Sitecom WLM-1000 User manual

Installation
guide
WLM-1000_QIG_201311219.indd 1-2 5/14/14 11:22 AM

Package content
Mobile
Wi
- Fi Router
EN
1x 3G Mobile Wi-Fi Router
1x Pouch SIM adapters
1x Battery
1x Micro USB cable
Package content
1x Pouch
1x Micro USB cable
WLM-1000_QIG_201311219.indd 3-4 5/14/14 11:22 AM

3G Signal LED Power LED
Micro USB Port
Power
On/Off
Wi-Fi Signal LED
Device overview 3G Signal LED
Blue ashing: Dial-up to a 3G network
Blue ashing slowly: Register to a 3G network
Blue solid: Successful 3G data connection
LED off: 3G data connection not successful:
e.g. SIM card is not activated, Pin is activated or router is in
sleep-mode
Power LED
Blue solid for 30 seconds, then off: Power on
Red ashing: Low power
Red solid: Low power and will be powered off soon
Green ashing: Battery is charging
Green solid: Charging completed
LED off: Router is in sleep-mode
Wi-Fi Signal LED
Blue solid: Wi-Fi is active
Blue ashing twice: Connected to Wi-Fi network
LED off: Wi-Fi is in sleep-mode
Power on/off button
Press and hold for 3 seconds to power on/off
Press briey to deactivate sleep-mode
EN
WLM-1000_QIG_201311219.indd 5-6 5/14/14 11:22 AM

Setup
1
a. Take off the back cover
EN
WLM-1000_QIG_201311219.indd 7-8 5/14/14 11:22 AM

c. Insert the battery and put on the back coverb. Insert your SIM-card (and optional micro-SD card)
SIM
micro
SD
(optional)
EN
WLM-1000_QIG_201311219.indd 9-10 5/14/14 11:22 AM

d. Charge the 3G Mobile Wi-Fi Router
OR
• Use the supplied micro-USB cable and connect to a notebook
or a USB wall charger.
• A full charge will take about an hour.
e. When the battery LED turns solid green the
3G Mobile Wi-Fi Router is fully charged
EN
WLM-1000_QIG_201311219.indd 11-12 5/14/14 11:22 AM

f. Press and hold the on/off button for 3 seconds to turn
the 3G Mobile Wi-Fi Router on
g. Check the status of the 3G Signal LED to determine
the status of your 3G connection
press
3 sec.
• If the LED turns solid blue, your SIM-card is not secured
with a pin code and you have a successful connection.
Continue with Step 2 only.
• If the LED stays off , your SIM-card is probably secured with
a pin code. Continue with Step 2 and 3.
EN
WLM-1000_QIG_201311219.indd 13-14 5/14/14 11:23 AM

Connect your
device to the
3G Mobile
Wi-Fi Router
2
a. Scan for Wi-Fi networks in your area
Click
PC
MAC
Click
EN
WLM-1000_QIG_201311219.indd 15-16 5/14/14 11:23 AM

c. Type the WPA2 codeb. Select the network name of your 3G Mobile Wi-Fi Router
PC PC MAC
MAC
• You can  nd the network name in the Network Detail Flyer or
on the inside of the back lid of your 3G Mobile Wi-Fi Router.
• You can  nd the WPA2 code in the Network Detail Flyer or
on the inside of the back lid of your 3G Mobile Wi-Fi Router.
Click
Click Click
Click
Click
EN
WLM-1000_QIG_201311219.indd 17-18 5/14/14 11:23 AM

Unlock your
SIM-card
3
a. Open your web browser and go to:
http://sitecom.modem
EN
WLM-1000_QIG_201311219.indd 19-20 5/14/14 11:23 AM
