SMART Centellis 2000 Quick start guide

Centellis 2000 Shelf - AC
Installation and Use
P/N: 6806800J87P
February 2021

© 2021 SMART Embedded Computing™, Inc.
All Rights Reserved.
Trademarks
The stylized "S" and "SMART" is a registered trademark of SMART Modular Technologies, Inc. and “SMART Embedded
Computing” and the SMART Embedded Computing logo are trademarks of SMART Modular Technologies, Inc. All other names
and logos referred to are trade names, trademarks, or registered trademarks of their respective owners. These materials are
provided by SMART Embedded Computing as a service to its customers and may be used for informational purposes only.
Disclaimer*
SMART Embedded Computing (SMART EC) assumes no responsibility for errors or omissions in these materials. These
materials are provided "AS IS" without warranty of any kind, either expressed or implied, including but not limited to,
the implied warranties of merchantability, fitness for a particular purpose, or non-infringement. SMART EC further does
not warrant the accuracy or completeness of the information, text, graphics, links or other items contained within these
materials. SMART EC shall not be liable for any special, indirect, incidental, or consequential damages, including without
limitation, lost revenues or lost profits, which may result from the use of these materials. SMART EC may make changes to
these materials, or to the products described therein, at any time without notice. SMART EC makes no commitment to update
the information contained within these materials.
Electronic versions of this material may be read online, downloaded for personal use, or referenced in another document as a
URL to a SMART EC website. The text itself may not be published commercially in print or electronic form, edited, translated,
or otherwise altered without the permission of SMART EC.
It is possible that this publication may contain reference to or information about SMART EC products, programming, or services
that are not available in your country. Such references or information must not be construed to mean that SMART EC intends
to announce such SMART EC products, programming, or services in your country.
Limited and Restricted Rights Legend
If the documentation contained herein is supplied, directly or indirectly, to the U.S. Government, the following notice shall apply
unless otherwise agreed to in writing by SMART Embedded Computing.
Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (b)(3) of the Rights in
Technical Data clause at DFARS 252.227-7013 (Nov. 1995) and of the Rights in Noncommercial Computer Software and
Documentation clause at DFARS 252.227-7014 (Jun. 1995).
SMART Embedded Computing, Inc.
2900 S. Diablo Way, Suite 190
Tempe, Arizona 85282
USA
*For full legal terms and conditions, visit www.smartembedded.com/ec/legal

Table of Contents
Centellis 2000 Shelf - AC Installation and Use (6806800J87P) 3
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Safety Notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Sicherheitshinweise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
1 System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
1.1 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
1.1.1 Shelf. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
1.1.2 Backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
1.1.3 Shelf Manager and Hub Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
1.1.4 Node Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
1.1.5 Rear Transition Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
1.1.6 AC Power Inlet Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
1.1.7 AC Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
1.1.8 Fan Trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
1.1.9 Air Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
1.1.10 User Card Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
1.2 System Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
1.3 Shelf Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
1.4 Standard Compliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
1.5 Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
2 Site Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
2.2 Site Planning Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
2.2.1 Receiving and Unpacking the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
2.2.2 Site and Installation Planning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
2.3 Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
2.3.1 Environmental Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
2.3.2 Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
2.4 Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
2.5 Mounting Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
2.6 Cooling Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
2.7 Acoustic Noise Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

4 Centellis 2000 Shelf - AC Installation and Use (6806800J87P)
Table of Contents
3 System Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
3.2 Before Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
3.2.1 Type Label Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
3.2.2 Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
3.2.3 Tools You Will Need. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
3.2.4 Torque Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
3.3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
3.3.1 Installing the System in a Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
3.3.2 Ground System/Bonding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
3.3.3 Powering-Up the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
3.4 Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
3.4.1 Powering Down the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
3.4.2 Disconnecting the System from Power Feed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
3.4.3 Removing the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
4 FRU Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
4.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
4.2 Installing and Removing RTMs and Blades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
4.3 Replacing the Shelf Manager and Hub Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
4.4 Covering Unused Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
4.5 Replacing AC Power Supply Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
4.6 Replacing Fan Trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
4.7 Maintaining Air Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
4.7.1 Replacing the System Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
4.7.2 Replacing the AC PSU Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
4.7.3 Storing the Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
5 Non-Field-Replaceable Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
5.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
5.2 Backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
5.2.1 Base Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
5.2.2 Fabric Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
5.2.3 Update Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
5.2.4 Synchronization Clock Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
5.3 Alarm Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Table of Contents
Centellis 2000 Shelf - AC Installation and Use (6806800J87P) 5
5.4 Power Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
6 Cooling Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
6.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
6.2 Cooling Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
7 Power Subsystem. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
7.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
7.2 Power Subsystem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
7.2.1 Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
7.2.2 Power Distribution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
7.2.2.1 Management Power Distribution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
7.2.2.2 High Power Distribution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
7.2.2.3 Power Interconnect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
7.2.3 PSU Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
7.2.3.1 PSU Input Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
7.2.3.2 PSU Output Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
8 Network Management and System Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
8.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
8.2 Accessing System Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
8.3 Network Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
8.3.1 Slot Numbers and Slot Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
8.3.2 Shelf Geographical Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
8.3.2.1 Setting the Shelf Geographical Address . . . . . . . . . . . . . . . . . . . . . . . . 102
8.3.2.2 Shelf Manager Replacement Scenarios . . . . . . . . . . . . . . . . . . . . . . . . . 103
8.3.3 IP Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
8.3.3.1 Out-of-Band Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
8.3.3.2 Backplane Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
8.3.3.3 Configuration File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
8.3.4 Restoring Factory Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
9 DHCP Configuration and Network Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
9.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
9.2 DHCP Configuration and Network Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

6 Centellis 2000 Shelf - AC Installation and Use (6806800J87P)
Table of Contents
9.2.1 Preparing a TFTP Server for Network Boot and Installation . . . . . . . . . . . . . . . . . 116
9.2.2 Preparing a DHCP Server for Network Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
10 Redundancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
10.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
10.2 Redundancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
10.2.1 Cold Standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
10.2.1.1 Heartbeat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
10.2.1.2 Data Replication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
10.2.1.3 HPI Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
10.2.2 System Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
10.2.3 Redundancy Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
10.2.3.1 Shelf Manager Switchover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
10.2.3.2 Shelf Manager Takeover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
10.2.3.3 Shelf Manager Failover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
10.2.3.4 Shelf Manager Insertion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
10.2.3.5 Shelf Manager Extraction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
11 Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
11.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
11.2 Software Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
11.2.1 Enclosed CDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
11.2.2 BBS Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
11.2.3 Firmware Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
11.3 Blade Insertion and Extraction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
11.3.1 Power-On After Blade Insertion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
11.3.2 Power-Down Before Blade Extraction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
A.1 Error List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
A.1.1 Mechanical. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
A.1.2 After Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
A.1.3 Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
A.1.4 Shelf Managers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

Table of Contents
Centellis 2000 Shelf - AC Installation and Use (6806800J87P) 7
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
B.1 SMART Embedded Computing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
B.2 Related Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

8 Centellis 2000 Shelf - AC Installation and Use (6806800J87P)
Table of Contents

List of Tables
Centellis 2000 Shelf - AC Installation and Use (6806800J87P) 9
Table 1-1 Standard Compliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Table 2-1 Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Table 2-2 Critical Temperature Limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Table 2-3 System Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Table 2-4 Dimensions and Weight of System and Components . . . . . . . . . . . . . . . . . . . . . . . . . 58
Table 3-1 Torque Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Table 7-1 PSU Input Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Table 7-2 PSU Output Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Table 8-1 Slot Numbering and Slot Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Table 11-1 Software Available on Shelf Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Table 11-2 Available Software Upgrade Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Table B-1 SMART EC Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Table B-2 Related Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

List of Tables
10 Centellis 2000 Shelf - AC Installation and Use (6806800J87P)

List of Figures
Centellis 2000 Shelf - AC Installation and Use (6806800J87P) 11
Figure 1-1 System Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Figure 1-2 System Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Figure 1-3 MF105 Hub Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Figure 1-4 AdvancedTCA System Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Figure 1-5 Shelf Management Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Figure 1-6 Sample Shelf Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Figure 2-1 Rack Mounting Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Figure 3-1 Rack Mounting Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Figure 3-2 System’s Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Figure 4-1 ATCA-MF105 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Figure 5-1 Location of Zones on a Blade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Figure 7-1 Two-PSU Shelf Power Distribution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Figure 8-1 Access via the Face Plate Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Figure 8-2 Access via Base Interface Channel 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Figure 8-3 Access via Base Interface Channel 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Figure 8-4 Dual Star Topology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Figure 8-5 IP Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Figure 8-6 Physical IP Address on Out-of-Band Interface . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Figure 8-7 Virtual Active IP Address on Out-of-Band Interface . . . . . . . . . . . . . . . . . . . . . . . 106
Figure 8-8 Virtual Standby IP Address on Out-of-Band Interface . . . . . . . . . . . . . . . . . . . . . 106
Figure 8-9 Physical IP Address on Backplane Interface 1 . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Figure 8-10 Physical IP Address on Backplane Interface 2 . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Figure 8-11 Virtual Active IP Address on Backplane Interfaces . . . . . . . . . . . . . . . . . . . . . . . 109
Figure 8-12 Virtual Standby IP Address on Backplane Interfaces . . . . . . . . . . . . . . . . . . . . . . 109
Figure 9-1 DHCP/TFTP Server Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Figure 11-1 Blade Power-On After Insertion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Figure 11-2 Blade Power-down Before Extraction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

List of Figures
12 Centellis 2000 Shelf - AC Installation and Use (6806800J87P)

Centellis 2000 Shelf - AC Installation and Use (6806800J87P) 13
About this Manual
Overview of Contents
This Installation and Use manual is organized as follows:
Chapter Description
About this Manual Lists all conventions and abbreviations used in this manual and
outlines the revision history
Safety Notes Describes the safety information which has to be regarded
Sicherheitshinweise German translation of the Safety Notes chapter.
Chapter 1, System Overview
on page 41 Provides an overview of the features of the system and lists
order numbers
Chapter 2, Site Preparation on
page 53 Provides site planning considerations and checklists, describes
the requirements and conditions
Chapter 3, System Installation
on page 61 Describes how to install and run the system
Chapter 4, FRU Installation on
page 71
Describes how to install and replace blades, RTMs, shelf
manager & hub boards, power components, fan trays and air
filters
Chapter 5, Non-Field-
Replaceable Units on page 89 Describes the backplane, the alarm panel and the power inlet
Chapter6, CoolingSubsystem
on page 93 Contains information on fans and fan trays
Chapter 7, Power Subsystem
on page 95 Contains information on power supplies and power distribution
Chapter 8, Network
Management and System
Access on page 99
Contains information on which component can be accessed via
which interface and information on the various addresses you
need to access system components
Chapter 9, DHCP
Configuration and Network
Boot on page 115
Contains information on preparing a TFTP server and a DHCP
server and describes how to boot the blades from a TFTP
server via network
Chapter 10, Redundancy on
page 121
Contains information on cold standby, dual star network
topology and actions of shelf manager and system manager
during switchover, takeover, failover, insertion, and extraction
Chapter 11, Software on page
127 Provides information that you need after you have successfully
installed the hardware

14 Centellis 2000 Shelf - AC Installation and Use (6806800J87P)
About this Manua
l
About this Manual
Abbreviations
This document uses the following abbreviations:
Appendix A, Troubleshooting
on page 133 This chapter helps you to solve problems which may occur
Appendix B, Related
Documentation on page 135 Lists related documentation and specifications
Chapter Description
Abbreviation Definition
AdvancedTCA
ATCA Advanced Telecom Computing Architecture
AMC AdvancedTCA Mezzanine Card
ANSI American National Standards Institute
ARP Address Resolution Protocol
AWG American Wire Gauge
BBS Basic Blade Services
CFM Cubic Feet per Minute
CGL Carrier Grade Linux
CISPR Comité International Spécial des Perturbations
Radioélectriques
CO Central Office
DHCP Dynamic Host Configuration Protocol
EMC Electromagnetic Compatibility
EMI Electromagnetic Interference
EMV Elektromagnetische Vertraeglichkeit
EN European Norm
ESD Electrostatic Discharge
ETSI European Telecommunication Standards Institute
FAE Field Application Engineers

About this Manual
Centellis 2000 Shelf - AC Installation and Use (6806800J87P) 15
FCC Federal Communications Commission
FCU Firmware Upgrade Utility
FRU Field Replaceable Unit
FUMI Firmware Update Management Instrument
GmbH Gesellschaft mit beschraenkter Haftung
HPI Hardware Platform Interface
IEC International Electric Code
IEEE Institute of Electrical and Electronics Engineers
IPM Intelligent Platform Management
IPMB Intelligent Platform Management Bus
IPMC Intelligent Platform Management Controller
IPMI Intelligent Platform Management Interface
MMC Mezzanine Management Controller
NAE National Academy of Engineering
NEBS Network Equipment Building System
NEC National Electric Code
OEM Original Equipment Manufacturer
OOB Out-of-band
PCI Peripheral Component Interconnect
PICMG PCI Industrial Computer Manufacturers Group
PMC PCI Mezzanine Card
PSU Power Supply Unit
RMCP Remote Management Control Protocol
RoHS Restriction of Certain Hazardous Substances
RTM Rear Transition Module
SAF Service Availability Forum
SCSI Small Computer System Interface
Abbreviation Definition

16 Centellis 2000 Shelf - AC Installation and Use (6806800J87P)
About this Manua
l
About this Manual
Conventions
The following table describes the conventions used throughout this manual.
SELV Safety Extra Low Voltage
SGA Shelf Geographical Address
ShM Shelf Manager
ShMC Shelf Management Controller
SSH Secure Shell
SW Ethernet Switch
TDM Time-Division Multiplexing
TPE Twisted-Pair Ethernet
UL Underwriters Laboratories
VCCI Voluntary Control Council for Interference
WEEE Waste from Electrical and Electronic Equipment
Abbreviation Definition
Notation Description
0x00000000 Typical notation for hexadecimal numbers (digits are 0 through F), for
example used for addresses and offsets
0b0000 Same for binary numbers (digits are 0 and 1)
bold Used to emphasize a word
Screen Used for on-screen output and code related elements or commands.
Sample of Programming used in a table (9pt)
Courier + Bold Used to characterize user input and to separate it from system output
Reference Used for references and for table and figure descriptions
File > Exit Notation for selecting a submenu
<text> Notation for variables and keys
[text] Notation for software buttons to click on the screen and parameter
description
... Repeated item for example node 1, node 2, ..., node 12

About this Manual
Centellis 2000 Shelf - AC Installation and Use (6806800J87P) 17
.
.
.
Omission of information from example/command that is not necessary at
the time
.. Ranges, for example: 0..4 means one of the integers 0,1,2,3, and 4 (used
in registers)
| Logical OR
Indicates a hazardous situation which, if not avoided, could result in death
or serious injury
Indicates a hazardous situation which, if not avoided, may result in minor
or moderate injury
Indicates a property damage message
Indicates a hot surface that could result in moderate or serious injury
Indicates an electrical situation that could result in moderate injury or death
Indicates that when working in an ESD environment care should be taken
to use proper ESD practices
No danger encountered, pay attention to important information
Notation Description

18 Centellis 2000 Shelf - AC Installation and Use (6806800J87P)
About this Manua
l
About this Manual
Summary of Changes
Document
Name
Publication
Date Description
6806800J87P February 2021 Updated Tables 1-4 and 7-1 for 62368-1 compliance.
6806800J87N January 2020 Rebrand to SMART Embedded Computing template
6806800J87M May 2016 Removed Declaration of Conformity.
6806800J87L May 2014 Rebranded to Artesyn.
6806800J87K July 2013 Added figure in Fabric Interface on page 90.
6806800J87J December 2012 Updated Standard Compliances on page 50.
6806800J87H November 2012 Updated Table 8-1 on page 102.
6806800J87G April 2012 Updated Enclosed CDs on page 127.
6806800J87F March 2012
Added a Caution in User Card Slots on page 45.
Added a Notice in System Installation on page 20 and
Systemerweiterung on page 36.
Added sections Laser on page 28 and Laser on page 38.
Updated Standard Compliances on page 50, EMC on
page 19 and EMV on page 29.
6806800J87E September 2011 Updated Table 1-1 on page50 and section MaintainingAir
Filters on page 81.
6806800J87D November 2010 Updated section Fans on page 134.
6806800J87C July 2010
Updated Ordering Information on page 52, Dimensions
and Weight on page 58, and Related Documentation on
page 135
6806800J87B February 2010 Updated Configuration File on page 111.
6806800J87A November 2009 Preliminary Installation and Use

Centellis 2000 Shelf - AC Installation and Use (6806800J87P) 19
Safety Notes
This section provides warnings that precede potentially dangerous procedures throughout
this manual. Instructions contained in the warnings must be followed during all phases of
operation, service, and repair of this equipment. You should also employ all other safety
precautions necessary for the operation of the equipment in your operating environment.
Failure to comply with these precautions or with specific warnings elsewhere in this manual
could result in personal injury or damage to the equipment.
SMART Embedded Computing intends to provide all necessary information to install and
handle the product in this manual. Because of the complexity of this product and its various
uses, we do not guarantee that the given information is complete. If you need additional
information, ask your SMART EC representative.
The product has been designed to meet the standard industrial safety requirements. It must
only be used in its specific area of office telecommunication industry, industrial control, and
development. It must not be used in safety critical components, life supporting devices or
on aircraft.
Only personnel trained by SMART EC or persons qualified in electronics or electrical
engineering are authorized to install, remove or maintain the product. The information given
in this manual is meant to complete the knowledge of a specialist and must not be used as
replacement for qualified personnel.
Keep away from live circuits inside the equipment. Operating personnel must not remove
equipment covers. Only factory authorized service personnel or other qualified service
personnel may remove equipment covers for internal subassembly or component
replacement or any internal adjustment.
Do not install substitute parts or perform any unauthorized modification of the equipment or
the warranty may be voided. Contact your local SMART EC representative for service and
repair to make sure that all safety features are maintained.
EMC
The product has been tested and found to comply with the limits for a Class A digital device
in this system, pursuant to part 15 of the FCC Rules, EN 55022 Class A respectively. These
limits are designed to provide reasonable protection against harmful interference when the
product is operated in a commercial, business or industrial environment.
The product generates and uses radio frequency energy and, if not installed properly and
used in accordance with this user's documentation, may cause harmful interference to radio
communications. Operating the product in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at his own
expense. To ensure proper EMC shielding, operate the system only with free slots
populated with filler blades.

20 Centellis 2000 Shelf - AC Installation and Use (6806800J87P)
Safety Notes
Safety Notes
To ensure EMC protection use only shielded cables when connecting peripherals to assure
that appropriate radio frequency emissions compliance is maintained. Installed blades
must have the face plates installed and all vacant slots in the shelf must be covered.
Grounding
If the product is not properly grounded, it may be damaged by electrostatic discharge.
Make sure that each of the system's parts contact the EMI gasket. The system contains
gaskets at the shelf and module level.
The shelf is also fitted with ESD snaps for the use with conductive wrist straps. Please take
care for proper ESD protection of the operator.
This is a Class A product based on the standard of the Voluntary Control Council for
Interference by Information Technology Interference (VCCI). If this equipment is used in a
domestic environment, radio disturbance may arise. When such trouble occurs, the user
may be required to take corrective actions.
The equipment is suitable for installation in a Common Bonding Network (CBN) or Isolated
Bonding Network (IBN).
System Installation
System Damage
To avoid system damage verify that the system environment meets the environmental and
power requirements given in this manual before installing the system.
Before you begin to set up and cable your new system, consider these guidelines:
Installation codes: This unit must be installed in accordance with the National
Electrical Code.
Overcurrent protection: A readily accessible listed branch circuit overcurrent
protective device must be incorporated into the building wiring. For appropriate
AWG rating of the overcurrent protection device see NEC Table 310.16 and other
national regulations.
The protective bonding conductor depends on your power distribution topology.
Make sure that you use an appropriate protective bonding conductor regarding the
rating of the branch circuit protection.
Install the system safely. Make sure that cables and cords are out of the way.
Make sure that the set-up is comfortable for users.
