Skoda KODIAQ 2016 Reference guide

BEFORE YOU SET OFF
Brief Instructions
ŠKODA KODIAQ

This brochure is intended to quickly acquaint you with some vehicle functions.
This does not replace the vehicle Owner's Manual, because it does not provide information on operation, e.g. the safety notices. Therefore, when
using our vehicles, proceed in accordance with the vehicle Owner's Manual in the first instance.
There is a QR code in the area of the titles of some described functions. Once these are read, a short animation with instructions is displayed
with respect to the affected function.
›Overview of this brochure by topic
›Unlocking and opening 1
›Correct and safe seating position 2
›Operating rear seats 4
›Lights and visibility 6
›Air conditioning system 8
›Instrument cluster 10
›Starting and stopping the engine 12
›Braking and parking 14
›Park Assist systems 15
›Driver assist systems 17
›OFF ROAD mode 21
›Hitch and trailer 22
›At the petrol station 24
›Telephone 26
›Radio 27
›Navigation 28
›Connectivity 29
›Online services ŠKODA Connect 30
›Warning lights overview 31
This brochure is also available to download in each language version on the website http://go.skoda.eu/owners-manuals, see QR code.

Unlocking and opening
›Key
Locking the vehicle
Unlocking the boot
lid
Unlocking the vehicle



›KESSY
The KESSY system enables the vehicle to be unlocked and locked by
means of sensors in the two front door handles without actively using
the key.
›Grip the front door handle to unlock the door.
›Touch the sensor on the exterior of the front door handle to lock the
vehicle.
›Luggage compartment lid
Vehicles fitted with manual lid operation
›To open press the button A and lift the flap.
›To close, grab the mount B and pull in the direction of the arrow.
Vehicles fitted with electric lid operation
›To open, press the button A, pull the button B or hold the button
 on the key.
›To close, press the button C, pull the button B and hold this or
hold the button  on the key (applies to vehicles with KESSY).

›Operating boot lid without contact
Open/close
›Speedily swing a foot under the rear bumper.
Operating conditions
The ignition is switched off.
You must have the car keys with you.
Disabling/Enabling can be carried out in the infotainment in the menu
 →  →
Open and close .


Correct and safe seating position
›Correct seating position for the driver
For your safety, and to reduce the risk of injury in an accident, the
steering wheel, the seat and headrest must be adjusted as follows.
Distance A - at least 25 cm
Distance B - at least 10 cm
Line C - top of the headrest at the same level with the top of the
head, where possible
2

›Adjusting front seats manually
Adjusting a seat in a for-
ward/back direction
Adjusting height of seat
Adjusting the angle of the
seat backrest
Adjusting lumbar support
A
B
C
D
›Adjusting front seats electrically
Adjusting lumbar support
Seat adjustment
Adjusting the angle of the
seat backrest
A
B
C
›Adjusting the steering wheel position
Steering wheel locked
Steering wheel unlocked
The forward/back position and the height of the steering wheel can be
adjusted.


3

›Adjusting exterior mirrors
The knob can be moved into the following positions.
Adjust the left mirror
Switch off mirror control
Adjust the right mirror
Fold mirrors
Mirror heater
By moving the knob in the direction of the arrows, the mirror surface
can be adjusted.





Operating rear seats
›Operating second row of seats
›To adjust forward/back position, pull lever A in the direction of ar-
row 1 and move the seat to the desired position in the direction of
arrow 2.
The Easy Entry function provides the access to the third row.
›To fold and slide the seat, pull the securing tab in the direction of
arrow 1.
›Fold the seat forwards and slide the seat in the direction of arrow 2.
›To fold back flap, adjust the seat's forward/backward position and
lift the seat back.
›Check this by pulling on the seat and on the seat backrest.
4

›Folding seat backs of the third row of seats
up/down
Before moving the seat backs, move the second row of seats forward
and remove the luggage compartment cover.
›To fold up, pull eyelet A in direction of arrow 1.
The seat back must engage audibly after folding up.
›To fold down, press the securing tab B in direction of arrow 2 and
fold the seat backs forwards in the direction of arrow 3.
›Folding third-row seats up/down
Before moving the seats, unlock the buckle tongues of the seat belts
(the straps must be completely retracted).
›Fold the seat backs forwards.
›To fold up, pull the eyelets simultaneously in the direction of arrow
1.
The seats are raised in the direction of arrow 2.
›To fold down, press the seats in the direction of arrow 3.
5

Lights and visibility
›Operating light function
Using headlights - turn switch
Switch off lights (except daytime running lights)
Automatically switch lights on/off
Switch on parking lights
Switch on the low beam
Operating fog lights / rear fog lamp - pull switch
Switch on the front fog light
Switch on the rear fog light
Headlight range control
On vehicles with LED headlights, headlight range control takes place
automatically.
On vehicles with Halogen headlights, headlight range control takes
place in the infotainment in the menu  →  →
Lights .






›Main beam
Switch on main beam (spring-tensioned position)
Switch off main beam / switch on headlight flasher (spring-ten-
sioned position)

 
›Turning signal system
Switch on the right turn signal
Switch on the left turn signal


6

›Windscreen wipers and washers
Rapid windscreen wiping
Slow windscreen wiping
Depending on equipment fitted:
Periodic windscreen wiping / automatic wiping in rain
To set the wiper interval for the position 
Wipers and washers off
Single windscreen wipe (spring-loaded position)






Spraying and wiping the rear window (spring-tensioned position)
Spraying the rear view camera (spring-tensioned position)
Wiping the rear window
Wipers and washers off
Spraying and wiping the windscreen (spring-tensioned position)




7

Air conditioning system
›Climatronic
Individual functions can be set off or switched on by turning the con-
trol dial or press the corresponding key. If the function is switched on,
a warning light lights up within or below the button.
Adjust the temperature for the left side
Adjust the blower speed
Adjust the temperature for the right side
Depending on equipment fitted:
 Auxiliary heating
 Heating of the passenger compartment using the residual heat
of the engine (after switching off the ignition)
Display the set temperature for the left side
Depending on equipment fitted:
 Seat heating for the front left seat
 Seat heating and ventilation for the left front seat
Depending on equipment fitted:
 Seat heating for the front right seat
 Seat heating and ventilation for the right front seat
Display the set temperature for the right side
Air flow to the windows
A
B
C
D
E
F
G
H

Air flow to the upper body
Air flow in the footwell
Recirculated air mode
Ventilation/defrosting of the windscreen
Heated rear window
Heated windscreen
Adjust Climatronic in the infotainment
Synchronise the temperature inside the entire vehicle according
to the temperature setting on the driver's side
Automatic mode
Cooling system










8
