Sitecom WMA-1000 Installation instructions

Wi-Fi Music Player
WMA-1000
Full Manual

Introduction
Congratulations on your purchase of the Sitecom Wi-Fi Music Player. The Sitecom Wi-
Fi Music Player allows you to stream Airplay and DLNA music content directly to your
home stereo set using S/PDIF or analogue stereo output.
Airplay
• Stream music directly to your stereo using your iPhone, iPod, iPad or even your Mac.
DLNA
•Stream music directly to your stereo using your Android phone or PC.
•Use the Sitecom Imedia app to stream music from any location in your network.

Index
1Key Features .............................................................................. 4
2Package Contents........................................................................ 4
3Cautions .................................................................................... 5
3.1 Usage Cautions ............................................................................................ 5
3.2 Power.......................................................................................................... 5
3.3 Radio Interference ........................................................................................ 5
3.4 Repair ......................................................................................................... 5
3.5 Disposal of the Player.................................................................................... 5
3.6 Other .......................................................................................................... 5
4Product Layout............................................................................ 6
4.1 Front Panel .................................................................................................. 6
4.2 Back Panel ................................................................................................... 7
5Getting Started ........................................................................... 8
5.1 Installation Requirements .............................................................................. 8
5.2 Installation Procedure ................................................................................... 8
6Connecting the Wi-Fi Music Player to your network........................ 10
6.1 Connecting the Wi-Fi Music Player to your network using OPS ...........................10
6.2 Connecting the Wi-Fi Music Player to your network without OPS (Manual Setup)..10
7Configuring your Wi-Fi Music Player ............................................. 13
7.1 Status Page .............................................................................................14
7.2 Settings Page ..........................................................................................16
7.3 Wi-Fi Setup Page......................................................................................17
Addendum A: GNU/GPL Leaflet......................................................... 18
Addendum B: GNU/GPL ................................................................... 19
Addendum C: Declaration of Conformity ............................................ 27
Revision 1.0
© Sitecom Europe BV 2013
Note: All the information contained in this manual was correct at the time of publication.
However, as our engineers are always updating and improving the product, your device’s
software may have a slightly different appearance or modified functionality than
presented in this manual.

1 Key Features
The key features of the Sitecom Wi-Fi Music Player include:
•OPS setup, with One-Push-Setup you can establish a connection with your router
within seconds.
•S/PDIF output, digital optical output for crystal clear sound.
•Stereo Jack output, for connecting the device to almost any output source
possible.
•Airplay support, stream music directly to your stereo using your iPhone, iPod, iPad
or even your Mac.
•DLNA support, stream music directly to your stereo using your Android phone or
PC.
2 Package Contents
Open the package carefully, and make sure that none of the items listed below are
missing. Do not discard the packing materials, in case of return; the unit must be
shipped back in its original package.
The contents of the package of the Sitecom Wi-Fi Music Player are:
•Sitecom Wi-Fi Music Player
•Optical TOSLINK cable
•Stereo-jack to RCA cable
•5V DC micro USB adapter
•Quick Installation Guide

3 Cautions
This player’s design and manufacturer has your safety in mind. In order to safely and
effectively use this player, please read the following before usage.
3.1 Usage Cautions
User should not modify this player. If commercial hard disk is being used, the
environmental temperature should be within +5 ~ +35 degrees Celsius.
3.2 Power
The player’s power voltage is DC 5V. When using this player, please connect the
supplied AC adapter to the player’s micro USB port. When placing the adapter cable,
make sure it can not get damaged or be subject to pressure. To reduce the risk of
electric shock, unplug the adapter first before cleaning it. Never connect the adapter
to the player in a humid or dusty area. Do not replace the adapter or cable’s wire or
connector.
3.3 Radio Interference
- If not properly shielded, almost all electronic devices will get radio interference.
Under some conditions, your player might get interference.
- The design of this player has followed the FCC/CE standard, and has followed the
following rules:
(1) This player may not cause harmful interference;
(2) This player could accept some interference received including interference that
may cause undesired operation.
3.4 Repair
If the player has a problem, you should take it to an appointed repair centre and let
the specialists do the repair, never repair the player yourself, you might damage the
player or endanger yourself or your data.
3.5 Disposal of the Player
When you dispose of the player, be sure to dispose it appropriately. Some countries
may regulate disposal of electrical device, please consult with your local authority.
3.6 Other
When using this player, please do not let the player come into contact with water or
other liquid, if water is accidentally spilled on the player, please use a dry cloth to
absorb the spillage. Electronic products are vulnerable, when using please avoid
shaking or hitting the player, and do not press the buttons too hard.
- Do not let the player come into contact with water or other liquid.
- Do not disassemble, repair or change the design of the player. Any damage done
will not be included in the repair policy.
- Do not press the OPS button too hard.
- Avoid hitting the player with a hard object, avoid shaking the player and stay away
from magnetic fields.
- If during electrostatic discharge or a strong electromagnetic field the product will
malfunction, unplug the power cable. The product will return to normal performance
the next time it is powered on.

4 Product Layout
4.1 Front Panel
Note: from firmware version 1.1.21A the device will light purple when it is configured
but not connect to a Wi-Fi network. This might be an indication of a bad connection or
a misconfigured password / network.
Item
Description
Power LED
The LED lights red when the device is switched on. During
audio streaming it is lit green.

4.2 Back Panel
Item
Description
S/PDIF
Use this port to connect the S/PDIF cable.
WPS / OPS button
Use this button to connect the device to your wireless
network if WPS / OPS is supported.
Audio Jack
Use this port to connect the RCA / audio jack cable.
Power
Use this port to connect the supplied 5v power-adapter.

5 Getting Started
Before beginning the installation, please read through the installation procedure
described in this manual.
5.1 Installation Requirements
To begin using the Wi-Fi Music Player, you will need:
•An output equipped with either S/PDIF or analogue input channel.
•Existing wireless network (802.11G / 802.11N)
5.2 Installation Procedure
The Wi-Fi Music Player installation procedure is summarized below:
1. Connect the Wi-Fi Music Player to an output source.
2. Connect the power to the Wi-Fi Music Player.
3. Connect the Wi-Fi Music Player to your existing wireless network.
5.2.1 Connect the Wi-Fi Music Player to an output source
The Wi-Fi Music Player supports digital audio over S/PDIF and analogue audio over
RCA /stereojack.
• Analogue Audio (RCA)
Connect the supplied 5V DC adapter to a free wall socket. Connect the other end
to the designated port on the back of the Wi-Fi Music Player.
Plug the supplied RCA / stereo jack cable into the analogue port and the red and
white connectors into the colour-coded Audio connectors of your stereo receiver.
Connect the red plugs to the Right (R) jacks and the white plugs to the Left (L)
jacks.

•Digital Audio (S/PDIF)
Connect the supplied 5V DC adapter to a free wall socket. Connect the other end
to the designated port on the back of the Wi-Fi Music Player.
Plug an optical cable into the corresponding port on the back of the Wi-Fi Music
Player. Connect the other end to the corresponding port on your Audio receiver.

6 Connecting the Wi-Fi Music Player to your
network
Once the Wi-Fi Music Player is connected to an audio output source, you’ll need to
connect it to your wireless network.
6.1 Connecting the Wi-Fi Music Player to your network using
OPS
6.2 Connecting the Wi-Fi Music Player to your network without
OPS (Manual Setup)
If the wireless router that you are using is not Sitecom branded, or it does not
support WPS / OPS setup follow below steps to connect the Wi-Fi Music Player to your
network;
1. On the back label of the device there is a network-name listed, search for wireless
networks and connect to the network corresponding of your Wi-Fi Music player

2. Once connected open a web browser, you should automatically be redirected to
the login-page of the device, if you don’t get redirected please fill in the network
name of the device which is mentioned on the back label with http:// in front of it
e.g. http://sitecom-e1aa you should see the following screen;
Login with username and password: admin
3. Select Wi-Fi Setup, select the network you want to connect the Wi-Fi Music player
to and fill-in the corresponding security key, click connect.

Wait two minutes. You should now be able to play your music following the
included Quick Installation Guide.

Note: If after manual configuration the LED is lit purple, this might indicate that the
password entered was not correct. To resolve this, reset the device by pressing the WPS
button for 15 seconds and repeat the procedure.
7 Configuring your Wi-Fi Music Player
This chapter describes the configuration settings of the Wi-Fi Music Player, to access the
configuration page login to your Wi-Fi Music Player by typing in the network-name or IP-
address in your browser;
At the bottom left of the screen there are 3 options:
Sitecom: clicking Sitecom will take you to the Sitecom website.
Mobile: select Mobile if you are accessing the Wi-Fi Music Player from a mobile
device (this enhances the interface to be viewed on mobile browsers).
Language: choose the language for the interface-page.
The username and password default setting is: admin/admin

7.1 Status Page
Once logged into the device you’ll see the status-page.
The status-page displays the actual settings of the device:
Device name: the device-name given to the device (by default Sitecom-XXXX).
Language: the chosen language of the interface.
Airplay Service: displays whether the Airplay service is enabled or disabled.
DLNA Service: displays whether the DLNA service is enabled or disabled.
Wi-Fi Connection: displays the current status of the Wireless connection.
Connection Type: displays whether the device has been setup using DHCP or
static IP configuration.
IP-Address: displays the current IP-address of the device.
Gateway: displays the current Gateway configured in the device.
DNS Server: displays the current DNS Server configured in the device.
Password Protection: displays whether the device is currently protected with or
without a password.
Firmware Version: displays the current Firmware Version which the device is
running.

Furthermore there are two buttons named;
Restore Factory Default: clicking this button will reset the device to its original
state.
Firmware Upgrade: clicking this button will allow you to upgrade the firmware of
the device the screen shows you the following:
Select the firmware file which can be downloaded from: www.sitecom.com and choose
upgrade.
Note:as described in the same screen, never shutdown or reboot the device while the
firmware upgrade is still in process! If for some or another reason the upgrade fails or
the device becomes inaccesible, press and hold the WPS button for 1 minute, this will
recover the firmware.

7.2 Settings Page
The settings page allows you to configure the device, e.g. enable or disable stream-
services, change password, change device name….
Device name: this field allows you change the device-name of the device, by
changing the name you can customize how the device appaers on playback
devices.
Note: If you change the name, this will also become the URL to access the device e.g.
when you change the name too wma-livingroom then the url to access the device will
become: http://wma-livingroom
Language: allows you to change the language of the interface.
Enable Airplay Service: enable or disable Airplay support.
Enable DLNA Service: enable or disable DLNA support.
Password Protection: enable or disable password protection.
Note: disabling password protection, allows other users to easily modify settings on
the device through the interface.
Username: change the username to access the device’s interface.
Password: change the password to access the device’s interface.
Show password: allows you to view the password which is normally been hided.
Note : when you’ve forgotten the username or password, please reset the device by
pressing the WPS button for 15 seconds.

7.3 Wi-Fi Setup Page
The Wi-Fi setup page allows you to manually setup a wireless connection if OPS / WPS
are not supported. It also displays the current Wi-Fi status.
Join into wireless lan: when this option is not checked, the device is
broadcasting his own SSID. When it is checked it indicates that it is associated
with a wireless network, and the device displays the current connection status. If
you uncheck Join into wireless lan, the device will broadcast its own SSID, check
the box again and it will connect to its previously configured profile.
Note: If you want to setup a Static IP, first connect the device to a network then change
Dynamic IP to Static IP and fill in the details, then click Save.
Select A Wireless Lan: select a network you wish to connect the Wi-Fi Music
Player with, if necessary fill in the associated network key.
Connection Manual Setup: use this option if you want to setup a manual
connection without using the wireless network selection screen. Fill in the SSID
and or the password of the network you want to associate the Wi-Fi Music Player
with and click Connect.

Addendum A: GNU/GPL Leaflet
Licensing Information
Parts of the firmware of the WMA-1000 Wi-Fi Music Player are subject to the GNU general public license.
This product includes third-party software licensed under the terms of the GNU General Public License.. You can
modify or redistribute this free software under the terms of the GNU General Public License. Please see
Appendix B for the exact terms and conditions of this license.
Specifically, the following part of this product is subject to the GNU GPL:
#
Package name
Source
1
Linux v2.6.32.9
www.kernel.org
2
busybox-1.15.2
http://www.busybox.net/
3
glibc-2.10.1
http://www.gnu.org/software/libc/
4
libupnp-1.6.15
http://pupnp.sourceforge.net/
5
gcc-4.3.0
http://gcc.gnu.org/
6
alsa-lib-1.0.23
http://www.alsa-project.org/
7
openssl-0.9.8i
http://www.openssl.org/
8
wireless_tools.29
http://www.hpl.hp.com/personal/Jean_Tourrilhes/Linux/Tools
.html
9
wpa_supplicant-0.6.10
http://w1.fi/wpa_supplicant/
10
iptables-1.4.6
http://www.netfilter.org/projects/iptables/index.html
11
bind-9.2.9
https://www.isc.org/software/bind
Availability of source code
Sitecom Europe BV has made available the full source code of the GPL licensed software, including any scripts
to control the compilation and installation of the object code on the Sitecom website.
No Warranty
The free software included in this product is distributed in the hope that it will be useful, but WITHOUT ANY
LIABILITY OF OR ANY WARRANTY FROM THE LICENSOR.

Addendum B: GNU/GPL
Version 3, 29 June 2007 Copyright © 2007 Free Software Foundation, Inc. http://fsf.org/
Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not
allowed.
Preamble
The GNU General Public License is a free, copyleft license for software and other kinds of works.
The licenses for most software and other practical works are designed to take away your freedom to share and
change the works. By contrast, the GNU General Public License is intended to guarantee your freedom to share
and change all versions of a program--to make sure it remains free software for all its users. We, the Free
Software Foundation, use the GNU General Public License for most of our software; it applies also to any other
work released this way by its authors. You can apply it to your programs, too.
When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are
designed to make sure that you have the freedom to distribute copies of free software (and charge for them if
you wish), that you receive source code or can get it if you want it, that you can change the software or use
pieces of it in new free programs, and that you know you can do these things.
To protect your rights, we need to prevent others from denying you these rights or asking you to surrender the
rights. Therefore, you have certain responsibilities if you distribute copies of the software, or if you modify it:
responsibilities to respect the freedom of others.
For example, if you distribute copies of such a program, whether gratis or for a fee, you must pass on to the
recipients the same freedoms that you received. You must make sure that they, too, receive or can get the
source code. And you must show them these terms so they know their rights.
Developers that use the GNU GPL protect your rights with two steps: (1) assert copyright on the software, and
(2) offer you this License giving you legal permission to copy, distribute and/or modify it.
For the developers' and authors' protection, the GPL clearly explains that there is no warranty for this free
software. For both users' and authors' sake, the GPL requires that modified versions be marked as changed, so
that their problems will not be attributed erroneously to authors of previous versions.
Some devices are designed to deny users access to install or run modified versions of the software inside them,
although the manufacturer can do so. This is fundamentally incompatible with the aim of protecting users'
freedom to change the software. The systematic pattern of such abuse occurs in the area of products for
individuals to use, which is precisely where it is most unacceptable. Therefore, we have designed this version of
the GPL to prohibit the practice for those products. If such problems arise substantially in other domains, we
stand ready to extend this provision to those domains in future versions of the GPL, as needed to protect the
freedom of users.
Finally, every program is threatened constantly by software patents. States should not allow patents to restrict
development and use of software on general-purpose computers, but in those that do, we wish to avoid the
special danger that patents applied to a free program could make it effectively proprietary. To prevent this, the
GPL assures that patents cannot be used to render the program non-free.
The precise terms and conditions for copying, distribution and modification follow.

TERMS AND CONDITIONS
0. Definitions.
“This License” refers to version 3 of the GNU General Public License.
“Copyright” also means copyright-like laws that apply to other kinds of works, such as semiconductor masks.
“The Program” refers to any copyrightable work licensed under this License. Each licensee is addressed as “you”.
“Licensees” and “recipients” may be individuals or organizations.
To “modify” a work means to copy from or adapt all or part of the work in a fashion requiring copyright
permission, other than the making of an exact copy. The resulting work is called a “modified version” of the
earlier work or a work “based on” the earlier work.
A “covered work” means either the unmodified Program or a work based on the Program.
To “propagate” a work means to do anything with it that, without permission, would make you directly or
secondarily liable for infringement under applicable copyright law, except executing it on a computer or
modifying a private copy. Propagation includes copying, distribution (with or without modification), making
available to the public, and in some countries other activities as well.
To “convey” a work means any kind of propagation that enables other parties to make or receive copies. Mere
interaction with a user through a computer network, with no transfer of a copy, is not conveying.
An interactive user interface displays “Appropriate Legal Notices” to the extent that it includes a convenient and
prominently visible feature that (1) displays an appropriate copyright notice, and (2) tells the user that there is
no warranty for the work (except to the extent that warranties are provided), that licensees may convey the
work under this License, and how to view a copy of this License. If the interface presents a list of user
commands or options, such as a menu, a prominent item in the list meets this criterion.
1. Source Code.
The “source code” for a work means the preferred form of the work for making modifications to it. “Object
code” means any non-source form of a work.
A “Standard Interface” means an interface that either is an official standard defined by a recognized standards
body, or, in the case of interfaces specified for a particular programming language, one that is widely used
among developers working in that language.
The “System Libraries” of an executable work include anything, other than the work as a whole, that (a) is
included in the normal form of packaging a Major Component, but which is not part of that Major Component,
and (b) serves only to enable use of the work with that Major Component, or to implement a Standard
Interface for which an implementation is available to the public in source code form. A “Major Component”, in
this context, means a major essential component (kernel, window system, and so on) of the specific operating
system (if any) on which the executable work runs, or a compiler used to produce the work, or an object code
interpreter used to run it.
The “Corresponding Source” for a work in object code form means all the source code needed to generate,
install, and (for an executable work) run the object code and to modify the work, including scripts to control
those activities. However, it does not include the work's System Libraries, or general-purpose tools or generally
available free programs which are used unmodified in performing those activities but which are not part of the
work. For example, Corresponding Source includes interface definition files associated with source files for the
work, and the source code for shared libraries and dynamically linked subprograms that the work is specifically
designed to require, such as by intimate data communication or control flow between those subprograms and
other parts of the work.
The Corresponding Source need not include anything that users can regenerate automatically from other parts
of the Corresponding Source.
The Corresponding Source for a work in source code form is that same work.
