Skymsen Fleetwood HEG-G3 User manual

UG0068 - May/2014
Instruction Manual
Panini Sandwich Grill
Model
HEG-G3
Office
Phone: [phone]
Fax: [phone]
www.skyfood.us[email protected] -
TOLL FREE 1-800-503-7534

01
HEG-G3 is made of stainless steel.Adjustable temperature control supplies heat
to both upper and bottom plate. Both features quick heating, easy operation and easy
cleaning.Adjustableupperplate,itissuitablefordifferentfoodthickness.
A.Specifications:
B.Note:
1. Beforeoperation,pleasecheck“thesafetynotes”ofthismanual.
2. Make sure unit is installed on a flat surface and stable to avoid oil from flowing to one
side.
3. Youcanadjusttheupperplatebymovingtheregulatoronthesideofthebottomplate.
C.TransportationandStorage:
During transportation, it should be careful accommodated to prevent heavy
vibration.Thepackagecannotbekeptintheopen-airforlongtime.Itshouldbestorageina
ventilated and non-corrosive facility. If it is necessary to put it in open air for long time, a
waterprooftentorcovershouldbeprovided.Itcannotbeputupside-down.
D.Operation:
1. Turn on the power and switch in the front. The red light will turn ON and the
griddlewillstarttoheatup.
2. Turnthe thermostatclockwise andsetthe desired temperature,thegreen lightwill
turnON,theupperandbottomplateswillstartheatingup.
MODEL HEG-G3
Voltage (V) 110
Power (kW) 1.8
Frequency (Hz) 60
Temperature Controlling (°F) 122-572
Unit Size (inches) 14x13x9

3. When the plates reach the set temperature, the thermostat will cut off the power
automatically, the plates stop heating and the green light is off. When the temperature is
lower than the setting, the electric circuit switches on, the plates are heating again, the
greenlightison.Thiscyclekeeptheplatesinthesettingtemperaturerange.
4. Moving the handle of upper plate, you can adjust the relative position of upper and
bottomplate.
E.ElectricDiagram:
K---Switch BT---Thermostat
HL1---Powerlight R1---BottomHeatingElements
HL2---HeatingIndicationLamp R2---UpperElements
F.Safetynotes:
1. The operation voltage should be the same as the power supply. The power voltage
differencecannotbebeyond10%.
2. Thegriddleshouldbeputonaflatandstablelocationwithgoodairfacilities.
3. Youshouldinstallpowerswitch,fuseandbreaker(model:DZ12l-60G/1N,theleakage
breakingcurrentis15mA,thenormalcurrentis7.5mA).
4. Otherobjectscannotbeputaroundtheswitch.
5. Beforeoperationyoushouldchecktheconversion.
02

03
General Safety Practices
The following safety instructions are addressed to both the operator of the
machine as well as the person in charge of maintenance.
The machine has to be delivered to the operator in perfect conditions of use by
the Distributor to the user. The user shall operate the machine only after being well
acquainted with the safety procedures described in the present manual. READ THIS
MANUAL WITH ATTENTION.
Basic Operation Practices
Dangerous parts
Some parts of the electric devices are connected to high voltage points.
These parts when touched may cause severe electrical shocks or even be fatal.
Never touch commands such as buttons, switches and knobs with wet hands, wet
clothes and/or shoes. By not following these instructions operator could be exposed to
severe electrical shocks or even to a fatal situation.
Warnings
The operator has to be well familiar with the position of ON/OFF Switch to make
sure the Switch is easy to be reached when necessary. Before any kind of maintenance,
physically remove plug from the socket.
Provide space for a comfortable operation thus avoiding accidents.
Water or oil spilled on the floor will turn it slippery and dangerous. Make sure the floor is
clean and dry.
Before giving any manual command (switch, buttons, turn keys or lever) be sure
the command is the correct one. Check this manual for further details if necessary.
Never use a manual command (switch, buttons, lever) unadvisedly.
If any work is to be made by two or more persons, coordination signs will have to be given
for each operation step. Every step of the operation shall be taken only if the sign has
been made and responded.
Advices
In case of power shortage, immediately turn the machine OFF.
Use recommended or equivalent lubricants, oils or greases.
Avoid mechanical shocks as they may cause failures or malfunction.
Avoid penetration of water, dirt or dust into mechanical or electrical components
of the machine.
DO NOT modify original characteristics of the machine.
DO NOT remove, tear off or maculate any labels stuck on the machine. If any
label has been removed or is no longer legible, contact your nearest dealer for
replacement.
IMPORTANT
If any item from the GENERAL SAFETY NOTIONS section is not applicable to
your product, please disregard it.
This product will be replaced or repaired under warranty, for a period of (1) year,
beginning from the date of purchase by the original purchaser/user (“End User”), or
eighteen (18) months from the date of shipment from SKYFOOD’s warehouse,
whichever expires first.
Accessories will be replaced or repaired under warranty, for a period of (30) days,
beginning from the date of purchase by the original purchaser/user (“End User”), or
eighteen (18) months from the date of shipment from SKYFOOD’s warehouse, whichever
expires first.
This warranty shall not take effect until a properly completed and executed WARRANTY
REGISTRATION form has been received by SKYFOOD EQUIPMENT, LLC, within thirty
(30) days from the date of purchase. The WARRANTY REGISTRATION is available either
in the Instruction Manual of every Product or at SKYFOOD’s website www.skyfood.us. The
End User must fill out the WARRANTY REGISTRATION form and send it to SKYFOOD
according to the instructions posted on the referred website. Failure to do so will VOID
the warranty.
No extended warranties for third party products. There are no other express
warranties or conditions other than the one offered by each manufacturer for
products sold by SKYFOOD, not under the FLEETWOOD by SKYMSEN and
SKYMSEN brand.
For questions or assistance, do not return the product or accessories to the store, please
call Toll Free 1-800-503-7534, or visit the Customer Service section at www.skyfood.us.
For faster service please have the items name, serial number, and proof of purchase for
the operator to assist you.
SKYFOOD reserves the right to change the terms of its limited warranty at any time
without any prior notice. It also reserves the right to change the design and
specifications of its equipment or any related documentation at any time. The end
user is not entitled to upgrades or refunds resultingfrom these changes.
Updates
These Terms and Conditions were last updated on January 14th, 2014.

04
SAFETY PROCEDURES AND NOTES BEFORE SWITCHING ON
IMPORTANT
Carefully read ALL INSTRUCTIONS of this manual before turning the machine ON.
Be sure to be familiar with the instructions and that you have well understood all
information contained in this manual. If you have any question contact your
supervisor or your nearest Dealer.
DangerAn electric cable or electric wire with damaged jacket or bad insulation could
cause electrical shocks as well as electrical leak. Before use, check conditions of all
wires and cables.
Advices
Be sure ALL INSTRUCTIONS in this manual have been thoroughly understood.
Every function and operational procedure have to be very clear to the operator.
Contact your nearest Dealer for further questions.
Any manual command (switch, button or lever) shall be given only after being
sure it is the correct one.
Precautions
The electric cable has to be compatible with the power required by the machine.
Cables touching the floor or close to the machine need to be protected against short
circuits.
AFTER THE WORK ENDS
Cares Always clean the machine, to do the cleaning SWITCH IT OFF,AND TAKE OUT
THE PLUG FROM THE ELECTRICITY SUPPLY SOCKET .
Never clean the machine BEFORE IT IS COMPLETELY STOPED.
Fit all the machine components in their due places, before switching it on again.
MAINTENANCE
Dangers
Any maintenance is dangerous if made with the machine switched on.
SWITCH IT OFFAND TAKE OUT THE PLUG FROM THE SOCKET, DURING ALL
THE MAINTENANCE OPERATION.
IMPORTANT
In any emergency situation, always take the plug out of its socket.
ADVICES
Ele tical o mec a i al maintenan e shall b ad y quali ied erso s.c r r h n c c e m eb f p n
T e pe son in charge o t e main e an e p roma ces sh ll c eck t e ma hine wr s
h r f h t n c efr n a h h c o k
u de TO AL SA ET NDITIONS.
nrT FY CO
SKYFOOD EQUIPMENT LLC - SERVICE
For questions or assistance, call SKYFOOD EQUIPMENT Toll Free: 1-800-503-7534, or
visit the Customer Service section at www.skyfood.us.
