an extension pipe（long side of the mouth) by rotating it.
To prevent a decrease in the suction of the vacuum cleaner, firmly insert the pipe connection.
An extension pipe with a diameter of 34~42 mm can be connected to round mouth of a tube, but it cannot guarantee a
coverage of all brand vacuum cleaners.
Please refer to the order shown on p. 11 for how to use a “connecting tube” accessories.
Please refer to the “ sold accessories ” section (p. 18) for information on “ attachment of
connections to the vacuum cleaner”” sold separately.
The main body
If you still cannot connect the vacuum cleaner using the connecting tube, contact the customer service ( p.19)
If the extension tube and the joint tube cannot be connected when using the brand
new vacuum cleaners like Mueller or Electrolux, please purchase a separately sold
accessory.
An attached joint
connector for a vacuum
cleaner
Vacuum cleaner

12
13
Attention
With intensive work and cleaning outside the plane,
the backflow prevention valve is activated, which
reduces or stops the suction of the vacuum cleaner,
which easily causes water leakage and malfunction.
The motion of a backflow prevention valve is to prevent a turn-over of a product that can cause a water flows into a vacuum
cleaner and cuts off an aero-entering.Stop the vacuum cleaner immediately if the countercurrent prevents the valve from
operating.After the product returns to the normal state, the countercurrent prevention valve will automatically recover,
at this time there will be a ball rolling sound.If you do not hear the ball rolling sound, please gently tap the
countercurrent valve.
Attention
When wastewater continues to be used beyond the water level line, it is easy to cause water leakage and vacuum cleaner breakdown.
To avoid a product malfunction, do not leave it in a constantly On mode.
Please note that when you turn off the power of the vacuum cleaner or unplug the extension pipe connection in the middle of the water jet,
the waste will flow backward from the suction inlet.
Exploitation
Key information
When at a start midway of a connected vacuum cleaner the suction power is being reduced (or when the dust indicator lights up), and when
the suction power of the vacuum cleaner is reduced due to the blockage of a filter paper bag and/or a dust cup, please refer to the following
content to adjust the vacuum cleaner’s intensity programme or use the air intake regulating switch to adjust the suction.
Turn on the vacuum cleaner and start the suction process.
The turbine fan at the top of the cover begins to rotate.
If in the process of starting a vacuum cleaner the suction power
has been reduced, please refer to the information on p.12 regarding onflow adjustment.
Press the water switch down to start cleaning
Please remove respirable solids such as pet droppings.
The amount of water sprayed will be reduced, when the suction port leaves the cleaning surface.
Please be careful not to block the top cover air intake and the nozzle air intake during cleaning.
Water switch
When the tank for wastewater is fully filled, lift the water switch ,
to stop splashing and remove water from the cleaning surface.
Please stop using a water sprayer if a wastewater tank is full. If it’s difficult to determine its level
while exploitation, please turn off the power of the vacuum cleaner to confirm.
water switch
When cleaning, the bottom of the body is placed on the cleaning surface
and the suction inlet is attached to the front of the cleaning surface for
movement
A proper exploitation The wrong ways to use
Lift the
bottom
Bottom suction inlet
Lift the
intake
Power ON
Before exploitation, first turn off the product’s air intake adjustment switch and set the vaccum cleaner to a solid position. When the
vacuum cleaner’s suction power decay has arisen, re-press an air-in regulating switch and set a vacuum cleaner in a suitable position
to open it.
The intake regulating switch is adjustable to 3 phases: a full cut-off, semi closure or a full open.
At ordinary times, please turn an air intake regulating switch to a full cut-off mode.
Ordinarily at a start The VC’s suction power coastdown
Air-in regulating switch
For suction power characteristics of the vacuum cleaner, please check a standard data plate.
Suction may vary depending on the brand type and dust clogging condition.
A vaccum cleaner with a suction power below 450W A vacuum cleaner with suction power above 450W
Set 1:
Set 2
Vacuum cleaner suction
setting set to the
strongest (max)
强
强
中
弱
切
弱
切
中
弱
切

14
15
Exploitation methods (continued)
The product body is placed on a flat stable space and the power of
the vacuum cleaner is turned off.
Do not tilt or shake the device violently, it may lead to a water
leakage.
Open the top cover and drain the wastewater.
After turning off the power of the vacuum cleaner, the upper eddy
current fan will rotate for a while, make sure that it stopped and
then eliminate a dirty water.
Please maintaint it carefully after using ( p.16)
An effective cleaning methods
It is difficult to clean the stains with pigments, for an effective cleaning, please use a detergent by pre-
applying it on a spot to be cleaned.
Attention
When cleaning the carpet, make a preliminary test using a detergent to see if it will change the color on a rug and then start cleaning.
In order to prevent discolouring of cleaned materials or fire accidents with a vacuum cleaner, it is absolutely forbided to
use inflammable, solute and solvent liquids such diluents, volatile oils and bleachers.
Do not open the buckle while the fan is still rotating.
Remove the top cover.
Removed top cover
Put on a towel or a rag
Rinse off the dirt first before using a product
※Better use a warm water below 40 degrees
With a few drops of detergent on a rug, use a
toothbrush or anything for cleaning to dissolve a stain.
Dip with detergent
Dissolve stains
Attention
Rug Stains
Pour away a wastewater with a water from a product.
Pour 600 ml of clean water into a container
The vacuum cleaner is turned on to instantly inhale water from
the container into the product.
If it can not be cleaned at a time, repeat steps 1-3.
Reused product allows to clean the carpet stains.
For a wash cleaning, please use a detergent.
Attention
Foam
Stain cleaning
Attention
The removed top cover should be moistened or rubbed with a cloth or placed in a place away from water.
Do not overturn a product when eliminating a wastewater to prevent its leakage.
Power OFF
Automatic cleaning function
（600mL）
Suitable detergent
Soda Fizzy soda
Citric acid
Oxygen bleach (clothing)
Less or non-foam detergent
苏打 碳
酸苏打 柠
檬酸
含氧漂白剂等
（衣物 用）
Unsuitable detergent
Kitchen neitr. detergent Laundry detergent
Detergent for cloth washing/ alkaline detergent
Foaming detergent are not recommended, because they easily
enter the vacuum cleaner with air. If you want to use it, please
consult the customer service in advance.
（ 19p.）
厨房用中性洗涤剂
洗衣用洗涤剂
碱性洗涤剂
http://www.sirius-agent.co.jp/faq/

16
17
Maintenance methods
Please perform a maintenance carefully.
Please do not use diluent, volatile oil, flammable substance, alkaline detergents, bleachers, etc.
(protects against discoloration, deformation, cracking, etc.)
A current product can be rinsed, avoid a direct sunlight on it after rinsing, dry thoroughly before using
The stains on the product can be rinsed off with a water, in a serious situation
can use a detergent that should be washed out immediately.
To not to cause a malfunction, please avoid a soak cleaning.
Storage methods
In order to prevent a malfunction and decrease of suction after using it, please keep it
in a storage as follows.
Set the water switch to the water spray position 「 」.
Wipe off the moisture on each part and store it.
There is a possibility of breeding mold and bacteria if it is stored in a water vapor storage.
The switch for clear water
Dry the moisture from inside on the upper cover before re-assembling and storing.
Neutral detergent
Be aware from problems
Please check the following in case a malfunction occurs while using this product.
Phenomenon
The absence of
clear water and its
deficiency
Cause
Wheather the water switch (a non water-jet) position is on an upward side「 」?
Ref.page
8・13
Is the bottom of the product body and the suction inlet lifted from the cleaning surface?
Put down the main body and the suction inlet of the product, keep close to the stain and
start cleaning the front by sliding movements.
6・13
Whether the air-in regulating switch widely open?
8・12
Whether the air intake of the suction inlet part clogged up?
7
Is the extension tube inserted?
10・11
Is the vacuum bag or cup for dust clogged? Is it overfilled by dust?
Does an overload protection device operating well?
–
Does the overload protection of the vacuum cleaner work?
Please refer to instructions for handling a troubleshooting.
–
A water leak
Is the small sucking tube coming off?
16
Has it been tipped over with a water inside of tanks?
There might be a water leak inside of a product’s body.
–
If the bottom head was not turned tightly?
7・9
Abnormal sound
and vibration
Are the eddy-current fan and the counter-current fan not installed properly, and the nuts
are not turned tightly?
16
Did the reset proceed after the backflow valve has been triggered?
12
Is there a hair or a fiber dust on a turbofan and a counterflow?
Please carry out a maintenance.
16
A suction reduction
of the vacuum
cleaner
Please adjust an air-in regulating switch and an intensity speed setting of the vacuum cleaner.
12
Is the vacuum bag or cup for dust clogged? Is it overfilled by dust?
Please refer to the instruction manual for cleaning.
–
Methods of disassembling and
installing of eddy current fans and
countercurrent fans.
Fixed nut
Fixed nut
Sealing gum cushion
When the sealing gasket inside the bottom cap is falling off, it
should be reloaded, please note that it is not distorted, misplaced
and uplifted.
About small sucking tube
Pay attention please
中性洗涤剂
