Skytech TM/R-1 User manual

REV 04/03
Page 1 of 4
TM/R-1
INSTALLATION AND OPERATING INSTRUCTIONS
INTRODUCTION
SKYTECH’S wireless remote wall mount timer system was developed to provide a safe, reliable and user-friendly wireless remote wall mount
timer for gas heating appliances. Its battery operation allows the system to operate independently of household current. The system operates
on radio frequencies with non-directional signals. The SYSTEMS operating range is approximately 20 feet. The system operates on one of
255 security codes programmed at the factory.
COMPONENT
THE SKYTECH TM/R-1 MUST BE INSTALLED EXACTLY
AS OUTLINED IN THESE INSTRUCTIONS
COMPLETELY BEFORE ATTEMPTING INSTALLATION.
FOLLOW INSTRUCTIONS CAREFULLY DURING
INSTALLATION. ANY MODIFICATION OF THE
SKYTECH TM/R-1 OR ANY OF ITS COMPONENTS
WILL VOID THE WARRANTY AND MAY POSE A FIRE
HAZARD.
WALL MOUNT TIMMER
The wall timer operates on a (2) 3V button cell batteries (included) made specifically for
remote controls and electronic lighters. Before using the wall timer, install the two (2) 3V
button cell batteries. Follow instructions below.
The wall timer has a 30 minute, 60 minute, 120 minute, and a OFF position Upon initial
use, there may be a delay of five seconds before the remote receiver will respond to the
wall timer.
TO INSTALL BATTERIES
1. Remove face from backing plate (Attached with (2) screws as shown to the right)
then locate the (2) holders for the 3V button cell batteries.
2. Slide the button cell batteries into the battery holders. (Make sure that the batteries
are installed with the (+) plus side facing up).
3. After the batteries are installed replace the face plate and the (2) screws.
TO REMOVE THE BATTERIES
1. Remove face from backing plate (Attached with (2) screws as shown at the right) then
locate the (2) holders for the 3V button cell batteries.
2. Insert a small screwdriver into the slot above the button cell battery and push the
battery out (Slots shown to the right).
3. After the batteries are installed replace the face plate and the (2) screws.
30
60
120
OFF
Insert Object
and Push
Battery Down
+
Plus
Side
+
Plus
Side
120 MIN
60 MIN
30 MIN
OFF
30 MIN
60 MIN
120 MIN
OFF
+
Plus
Side
+
Plus
Side
TOP
TRANSMITTER
REMOTE RECEIVER
SLIDE
BUTTONS
REMOTE
ON
OFF
SLIDE-ON COVERPLATE
R
E
M
O
T
E
ON
OFF
2 ea. 12V (A23) Transmitter
battery(included in
transmitter)
4 ea.
WALL-MOUNT COVERPLATE HARDWARE
(2) 3V Button Cell Transmitter
batteries (included in
transmitter)
AA BATTERIES
3V
3V
30 MIN
60 MIN
120 MIN
OFF
WIRING KIT
www.FireplaceRemoteControls.com
1.888.977.6849

REV 04/03
Page 2 of 4
TOP
Requires 4-AA 1.5V
alkaline batteries
(not included)
Battery cover slides on/off
Slide
Switch
ON
REMOTE
OFF
WALL
Plastic Switch Box
Remote Receiver
Cover Plate
Receiver
Slide
Button
TOP
R
E
M
O
T
E
ON
OFF
WALL MOUNTING THE TIMER
1. Remove face from backing plate and locate the (2) two holes that mount
the plate to the wall.
2. Locate the (2) two mounting holes and mark the holes on the wall.
3. Use the (2) two dry wall anchors and screws ( that are supplied) to mount
the base plate to the wall as shown.
4. Thermostat can also be mounted onto an existing (Plastic) electrical box.
5. Base plate should be mounted level on the wall for best operation.
REMOTE RECEIVER
IMPORTANT: THE REMOTE RECEIVER SHOULD BE POSITIONED WHERE AMBIENT
TEMPERATURES DO NOT EXCEED 130 DEGREE F.
The remote receiver (right) operates on four 1.5V AA- size batteries (Included). It is recommended that ALKALINE
batteries be used for longer battery life and maximum microprocessor performance. IMPORTANT: New or fully
charged batteries are essential to proper operation of the remote receiver.
NOTE: The remote receiver will only respond to the transmitter when the 3-position slide button on the remote
receiver is in the REMOTE (center) position.
The remote receiver houses the microprocessor that responds to commands from the wall timer to control system
operation. The remote receiver has a 3-position slide switch (see figure at right) for selecting the mode of operation:
ON/REMOTE/OFF.
•With the slide switch in the ON position (toward the word TOP), the system will remain on until the slide switch is placed in the OFF or
REMOTE position. This manual switch will turn ON or OFF the system, without the wall timer or good batteries.
•With the slide switch in the REMOTE position (centered), the system will only operate if the remote receiver receives commands from the
wall timer. Upon initial use or after an extended period of no use the ON button must be pressed for up to five seconds.
•With the slide switch in the OFF position (away from the word TOP), the system is off.
•It is suggested that the slide switch be placed in the OFF position if you will be away from your home for an extended period of time. If the
remote receiver is mounted out of children’s reach, placing the slide switch in the OFF position also functions as a safely “lock out” by both
turning the system off and rendering the wall timer inoperative.
INSTALLATION
NOTE: When the remote receiver is installed as a wall switch, It is recommended that it be installed
in a PLASTIC switch box. Remote functions may not operate properly if the remote
receiver is installed in a steel switch box.
Make sure the remote receiver switch is in the OFF position (toward the small hole on the receiver’s face). It is recommended that 18 gauge,
stranded wires Included) be used for wire installation between the terminal wiring block on the millivolt gas valve or electronic ignition system
and the wire terminals on the remote receiver. For best results, use 18-gauge wire that has not been spliced and measuring no longer than 20
ft.
WALL MOUNT
Install four 1.5V AA-size ALKALINE batteries (Included) in the remote receiver. For best performance,
remote receiver batteries should be factory fresh when installed. Very little battery power is required to
operate the remote receiver, but the electronics are turned to operate best when battery output is
greater than 5.3 volts. For new AA batteries should provide an output voltage of 6.0 to 6.2 volts.
Position the remote receiver so the word TOP is facing up, then install the remote receiver into the
plastic switch box using the two long screws provided. Install the cover plate using the two short screws
provided.
Push the remote receiver slide button over the remote receiver slide switch. Reverse installation of the
slide button if it appears off center.
WALL
30
60
120
OFF
www.FireplaceRemoteControls.com
1.888.977.6849

REV 04/03
Page 3 of 4
REMOTE
ON
OFF
Slide-on cover plate
TOP
Remote
Receiver
(bottom view of slide-on cover plate)
Face
Plate
Receiver Slide Button (back)
Wire Terminals
Remote
Receiver
2. Tighten screws
to hold wires
1. Insert wires into
wire terminals
ELECTRONIC MODULE
TR TH
REMOTE
RECEIVER
neutral wire
24VAC
hot wire
120VAC
110/24VAC
Transformer
TERMINAL BLOCK
ON MILLIVOLT
GAS VALVES
TH
TP TP TH
THERMOPILE/
PILOT LIGHT
REMOTE
RECEIVER
HEARTH MOUNT
The remote receiver can be placed on the fireplace hearth or under the fireplace, behind the control
Access panel.
Position where the ambient temperature does not exceed 130 degrees F. With the battery compartment
on the bottom, install the slide-on cover and receiver slide button. Reverse installation of the slide
button if it appears off center.
PROTECTION FROM EXTREME HEAT IS VERY IMPORTANT. Like any piece of electronic
equipment, the remote receiver should be kept away from temperatures exceeding 130 degrees F.
Battery life is also significantly shortened if batteries are exposed to high temperatures.
WIRING INSTRUCTIONS
WARNING
DO NOT CONNECT REMOTE RECEIVER DIRECTLY TO 110-120 VAC POWER. THIS WILL BURN OUT THE
REMOTE RECEIVER AND THE ELECTRONIC MODULE. CONSULT GAS APPLIANCE MANUFACTURER’S
INSTRUCTIONS AND WIRING SCHEMATICS FOR PROPER PLACEMENT OF ALL WIRES. ALL
ELECTRONIC MODULES ARE TO BE WIRED TO MANUFACTURER’S SPECIFICATIONS
THE DIAGRAMS THAT FOLLOW ARE FOR ILLUSTRATION PURPOSES ONLY. FOLLOW INSTRUCTIONS
FROM MANUFACTURER OF GAS VALVE AND/OR ELECTRONIC MODULE FOR CORRECT WIRING
PROCEDURES. IMPROPER INSTALLATION OF ELECTRIC COMPONENTS CAN CAUSE DAMAGE TO
ELETRONIC MODULE. GAS VALVE, AND REMOTE RECEIVER.
A qualified electrician or a gas technician who is familiar with the gas appliance and gas valves that will be operated by
this remote should install this remote control system. Incorrect wiring connections WILL cause damage to the gas
valve or electronic module operating the gas appliance and may also damage the remote receiver. Attach the two 18
gauge wires provided to the receiver as shown.
WIRING MILLIVOLT VALVES
Installer must connect two 18 gauge wires from the remote receiver to the TH and TH/TP terminals on
the millivolt gas valve. (It does not matter which receiver wires are connected to the designated
terminals listed above.)
Operation of the remote receiver is similar to a wall switch in that both turn the gas valve on and off.
The remote receiver’s input signals come from the ON/OFF buttons on the transmitter.
WIRING ELECTRONIC SPARK IGNITIONS
Connect the neutral wire from the 24VAC transformer to the TR (transformer) terminal on the
ELECTRONIC MODULE. Connect the hot wire from the 24VAC transformer to either of the wire
terminals on the remote receiver. Connect another wire (included) between the other receiver wire
terminal and the TH (thermostat) terminal on the ELECTRONIC MODULE.
www.FireplaceRemoteControls.com
1.888.977.6849

REV 04/03
Page 4 of 4
BATTERY LIFE
Life expectancy of alkaline batteries in the SKYTECH TM/R-1 should be at least 12 months. Replace all batteries annually. When the wall
timer no longer operates the receiver. Or the remote receiver does not function at all; the batteries should be checked. It is important that the
remote receiver batteries are fully charged, providing a combined output voltage of at least 5.3 volts. The length of the wire between the
remote receiver and the gas valve directly affects the operating performance of the remote system. The longer the wire, the more battery
power is required to deliver signals between the remote receiver and the gas valve. The wall timer should operate with as little as 4.0 volts
battery power, Measured at the (2) 3 volt button cell batteries.
TROUBLE SHOOTING
If you encounter problems with your fireplace system, the problem may be with the fireplace itself or it could be with the SKYTECH wall timer
system. Review the fireplace manufacturer’s operation manual to make sure all connections are properly made. Then check the operation of
the SKYTECH system in the following manner:
•Make sure the batteries are correctly installed in the RECEIVER. One reversed battery will keep receiver from operating properly.
•Check batteries in WALL THERMOSTAT to make sure contacts are touching (+) and (-) ends of button cell batteries.
•Keep RECEIVER from temperatures exceeding 130 degrees F. Battery life shortened when ambient temperatures are above 115
degrees F.
•If RECEIVER is installed in tightly enclosed metal surround, the operating distance will be shortened. Reposition RECEIVER into “free air”
space.
FREQUENCY (DISTANCE) ADJUSTMENT PROCEDURE
Due to the location of the receiver in the appliance. The receiver may be subjected to hot and cold conditions this may cause the frequency to
change. Follow instructions below to make the adjustment: Check the battery level, If low, replace all batteries.
1. Remote face plate of the timer from the base plate and locate the adjustment hole.
2. Using a small screwdriver, (eyeglass screwdriver works best) turn the adjustment screw
clock wise, no more than 1degree –2 degrees. Just a slight movement of this screw should
improve the operating distance. If turning clockwise does not fix the problem, return screw
to original position and turn 1 degree- 2 degrees counter-clockwise. This procedure is like
turning your radio. Too much adjustment will cause complete loss of frequency match
between the transmitter and receiver. You should not have to turn the adjustment screw
more than 5 degrees, 1/8 turn, in either direction to improve operating distance.
3. Replace the face of the timer to the base plate.
SPECIFICATIONS
Batteries: Transmitter (2) 3V Button Cell Batteries
Batteries: Remote Receiver 6V-4 ea AA 1.5V ALKALINE FCC ID No’s: TRANSMITTER -K9LTN-R-1; RECEIVER: K9L2001R
Operating Frequency: 303.875MHz Canadian ISC No.’s: TRANSMITTER –2439A-TM-R-1; RECEIVER- 2439-101-521A
WARRANTY
All warranty information is listed on the warranty sheet packed with this product. If you did not receive
this warranty sheet, please contact Skytech Systems, Inc. at the following:
9230 Conservation Way, Fort Wayne, IN 46809
[phone] or [phone]
FOR TECHNICAL SERVICE CALL: U.S. INQUIRIES CANADIAN INQUIRIES
888/672-8929 or 877/472-3923
260/459-1703
Website: skytechsystem.com
MANUFACTURED EXCLUSIVELY FOR SKYTECH II, INC
FCC REQUIREMENTS
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY
UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S
AUTHORITY TO OPERATE THE EQUIPMENT
