Operation Guide 3242
E-9
About the Backlight
About the Auto Light Switch Function
When the auto light switch function is turned on, the backlight automatically turns on
for two seconds under the conditions described below. Avoid wearing the watch on
the inside of your wrist. Doing so causes the auto light switch to operate when not
needed, which shortens battery life.
Moving the watch to a position that is parallel to the ground and then tilting it
towards you approximately 40 degrees causes the backlight to illuminate.
Parallel to ground 40°
E-8
After you set the time and date, press5. Ato return to the Timekeeping Mode.
E-7
While the seconds digits are selected (flashing), press3. Dto reset the seconds to
00. If you press Dwhile the seconds count is in the range of 30 to 59, the seconds
are reset to 00 and 1 is added to the minutes. If the seconds count is in the range of
00 to 29, the minutes count is unchanged.
While any other digits (beside seconds) are selected (flashing), press4. Dto
increase the number or Bto decrease it. While the 12/24-hour format setting is
selected, press Dor Bto toggle it between 12 and 24.
Except for when adjusting the seconds or setting the 12/24-hour format, holdingx
down a button changes the current selection at high speed.
When the 12-hour format is selected, the indicatorxPappears on the display to
indicate “P.M.” times. There is no indicator for “A.M.” times.
When the 24-hour format is selected, the indicatorx24 appears on the display.
The year can be set in the range of 2000 to 2099.x
The watch’s built-in full automatic calendar makes allowances for different monthx
lengths and leap years. Once you set the date, there should be no reason to
change it except after you have the watch’s battery replaced.
The day of the week is displayed automatically in accordance with the date (year,x
month, and day) settings.
E-6
Timekeeping Mode
To set the time and date
Hold down1. Awhile in the Timekeeping Mode until the
seconds digits flash on the display because they are
selected.
Press2. Cto change the selection in the following
sequence.
Seconds Hour Minutes
CC
C
C
Day Month Year
C
C
C
12/24-Hour Format
Day of week
PM
indicator
Hour : Minutes Seconds
Month – Day
E-5
This watch returns to the Timekeeping Mode whenever you hold down thexCbutton
for one or two seconds. If you ever lose track of what mode you are in or what you
should do next, hold down Cto return to regular timekeeping.
In any mode pressxLto illuminate the display.
CC
C
Stopwatch Mode Alarm Mode Dual Time Mode
E-4
General Guide
PressxCto change from mode to mode.
After you perform an operation in any mode, pressingxCreturns to the Timekeeping
Mode.
If you do not press any button for a few minutes while making settings in any modex
(indicated when settings are flashing), the watch automatically clears the setting screen
(settings stop flashing) and returns to the normal display for the mode you are in.
C
Timekeeping Mode Countdown Alarm
Mode
C
E-3
Procedure Lookup
The following is a handy reference list of all the operational procedures contained in
this manual.
To set the time and date ......................................................................................... E-6
To switch the auto light switch function on and off........................................... E-11
To set the countdown start time .......................................................................... E-14
To use the countdown alarm................................................................................ E-15
To switch auto repeat timing and the progress beeper on and off .................. E-16
To turn the Auto-Start function on and off.......................................................... E-19
To set the Target Time and to turn it on and off................................................. E-20
To set the alarm time............................................................................................. E-22
To turn the daily alarm and hourly time signal on and off ................................ E-23
To test the alarm sound........................................................................................ E-24
To set the Dual Time ............................................................................................. E-25
E-2
Contents
General Guide.......................................................................................................... E-4
Timekeeping Mode .................................................................................................. E-6
About the Backlight................................................................................................. E-9
Countdown Alarm Mode ....................................................................................... E-14
Stopwatch Mode.................................................................................................... E-17
Alarm Mode............................................................................................................ E-22
Dual Time Mode..................................................................................................... E-25
Specifications ........................................................................................................ E-27
E-1
About This Manual
Note that the product illustrations in this manual are intended for reference only,x
and so the actual product may appear somewhat different than depicted by an
illustration.
MA1110-EA

Operation Guide 3242
E-19
About the Auto-Start function
With the Auto-Start function, the watch performs a 5-second countdown. When the
countdown reaches zero, stopwatch operation starts automatically. During the final
three seconds of the countdown, a beeper sounds with each second.
To turn the Auto-Start function on and off
While the display is showing all zeros in the Stopwatch Mode, press Bto toggle it
on and off.
The indicatorxAUTO-ST appears and 05 is shown in the upper display while Auto-
Start is turned on. The AUTO-ST indicator is not shown and the upper part of the
display shows the current time when Auto-Start is turned off.
About the Target Time function
With the Target Time function, an alarm sounds for ten seconds whenever the time
being kept by the stopwatch reaches a target time you have preset.
E-18
(a) Elapsed time measurement
DDDDB
Start Stop Re-start Stop Reset
(b) Split time measurement
DBBDB
Start Split Split release Stop Reset
(c) Split time and two finishes
DBDBB
Start Split
First runner
finishes.
Stop
Second runner
finishes.
Record time of
first runner.
Split release
Record time of
second runner.
Reset
E-17
Stopwatch Mode
The Stopwatch Mode lets you measure elapsed
time, split times, and two finishes. The range of the
stopwatch is 23 hour, 59 minutes, 59.99 seconds. You
can also have an alarm sound when a target time is
reached. The Stopwatch Mode also features an Auto-
Start function.
Current time
Target time on indicator
1/100 Seconds
Seconds
Minutes
Mode
indicator
E-16
To switch auto repeat timing and the progress beeper on and off
Hold down1. Awhile in the Countdown Alarm Mode. The hour digits flash on the
display because they are selected. Press Aagain to move the flashing to the auto
repeat ON/OFF setting.
Press2. Dor Bto toggle auto repeat on ( ) and off.
Press3. Cto move the flashing to the progress beeper ON/OFF setting.
Press4. Dor Bto toggle the progress beeper on ( ) and off.
Press5. Ato return to the Countdown Alarm Mode.
When the end of the countdown is reached while auto repeat is on, the alarmx
sounds, but the countdown restarts from the beginning without stopping. You can
stop the countdown by pressing Dand manually reset to the start time by pressing
B.
If you set a starting time of 10 seconds or less and have Auto Repeat turned on,x
the countdown alarm tone (which normally sounds for 10 seconds) sounds for only
one second.
When the progress beeper is turned on, the watch beeps as the countdown timex
passes the 10, 5, 4, 3, 2, and 1-minute marks, and the 50, 40, 30, 20, 10, 5, 4, 3, 2,
and 1-second marks.
E-15
Press3. Dto increase the selected number or Bto decrease it. Holding down either
button changes the selection at high speed.
PressxDand Bat the same time to clear the starting time to 0:00' 00".
To set the starting value of the countdown time to 24 hours, set 0:00' 00".x
After you set the countdown start time, press4. Atwice to return to the Countdown
Alarm Mode.
To use the countdown alarm
Press1. Dwhile in the Countdown Alarm Mode to start the countdown alarm.
Press2. Dagain to stop the countdown alarm.
You can resume countdown alarm operation by pressingxD.
Stop the countdown alarm and then press3. Bto reset the countdown time to its
starting value.
When the end of the countdown is reached and auto repeat timing is off, thex
alarm sounds for 10 seconds or until you stop the alarm by pressing any button.
Countdown timing stops and the countdown time is automatically reset to its starting
value after the alarm stops.
E-14
Countdown Alarm Mode
The countdown alarm can be set within a range of
1 second to 24 hours. When the countdown reaches
zero, an alarm sounds for 10 seconds or until you press
any button.
To set the countdown start time
Hold down1. Awhile in the Countdown Alarm Mode.
The hours digits flash on the display because they
are selected.
Press2. Cto change the selection in the following
sequence.
CC
Hour Minutes Seconds
C
Current time
Progress beeper on indicator
Auto repeat on indicator
1/10 Seconds
Seconds
Minutes
Mode
indicator
E-13
Warning!
Never try to read your watch when mountain climbing or hiking in areas thatx
are dark or in areas with poor footing. Doing so is dangerous and can result in
serious personal injury.
Never try to read your watch when running where there is the danger ofx
accidents, especially in locations where there might be vehicular or pedestrian
traffic. Doing so is dangerous and can result in serious personal injury.
Never try to read your watch when riding on a bicycle or when operating ax
motorcycle or any other motor vehicle. Doing so is dangerous and can result
in a traffic accident and serious personal injury.
When you are wearing the watch, make sure that its auto light switch functionx
is turned off before riding on a bicycle or operating a motorcycle or any other
motor vehicle.
Sudden and unintended operation of the auto light switch can create a
distraction, which can result in a traffic accident and serious personal injury.
E-12
The auto light switch indicator is shown on the display in all modes while the autox
light switch function is on.
In order to protect against running down the battery, the auto light switch function isx
automatically turned off approximately three hours after you turn it on. Repeat the
above procedure to turn the auto light switch function back on if you want.
PressingxLwhile in the Timekeeping Mode illuminates the display, regardless of
the auto light switch’s on/off setting.
Caution
The backlight of this watch employs an electro-luminescent (EL) light, which loses itsx
illuminating power after very long term use.
Frequent use of the backlight shortens the battery life.x
The watch emits an audible sound whenever the display is illuminated. This isx
because the EL light vibrates slightly when lit. It does not indicate malfunction of
the watch.
E-11
Under certain conditions the backlight may not light until about one second or lessx
after turning the face of the watch towards you. This does not necessarily indicate
malfunction of the backlight.
To switch the auto light switch function on and off
In the Timekeeping Mode, hold down Bfor one or two seconds to turn the auto light
switch function on and off.
Auto light switch indicator
Hold down B.
ON OFF
E-10
The backlight may not illuminate if the face of the watch is more than 15 degreesx
off parallel to the left or right. Make sure that the back of your hand is parallel to the
ground.
Parallel to ground More than 15 degrees
too high
More than 15 degrees
too low
Static electricity or magnetic force can interfere with proper operation of the autox
backlight function. If the auto backlight does not illuminate, try moving the watch
back to the starting position (parallel with the ground) and then tilt it back toward you
again. If this does not work, drop your arm all the way down so it hangs at your side,
and then bring it back up again.

Operation Guide 3242
E-28
Illumination: EL Backlight (electro-luminescent panel)
Battery: One lithium battery (Type: CR1616)
Battery life: 3 years under the following conditions
One 2-second light operation per dayx
One 20-second alarm operation per dayx
E-27
Specifications
Accuracy at normal temperature: ± 30 seconds a month
Timekeeping: Hour, minutes, seconds, pm (P), day of the week, month, day
Time format: 12-hour and 24-hour formats
Calendar system: Full Auto-calendar pre-programmed from the year 2000 to 2099
Countdown Alarm
Measuring unit: 1/10 second
Input range: 1 second to 24 hours
Others: Auto repeat function, Progress beeper function
Stopwatch
Measuring unit: 1/100 second
Measuring capacity: 23 hours 59 minutes, 59.99 seconds
Measuring modes: Elapsed time, split time and two finishes
Others: Target Time Alarm, Auto-Start
Alarm: Daily alarm, hourly time signal
Dual Time
E-26
After you set the time, press4. Ato return to the Dual Time Mode.
In the Dual Time Mode, the seconds count is synchronized with the seconds countx
of the Timekeeping Mode.
In the Dual Time Mode, pressxBto toggle between the 12-hour and 24-hour
formats.
E-25
Dual Time Mode
The Dual Time Mode lets you keep track of the time in
another time zone. You can also select the timekeeping
format (12-hour or 24-hour) separately from the
Timekeeping Mode.
To set the Dual Time
Hold down1. Awhile in the Dual Time Mode. The hour
digits flash on the display because they are selected.
Press2. Cto change the selection in the following
sequence.
Hour Minutes
C
Press3. Dto increase the selected digits and Bto
decrease them. Holding down either button changes the
selection at high speed.
Current time
Minutes
Hour
Mode indicator
E-24
The alarm on indicator (x) and the Hourly Time Signal on indicator ( ) are
shown on the display in all modes while these functions are turned on.
To test the alarm sound
Hold down Bwhile in the Alarm Mode to sound the alarm.
Note that pressingxBalso changes the alarm and the hourly time signal ON/OFF
settings.
E-23
Press3. Dto increase the selected digits and Bto decrease them. Holding down
either button changes the selection at high speed.
The format (12-hour and 24-hour) of the alarm time matches the format you selectx
for regular timekeeping.
When setting the alarm time using the 12-hour format, take care to set the timex
correctly as morning (no indicator) or afternoon (P).
After you set the alarm time, press4. Ato return to the Alarm Mode.
To turn the daily alarm and hourly time signal on and off
Press Bwhile in the Alarm Mode to change the status of the daily alarm and hourly
time signal in the following sequence.
BBB
Both OFF Daily Alarm
Only
Hourly Time
Signal Only
Both ON
B
E-22
Alarm Mode
When the Daily Alarm is switched on, the alarm
sounds for 20 seconds at the preset time each day.
Press any button to stop the alarm after it starts to
sound. When the Hourly Time Signal is on, the watch
beeps every hour on the hour.
To set the alarm time
Hold down1. Auntil the hour digits start to flash on
the display. The hour digits flash because they are
selected.
This operation will switch the Daily Alarm onx
automatically.
Press2. Cto change the selection in the following
sequence.
Hour Minutes
C
Current time
Hourly time signal on indicator
Minutes
Hour
Mode indicator
Alarm on indicator
E-21
Press5. Dor Bto toggle the target time on and off.
Press6. Ato return to the Stopwatch Mode.
Important!
The alarm will not sound if you do not turn on the target time.
PressxA, Cor Lto stop the alarm after it starts to sound.
E-20
To set the Target Time and to turn it on and off
While the display is showing all zeros in the Stopwatch1.
Mode, hold down A, and the hour digit of the target
time starts to flash because it is selected.
Press2. Cto change the selection in the following
sequence.
CC
Hour Minutes Seconds
C
Press3. Dto increase the selected number or Bto
decrease it. Holding down either button changes the
selection at high speed.
PressxDand Bat the same time to clear the setting
to 0:00' 00".
Press4. Ato move the flashing to the target time ON/
OFF setting.
Hour
Target time on indicator
Seconds
Minutes
Mode
indicator
