User Manual
Forevala S20
On-Camera Microphone

Thank you for choosing SmallRig Forevala S20
on-camera microphone!
Equipped with a built-in cardioid microphone and designed with stereo
recording mode, SmallRig Forevala S20 on-camera microphone was
distinguished in recording extremely vivid presence sound! The feast
of sound is right beyond. Hopefully you will be able to use this efficient
tool to record beautiful sounds and save time!
3.5mm TRS
Output
3.5mm TRS
Input
Shock
Mount
Bottom Of
Shock Mount
Mono / Stereo
Button
Quick overview of your S20!
1
43
2
56
Built-in Cardioid
Mic

Instructions
3.5mm TRS output: Connect the recording device like a DSLR camera
to S20 with the TRS camera cable via this jack. Or connect the
smartphone to S20 with TRRS phone cable via this jack. For iPhone 7
or version above, it required the extra lightning to 3.5mm headphone
jack adapter (not included).
Built-in cardioid mic: Distinct in noise, echo reduction, the cardioid
condenser microphone is super in capturing the best sound details.
3.5mm TRS input: Connect the extra microphone like the customized
lavalier microphone enclosed with the S20 via this port for stereo
sound recording purpose.
Bottom of shock mount: With a locking knob, you can fix or quickly
disassemble the shock mount. The shock mount is adaptable to the
cold shoe mount or the tripod with a 1/4” screw thread.
Shock mount: Besides firmly loading S20, the shock mount can also
reduce vibrations and filter noise.
Mono/ stereo button: Toggle the “M” / “S” button to switch to the
“Mono” / “Stereo” mode.
1.Fix the S20 on-camera microphone onto the shock mount.

2.Fix the shock mount onto the cold shoe mount on a DSLR camera or a
camcorder, or the 1/4” screw thread of a tripod.
3.Putting a furry windscreen or a foam windscreen onto S20 can effectively
eliminate wind noise based on recording scene needs.

4.Connect the 3.5mm output jack of S20 with the 3.5mm input jack of
DSLR camera via the 3.5mm TRS cable.
5.For the professional stereo effects, please connect a extra microphone
like the customized lavalier microphone to the S20 and toggling the mode
switch button to “S” mode. In this manner, you can obtain a stereo sound
which is more suitable for interview purpose.

A.When using a DSLR camera or a camcorder for recording, please link
the S20 and the DSLR camera with the 3.5mm TRS cable. If it was going
to install on the cold shoe adapter of a DSLR camera or a camcorder,
please tighten the locking knob until the bottom of the shock mount was
completely fixed to the devices.
B.When you’re using a cell phone or tablet with 3.5mm input jack for
recording, please connect it with a 3.5mm audio cable labelled as “for
phone”.
C.If your mobile phone does not have a 3.5mm microphone input jack,
please use the 3.5mm converter cable provided by the corresponding
mobile phone manufacturer. Connect the 3.5mm dongle cable with the
"for phone" tagged cable first, and then connect the 3.5mm dongle to your
mobile phone.
Operation tips
In the Box
On-camera Microphone
Lavalier Microphone
Patented Suspension Mount
Foam Windscreen
Furry Windscreen
3.5mm Camera Cable
3.5mm Smartphone Cable
Sticker Sets
Carrying Bag
User Manual
× 1
× 1
× 1
× 2
× 1
× 1
× 1
× 1
× 1
× 1

Q1: Is it compatible with different devices?
A1: Yes. S20 is compatible with devices having 3.5mm microphone
input jacks, such as DSLR camera / camcorder/ portable recorder /
Windows or Mac OS PC / mobile phone / laptop.You can opt for
3.5mm TRS camera cable to connect DSLR camera / camcorder/-
portable recorder / Windows or Mac PC. Or you can select 3.5mm
TRRS mobile phone cable to plug into mobile phone/laptop. For
iPhone 7 or version above, it required the 3.5mm to lightning dongle
(not included).
Q2: Does S20 record in stereo or mono? Is it possible for the built-in
microphone on the camera to record simultaneously with S20?
A2: Yes, it can record stereo by the following steps:
1. Plug the external microphone into the 3.5mm microphone input
jack.
2. Toggle the “M” or “S” buttons to “S” (i.e. Stereo mode).
3. Turn on the recording device and record the stereo sound.When S20
was working, the built-in microphone on your camera didn’t allowed
to record in synchrony.
FAQ
Q3: Do you think this better for vlogs, skits, and action video shots overall?
A3: For vlogs, skits, and action video shoots，S20 would be powerful for
interviews or conversations with the dual cardioid microphone feature.
Record in synchrony.
a.Operation and storage conditions: Please keep the tools out of fire
source, especially keep it away from temperature higher than 158°F
(70°C) - or lower than -50°F (-10°C). Be cautious the required working
temperature should between 32 ~ 113°F (0 ~ 45°C). Please keep it in dry,
clean area, free from oil, water, or chemical liquid. Those measures will
help the device maintain longer lifespans, also it will do great help to
keep the dangerous situation far away.
b.The Child can only operate this device with the guidance of adults,
please do not let them operate this device alone.
Warnings

c.FCC statement: This device complies with Part 15B of the FCC rules. Operation is
subject to the following two conditions:
1).This device may not cause harmful interface;
2).This device must accept any interference received, including interference that
may cause undesired operation.
d.CE compliance: This device complies with EN 60065 standard, which means this
device will not do harm to the user or products as following situations:
1.Electric shock 2) High temperature 3) Radiation 4) Explosion from inner 5)
Mechanical Harm 6) Fire Hazard 7) Chemical burns.
e.EU Conformity Statement: This product and - if applicable - the supplied
accessories too are marked with “CE” and comply therefore with the applicable
harmonized European standards listed under the EMC Directive 2014/30 / EU, the
RoHS Directive 2011 / 65/EU and Amendment (EU) 2015 / 863.
f.WEEE Notice: 2012 / 19/EU (WEEE directive): Products marked with this symbol
cannot be disposed of as unsorted municipal waste in the European Union. For
proper recycling, return this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated collection points. For more
information see: www.recyclethis.info
g.ROHS compliance: This product is in compliance with Directive 2011 / 65 / EU of
the European Parliament and of the Council of 8 June 2011 on the restriction of the
use of certain hazardous substances in electrical and electronic equipment.
Specifications
Product Components
Dimensions
Materials
Polar Pattern
Microphone Type
Sensitivity
Frequency Range
SNR
Input Jack
Output Jack
On-Camera Mic
φ20 × 82mm
Aluminum alloy
Cardioid
Condenser
-38dB ± 3dB
50Hz ~ 20kHz
70dB
3.5mm
3.5mm
Lavalier Mic
6.7ft
TPE + PC
Cardioid
Condenser
-42 ± 3dB
50Hz ~ 20kHz
65dB
/
3.5mm

This warranty does not cover:
1. Defect caused by users' violation of the “Warnings” and “Instructions”.
2. The product identification or SN label is removed or defaced in any way.
3. Product damage caused by problems not attributable to the quality of the products such
as improper use of the products.
4. Product damage caused by unauthorized modification, disassembly, repair and other acts.
5. Product damage caused by fires, floods, lightning and other force majeure factors.
Warranty Mode:
• For the products within the scope of warranty, SmallRig will repair or replace them on
the basis of specific failures; the repaired/replaced products/parts are entitled to the
remaining part of the original warranty period.
Contact Information:
• You're advised to contact the online customer service personnel of corresponding
shopping platform and submit a repair service application.
• You may also apply for repair service through SmallRig's service email.
Service Email: [email protected]
For more support information: www.smallrig.com/support
Guarantee Card
ID No.
Item Name
Purchase Date
User Name
Mobile
Address
Receipt
After-sale warranty terms:
1. 7 Days DOA Return Policy: Within 7 days from the date of the package receipt, return or
replacement can be done if the item received is malfunctioning or physical damaged
(not caused by human abused), return shipping cost will be on SmallRig’s charge.
2. SmallRig products are entitled to warranty services as of the date of payment.
•Electronic products: 1-year warranty, 1-year free warranty service.
•Non-electronic products: 2-year warranty, 2-year free warranty service.
Note: In case of any conflict between our warranty period policy and applicable laws and
regulations of the country/region where the products are sold, the latter shall prevail.
Service Warranty
Please keep your original receipt and guarantee card. Be sure the dealer has written on
it the date of purchase and SN of the product. These are required for warranty service.

Add: Rooms 103, 501 and 601, Building 5, Fenghe Industrial Park, Nos. 1301-50
Guanguang Road, Longhua District, Shenzhen, Guangdong, China.
Manufacturer: Shenzhen Leqi Network Technology Co., Ltd.
Consignor: Shenzhen LC Co., Ltd
Add: Rooms 602, Building 5, Fenghe Industrial Park, No. 1301-50 Guanguang Road,
Xinlan Community, Guanlan Street, Longhua District, Shenzhen, Guangdong, China.
ProlinxGlobalLTD
27OldGloucesterStreet London,WC1N3AX,UK
[email protected]
UK
ProlinxGmbH
Brehmstr.56,40239Duesseldorf Germany
[email protected]
EC REP
REP
Made in China
