Skylark FPV User manual

Skylark FPV http://www.SkylarkFPV.com
Skylark FPV 433 UHF Long Range
User Manual
1. Specification
A. Transmitter voltage：10V-16.8V Current: <500mA
B. Receiver voltage:4V-8.4V Current:<50mA
2. RC Transmitter
Please always mount the antenna before power on the device
on
Transmitter LED:
LED2 Status
Solid The receiver cannot detect any
PPM signal, please check the
PPM cable.
Off Normal mode
Quick Blink Binding mode

Skylark FPV http://www.SkylarkFPV.com
Transmitter buzzer
Buzzer Status
Beep Fail safe setting
Keep beep System exception
3. RC receiver
LED Indication
LED Status
Off Receiving signals
Slow Blink No signal reception
Quick Blink Binding mode
Solid Failsafe mode
4. Binding
Press transmitter [SET] button, then power on, the LED will quick blinking, it
into binding mode
Power on receiver, then press receiver [SET] button 3 seconds, receiver
binding is successful

Skylark FPV http://www.SkylarkFPV.com
5. Failsafe setting
Turn on the transmitter,
Keep the remote control in failsafe position
Press transmitter [SET] button 3 seconds,
Wait for the transmitter's voice of beep, it will send the failsafe data
If the receiver get the data, its LED will blink several times, the setting finish
