SkyLine Lazy Susans CB33 User manual

Assembly Instrucons
These assembly instrucons are only applicable for
all base reach Lazy Susans ONLY:
Item No: CB33 and CB36
General Instrucons:
Carefully read the instrucons before starng the in-
stallaon.
During assembly, please follow all generally accepted
safety procedures.

Assembly Instrucons
Prior to assembly, please make sure you have (1) Face Frame box,
(1) Carcass box, which will have all the parts in the quanes men-
oned below. If you are missing any part, please stop and nofy your
sales team member.
The following is the list of all items contained in this box:
Required Tools
Screwdriver
Adjustable Wrench
Measuring Tape
Pencil
Level
Silicone
Item Descripon Qty
AFace Frame 1
BFace Frame 1
B-1Le Side Panel 1
B-2Right Side Panel 1
B-3Right Rear Panel 1
B-4Le Rear Panel 1
CBoom w/
turntable 1
EBack Panel 1
FShelf w/turntable 1
GLong ToeKick 1
G-1Short Toe Kick 1
JHardware Box 2
MDoor 2

Instrucons
1. Assembling the Door set, put two doors set on a
at surface and align them from the screw marks.
2. Put face frame (a) down on a at so working sur-
face. (Figure 1)
3. Insert the le panel (B) into the grooves of face frame (A)
on the mangec latch side. Align the plasc half part of the
cam lock connectors. Make sure it ts and lock connectors
with screwdriver by turning the screw located on the cam
lock connector to the right 180 degrees (see Figure 2) Stand
up side panel up right at this me.
F
4

Instrucons

Maintenance
For daily cleaning, use a dry cloth with a so liquid cleanser.
Never use abrasive cleaners containing acetone, chlorine or strong bleach.
Also, do not use tools such as scrapers, metallic brushes, and other products
that can scratch or tarnish surfaces.
Under no circumstances should you use a chrome cleaner or chrome-plated
or brass trim, hinges, handles, sockets, etc.
Good venlaon is essenal to maintain the quality and appearance of the
cabinets. .
