Sit-Stand Flytta 2 User manual

ASSEMBLY GUIDE
STANDING DESK MEGASTORE
®

2
Inventory
A x2
G x1 H x1 I x1
J x12 K x8 L x2 M x18 N x12 O x4 P x1
B x2 C x1 D x2 E x2 F x2

3
Step 1. Step 3.
Step 4.
Step 2.
NOTE: Do not fully tighten the screws.
NOTE: Do not fully tighten the screws.
D
C
D
A
H
G
A
H
F
F
F
F
D
F
x4
x4
J
K
A A
H
NOTE: Push plastic inserts (F)
until they click into place.
NOTE: Metal frame (C)should
slide under the plastic inserts (F).

4
Step 5. Step 7.
Step 8.
x4
Step 6.
NOTE: Bolts on the far edge of the legs
must be able to hook into the crossbar.
NOTE: Fully tighten the screws (K). Attach parts Bbefore parts E.
K
E E
E
B
S
x8
J
Step 1
Step 2
E
K
P
P

5
Step 9. Step 10.
Step 11.
NOTE: Fully tighten the screws.
Min 1150mm
Max 1730mm
x4
x12
x16
Max 1730mm
Min 1150mm
M

6
Step 12. Step 13.
M
L
x2
x2
A
A
23
B
B
1
Step 14.

7
Reset Procedure
Lower the frame to its lowest position
by pressing the down arrow on the hand
control. Release the button. Press the
button again and keep it pressed for 10
seconds, the reset is now carried out and
the frame is ready to use.
Fahren Sie die Tischplatte mit der Taste
“Pfeil nach unten“ zum tiefsten Punkt! Die
Taste loslassen. Die Taste noch einmal
herunterdrücken und sie ca. 10 Sekunden
halten bis Sie eine kleine Bewegung der
Tischplatte bemerken.
ENG
DE

8
Memory Setting Control Panel
Operation
Save Key Up Key Down KeyMemory Position Keys 1, 2, 3 and 4
S12 3 4
1. Adjust the desktop to the position you want to save
(the display will show the desktop height e.g. 73cm)
2. Press the Memory Key (the display will show an S)
3. Press the required memory position key
(e.g. 2 – the display will now show S2)
4. The desktop position has now been saved
1. Press the required memory position key (e.g. 2) and hold it
down. The desktop will move until it reaches that position. If you
release the key, then it will stop moving and the saved desktop
position will not be reached.
2. The desktop has reached the desired position, release the key.
1. Press the down key until the desktop reaches its lowest point
2. Press the down arrow again and hold it for about 5-10 seconds. After this
time, the desktop will lower further, and the motors will click
3. Release the down arrow key. The desk will now move freely
1. Move the desktop to where the container / shelf stop position
shall be stored. Do this by pressing the up or down key until you
reach the desired position
2. Press the Save Key for 10 seconds. The compact will click twice
when the position is stored
*Please note a container stop can only be stored in the lower
half of the movement area and a shelf stop in the upper half of
the movement area.
1. Move the desktop to any position in the lower half (container stop) or upper half
(shelf stop) of the movement area. Do this by using the up or down keys
2. Once in the desirable position, press and hold the memory key for 10 seconds.
The compact will click once when the container/shelf stop has been
Saving a desktop position
Adjusting the desktop to a saved position
Manual resetContainer and Shelf-Stop positions (activation)
Container and Shelf-Stop positions (deactivation)

9
Memory Setting Control Panel
Fault Protocol
Cause Remedy
The COMPACT control unit is tted
with overheating protection. Over
heating has caused the control unit to
stop.
Wait until the control unit has cooled
down and HOT is no longer displayed.
The COMPACT control unit is then
operational again.
Cause Remedy
There is an internal fault in the
COMPACT control unit.
Proceed as indicated in the following
error list.
Code Cause Remedy
00 Internal Error Channel 1
Unplug power cord and contact customer
service.
01 Internal Error Channel 2
02 Internal Error Channel 3
12 Defect Channel 1 Unplug the control unit. Fix the external
short circuit or
Plug in the correct motor the motor
socket that shows the error. Start the
control unit again.
13 Defect Channel 2
14 Defect Channel 3
24 Overcurrent motor M1
Remove jammed objects from the driving
area.
Desk might be overloaded - remove load
from desktop.
Contact customer service.
25 Overcurrent motor M2
26 Overcurrent motor M3
48 Overcurrent motor group 1
49 Overcurrent motor group 2
60 Collision protection
62 Overcurrent control unit
Code Cause Remedy
36 Plug detection in M1 motor socket
Plug in the correct motor to the motor
socket that shows the error. Reset all
motors.
37 Plug detection in M2 motor socket
38 Plug detection in M3 motor socket
61 Actuator changed
55 Sunchronisation lost motor group 1 Remove load from desktop.
Reset all motors: If the error occurs again
after reset, contact customer service.
56 Sunchronisation lost motor group 2
67 High voltage unplug power cord and contact customer
service.
81 Internal error
Make a manual reset.
Unplug the power cord and plug it in
again after a few seconds.
If this error occurs frequently, unplug
the power cord and contact customer
service.
The display reads HOT.
The display reads E + an error code.
