SMART BRACELET TW7 User manual

Model:TW7 Ver:1.0
20:50
中国 电信4G中国 电信4G
07:00 At Shennan Road
Walk 40min
07:40
Onvehicle 20min
08:00 At middle School
Sedentary 45min
16:00
RUN 30min
17:30
Bicycling 10min
23:00
Sleep 480min
Today
steps Sleep
9860 7"30"
At Futian Road
At Playing Field
At Green Road
At Nanshan Garden
09:45 At middle School
Walk 40min
User manual
Clock Pedometer
Calorie Track Sleep
Quality
reminding
Sports
In-call SM S
Reminding
Remote
waterproof
Ip67
shooting
Phone
Anti-lost
Raise Hand To
Brighten Screen
Detect
Pattern
Smart Wristband
Smart Wristband
Movement all day record
Movement all day record

To know about the wristband
To achieve skillful operation via Three steps
To install Apps and bind wristband
To check movement and exercise track
Alarm setting
Longtime sitting reminding / Drinking water reminding
To check sports and sleep data
To find the phone
2
3
4
6
7
7
5
8
In-call and SMS reminding
Remote shooting
9
10
Details for screen displays
FAQs
14
15
19
Specifications 1
To watch the screen clearly under the sun 11
To quickly lighten the screen
11
Anti-lost reminding
13
Content

short press key
Screen displays
2
USB port for charging
Host
To know about the wristband
Corresponding indicator lights will be on when data of step
-counting, sleep, goal, low battery reminding, clock and alarm
and Bluetooth connection is shown on the screen;
(to) lighten the screen, change the mode and set the wristband;
find more functions by connecting with the smartphone;

1.Check and ensure the wristband
package is complete
Including one wristband, one manual
2.Fully charge the wristband
The charging icon keeping still indicates
that the battery is fully charged
3.Install applications and bind the
wristband
Please turn to page 4 for more information
It takes about 1.5 hours to recharge
2
To achieve skillful operation via Three steps
3
1
Tips

1. Ensure that the smartphone is connected to the mobile network or WLA N and
the wristband is not being charged.
2. Scan QR code to download applications. Go to Google Play Store for Android
phone and App Store for iPhone to search “smartfit mini”or “xv-watch”for
downloading.
3. Click , finish matching and account binding according to screen tips; the
time on the wristband will update automatically in accordance with that on the
smartphone.
Tips
Tips
To install Apps and bind wristband
AP P download
4
Note: when the phone APP and bracelet Bluetooth pairing status,
you need to press the button to light the bracelet screen

· Click to switch to check data of sleep, deep sleep and light sleep.
Click to enter the application, you can:
The wristband can record real-time steps, calories and sleep data; longtime
record can supervise personal activity condition and change; it is your special
expert of health and sports.
· Slide the screen downward to manually synchronize wristband data and
smartphone data, all data is saved on the smartphone.
· Click to switch to check data including steps, distance, burned calorie and
time of exercise.
Tips
Wristband can upload data to the smartphone automatically
·Re-open APP to successfully connect wristband with the smartphone, the
wristband will upload data to the smartphone automatically after one minute.
·When the wristband and the smartphone are connected, if there is no data
uploaded over 3 hours after app goes back to interface from the background,
the wristband will upload the data to the smartphone automatically.
To check sports and sleep data
Tips
Tips
5

1.Click —> 。
2.The map has functions of zoom in and out。
After using the camera, video, record and notes function in APP, auto-matching
and positioning to pictures, videos, records and texts on the way will be done to
conveniently check your travelling departure time and travelling places. It can
witness your travel in a good way. (this function is available after opening GP S).
Your activity route can be found via smartphone app, the best witness of you travel.
Tips
Tips
Movement and exercise track
6

1.Click —> —>Config—>Smart alarm clock。
2.After finishing setting, click 。
1.Click —> —> Config band—>Vibration setting—>Sedentary alert on/off
2.After finishing setting, click 。
Have you got a fat belly that bothers you a lot due to lack of sports for busy work?
The wristband is a great helper to remind you of sports when you are sitting for a
long time.
Drinking alert on/off。
Alarm
Reminding: longtime sitting/drinking water
7

Sometimes you may have no idea where your smartphone is and depressed think
that it plays hide-and-seek with you. However, no matter where it is, the wristband
can help you find it with Bluetooth connection.
1. Under connection status, continuously and quickly touch the button twice, the
smartphone will make a sound after receiving calling from wristband;
2. Short press the key twice quickly, the smartphone will vibrate even it is in silent
mode;
Tips
This function will be available after open it in setting of APP.
1. Click
—> —>Extra setting—> Tap twice to locate device.
2. After finishing setting, click .
Tips
Tips
To find the phone
8

When the smartphone is in silent mode or when you are in a noisy environment,
it’s quite possible to miss a call. Start the in-call reminding function, then you
will no longer miss any call.
1. Click → → Config band →Push notification → phone alert on/off。
2. After finishing setting, click 。
Tips
You can also set reminding for information from APP like SMS and email;
furthermore, “DO N OT Remind” can be also set for a certain time period.
When the wristband vibrates and the icon appears, it means that the
smartphone has an in-call.
When the wristband vibrates and the icon appears, it means that the
smartphone has a SMS.
Tips
Tips
9
In-call reminding

1.Click —> —>
Find a proper supporting point for the phone, the wristband will soon become a
selfie camera, which allows you to take a perfect selfie without shaking.
2 When the smartphone enters camera condition, quickly and continuously touch.
the wristband button twice to take photos, the photos will be saved on the
smartphone.
Tips
If you use the wristband to take photos, APP will conduct auto-matching and
positioning to pictures, through which you can check your travelling departure
time and photos of travelling places, the best witness for your travel. (this
function is available after opening GPS).
The smartphone can be fixed at different places, such as support and branch.
Use your rich imagination to take brilliant and interesting photos!
10
Tips
Tips
Tips
Remote shooting

෎◌ׄ൭ߌ௠ଞ
Several ways to lighten the screen of the wristband:
Press the key for a short time to lighten the screen so as to check time/number of
steps/sleep time…
Hold up your arm with wristband and lightly turn it around to lighten the screen
Tips
The function that hold up an arm to light the screen can be
turned on or off by wristband setting
Setting method: short press the key to lighten the screen---continue to press the
key until this icon appears---after entering the setting, long press the key
to change the setting menu, select this icon to open this function, select
this icon to close this function;
Tips
Tips
Tips
Tips
It’s pleasing to do sports under the sun, and the screen brightness can be adjusted
according to personal preference.
Setting method: short press the key to lighten the screen → touch the button again
to find , then long press the button→ enter the setting menu to find ,
then touch the key to adjust the brightness.
To watch the screen clearly under the sun
To quickly lighten the screen
11

You may leave your smartphone home, or get it lost in the café, so many
unbearable memories. Anti-lost reminding is practically an indispensable function.
Under connection status, the wristband will display and vibrate for reminding
once it gets far away from the smartphone.
Tips
This function can be turned on or off via settings;
Setting method:
Short press the key to lighten the screen → press it again to find , then long
press it → enter the setting and long press the button to switch the menu, select
to open this function, select to close this function.
Tips
Tips
Tips
Tips
Tips
Tips
Tips
Anti-lost reminding
12

It means steps, followed by the steps data
STEP
It means time, followed by the date
:08
１
２
SLEEP It means duration of sleep, followed by relevant data
GOAL
It means steps goal prompt, followed by step number
The wristband is
in the state of charge
the wristband finished
charging and is fully charged
The wristband Bluetooth is search broadcast signal for matching
The wristband is
successfully connected
with the smartphone
The wristband fails to
connect with the smartphone
Details for screen displays
13

It means the brightness of LED screen
It means anti-lost reminding, that the distance between wristband
and smartphone is beyond range or the connection is unavailable
it means longtime sitting
and time for exercises
It means reminding for
drinking water
It means in- call
reminding It means SMS reminding
It means entering
setting menu
It means that the smartphone
is calling for the wristband
It means turning on the
function that hold up an
arm to lighten the screen
It means turning on the
anti-lost function
It means turning off the
function that hold up an
arm to lighten the screen
It means turning off the
anti-lost function
Explanations for
status of indicator
lights
Achieved goals sleep
low battery alarm Bluetooth connected
step-counting
14

FAQs
(1)What type of mobile phones does the wristband support?
A: system (Android 4.3 or above, iOS 7.0 or above), internal storage at least 1G,
Bluetooth 4.0 or above;
(2)What functions does it have if it is not connected with smartphone?
A: If it is not connected with smartphone, the wristband can do step-counting
or record sleep data. If the movement reminding function and alarm function
were set and synchronized before, these two functions remains effective when
using the wristband alone.
(3)How to adjust the wristband time?
A: The wristband time is adjusted automatically via AP P connection; the adjusted
time is synchronized with the smartphone.
15
(4)Why can’t the wristband be searched while binding or connecting?
B: Check if the wristband has bound with other phones, if so, it needs to be
removed for another binding.
C: If the wristband has bound with another phone which is not there at present,
the connection can also be removed via pressing key. Operation method:
after lighten the screen, quickly and continuously press the key for over
ten times to remove the connection.
FAQs
A:when the phone APP and bracelet Bluetooth pairing status, you need to press
the button to light the bracelet screen.

(5) Will the wristband be useless if the smartphone is lost?
A: No, it won’t. Just change a smartphone and download APP to bind the
wristband, but the data on the previous phone gets lost.
(6): Can I lend my wristband to others?
A: Yes, you can. Just do it after removing the current binding. Otherwise,
others cannot connect the wristband.
A: Yes, it will. Click , slide the screen in main interface downward
(7) Is there a switch to turn on or off the wristband?
A: No. It’s not necessary. It will be dormant under low battery. Wake it up by
charging.
(8) Can the wristband answer the call?
A: No. It only allows in-call reminding.
(9) Can I take a shower or help my wife to wash vegetables when wearing the
wristband?
A: Yes, you can. The wristband is IP67 level waterproof, it is ok to contact
water for a short time.
(10) Will the smartphone connect to the wristband automatically when the
Bluetooth is cut off?
(11) How long is the stand-by time?
A: The latest BL E Bluetooth technology is adopted for the wristband, the
power consumption is lower with stand-by time over seven days. 16

(12) How to judge that the wristband is in low battery?
A: Lighten the screen, the yellow indicator light will shine or the battery icon
on the screen will shine for low battery reminding.
(14) Can the wristband be charged via portable power supply?
A: Portable power supply with minimum output current less than 2000mA can
be usefd for charging;
(15) When the smartphone screen becomes black for dormancy, the connection
between wristband and smartphone is cut off, what’s wrong with that?
A: It’s a matter of setting. 1. Click setting → lower power mode management →
select wristband application in protected background application;
B: Click setting →rights management → application, select wristband
application, tick “trust this application”
17
（13）The device does not vibrate now. What's the cause?
A: Check the equipment is insufficient power, when the power is too low, will close the
（16）Device only shows the time, did not show the number of steps and sleep data,
vibration warning, again full of electricity can restore vibration reminder.
what is the reason?
A The first use before the need to bind the device with the mobile APP, ：
device to activate all the display.
B If you only want to use the device alone, you can first bind the device with the APP, ：
and then close the phone side APP can exit the AP P without lifting the binding.

(18) Does all data shown on the screen belong to the current day?
A: Yes. All data will be cleared and reset after 12 a.m.
(19) The data of yesterday was not synchronized, can I still find it today?
A: Yes. The wristband data can be saved for 3 days, after that, it will be
covered by new data. Synchronizing data once a day is suggested;
(20) The smartphone has alarm function, is it necessary for the wristband to
open this function again?
A: The wristband alarm reminds us by vibration, it is quiet and won’t disturb
others.
(21) Why is the screen not lightened after I turned my wrist around?
A: Check if the function that hold up an arm to lighten the screen is turned on;
B: When it is in the state of step-counting, you need to stop and wait for
seconds, then turn your wrist with your palm facing up so as to lighten
the screen in a more effective way;
(22) The step-counting function seems not so accurate.
A: Step-counting will be done when it detects arm swing, small range of swing
is not useful. The frequency which is the same as arm swing will be also
counted as one step;
（17）What if the wristband button has no respond?
A：Smart wristbands may have no power, try recharging them。
18

IP X67
25X16X9mm
18g
65mAh
Model：Tw7 Smartband
App OS: IOS7.1&above,Android4.4&above
function: pattern detect、Track、Clock、Pedometer、Sleep quality、
In-call and SMS reminding、Take photos、Sports reminding
Waterproof:
Display：LE D White
Bluetooth：BL E4.0
Material：Silica gel&PC
Dimension：
Net weight:
Battery Capacity
Charging: US B Port
Charging time: About 1 hours
Specifications
19
