Sleipner SRHV240 User manual

SLEIPNER MOTOR AS
P.O. Box 519
N-1612 Fredrikstad
Norway
www.sleipnergroup.com
DOCUMENT ID:
REVISION:
DATE:
LANGUAGE:
Installation Guide
For Hydraulic Retractable Thruster Models
SRHV240, SRHV320
EN
I M
2933
9
2023

22933 92023
-
SH 240 & SH 320
The installer must read this document to ensure necessary familiarity with the product before installation.
Instructions in this document cannot be guaranteed to comply with all international and national regulations. It is the responsibility of the
installer to follow all applicable international and national regulations when installing Sleipner products.
The recommendations given in this document are guidelines ONLY, and Sleipner strongly recommends that advice is obtained from a person
familiar with the particular vessel and applicable regulations.
This document contains general installation instructions intended to support experienced installers. If you are not skilled in this type of work,
please contact professional installers for assistance.
If required by local regulation, electrical work must be done by a licensed professional.
Appropriate health and safety procedures must be followed during installation.
Faulty installation of Sleipner products will render all warranties given by Sleipner Motor AS.
Ensure appropriate access to Sleipner products during installation planning for service, inspection and component replacement.
MC_0038
Responsibility of the Installer
MC_0425
For thruster systems
• Do not install the thruster in a position where you need to cut a stiffener/ stringer/ support that may jeopardise the hull integrity without checking
with the boat builder this can be done safely.
• Paint the gear leg and propellers with anti-fouling. (NB: Do not paint the anodes, sealing, rubber fi ttings or propeller shafts)
• There is only room for a thin coat of primer and two layers of anti-fouling between the tunnel and the props.
• Never run the thruster out of water without load. Operated at no load, the motor will reach extremely high speed, damaging the system.
Failure to follow the considerations and precautions can cause serious injury, damage and will render all
warranties given by Sleipner Motor as VOID. MC_0411
When installing an S-Link™ system connect ONLY original Sleipner S-Link™ products or other authorized control equipment directly to the S-Link™ bus.
Connecting non-authorized third-party equipment, it must always be connected through a Sleipner supplied interface product.
Any attempt to directly control or connect into the S-Link™ control system without a designated and approved interface will render all warranties and
responsibilities of all of the connected Sleipner products. If you are interfacing the S-Link™ bus by agreement with Sleipner through a designated
Sleipner supplied interface, you are still required to install at least one original Sleipner control panel to enable efcient troubleshooting if necessary.
MC_0105
MC_0474
For retract thrusters
• Stern mounted retract thrusters must not be installed to conflict with propulsion propellers or its water trail. (NB: consult a naval architect for
an exact position.)
• Paint inside the retract housing with anti-fouling. (NB: Do not paint the drive shaft.)
Sleipner Motor AS
P.O. Box 519, Arne Svendsensgt. 6-8
N-1612 Fredrikstad, Norway
MC_0020
Contents
Installation Manual
Responsibility of the Installer .................................................................................................................................................................... 3
General Installation Considerations and Precautions Guidelines ............................................................................................................ 3
Product Measurements ............................................................................................................................................................................ 4
Product Specications................................................................................................................................................................................ 5
Positioning of the tunnel / thruster ............................................................................................................................................................ 6
Tunnel Length ............................................................................................................................................................................................. 7
Tunnel Installation in Sailboats.................................................................................................................................................................. 8
Water Deflection......................................................................................................................................................................................... 9
Tunnel Ends ............................................................................................................................................................................................. 10
Tunnel Installation............................................................................................................................................................................ 11 - 12
Stern Tunnel Installation......................................................................................................................................................................... 13
Gear Leg & Motor Bracket Installation.................................................................................................................................................... 14
Propeller Installation............................................................................................................................................................................... 15
Motor Installation .................................................................................................................................................................................... 16
Electrical Installation .............................................................................................................................................................................. 17
Product Lug Connection Conguration .................................................................................................................................................. 17
Electrical Reference Guide....................................................................................................................................................................... 18
Manual Main Switch Wiring Diagram 12V Thruster ................................................................................................................................ 19
Automatic Main Switch Wiring Diagram 12V Thruster ........................................................................................................................... 20
Control Panel Installation ....................................................................................................................................................................... 21
Pre-delivery Checklist ........................................................................................................................................................... 22
Service and Support ............................................................................................................................................................... 23
Product Spare Parts and Additional Resources ....................................................................................................................... 23
Warranty Statement ............................................................................................................................................................... 23
Accidental activation of the retract mechanism can cause serious injury due to the high-pressure
force used for closing the hatch. IF operating the hatch during any work/ maintenance around or
inside the retract hatch, USE CAUTION.
MC_0411

3
2933 92023
-
SH 240 & SH 320
MC_0009
If an original Sleipner hydraulic system is NOT installed, please ensure the following:
• Install an oil  lter to keep the oil clean.
• Fit an oil cooler to ensure that the maximum oil temperature is below 75°C. Recommended operation temperature of hydraulic oil is 40-60°C.
• Hydraulic thrusters are supplied with hydraulic motors only.
• The installed hydraulic system is the responsibility of the  tter/ installer and must be within the limitations outlined in this manual to ensure no
damage is caused to the thruster.
• The hydraulic valve must have flow and pressure limits that are either set within or can be adjusted to the limits of the thrusters capability.
• We strongly advise that a shock valve is  tted and set to 10% - 15% above the chosen maximum pressure set in the valve. This will prevent the
system from being damaged if the propellers are blocked for any reason.
• Install a device to ensure the drive direction cannot be suddenly changed, as this can severely damage the gear leg. (NB: Use a electric control
system or a valve that ensures minimum 1 second delay when changing drive direction.)
The installer must read this document to ensure necessary familiarity with the product before installation.
Instructions in this document cannot be guaranteed to comply with all international and national regulations. It is the responsibility of the
installer to follow all applicable international and national regulations when installing Sleipner products.
The recommendations given in this document are guidelines ONLY, and Sleipner strongly recommends that advice is obtained from a person
familiar with the particular vessel and applicable regulations.
This document contains general installation instructions intended to support experienced installers. If you are not skilled in this type of work,
please contact professional installers for assistance.
If required by local regulation, electrical work must be done by a licensed professional.
Appropriate health and safety procedures must be followed during installation.
Faulty installation of Sleipner products will render all warranties given by Sleipner Motor AS.
Ensure appropriate access to Sleipner products during installation planning for service, inspection and component replacement.
MC_0038
Responsibility of the Installer
MC_0425
For thruster systems
• Do not install the thruster in a position where you need to cut a stiffener/ stringer/ support that may jeopardise the hull integrity without checking
with the boat builder this can be done safely.
• Paint the gear leg and propellers with anti-fouling. (NB: Do not paint the anodes, sealing, rubber fi ttings or propeller shafts)
• There is only room for a thin coat of primer and two layers of anti-fouling between the tunnel and the props.
• Never run the thruster out of water without load. Operated at no load, the motor will reach extremely high speed, damaging the system.
Failure to follow the considerations and precautions can cause serious injury, damage and will render all
warranties given by Sleipner Motor as VOID. MC_0411
When installing an S-Link™ system connect ONLY original Sleipner S-Link™ products or other authorized control equipment directly to the S-Link™ bus.
Connecting non-authorized third-party equipment, it must always be connected through a Sleipner supplied interface product.
Any attempt to directly control or connect into the S-Link™ control system without a designated and approved interface will render all warranties and
responsibilities of all of the connected Sleipner products. If you are interfacing the S-Link™ bus by agreement with Sleipner through a designated
Sleipner supplied interface, you are still required to install at least one original Sleipner control panel to enable efcient troubleshooting if necessary.
MC_0105
MC_0474
For retract thrusters
• Stern mounted retract thrusters must not be installed to conflict with propulsion propellers or its water trail. (NB: consult a naval architect for
an exact position.)
• Paint inside the retract housing with anti-fouling. (NB: Do not paint the drive shaft.)
MC_0440
General Installation Consideration and Precaution Guidelines

42933 92023
-
SH 240 & SH 320
MG_0422
W
ID
L
+L
H
MH
RD
RW
MW
WD
MC_0168
Product Measurements
Measurement
code Measurement description mm inch
H Height 390 15.4
L Length 688 27.1
+L Additional Length 42 1.7
W Width 481 18.9
ID Internal Diameter 250 9.80
WD Water Depth 250 9.80
RD Retract Depth 361 14.2
RW Retract Width 347 13.7
MW Mould Width 414 16.3
MH Mould Height 98 3.9
SRH 240

5
2933 92023
-
SH 240 & SH 320
MG_0421
W
RW
MW
H
MH
RD
ID
L
WD
MC_0168
Product Measurements
Measurement
code Measurement description mm inch
H Height 390 15.4
L Length 688 27.1
+L Additional Length 42 1.7
W Width 481 18.9
ID Internal Diameter 250 9.80
WD Water Depth 250 9.80
RD Retract Depth 361 14.2
RW Retract Width 347 13.7
MW Mould Width 414 16.3
MH Mould Height 98 3.9
SRH 240
MC_0364
Product Measurements
Measurement
code Measurement description mm inch
H Height 455 17.9
L Length 843 33.2
W Width 580 22.83
ID Internal Diameter 300 11.8
WD Water Depth 300 11.8
RD Retract Depth 445 17.5
RW Retract Width 415 16.3
MW Mould Width 480 18.9
MH Mould Height 115 4.5
SRH 320

62933 92023
-
SH 240 & SH 320
MC_0169
Product Specifi cations
Product Lubrication Light Duty
Thrust is kg
Heavy Duty
Thrust is kg
Power Output
kW / Hp
Weight
kg / lbs
Maximum
Operation Time
SH240 Sealed - Oil bath from tank EP-90 240 kg / 529 lbs 220 kg / 440 lbs 14.9 kW / 20 hp 13.5 kg / 29.76 lbs
Continuous
SH320 Sealed - Oil bath from tank EP-90 320 kg / 705 lbs 270 kg / 594 lbs 17.16 kW / 23.3 hp 17.16 kg / 37.83 lbs
MC_0169
Flow and Pressure Specifi cations
1) Max. thrust: 182kg
2) Max. thrust: 228kg
60 % 80 % 100 %
Thruster model Motor
type Flow Pressure Flow Pressure Flow Pressure
SH240
U,G,P 8 L/min-Bar 19.1 217 21.4 275 21,4 2751)
USG-PSI 5.05 3147 5.65 3988 5.65 39881)
U,G,P 10 L/min-Bar 23.8 174 27.5 232 30 2752)
USG-PSI 6.29 2523 7.23 3364 7.93 39882)
U,G,P 11 L/min-Bar 26.2 158 30.2 211 33,8 264
USG-PSI 6.9 2291 8.0 3060 8.9 3828
U,G,P 14 L/min-Bar 33.1 124 38.2 166 42.7 207
USG-PSI 8.7 1798 10.1 2407 11.3 3002
U,G,P 16 L/min-Bar 38.1 109 44.0 145 49.2 181
USG-PSI 10.1 1581 11.6 2103 13.0 2625
U,G,P 19 L/min-Bar 45.1 92 52.1 122 58.3 153
USG-PSI 11.9 1334 13.8 1769 15.4 2219
60 % 80 % 100 %
Thruster model Motor
type Flow Pressure Flow Pressure Flow Pressure
SH320
U,G,P 11 L/min-Bar 23.8 249 24.9 274 24.9 2741)
USG-PSI 6.29 3611 6.58 3973 6.58 39731)
U,G,P 14 L/min-Bar 30.1 196 34.7 261 35.6 2742)
USG-PSI 7.95 2842 9.17 3785 9.41 39732)
U,G,P 16 L/min-Bar 34.6 171 39.9 229 43.7 2743)
USG-PSI 9.14 2480 10.54 3321 11.55 39733)
BA 16 L/min-Bar 33.8 172 39.0 230 43.6 287
USG-PSI 8.93 2494 10.30 3335 11.52 4162
U,G,P 19 L/min-Bar 41.0 144 47.3 193 52.9 241
USG-PSI 10.83 2088 12.50 2799 13.98 3495
BA 19 L/min-Bar 40.1 145 46.3 194 51.8 242
USG-PSI 10.59 2103 11.44 2813 13.69 3509
U,G,P 23 L/min-Bar 49.4 121 57 162 63.8 202
USG-PSI 13.05 1755 15.06 2349 16.86 2929
1) Max. thrust: 211kg
2) Max. thrust: 269kg
3) Max. thrust: 307kg
Motor type Port A/B Drain Port
G16 22L, Metric DIN 2353 1/4” BSP
G19 22L, Metric DIN 2353 1/4” BSP
G23 22L, Metric DIN 2353 1/4” BSP
Connection of Hydraulic Hose to Motor
Follow the de ned hose speci cations to connect hydraulic hoses to the motor.
MC_0172
MC_0609
Hull Specifi cations
Use sealants, adhesives or bonding material compatible with the materials of your vessels hull and Sleipner product.

7
2933 92023
-
SH 240 & SH 320
MC_0169
Product Specifi cations
Product Lubrication Light Duty
Thrust is kg
Heavy Duty
Thrust is kg
Power Output
kW / Hp
Weight
kg / lbs
Maximum
Operation Time
SH240 Sealed - Oil bath from tank EP-90 240 kg / 529 lbs 220 kg / 440 lbs 14.9 kW / 20 hp 13.5 kg / 29.76 lbs
Continuous
SH320 Sealed - Oil bath from tank EP-90 320 kg / 705 lbs 270 kg / 594 lbs 17.16 kW / 23.3 hp 17.16 kg / 37.83 lbs
MC_0169
Flow and Pressure Specifi cations
1) Max. thrust: 182kg
2) Max. thrust: 228kg
60 % 80 % 100 %
Thruster model Motor
type Flow Pressure Flow Pressure Flow Pressure
SH240
U,G,P 8 L/min-Bar 19.1 217 21.4 275 21,4 2751)
USG-PSI 5.05 3147 5.65 3988 5.65 39881)
U,G,P 10 L/min-Bar 23.8 174 27.5 232 30 2752)
USG-PSI 6.29 2523 7.23 3364 7.93 39882)
U,G,P 11 L/min-Bar 26.2 158 30.2 211 33,8 264
USG-PSI 6.9 2291 8.0 3060 8.9 3828
U,G,P 14 L/min-Bar 33.1 124 38.2 166 42.7 207
USG-PSI 8.7 1798 10.1 2407 11.3 3002
U,G,P 16 L/min-Bar 38.1 109 44.0 145 49.2 181
USG-PSI 10.1 1581 11.6 2103 13.0 2625
U,G,P 19 L/min-Bar 45.1 92 52.1 122 58.3 153
USG-PSI 11.9 1334 13.8 1769 15.4 2219
60 % 80 % 100 %
Thruster model Motor
type Flow Pressure Flow Pressure Flow Pressure
SH320
U,G,P 11 L/min-Bar 23.8 249 24.9 274 24.9 2741)
USG-PSI 6.29 3611 6.58 3973 6.58 39731)
U,G,P 14 L/min-Bar 30.1 196 34.7 261 35.6 2742)
USG-PSI 7.95 2842 9.17 3785 9.41 39732)
U,G,P 16 L/min-Bar 34.6 171 39.9 229 43.7 2743)
USG-PSI 9.14 2480 10.54 3321 11.55 39733)
BA 16 L/min-Bar 33.8 172 39.0 230 43.6 287
USG-PSI 8.93 2494 10.30 3335 11.52 4162
U,G,P 19 L/min-Bar 41.0 144 47.3 193 52.9 241
USG-PSI 10.83 2088 12.50 2799 13.98 3495
BA 19 L/min-Bar 40.1 145 46.3 194 51.8 242
USG-PSI 10.59 2103 11.44 2813 13.69 3509
U,G,P 23 L/min-Bar 49.4 121 57 162 63.8 202
USG-PSI 13.05 1755 15.06 2349 16.86 2929
1) Max. thrust: 211kg
2) Max. thrust: 269kg
3) Max. thrust: 307kg
Motor type Port A/B Drain Port
G16 22L, Metric DIN 2353 1/4” BSP
G19 22L, Metric DIN 2353 1/4” BSP
G23 22L, Metric DIN 2353 1/4” BSP
Connection of Hydraulic Hose to Motor
Follow the de ned hose speci cations to connect hydraulic hoses to the motor.
MC_0172
MC_0609
Hull Specifi cations
Use sealants, adhesives or bonding material compatible with the materials of your vessels hull and Sleipner product.

82933 92023
-
SH 240 & SH 320
Preparing a Sandwich Hull for Retract Systems MC_0067
For vessels with sandwich hull construction, additional reinforcement of the area around the SRF flange is required.
1. To achieve maximum strength and bonding in the area around the installation of the SRF flange remove the inner laminate and core material to
expose the outer laminate. Remove enough area for a 100mm (minimum) clearance surrounding the SRF flange.
2. Reinforce the area by applying several bonding layers to strengthen the hull for the operation of the retract thruster.
Cross section of a sandwich core hull Inner laminate
Core
Outer laminate
Gel coat
MG_0472
1
2
Area removed to the outer laminate
Minimum 100mm Minimum 100mm
SRF flange SRF flange
Reinforced bonding layers
MG_0121
Retract Thruster
Ensure enough space for the complete retract unit including room for installation of SRF flange and for future service. Allow 100 mm of clear space
around the thruster for moulding of the SRF flange. Ensure that when the thruster is deployed the depth of the propeller exceeds the minimum tunnel
depth defined in below table.
Installing the thruster below the waterline as outlined is important for two reasons:
1. Avoid drawing air from the surface which will reduce performance and increase noise levels.
2. To get as much water pressure as possible to achieve maximum thrust.
100 mm of clear space
around the thruster for
moulding the retract frame.
Stern installation
To avoid conflict between the thruster and propulsion propellers, trim tabs or rudders the stern installation can be offset from the keel center line.
Bow installation
The thruster must be installed in the center line of the keel and as far forward as possible while following the minimum propeller water depth
requirement. The thruster must always be installed so the hatch is opened towards the bow.
Transom
Retract thruster
Thruster moved to
avoid conflict
Thruster moved to
avoid conflict
Bow retract thrusterStern retract thruster
WATERLINE
Positioning of the Retract Thruster
Retract system 80 to 100 185 mm
Retract system 130 to 240 250 mm
Retract system 250 to 300 300 mm
Retract system 650 386 mm
Minimum Tunnel Depth
Hatch opens
towards the bow
Hatch opens towards
the direction of the bow
Retract thruster
WATERLINE

9
2933 92023
-
SH 240 & SH 320
Preparing a Sandwich Hull for Retract Systems MC_0067
For vessels with sandwich hull construction, additional reinforcement of the area around the SRF flange is required.
1. To achieve maximum strength and bonding in the area around the installation of the SRF flange remove the inner laminate and core material to
expose the outer laminate. Remove enough area for a 100mm (minimum) clearance surrounding the SRF flange.
2. Reinforce the area by applying several bonding layers to strengthen the hull for the operation of the retract thruster.
Cross section of a sandwich core hull Inner laminate
Core
Outer laminate
Gel coat
MG_0472
1
2
Area removed to the outer laminate
Minimum 100mm Minimum 100mm
SRF flange SRF flange
Reinforced bonding layers
MG_0121
Retract Thruster
Ensure enough space for the complete retract unit including room for installation of SRF flange and for future service. Allow 100 mm of clear space
around the thruster for moulding of the SRF flange. Ensure that when the thruster is deployed the depth of the propeller exceeds the minimum tunnel
depth defined in below table.
Installing the thruster below the waterline as outlined is important for two reasons:
1. Avoid drawing air from the surface which will reduce performance and increase noise levels.
2. To get as much water pressure as possible to achieve maximum thrust.
100 mm of clear space
around the thruster for
moulding the retract frame.
Stern installation
To avoid conflict between the thruster and propulsion propellers, trim tabs or rudders the stern installation can be offset from the keel center line.
Bow installation
The thruster must be installed in the center line of the keel and as far forward as possible while following the minimum propeller water depth
requirement. The thruster must always be installed so the hatch is opened towards the bow.
Transom
Retract thruster
Thruster moved to
avoid conflict
Thruster moved to
avoid conflict
Bow retract thrusterStern retract thruster
WATERLINE
Positioning of the Retract Thruster
Retract system 80 to 100 185 mm
Retract system 130 to 240 250 mm
Retract system 250 to 300 300 mm
Retract system 650 386 mm
Minimum Tunnel Depth
Hatch opens
towards the bow
Hatch opens towards
the direction of the bow
Retract thruster
WATERLINE

10 2933 92023
-
SH 240 & SH 320
MG_0117
1 2
3
Hull profile to cut
from SRF flange
Ensure SRF flange edge
sits flush on the hull
Ensure SRF
flange is centred
Mark using
internal edge
Bow thrusters must be positioned on
the boat centre line.
Stern thrusters can be positioned off
the centre line.
Ensure to have a minimum
of 100mm space around
the thruster installation to
have service access
Important
The minimum SRF flange height is stated
on the product measurment page (MH)
-Ø185mm = 72mm
-Ø200mm = 97mm
-Ø300mm = 115mm
-Ø386mm = 147.5mm
WARNING
DO NOT cut the SRF flange length edge
For guidance or methods to transfer the
hull profile to the SRF flange for cutting,
consult a naval architect. DO NOT cut
the SRF flange length edge.
Marking and Trimming of SRF Flange
1. Identify the location of the thruster considering space required for installation, operation and future maintenance.
2. Flip the SRF flange upside down and position it at the identi ed installation location. Use the internal edge to mark the hull for cutting the thruster
hatch.
3. The SRF flange must sit so the two side rails run flush with the hull. To do so the SRF flange must be trimmed down to match the hull pro le
curvature. (NB: For guidance or methods to transfer the hull profi le to the SRF flange for cutting, consult a naval architect. DO NOT cut the SRF
flange length edge.)
MC_0068

11
2933 92023
-
SH 240 & SH 320
MG_0117
1 2
3
Hull profile to cut
from SRF flange
Ensure SRF flange edge
sits flush on the hull
Ensure SRF
flange is centred
Mark using
internal edge
Bow thrusters must be positioned on
the boat centre line.
Stern thrusters can be positioned off
the centre line.
Ensure to have a minimum
of 100mm space around
the thruster installation to
have service access
Important
The minimum SRF flange height is stated
on the product measurment page (MH)
-Ø185mm = 72mm
-Ø200mm = 97mm
-Ø300mm = 115mm
-Ø386mm = 147.5mm
WARNING
DO NOT cut the SRF flange length edge
For guidance or methods to transfer the
hull profile to the SRF flange for cutting,
consult a naval architect. DO NOT cut
the SRF flange length edge.
Marking and Trimming of SRF Flange
1. Identify the location of the thruster considering space required for installation, operation and future maintenance.
2. Flip the SRF flange upside down and position it at the identi ed installation location. Use the internal edge to mark the hull for cutting the thruster
hatch.
3. The SRF flange must sit so the two side rails run flush with the hull. To do so the SRF flange must be trimmed down to match the hull pro le
curvature. (NB: For guidance or methods to transfer the hull profi le to the SRF flange for cutting, consult a naval architect. DO NOT cut the SRF
flange length edge.)
MC_0068
Marking and Trimming of SRF Flange
4. Prepare for cutting the hatch door. Drill 4 holes at a 45º angle towards the starboard and port side. (NB: Cutting the hatch from outside the hull
the 4 drill hole from the internal marked corners will aid in determining the hatch profi le from the outside.)
5. The hatch opening must be cut at an angle of 45º on three sides and 30º on the side facing the bow. This ensures that forces from water hitting
the closed hatch is absorbed by the surrounding hull. (NB: Use a suitable cutting tool able to be set to the desired angle.)
MC_0068
MG_0724
4
5
Drill 4 holes in
each corner at 45º
30º
30º
30º
45º
45º
45º
45º
45º
Bow Stern
Starboard Port
Hull
Hull
Important
When cutting use a suitable guide tool
to ensure correct cutting angles.
45º
45º
45º
45º
Starboard Port
Hull 45º
45º
45º
45º

12 2933 92023
-
SH 240 & SH 320
MG_0118
Controller
Controller
SETTINGS
UP
DOWN
FAULT
STATUS
(FUSE) ON
1 2 3 4
Hatch does not close
with pressure
Conflict with hatch
and hull
Apply polyester or resin to corner areas to
temporally hold the retract unit in place Remove red
distance part
From power
supply
+
+-
Hatch closed with
pressure
hatch opens
without conflict
2
3
4
1




Retract thruster
SR/ER - V/ L
Installation Pre-check
Temporarily set up the complete installation to ensure no conflicts during the  nal operation of the thruster.
1. Use epoxy  ller in the 4 corners of the SRF flange and set it over the hatch. Attach the retract housing retract flange with 4 corner screws to hold.
Use polyester or resin to attach the hull hatch to the retract unit. (NB: Ensure correct orientation for the thruster to open the hatch facing the
direction of water flow. Remember attachment is for temporary checking of thruster operation only.)
2. Temporarily connect DC cables (NB: Refer to the label on actuators for correct voltage) to the cables on the terminals on the controller. Set switch
no. 4 on the DIP-switch marked “SETTINGS” to ON. Deploy thruster and remove the red distance part located above the tunnel.
3. Press “DOWN” to extend the tunnel and check the hatch opens fully without touching the hull. If the hatch is obstructed by the hull in the front,
lift the aft end of the SRF flange maintaining the reference height in front - until the hatch clears the hull when opened.
4. Press “UP” to retract the tunnel. Ensure when the hatch is closed extra pressure is on the contact surface between the hatch and the hull only. If
the hatch is not closing with pressure on the contact surfaces the entire SRF flange must be raised.
After all, pre-checks are completed the retract system can be installed.
MC_0068
IMPORTANT
The hatch contact edges and the hull contact edges MUST work as the mechanical end stop. During cruising, slamming forces from the water must
be absorbed by these areas, not the thruster.
Accidental activation of the retract mechanism can cause serious injury due to the high-pressure
force used for moving the hatch. IF operating the hatch during any work/ maintenance around or
inside the retract hatch, USE CAUTION.
MG_0133
Conflict with hatch
and hull
Hull
Hull
Hull
Hull
Hatch closed with
pressure
hatch opens
without conflict
3
12

hatch opens
without conflict
Raise SRF flange
on stern end
Use wedge to prop
the SRF flange to
required height


13
2933 92023
-
SH 240 & SH 320
MG_0118
Controller
Controller
SETTINGS
UP
DOWN
FAULT
STATUS
(FUSE) ON
1 2 3 4
Hatch does not close
with pressure
Conflict with hatch
and hull
Apply polyester or resin to corner areas to
temporally hold the retract unit in place Remove red
distance part
From power
supply
+
+-
Hatch closed with
pressure
hatch opens
without conflict
2
3
4
1




Retract thruster
SR/ER - V/ L
MG_0133
Conflict with hatch
and hull
Hull
Hull
Hull
Hull
Hatch closed with
pressure
hatch opens
without conflict
3
12

hatch opens
without conflict
Raise SRF flange
on stern end
Use wedge to prop
the SRF flange to
required height

Required Modifi cations After Pre-check
To increase the space between the hatch and the hull the entire SRF flange and motor must be raised at the stern end.
1. With the hatch in the open position raise the stern end of the SRF flange and motor until the appropriate clearance is achieved. (NB: continue to
raise the stern height until this is obtained.)
2. Use a wedge to keep the thruster stable.
3. Open and close the hatch to ensure:
- Clearance between the hull and hatch when the thruster is open
- Hatch closes flush with the hull with full contact between hatch and hull.
4. Record the height and keep the wedges in place and secure the position of the SRF flange with epoxy  ller in the corners.
MC_0068
!Please refer to the graphic for special considerations relating to your model !

14 2933 92023
-
SH 240 & SH 320
MG_0119
Apply Epoxy filler or
equivalent for bonding
between hull and SRF flange
Hull
Retract SRF
flange
Layers of fiberglass cloth
Grind in this area, deepest where the
hull and lower unit meets.
Inside and outside
moulding surfaces must be
ground to remove coating/
material to achieve correct
adhesion for moulding.
12
3 4
5
If there are gaps between SRF and hull fill with extra
epoxy filler or equivalent. Grind and smooth the
surfaces after curing time.
SRF Flange Installation
Start the laminating with a strong attachment point in each corner between the hull and the outside of the lower unit. Use epoxy and  breglass cutting
or similar, which laminating material is the boat builders responsibility.
1. Before grinding of hull and SRF flange, precautions must be taken against grinding dust inside the boat. Surfaces to be moulded/ bonded must be
ground to remove coating and material to achieve suf cient adhesion.
2. Apply epoxy  ller or equivalent on bottom edges of SRF flange or on the hull for bonding between connection surfaces. Ensure the  ller is
compatible with hull materials.
3. Place the SRF flange into position ensuring the correct orientation. If there are gaps between SRF and hull,  ll with extra epoxy  ller or
equivalent. Grind and smooth the surfaces after curing time.
4. Laminate the inside and outside of the SRF flange to the hull by applying several layers of  breglass and ensure that the resin and  breglass is
compatible with hull materials.
5. After curing time, smooth all moulded surfaces and apply coating. Apply putty before coating if necessary.
Once the coating has cured the retract housing can be installed.
MC_0068

15
2933 92023
-
SH 240 & SH 320
MG_0119
Apply Epoxy filler or
equivalent for bonding
between hull and SRF flange
Hull
Retract SRF
flange
Layers of fiberglass cloth
Grind in this area, deepest where the
hull and lower unit meets.
Inside and outside
moulding surfaces must be
ground to remove coating/
material to achieve correct
adhesion for moulding.
12
3 4
5
If there are gaps between SRF and hull fill with extra
epoxy filler or equivalent. Grind and smooth the
surfaces after curing time.
MG_0122
Apply MS polymer or
equivalent on flange
surface
Tighten bolts to
4Nm - 2.9lb/ft
Retract thruster
Retract thruster
SRF Flange Installation
Start the laminating with a strong attachment point in each corner between the hull and the outside of the lower unit. Use epoxy and  breglass cutting
or similar, which laminating material is the boat builders responsibility.
1. Before grinding of hull and SRF flange, precautions must be taken against grinding dust inside the boat. Surfaces to be moulded/ bonded must be
ground to remove coating and material to achieve suf cient adhesion.
2. Apply epoxy  ller or equivalent on bottom edges of SRF flange or on the hull for bonding between connection surfaces. Ensure the  ller is
compatible with hull materials.
3. Place the SRF flange into position ensuring the correct orientation. If there are gaps between SRF and hull,  ll with extra epoxy  ller or
equivalent. Grind and smooth the surfaces after curing time.
4. Laminate the inside and outside of the SRF flange to the hull by applying several layers of  breglass and ensure that the resin and  breglass is
compatible with hull materials.
5. After curing time, smooth all moulded surfaces and apply coating. Apply putty before coating if necessary.
Once the coating has cured the retract housing can be installed.
MC_0068
Motor House Installation
1. Apply MS Polymer or equivalent on SRF flange top surface to seal and avoid water leakage. (NB: Ensure that glue is compatible with SRF and
thruster case materials.)
2. Place the upper thruster Housing down on the SRF flange.
3. Insert and fasten bolts. Start with the 4 corner bolts followed by the remaining to required torque.
MC_0068
!Please refer to the graphic for special considerations relating to your model !

16 2933 92023
-
SH 240 & SH 320
MG_0129
1
4 5
6
78
2 3
Pin bolts with sharp
ends to punch mark
the hole pattern to
hatch
Tap/ press to get punch
marks of hole pattern
Drill holes
Countersink all
4 holes
Apply a layer of
aluminium or
duct tape on
hatch opening
edges
Apply filler on
hatch edges Smooth out filler and add more if
needed. After curing time grind and
smoothen the surface
Unscrew and remove hatch to smooth
off excessive material before coating
the hatch.
Apply coating
Tighten bolts
and nuts Glue tunnel rings
to hatch before
tightening bolts
Inside of hatch
Outside of hatch
Ensure to adjust the hatch bolts so
they do NOT conflict the tunnel.
Bolts must be tightened firmly.
Run the tunnel IN with
filler on hatch edges
The hatch contact edges and the hull contact
edges MUST work as the mechanical end stop.
During cruising, slamming forces from the water
must be absorbed by these areas, not the thruster.
Hatch Installation
1. Fit pin bolts to the lower tunnel rods. The ends of the bolts must be sharp to create marks in the hatch. The pin bolts must be at the correct height
so the hatch will  t in its inner position.
2. Place hatch in its inner position, then press or tap with a hammer to create punch marks inside of the hatch.
3. Drill 4 marked holes and countersink the outer hull side. (NB: drill holes vertical to the hatch surface.)
4. Temporary  t the hatch to the tunnel rings. Ensure the bolts do NOT conflict with the propeller tunnel. (NB: Bolts can be cut, depending on hatch
thickness.)
5. Apply a layer of aluminium or duct tape on hatch opening edges on the hull. Apply Epoxy  ller or equivalent to hatch edges to create a perfect
seal connection between hatch and hull.
6. Operate the thruster to “IN” position. Smooth out the  ller and add more if needed. After curing time, grind and smooth the surface.
7. Unscrew and remove hatch to smooth off excessive material before coating the hatch.
8. Apply epoxy glue or similar on to tunnel rings contact surface, so the hatch will be secured properly. Now re-install hatch in its correct position.
Tighten bolts so hatch will  t properly.
9. Apply coating inside and outside of the hatch and on the hull.
MC_0068
!Please refer to the graphic for special considerations relating to your model !

17
2933 92023
-
SH 240 & SH 320
MG_0129
1
4 5
6
78
2 3
Pin bolts with sharp
ends to punch mark
the hole pattern to
hatch
Tap/ press to get punch
marks of hole pattern
Drill holes
Countersink all
4 holes
Apply a layer of
aluminium or
duct tape on
hatch opening
edges
Apply filler on
hatch edges Smooth out filler and add more if
needed. After curing time grind and
smoothen the surface
Unscrew and remove hatch to smooth
off excessive material before coating
the hatch.
Apply coating
Tighten bolts
and nuts Glue tunnel rings
to hatch before
tightening bolts
Inside of hatch
Outside of hatch
Ensure to adjust the hatch bolts so
they do NOT conflict the tunnel.
Bolts must be tightened firmly.
Run the tunnel IN with
filler on hatch edges
The hatch contact edges and the hull contact
edges MUST work as the mechanical end stop.
During cruising, slamming forces from the water
must be absorbed by these areas, not the thruster.
Motor to House Installation
1. Install the motor onto the motor bracket ensuring both the couplings and the drive shafts have locked together. The motor must be installed
with the solenoid facing the control box. (NB: depending on your coupling you may need to wiggle the motor into place. Ensure the connection
couplings are engaging correctly. Ensure the motor cable terminals are accessible for electrical installation later.)
2. Fasten the bolts holding the motor to the motor bracket with the above torque.
3. Check the drive shafts engage by rotating the propeller. It is required the propeller can rotate via hand power. (NB: Rotating the propellers can be
hard because of the gear reduction and the motor.)
4. Apply the gear leg and propeller with anti-fouling designed for propellers. Do not apply to the propeller drive shaft, the anodes or the end of the
gear leg facing the propellers.
(NB: The motor must be covered to avoid dust from fabrication/ maintenance operation entering the motor or the solenoids. After fabrication
maintenance operations have ceased the cover must be removed before operating the thruster.)
MC_0173
!Please refer to the graphic for special considerations relating to your model !
MG_0185
Bolt tightening force (4x):
33 Nm (24 lb/ft)
Install the relevant motor and
other electronics according to
electrical instructions in the
manual
Hatch Installation
1. Fit pin bolts to the lower tunnel rods. The ends of the bolts must be sharp to create marks in the hatch. The pin bolts must be at the correct height
so the hatch will  t in its inner position.
2. Place hatch in its inner position, then press or tap with a hammer to create punch marks inside of the hatch.
3. Drill 4 marked holes and countersink the outer hull side. (NB: drill holes vertical to the hatch surface.)
4. Temporary  t the hatch to the tunnel rings. Ensure the bolts do NOT conflict with the propeller tunnel. (NB: Bolts can be cut, depending on hatch
thickness.)
5. Apply a layer of aluminium or duct tape on hatch opening edges on the hull. Apply Epoxy  ller or equivalent to hatch edges to create a perfect
seal connection between hatch and hull.
6. Operate the thruster to “IN” position. Smooth out the  ller and add more if needed. After curing time, grind and smooth the surface.
7. Unscrew and remove hatch to smooth off excessive material before coating the hatch.
8. Apply epoxy glue or similar on to tunnel rings contact surface, so the hatch will be secured properly. Now re-install hatch in its correct position.
Tighten bolts so hatch will  t properly.
9. Apply coating inside and outside of the hatch and on the hull.
MC_0068
!Please refer to the graphic for special considerations relating to your model !

18 2933 92023
-
SH 240 & SH 320
MG_0186
FWD Drain
Port A
Port B
Motor type Port A/B Drain Port
G16 22L, Metric DIN 2353 1/4” BSP
G19 22L, Metric DIN 2353 1/4” BSP
G23 22L, Metric DIN 2353 1/4” BSP
Connection of Hydraulic Hose to Motor
Follow the de ned hose speci cations to connect hydraulic hoses to the motor.
MC_0172

19
2933 92023
-
SH 240 & SH 320
MG_0186
FWD Drain
Port A
Port B
Oil Tank Installation
1. Install the oil container above the waterline by at least 20% of the distance from the waterline to the centre of the tunnel. This ensures enough
overpressure for the oil in the gear leg.
2. Install the oil tube from the oil container to the feed nipple on the motor bracket. Fasten both the tube clamp screws. (NB: Ensure the oil tube has
no loops and forms an airlock to stop the oil flow. Ensure the oil tube angle is suffi cient to allow oil to flow freely into the gear leg.)
3. Fill the oil container with the same gear oil used in the gear leg. The oil container works as an indicator to ensure oil is in the gear leg at all times.
(NB: Fill and drain the gear leg simultaneously while replacing the oil to ensure the system is never empty.)
MC_0023
!Please refer to the graphic for special considerations relating to your model !
MG_0184
WATERLINE
20% x waterline to tunnel
centre
Oil tank
Pivot shaft
Oil valve
The oil tank is placed higher than the pumps to ensure
enough gravity feed and pressure for feed ports. (NB: The
height of oil levels in the hydraulic tank should be higher
than the connected hydraulic pumps.)
Find a suitable location for the hydraulic tank installation for
future maintenance accessibility. There must be enough
space around the oil tank to change filters, fill oil and inspect
gauges and indicators

20 2933 92023
-
SH 240 & SH 320
MG_0725
The Top wiring diagram is for a single bow or stern thruster system
The top and bottom wiring diagram is for a dual thruster system, for example a bow and stern installation.
Wiring Diagram Hydraulic Retract Thruster
S-Link Backbone cable
Control
panel
S-Link Spur cable
S-Link Spur cable
See S-Link System Description chapter for detailed information on
installation of S-Link Power cable and additional S-Link
components.
S-Link Backbone cable
12V/24V
DC Supply
PHC-3
Fuse 30A
Switch
12V/24V
DC Supply
Fuse 30A
Switch
