Skywell 5T Setup guide

1
SKYWELL 5T
Quick Start User Guide
Atmospheric Water Generator
5T INFORMATION AVAILABLE AT SKYWELL.COM
User Manual
Quick Start User Guide
Service Manual
Service Videos
Parts Catalog
Warranty Procedures
Skywell App Guide
When using electrical appliances, basic safety precautions should be followed to
reduce the risk of fire, electric shock and injury to persons or property.
If the Skywell 5T is without power for more than 4 consecutive hours:
DO NOT drink the water.
Contact your dealer technician to fully clean the Skywell 5T per the Sanitize the
Skywell section in the Skywell 5T Service Manual.

2
DISPENSE WATER
Dispense Cold Water
After water generation, it may take up to 90 minutes for the water to reach its
maximum cold temperature of 37° Fahrenheit (2.7°Celsius). During this time, the
compressor may run continuously. Cold water available for dispense will be
aligned with overall water generation, which is influenced by the ambient
conditions.
1. Place your cup on the center of the driptray.
2. Press the blue circle button to the right of the touch screen to dispense cold
water.
3. Press the blue circle button for the duration of the dispense until the desired fill
level isobtained
Dispense Hot Water
After water generation, the Skywell is able to heat the water up to 208°
Fahrenheit (97.7°Celsius) within 15-20 minutes. Hot water available for dispense
will be aligned with overall water generation, which is influenced by the
ambient conditions.
1. Place your cup on the center of the driptray.
2. Press and release the top red unlock button (Child Safety Lock) on the left of
the touchscreen. You have approximately 10 seconds to begin hot water
dispense before the red unlock button will need to be pressedagain.
3. Press the bottom red circle button (below the red unlock button) to dispense
hot water. Use with caution.
4. Press the red circle button for the duration of the dispense until the desired fill
level is obtained.
5. Never allow children to dispense hot water without proper and direct adult
supervision.
Child Safety Lock
Hot Dispense Button Cold Dispense Button

3
Additional Pages
Create HydrationProfile
Eco Quiz
Skywell Contact Information
THE SKYWELL APP
More details regarding the Skywell App can be found in the Skywell App Guide at
www.skywell.com.
Date & Time
Custom Logo
(optional)
Current Water
Level
Quiet Mode
Settings
Current Hot Water
Temperature
16.9 oz
bottles saved
Current Cold Water
Temperature
Track
Hydration
Contact Info
Tap once to enter
Service Mode
Tap once to switch
between Celsius
and Fahrenheit

4
CREATE PERSONAL HYDRATION PROFILE
On the Dashboard page
of the Skywell App, tap
the arrow on the right
side
On the Hydration Profile
page, tap the + button to
create your profile and
track hydration
Enter your first name
and last name initial in
the fields on the page
Optional Profile Features:
º Avatars
- Select an avatarbytapping onthe
penciliconatthetopofthepage
- Browsethrough Skywell’savataroptions
bytappingon the“AvatarTypes” dropdownmenuon thetop rightof
thepageandbyusingtherightandleftarrows
º Daily Hydration Goals
- Set daily hydrationgoal by swiping the bottombar tothe right.
º PIN Code
- To have your HydrationProfileprotectedwitha unique PIN numberso it is only
accessible by you, tap the “ON” button under “ENABLE PIN”. Note: you will be
promptedtocreatea 4-digitPIN codeonce you haveselectedallof your other
desiredprofilefeaturesandtapthe“OK”buttononthebottomofthepage.
ADDING WATER DISPENSED DATA TO HYDRATION PROFILE
After you’ve dispensed
your water, a page
displayingwater
dispense data will
appear
Tap on the “Add to
Profile”buttononthe
bottom of the page Select your profile
from theHydration
Profiles page
The dispensed water
data is automatically
added to your
Hydration Profile
