Skyrc TX58200 User manual

Red
7-18V Input
Ground Input
Black
Yellow
Video Input
Ground Output Green
5V Output
to Camera Orange
Microphone
SMA Connector
SkyRC S-WAVE's TX58200 FPV video transmitter (Tx) is used for sending video signals from a camera
mounted inside quadcopter to a 5.8GHz receiver (Rx) on the ground. The medium 200mW transmission
power means more pilots can fly together without overpowering each other on close frequencies.
TX58200 use single button, LEDs interface to select and display band/frequency. Five bands with a total
of 40 frequencies in the 5.8GHz spectrum can be selected by user. It also comes a clean pre-wired
harness. The Tx includes a 5V output to power FPV cameras and an on-board microphone to transmit
audio to your receiver.
Red
Black
Yellow
Green
Orange
ToBattery
ToCamera
Input Power Connection
Connect the red and black wire to the battery. Make sure
polarities match! Do NOT exceed the acceptable input
voltage range of 7.4 - 18 volts, which can be achieved
with a 2S-4S lithium-polymer(LiPo) battery.
Camera Connection
Connect the yellow, green and orange wire to the camera’s video signal output.
Yellow wire to video signal output
Green wire to ground
Orange wire to power input
INSTRUCTIONMANUAL
TX58200 SK-600108-01
INTRODUCTION
CONNECT TO BATTERY AND CAMERA
Aluminum
Heat Sink
BAND/
CHANNEL
Button
BAND
LED Display
A,B,E,F,R
CHANNEL
LED Display
1,2,3,4,5,6,7,8

Manufacturedby
SKYRCTECHNOLOGYCO.,LTD.
www.skyrc.com
5.740GHz 5.760GHz 5.780GHz 5.800GHz
5.820GHz 5.840GHz 5.860GHz 5.880GHz
5.725GHz 5.745GHz 5.765GHz 5.785GHz
5.805GHz 5.825GHz 5.845GHz 5.865GHz
5.733GHz 5.752GHz 5.771GHz 5.790GHz
5.809GHz 5.828GHz 5.847GHz 5.866GHz
5.705GHz 5.685GHz 5.665GHz 5.645GHz
5.885GHz 5.905GHz 5.925GHz 5.945GHz
BAND A BAND B
BAND E BAND F
RoHS
40 channels: Covers 5 Bands
Transmitter frequency: 5645-5945GHz
Power output: 200mW
Operating Voltage: 7-18V
Operating Temperature: -10 +50 C
Video Input Impedance: 75 Ohm
Antenna Connector: SMA Female Connector
One button and LEDs for frequency selection
method is easy and intuitive.
Frequency Selection: Single push to change frequency,
push and hold for 2 seconds to change band.
BAND
CHANNEL
SELECT THE BAND/CHANNEL
SPECIFICATION
FPV REGULATORY NOTICE
Use and operation of this type of product in the USA and many other countries may require a license and some
countries may forbid its use entirely. In the USA, you need a “HAM” amateur radio license. Use of this product
without having a HAM license is forbidden. It is your responsibility to ensure that the use of this product meets
the requirements imposed by your government’s rules and regulations for RF devices.
7504-0804-01
Video Format: NTSC/PAL
Audio: Includes on board microphone
Provides 5V power output for FPV cameras
Transmitting distance > 300m (open area)
SMA Antenna connector
Dimensions: 32.8x22x11.8mm (not including SMA adapter)
Weight: 11.5g (without antenna)
5.658GHz 5.695GHz 5.732GHz 5.769GHz
5.806GHz 5.843GHz 5.880GHz 5.917GHz
BAND R
