smart home ControLinc Maxi 4071 User manual

Quick-Start Guide
X10 TABLETOP CONTROLLER
SStteepp
11..Plug the ControLinc Maxi into an unswitched wall outlet.
SStteepp
22..Choose the X10 addresses you would like to control (e.g. A1).
SStteepp
33..With the cover closed, press and hold the DIM and ON buttons for 3 seconds, until the sounder is heard
and the Status LED begins blinking.
Your ControLinc Maxi is now in Setup Mode; you have 30 seconds to complete Step 6.
SStteepp
44..On your ControLinc Maxi, press the ON button of the channel to be programmed.
SStteepp
55..Open the cover and select a House Code (Buttons A through P).
SStteepp
66..Select a Unit Code (Buttons 1 through 16).
The ControLinc Maxi will beep, and the Status LED will stop blinking.
SStteepp
77..Test the address by closing the cover and press the ON and OFF buttons several times to make sure
everything is working properly.
SStteepp
88..Repeat for the other channels as desired.
The ControLinc Maxi is a simple yet powerful controller for your X10 system.
ON/OFF
Buttons
Main ON/ OFF Buttons
BRIGHT/DIM
Buttons
Congratulations! You Can Now Remotely Control Your X10 Device.
ControLincTM Maxi (#4071)
Set Up Your ControLinc Maxi to Control an X10 Address Remotely
Smarthome
Limited Warranty
Smarthome warrants to the original consumer of this product that, for a period of two years from the date of purchase, this product will be free from defects in material and workmanship and will perform
in substantial conformity to the description of the product in the owner's manual. This warranty shall not apply to defects or errors caused by misuse or neglect.
©
Copyright 2005 Smarthome, 16542 Millikan Ave., Irvine, CA 92606-55027
800.SMART.HOME
- 949.221.9200 - www.smarthome.com
NNeeeedd
HHeellpp?? FFoorr aassssiissttaannccee ccaallll yyoouurr ffrriieennddllyy ssuuppppoorrtt
ppeerrssoonn
@@ 880000-SSMMAARRTTHHOOMMEE ((88000
0-776622-77884466))
Status LED
Using your ControLinc Maxi - Closed Cover
Five sets of ON/OFF buttons are used to control your devices.
Press
the ON button to turn your lamp or appliance on.
Press the OFF button to turn your lamp or appliance off.
Press
and hold the ON button to brighten your lamp.
Press
and hold the OFF button to dim your lamp.
Main ON and OFF buttons control all of your lamps assigned to the 5 channels above.
Press the Main ON button to send ON commands for all five channels.
Press the Main OFF button to send OFF commands for all five channels.
BRIGHT and DIM buttons control the brightness of your lamps (affects the last X10 address controlled).
Press
and hold the BRIGHT button to brighten your lamps.
Press
and hold the DIM button to dim your lamps.

Smarthome
Limited Warranty
Smarthome warrants to the original consumer of this product that, for a period of two years from the date of purchase, this product will be free from defects in material and workmanship and will perform
in substantial conformity to the description of the product in the owner's manual. This warranty shall not apply to defects or errors caused by misuse or neglect.
©
Copyright 2005 Smarthome, 16542 Millikan Ave., Irvine, CA 92606-55027
800.SMART.HOME
- 949.221.9200 - www.smarthome.com
Quick-Start Guide
X10 TABLETOP CONTROLLER
NNeeeedd
HHeellpp?? FFoorr aassssiissttaannccee ccaallll yyoouurr ffrriieennddllyy ssuuppppoorrtt
ppeerrssoonn
@@ 880000-SSMMAARRTTHHOOMMEE ((880000-776622-77884466))
Using the Open-Cover Functions
Turning an X10 address ON
•Press the House Code button (A through P).
•Press the Unit Code button (1 through 16).
•Press the (Main) ON button to turn your device on.
Turning an X10 address OFF
•Press
the House Code button (A through P).
•Press the Unit Code button (1 through 16).
•Press the (Main) OFF button to turn your device off.
Controlling the brightness of your lamps
•Press
the House Code button (A through P).
•Press the Unit Code button (1 through 16).
Either
•Tap the BRIGHT button to brighten your lamp
incrementally.
•Tap the DIM button to dim your lamp incrementally.
OR
•Press
and hold the BRIGHT button to brighten your lamp until you release.
•Press
and hold the DIM button to dim your lamp until you release.
Sending Preset DIM commands to an address
•Press the House Code button (A through P).
•Press the Unit Code button (1 through 16).
•Press
the DIM% button to turn your lamp on.
•Press any blue-labeled button (e.g.: 35 for 35% or 100 for 100%).
(Not all X10 products support preset dim commands.)
Hint: if you want to control 2 devices on the same housecode you only have to press the housecode once.
Troubleshooting Tips
•The LED on the ControLinc Maxi is not turning on.
Make sure you are not on a switched outlet.
•Factory Reset Instructions.
Unplug the ControLinc Maxi for about 10 seconds. While holding down the BRIGHT button on the
ControLinc Maxi, plug it in, continuing to hold down the BRIGHT button. Release the BRIGHT button.
After several seconds, the Status LED will illuminate steadily, indicating that reset is complete.
For setup and usage instructions of advanced features the User's Guide can be found at
www.smarthome.com/4071.html.
House Code
Buttons
Unit Code
Buttons
