Skymsen FLEETWOOD RG-5M User manual

Office
Phone: [phone]
Fax: [phone]
Warehouse
Phone: [phone]
Fax: [phone]
www.skyfood.us[email protected] -
TOLL FREE 1-800-503-7534
UG0074 - August /2011
Instructions Manual
Hot Gog Roller Grill
Models
RG-5M / RG-9M

RG SERIES OF HOT DOG WARMER
Our Respective User:
Many thanks for you to bought our products, we surely would provide the perfect service
after sold, and we will be taken the good quality & good credit as our fine tradition for you.
. Synopsis:
RG series of hot dog warmer is the new product which is absorbs foreign top skill to
open up. It uses the international popular design, high quality of stainless steel body, very
beautiful and luxurious appearance. It was used the Germany electrical equipment parts, thrifty
and safety. And it’s very easy to clean as we paint ed stainless steel roller. Be provided with
warmer function and easy control. And the machine is complete function, good quality,
suitable for supermarket, bar, western-style restaurant, hotel etc.
. Operation:
Before use, check the power supply corresponds to the required as this machine and the
switch & insurance fuse is it suit with the machine requirement. It should be put on the floor
with dependable. Strictly prohibit placing the combustibles around the stove. Should keep the
good ventilate environment to avoid heating, to let the machine running longer.
Control step:
1. Place the machine stable, turn the switch to “OFF” placement, and thermostat go to
zero one.
2. Put the hot dog intestine on the framing.
3. Put through the power supply, turn to “ON”, then the indication light is working, just
adjust to the right temperature, and then the greenlight is on, the thermal pipe start to

go warmer. When the temperature is to the enactment one, the thermostat would cut
down the power supply, and then the green light will be off and stop to working. When
the temperature was down, the thermostat put through the power supply with
automotive to guarantee the temperature is on the set up scope. (remark: Model#
RG-11 and RG-11X have two thermostat knobs, the left one is control six pipes in
front, the right one is control five pipes in back)
4. When the hot dog intestine is ok, you can eat it after take out by chopsticks; avoid
using metal one to take out.
5. If you want to stop the machine, just turn to “OFF” placement that is ok.
. Technical Specification:
. Circuit Diagram:
RG-5 RG-9 RG-9X
RG-7 RG-7X RG-7L RG-11 RG-11X
HL?Indication light C?capacitor SA?Boat style switch with light
EH?Heating pipe M?Motor ST1~2?Non-sect thermostat part
RG-5M
Voltage................................. 110 V
Power Rating........................ 0.15 kW
Height................................... 6 3/4 ”
Width.................................... 17 1/4 ”
Depth.................................... 11 3/16 ”
Net Weight............................ 16.5 lb
Shipping Weight................... 17.6 lb
No. of Rollers....................... 5
RG-9M
Voltage................................. 110 V
Power Rating........................ 0.27 kW
Height................................... 6 3/4 ”
Width.................................... 21 5/8 ”
Depth.................................... 17 1/8 ”
Net Weight............................ 26.4 lb
Shipping Weight................... 27.5 lb
No. of Rollers....................... 9

.Maintenance:
After use for each time, please clean it with softy dry fabric, pleae use middle washing
tank to clean if necessary, avoid using sharp metal, and strictly prohibit cleaning with water.
. Notes:
When you use this machine, do not touch the electrical heating floor to avoid scald.
You should take out the plug or switch when machi ne was stop, it’s avoid the accident to
happen. All safeguard maintain work should be in process after shut down power supply. If
machine appear hitch, do not dismantle by yourself,please send to our agent or sales supplier
for repair.

General Safety Practices
The following safety instructions are addressed to both the operator of the
machine as well as the person in charge of maintenance.
The machine has to be delivered to the operator in perfect conditions of use by
the Distributor to the user. The user shall operate the machine only after being well
acquainted with the safety procedures described in the present manual. READ THIS
MANUAL WITH ATTENTION.
Basic Operation Practices
Dangerous parts
Some parts of the electric devices are connected to high voltage points.
These parts when touched may cause severe electrical shocks or even be fatal.
Never touch commands such as buttons, switches and knobs with wet hands, wet
clothes and/or shoes. By not following these instructions operator could be exposed to
severe electrical shocks or even to a fatal situation.
Warnings
The operator has to be well familiar with the position of ON/OFF Switch to make
sure the Switch is easy to be reached when necessary. Before any kind of maintenance,
physically remove plug from the socket.
Provide space for a comfortable operation thus avoiding accidents.
Water or oil spilled on the floor will turn it slippery and dangerous. Make sure the floor is
clean and dry.
Before giving any manual command (switch, buttons, turn keys or lever) be sure
the command is the correct one. Check this manual for further details if necessary.
Never use a manual command (switch, buttons, lever) unadvisedly.
If any work is to be made by two or more persons, coordination signs will have to be given
for each operation step. Every step of the operation shall be taken only if the sign has
been made and responded.
Advices
In case of power shortage, immediately turn the machine OFF.
Use recommended or equivalent lubricants, oils or greases.
Avoid mechanical shocks as they may cause failures or malfunction.
Avoid penetration of water, dirt or dust into mechanical or electrical components
of the machine.
DO NOT modify original characteristics of the machine.
DO NOT remove, tear off or maculate any labels stuck on the machine. If any
label has been removed or is no longer legible, contact your nearest dealer for
replacement.
IMPORTANT
If any item from the GENERAL SAFETY NOTIONS section is not applicable to
your product, please disregard it.

SAFETY PROCEDURES AND NOTES BEFORE SWITCHING ON
IMPORTANT
Carefully read ALL INSTRUCTIONS of this manual before turning the machine ON.
Be sure to be familiar with the instructions and that you have well understood all
information contained in this manual. If you have any question contact your
supervisor or your nearest Dealer.
Danger
An electric cable or electric wire with damaged jacket or bad insulation could
cause electrical shocks as well as electrical leak. Before use, check conditions of all
wires and cables.
Advices
Be sure ALL INSTRUCTIONS in this manual have been thoroughly understood.
Every function and operational procedure have to be very clear to the operator.
Contact your nearest Dealer for further questions.
Any manual command (switch, button or lever) shall be given only after being
sure it is the correct one.
Precautions
The electric cable has to be compatible with the power required by the machine.
Cables touching the floor or close to the machine need to be protected against short
circuits.
AFTER THE WORK ENDS
Cares
Always clean the machine, to do the cleaning SWITCH IT OFF, AND TAKE OUT
THE PLUG FROM THE ELECTRICITY SUPPLY SOCKET .
Never clean the machine BEFORE IT IS COMPLETELY STOPED.
Fit all the machine components in their due places, before switching it on again.
MAINTENANCE
Dangers
Any maintenance is dangerous if made with the machine switched on.
SWITCH IT OFF AND TAKE OUT THE PLUG FROM THE SOCKET, DURING ALL
THE MAINTENANCE OPERATION.
IMPORTANT
In any emergency situation, always take the plug out of its socket.
ADVICES
lect ical or mechani a ma nt nance s all be m de y qua ified persons.
E r c l i e h ab l
T e p rson in charge f hma ntenance per o m nces h ll check h ma hin wo ks
h e o tei f r a s a t e c e r
u d r TOT L SAFE Y CO DITION .
n e A T N S

SKYFOOD EQUIPMENT LLC - SERVICE
For questions o r assistance, call SKYFOOD EQUIP MENT Toll Free : 1-800-503-7534, or
visit the Customer Service section at www.skyfood.us.
SKYFOOD’S LIMITED WARRANTY
Un less otherwise specified,new FLEETWOOD by SKYMSEN and SKYMSEN products,
excluding accessories, sold by SKYFOOD EQUIPMENT, LLC. (“SKYFOOD”), for use only
in the continen tal United States (collectively, “Products” or singularly, “Product”), are
warran ted to be free from defects in materials and workmanship for a period of one (1)
yea r from the date of purchase by the original purchaser/user (“End User”), or eighteen
(18) months from the date of shipment from SKYFOOD’s warehouse, whichever expires
first. Several new products and accessories may be warranted for a period other tha n one
(1) year whil e others may be subject to travel li mitations, as specified on the products
Instruction Manual. Proof of purcha se must be presented; if not this warra nty will be
VOID. No warranty is given or imp lie d to a subsequent transferee or any other third party.
Thi s warranty is expressly conditional upon SKYFOOD being notified of any defects in
materials or workmanship with in five (5) days of its occurrence, wi thin the warranted time
period. If a notice of a claim under this warranty is timel y made by the End User,
SKYFO OD or a SKYFOOD’s designated service company (“Service Company”), will rep air
or replace the Product, at SKYFOOD’s discretion, subject to the a dditional conditions
hereinafter described.
Thi s warranty shall not apply if damage occurs from improper installation or maintenance
performed b y an unauthorized service company (“Service Company”), wrong voltage, nor
to the extent that Products or parts have been used other than in conformance with
operating and maintenance instructions, subjected to misuse or a buse or dama ged by
accident, acts of God, abnormal use, stress or any other matter unrelate d to SKYFOOD,
and beyond its reasonable control. This w arranty does NOT cover s ervic e labor and
tra ve l to perform adjustments on products and/or accessories. In addition to wear and
tear of certain items, such as, but not limited to; glass parts, blades, stones, ch opp er
cutting knives, plates, slicing knives, cutting disc, gaskets, oil changes, sealing tape, heat
seal wires, worm gears, self-lubricating bushings, carbon brushes for electric motors, a nd
other parts exp endable by nature and that need to be replaced frequently. Electrical
components are subject to na tural wear and tear, and are NOT covered by this
warranty. THIS WARRANTY EXCLUDES ALL ORAL, STATUTORY, EXPRESS OR
IMPLIED WARRANTIES WHICH MAY BE APPLICABLE TO SKYFOOD, INCLUDING,
BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY AND
FITNESS FOR PARTICULAR PURPOSE. Under no circumstances shall SKYFOOD be
liable for loss of use, revenue o r profit or for incidental or consequential dama ges.
SKYFO OD shall un der no circumstances be liable for any loss, damage, concealed
damage, expense or d elay of goods for any reason when said goods are in th e custod y,
possession or con trol of third parties selected by SKYFOOD to forward, e nter, clear,
transport, or render other services with respect to such goods. The sole and e xclusive
remedy for breach of any warranty is limited to the remedies provided in the paragra ph
above.
All products held at non-comme rcial facilities or domiciles, mu st be taken or shipped,
shipping charges prepaid, either to SKYFOOD's facility or a SKYFOOD's designated
service company ("Service Company"). Products held at commercial facilities and weighing
This product will be replaced or repaired under warrant y, for a period of (1) year,
beginning from the date of purchase by the original purchaser/user (“End User”), or
eighteen (18) months from the date of shipment from SKYFOOD’s warehouse,
whichever expires first.
Accessories wil l be re placed o r repaired under warranty, for a period of (30) days,
beginning from the date of purchase by th e original purchaser/user (“End User”), or
eighteen (18) months from the date of shipment from SKYFOOD’s wa rehouse, whichever
expire s first.
This warranty shall not take effect until a properly completed and executed WARRANTY
REGISTRATION form has been received by SKYFOOD EQUIPMENT, LLC, within thirty
(30) days from the date of purch ase. The WARRANTY REGISTRATION is available either
in the Instruction Manual of every Product or at SKYFOOD’s website www.skyfood .us. The
End User must fill out the WARRANTY REGISTRATION form and send it to SK YFOOD
according to the instructions posted on the referred website. Failure to do so will VOID
the warranty.
No extended warranties for third party products. There are no other express
warranties or conditions othe r than the one offered by each manufacturer for
products sold by SKYFOOD, not under the FLEETWOOD by SKYMSEN and
SKY MSEN brand.
For questions or assistance, do not return the p roduct or accessories to the store, please
call Toll Free 1-800-503-7534, or visit the Customer Service section at www.skyfood.us.
For faster service please have the items name , serial number, and proof of purchase for
the operator to assist you.
SKY FOOD reserve s the right to change the term s of its limited warranty at any time
without any prior notice. It also reserves the right to change the design and
specifications of its equipment or any related documentation at any time. The e nd
user is not entitled to upgrades or refunds resulting from these changes.
Updates
These Terms and Conditions were last updated on January 14th, 2014.
