Skope CONSORT PLC075TI User manual

LC075TI, LC125TI,
LC150TI, LC200TI
SKOPE CONSORT
Convection Panel Heaters
Installation and Operating Instructions MAN0981 Rev. 2.0 March 2010

2LC075TI, LC125TI, LC150TI, LC200TI
SKOPE CONSORT Convection Panel Heaters
Safety Information
Whenusinganyelectricalappliance,safetyprecautionsshouldalways
be observed.Read these instructions carefully, and retain for future
reference. For service, contact your nearest authorised service agent.
•When used by, or near, young children or infirm persons, close
supervision is necessary. Young children should be supervised to
ensure thatthey do not play with the appliance, nor touch
anywhere near the outletgrille.
•Do NOTtouch the outletgrille, as it is VERY hot.
•Do NOTuse this appliance other than for its intended use.
•Do NOTcover the grilles or place any objector material up against
the unit, as this may block entry or exhaust of airflow.
•Do NOT probe any opening toremovefluff.To ensure trouble-free
performance itis recommended that on a regular basis the unit be
isolated from the power supply and a vacuum cleaner used to
remove dustand fluff from the inlet and outlet grilles.
•Do NOTallow the supplycord to come into contact with heated
surfaces during operation.
•Use this appliance with the voltage specified on the rating label.
•Be very careful notto touch hot surfacesor moving parts.
•Ifthe supply cord becomes damaged, itmustbe replaced by a
SKOPE authorised service agent, or similarly qualified person,in
order to avoid a hazard.
•Regulations require that electrical work be carried out by
authorised persons. For your own safetyand that of others,ensure
this is done.

3
LC075TI, LC125TI, LC150TI, LC200TI
SKOPE CONSORT Convection Panel Heaters
Installation Regulations
This appliance MUST be installed in accordance with relevant wiring
rules and regulations which cover installation ofappliances and
accessoriesindampsituationssuch asbathrooms,showers,laundries
and other areas with fixed water containers (in Australia and New
Zealand - AS/NZS 3000:2000 Wiring Rules).
IMPORTANT: The heater must not be located immediately below a
socketoutlet. A suitable disconnection device (acting in all active
supplies) is required to be incorporated in the fixed supplywiring.
The heater must be mounted a minimum distance of:
•150mm from floor level
•400mmm belowa fixture or ceiling
•300mm from adjacent walls
Installation Dimensions
Model A B C
PLC075TI 442mm 196mm 123mm
PLC125TI 614mm 364mm 125mm
PLC150TI 680mm 488mm 96mm
PLC200TI 852mm 616mm 118mm
Figure 1: Installation dimensions

4LC075TI, LC125TI, LC150TI, LC200TI
SKOPE CONSORT Convection Panel Heaters
Installation Instructions
Thewallbracket supplied with the heater must be usedwhenattaching
heater to the wall. To attach heater tothe wall:
1.Remove wall bracket from the heater, with the chains attached,
byremoving the two securing screws from top of the rear panel.
2.Fix wall bracket to wall using the four fixing screw holes provided
(see Figure 1for dimensions).
3.Locate heater onto both bottom lugs of the wall bracket.
4.Hinge heater upwards, and replace retaining screws with link
plates of chain attached,and move heater to upright position.
The linkplates should slide under the wall bracket retaining slot.
5.Tighten both retaining screws (see Figure 2 below).
Figure 2:Wallbracket
Wall bracket retaining slot
Heater
Retaining
screw
Fixing
screw
Chain link plate
Chain
Wall
bracket

5
LC075TI, LC125TI, LC150TI, LC200TI
SKOPE CONSORT Convection Panel Heaters
Operation
The controls are located behind a cover on the right hand end ofthe
heater.When the appliance is connected to the mains supply the neon
indicator on front of the heater should be illuminated. The operation of
the heater is controlled by use ofthe following controls:
Heat Switches
The heat output is controlled by two switches located under the
thermostat knob (see Figure 3below). One switch depressed will give
half the heater output,while both switches depressed will give full heat
output.
Thermostat
The heater is fitted with a built-
in thermostatto control the
temperature level towhich the
room is heated.The
thermostat adjustment knob is
located on the right hand end
and isnumbered. Rotate the
knob clockwise to a higher
number to raise the room
temperature. Once setit is
unlikely to require to be
touched again.
Frost Watch
The ‘FrostWatch’ function is
intendedtokeepvacatedareas
above freezing level, so water
pipes do not burst.
To setthe heater to the FrostWatchmode, turn the thermostat control
knob fullyanti-clockwise until the frostsymbol aligns with mark.
Figure 3: Control panel
Heat
switches
24-hour
timer dial
Thermostat
knob
Selector
switch

6LC075TI, LC125TI, LC150TI, LC200TI
SKOPE CONSORT Convection Panel Heaters
24-Hour Timer
Theheater mustbeconnectedtothemainssupplyinorderforthetimer
to operate continuously.
Set the correcttime on the timer by rotating the dial clockwiseuntil the
correct time is indicated on the 24-hour clockface.
Automatic Operation
Move the selector switch (immediately beneath the timer) to the auto
position designated .
The 24-hour timer can be set to give any combination of On/Off
intervals to aminimum of 15 minutes on. Select the 'On' time required
by pressing the black segment (on the circumference of the timer)
adjacentto the time required outwards. This will cause the heater to
switch 'On' at the selected time for 15 minutes operation. Each
additional segment pressed out willgive a further 15 minutes of
operation.In this way, select the lengthof time required for the unitto
be 'On' and push out the number of 15-minute segments necessary to
select the time period required.
The timer can be setto give as many 'On' periods as required during
any 24-hour period.
This program will repeat itselfevery 24 hoursuntil changed. This
program may be overridden atany time by switching to manual
operation.
Manual Operation
Move the selector switch, immediately beneath timer, to the manual
position designated . The heater will now run continuously,
controlled by the heatswitches and thermostat setting.

7
LC075TI, LC125TI, LC150TI, LC200TI
SKOPE CONSORT Convection Panel Heaters
Thermal Operated Cut-Out
The appliance is fitted with an Electronic Safety Control(ES). This is
a safety device, which switches the heater off if,for anyreason, the
appliance overheats. The ES control can only be re-set after the
appliance has cooled down.In order to re-set the ES control, proceed
as follows:
1.Switch off appliance and leave for approximately 5 minutes.
2.Switch appliance back on and ES control will re-set.
3.Ensure that the appliance is functioning correctly. If the ES
control operates again,the appliance should be checked bya
competent electrician.
The heater carries a 'Do Not Cover' label to warn the user that ifthe
appliance is covered, there is a riskofoverheating.
CAUTION:
In order to avoid a hazard due to inadvertent resetting of the thermal
cutout, thisappliancemust NOT be supplied through an external timer.
If your heater does not work:
•Check that power is available to the heater. The neon indicator on
front of the heater should be illuminated.
•Checkthat the thermal cut-out has not operated. Ifthe cut-outhas
operated followthe re-set instructionsabove.
•Do not attemptto repair the heater.
Care
The heater is bestwiped down with a damp cloth. Do notuse any
abrasivecleaners. Always disconnect theheaterfrom the mainspower
before cleaning the heater. When cleaning the heater:
•Do NOTuse any abrasive cleaners
•Do NOTtouch the heater with wethands,or in any way bring
water into contact with the heater.

8LC075TI, LC125TI, LC150TI, LC200TI
SKOPE CONSORT Convection Panel Heaters
Specifications
SKOPE Industries Limited reserve the right to alter specifications without notice.
Contact Addresses
Dimensions
Model: LC075 LC125TI LC150TI LC200TI
Height: 430mm 430mm 430mm 430mm
Width: 442mm 614mm 680mm 852mm
Depth: 93mm(includes rear fixing bracket)
Weight: 3.7 kg 4.9kg 5.4 kg 6.5 kg
Electrical
Wattage: 675-750 W 1125-1250W 1350-1500 W 1800-2000 W
Supply: 230-240 Volts a.c. 50 Hz.
Wiring: 1.8mflexible cord and plug. This appliance MUST be Earthed.
Ingress Protection Rating: IPX4
