Black Box POWER MATE SWI070A User manual

1
Hooks up to existing
phone line—no need
for additional line.
Provides On/Off or
Pulse-Power-Off
remote or manual
control, up to 1 A.
Extension port
connects with phone,
fax, modem, or other
telephone device for
ring-through operation.
Programmable dual-
level security.
T
he Power Mate allows you to
remotely control the AC power
to an attached device via any
tone-dial (DTMF) phone. It plu s
ri ht into an existin phone line,
so there’s no need to invest in an
additional or special line. Plus it
includes an extension port so you
can still plu in a telephone
device (phone, modem, or fax) for
use on the same line.
A recessed, three-position
slide switch on the Power Mate
unit allows for local or remote
power control. Set it to On or Off
to keep the attached device on or
off with no power control from the
phone line. Calls will o directly to
the extension phone device, just
as if the Power Mate were not
there. In the Auto position, phone-
line control is enabled and the
power status stays in the previous
switch-position mode (either On
or Off) until chan ed remotely.
Turn on, turn off, or restart
any device—from a telephone anywhere.
KeyFeatures
POWERMATE
Remote Power Control
When the Power Mate is set
for remote power control, you can
control the power from any
touchtone phone. You decide the
number of rin s before the Power
Mate picks up an incomin call,
the security level, and the method
of passin a call on to the
extension.
Power Mate offers four
different call-answer modes. In all
modes, the unit will answer and
listen for a power-control code.
When a code is received, the unit
will respond with the AC power
status and allow power-control
commands to be entered. When
you’re throu h enterin
commands, the Power Mate will
either rin the extension device or
disconnect the call.
Normal Answer Mode
Power Mate answers the call
and sends a “rin back” si nal (so
it sounds like the phone is still
rin in ), waitin between rin s for
the command control code. If no
tones are received after two
rin backs, the unit will either rin
the extension port or disconnect
the call accordin to the security
level settin . This mode is recom-
mended if voice or fax calls are
re ularly received on the in-
comin line and you don’t want
callers to know that a control
device is present.
Answer-and-Prompt Mode
Upon answerin , Power Mate
sends three short beeps to
prompt you to enter the command
control code. After a six-second
pause, if no code is received,
Power Mate will either rin the
extension port or disconnect the
call, dependin on the security
settin . Use this mode for a more
secure line or if you want a
specific cue when control codes
should be entered.
Black Box Corporation • 1000 Park Drive • Lawrence, PA 15055-1018 • Tech Support: 724-746-5500 • www.blackbox.com • e-mail: [email protected]
© 2005. All ri hts reserved.
Black Box Corporation.
6/10/2005 #22622

2
Approvals: FCC re istered
(complies with Part 68 and
Part 15 Class B)
Power: Source: 120 VAC, 60 Hz;
Switchin : 10 A maximum
Size: 2.25"H x 4.5"W x 8.25"D
(5.7 x 11.4 x 21 cm)
Weight: 2 lb. (0.9 k )
Specifications
Ordering Information
I EM CODE
Power Mate...............................................................SWI070A
Answer-and-Quiet Mode
After answerin , Power Mate
waits 10 seconds in quiet for a
control-code entry. If none is
received, the unit either rin s the
extension port or disconnects,
dependin on the security level.
Answer-and-Quiet Mode is
su ested if you want secure
power control and the shortest
time delay before the extension
is run or if you want to use your
modem’s wait-for-quiet answer
command.
Answer-and-Dial one Mode
Power Mate answers a call
and responds with 4 seconds of
dial tone followed by 6 seconds
of silence. If no control code is
entered durin the silence, the
unit either rin s the extension port
or disconnects, dependin upon
the security settin . This mode is
ood for automated access and
when you want to use your
modem’s wait-for-second-dial-
tone command.
Power Control
In any answer mode, Power
Mate waits durin the quiet part
of the sequence for either a
security code or “1” to be
entered, promptin it to respond
with the power status (one beep
for Off, two beeps for On). You can
then choose to chan e or reset
the power, to rin the extension
port, or to end the call.
To chan e the power settin ,
enter “#.” The Power Mate
switches from On to Off or vice
versa. The unit then responds
with the new status.
For Power Reset, enter “*.”
The unit will pulse the power for a
user-set interval (5 to 45 seconds).
The Power Mate reports the
power status at the start of the
pulse, then a ain after the preset
amount of time.
At any time after you enter the
control/ security code, you can
access the extension port by
enterin “0”. After this is done,
the Power Mate accepts no more
power-control commands but
continues to monitor the call. It
han s up the line upon call
completion.
Power Mate can be set to
automatically switch power to
Off after a user-preset delay (5 to
90 seconds) upon call completion.
This option is useful, for example,
for switchin a PC on before and
off after you use its modem on the
Power Mate’s extension port.
Your PC stays secure—it’s shut
down unless someone who
knows how to use the Power
Mate calls to access it. If power
is already set to Off when a call
is terminated, then this feature
is disabled.
Security Settings
Power Mate includes three
user-settable security levels:
Disabled, for power control only,
or for both power-control and
extension-port-rin in functions.
For the second and third options,
you set a one- to six-di it security
code that will be required when
callin to perform remote-control
operations.
The power-only security level
allows all callers unrestricted line
access but requires entry of the
security code for power control.
When security is set for power
and extension-port functions, a
security code must be entered by
all callers in order to use either
the Power Mate or the telephone
device attached to its extension
port.
Incorrect security-code
entries are answered with a low
error tone and a pause for a
second attempt. If the second
attempt is incorrect, Power Mate
either rin s the extension-port
device or disconnects the call,
dependin on the security-level
settin .
WithPowerMate,youcanmaintainpowercontrol
overthephone,fromanylocation.
Ext.
Line
AC-Powered
Device
AC Source
Dial Line
Power
Mate
