Sitecom X7 AC1200 User manual

Installation guide
WLR-7100_v1001_QIG_20130425.indd 1-2 25-09-14 13:56

Package content
Wi - Fi router
AC12 0 07
1x WLR-7100 Wi-Fi Router 1x Power adapter
1x Network cable
1x CD Router USB Software
1x WLR-7100 Wi-Fi Router
UK Full manual available in English
NL Volledige handleiding beschikbaar in het engels
IT Il manuale utente completo è disponibile in lingua inglese
DE Vollständiges Handbuch in englischer Sprache verfügbar
ES Manual completo disponible en inglés
PT Manual completo disponível em inglês
FR Manuel complet disponible en anglais
RU Подробное руководство доступно на английском языке
www.sitecomlearningcentre.com
