Chapter 1
Introduction
Thisdocumentprovidesstep‐by‐stepinstructionsforinstallingtheSLS™MA390C3‐Axis
SpeakerSystem.TheMA390Cwasdevelopedtoreducethetimeandexpenserequired
wheninstallingspeakersinDolbyAtmos®cinemaenvironments.
THISEQUIPMENTMUSTBEINSTALLEDBYLICENSEDANDPROFESSIONAL
INSTALLERS.
1.1 Tools Required.
ToinstalltheMA390C,youneedthefollowingtools:
•M8Allenwrenchformainyokeattachmentpoint(M10bolt)
• Phillipsscrewdriverforbarrierstripspeakerwireinputs
1.2 Spare Parts
YoushouldreplaceanydefectivecomponentswithSLSapprovedparts.Contactthe
factorydirectlyat417‐883‐4549toobtainapprovedreplacementparts.SLSisnot
responsibleforproblemscausedbyusingpartsnotprovidedbySLSfortheSLSsupplied
portionoftherigging.
1.3 MA390C Specifications
FollowingaretheMA390Cgeneralspecifications:*
•Frequencyresponse:60Hzto20kHz
• Sensitivity:1watt@1M:96dB
• Continuouspowerrating:300watts
•MaximumcontinuousratedSPLat1meter:121dB
•ProgramratedSPLat1meter:124dB
• Recommendedamplifierpowerrating:600wattsat8ohms
• Coverageangle:90degreesconical
• Driver:12‐inchlow‐frequencywithcoaxiallymounted1.75‐inchhighfrequency
•Size(includingyokepositionedoverinputplateandyokefasteners):
•Width:21.7inches(551millimeters)
•Height:20inches(508millimeters)
•Depth:16.1inches(410millimeters)
•Netweight:28pounds(12.7kilograms)
*Duetoproductimprovementresearch,SLSAudioreservestherighttomakechangesto
existingproductswithoutnotice.

2SLS™ MA390C Installation Guide
Introduction
1.4 Customer Support
IfyouneedassistanceinstallingtheMA390Corhaveotherquestions,youcancontactusat:
Portal:www.dolbycustomer.com
Email:[email protected]
Region SupportPhone Numbers
Americas +1-415‐645-4900
EMEA +44‐179-384-2130
APAC +86‐105-910-3066
Japan [phone]

SLS™ MA390C Installation Guide 3
Chapter 2
Installing the MA390C
Thischapterisprovidedforlicensedprofessionalinstallers.Thefollowingsectionsinclude
step‐by‐stepinstructionsforinstallingtheSLSMA390C3‐AxisSpeakerSystem.
2.1 Installing the System
FollowingaretheMA390Cinstallationinstructions.
2.1.1 Identifying the MA390C Rigging Parts
ThefollowingpartsareincludedintheMA390Cpackingkit.Usethesepartsalongwith
yourdesiredmountingmethod(typically,all‐threadmountedtostructure).TheMA390C
shipswiththeyokeinstalled,butthespeakerbodyisnotshownforclarity:
1. Two20mmsteelwashers
2. Two20mmneoprenewashers
3. Oneyokewithslotforside‐to‐sideangleadjustments(whileuser‐suppliedcaptive
boltsarestillloose)
Figure 2-1 Rigging Assembly

4SLS™ MA390C Installation Guide
Installing the MA390C
2.1.2 Positioning
TheMA390Cprovide3‐axisaimingadjustmentswhenusingasinglemountpointtothe
structure.Toproperlyaimthespeaker,youneedtoadjusttwoofthethreeaxes.Thetwoaxes
toadjustvariesforwallmountedorceilingmountedspeakers.Forwallmounting,angles
CandDneedadjusting.Foroverheadmounting,anglesCandGneedadjusting.The
Dolby®RoomDesignTool
spreadsheetprovidestherequiredadjustmentangles forboth
overhead and sidewallpositions. TheDolbyAtmosRoomDesignToolisanExcel‐based
toolthatisusedtohelpdesignaroomandplanequipmenttoensurethatthedesignmeets
Dolbyrequirements.Youcandownloadthistoolatwww.dolbycustomer.com.Ifyoudo
nothaveaccess,pleasecontactourteamatCinemaSup[email protected]torequestthetool.
Figure2‐1
TheprovidedyokeattachmenttothespeakerpivotpointislabeledAngle D.Thepartingline
inthespeakerenclosureistheangleindicator.
Figure2‐2
Figure 2-2 Angle D at 0, 45, and 90 Degrees Using Speaker Body Parting Line as Indicator
TheslotintheyokeslidingadjustmentislabeledAngle C.Thefollowingfigureisanexample
ofasinglepointtostructureriggingsetupusedwiththeAngle C yokestickertoindicate
thedesireddegree.Thecenteroftheuser‐providedsuspensionpointisusedasareference
tosettheangle.
Figure2‐3
Figure 2-3 Angle C at 0 and 45 degrees (Up to 70 Degrees is Obtainable)
ThesinglepointattachmenttothestructurepivotpointislabeledAngle G (containedinthe
packingkit).Thefollowingfigureisanexampleofusingasingleriggingpointfor
suspension.Thisprovidedanglestickerneedstobeadheredtoaceilingtileinthecorrect
orientationasmarkedonthesticker(thearrowpointingtoscreendirection).Thesideof
theyokeisusedastheangleindicator.
Figure2‐4
Figure 2-4 Angle G at 0 and 45 Degrees

Dimensions
SLS™ MA390C Installation Guide 5
2.1.3 Connecting Audio
Toconnectaudio,connectyourspeakerwiretotheyokewithoutmakingcontactwiththe
speakerenclosure(tominimizeanybuzzing).Thebarrierstripsaccept16to12gaugewire,
eitherwithspadelugsorbarewire.
2.1.4 Connecting the Safety Cable
Youmustconnectasafetycable(notincluded)asfollows:
1. Usethesafetycabletoindependentlyconnectthespeakertothebuildingstructure.
AnM6eyebolt(notshown)thatisattachedtothespeakerinputplateisprovidedfor
thispurpose.
2. PullthesafetycablesnuglyagainsttheM6eyebolt,andsecurethesafetycabletothe
yokeusingzipties(notprovided)tominimizethepossibilityofbuzzingagainstthe
cabinetortheeyebolt.
2.2 Dimensions
FollowingaretheMA390Csideandfrontviews.
Figure2‐5
Figure 2-5 MA390C Side View and Front View
Side View Front View
(Dimensions in inches and millimeters [in brackets])
[405.6]
13.77
[349.8]
9.71
[246.7]
9.00
[228.6]
15.97
4.77
[121.2]
[550.7]
21.68
[508]
20.00

SLS™ MA390C Installation Guide 7
Appendix A
Environmental Compliance and Regulations
Toxic or Hazardous Substances and Elements Compliance
FollowingistheMA390Cenvironmentalcomplianceinformationfortoxicorhazardous
substancesandelements.
FigureA‐1
Note: Foradditionalenvironmentalinformation,includingtheDolbyDeclarationsof
Conformity,gotohttp://www.dolby.com/us/en/about/environmental-commitment.html.

8SLS™ MA390C Installation Guide
Environmental Compliance and Regulations
EU Environmental Regulations and Compliance
FollowingaretheMA390CEUenvironmentalregulationsandcomplianceinformation.
Waste Electrical and Electronic Equipment (WEEE)
AllDolbyproducts,whichmustberecycledorhandledseparately,aremarked
withthisWEEElabelinaccordancewiththeEUWEEEDirective.
Restriction of Hazardous Substances Directive (RoHS)
AllDolbyproductscomplywiththerequirementsoftheEURoHSDirective.FortheDolby
DeclarationsofConformity,goto
http://www.dolby.com/us/en/about/environmental-commitment.html.
Product End-of-Life Information
ThisproducthasbeendesignedandbuiltbyDolbyLaboratoriestoprovidemanyyearsof
service,andisbackedbyourcommitmenttoprovidehigh‐qualitysupport.Whenthe
producteventuallyreachestheendofitsserviceablelife,itshouldbedisposedofin
accordancewithlocalornationallegislation.Forinformationregardingdisposal,goto
http://www.dolby.com/us/en/about/environmental-commitment.html.
