SMARTERFRESH SF-B80H User manual

Hand Held Brass Bidet Installation
Model SF-B80H
INCLUDED COMPONENTS:
Brass Bidet Sprayer Head
Ÿ
Brass Shut Off T-Valve Adapter
Ÿ
Stainless Steel Bidet Hose with PEX Inner Tube
Ÿ
Bidet Hook Holder for Toilet Tank (Transion to Wall Mount Included)
Ÿ
PRIOR TO INSTALLATION:
Analyze water supply line --- if line that connects the boom of toilet tank to exisng water
line shutoff valve is rigid pipe, you will need to purchase a flexible toilet connector . (Figure A)
Depending on length, connector can be found at hardware stores for under $5. Replace rigid
pipe with flexible toilet connector.
H ving a flat rubber jar opener or a pair of large pliers on hand can help with
a
(Figure B)
loosening and ghtening.
INSTALLATION:
1) Place towel on floor underneath installaon area.
2) At wall, turn off water supply valve & flush toilet, holding down handle to decrease
amount of tank water to minimal level at boom of tank.
3) Disconnect flexible toilet connector by unscrewing from directly under toilet tank. (Some
minor water dripping is normal once unscrewed).
4) Make sure exisng rubber washer is lying flat inside top of Shut Off T-Valve Adapter and
aach adapter at toilet tank where flexible toilet connector was just removed from (Figure
C).
5) Reconnect flexible toilet connector to boom of Shut Off T-Valve Adapter .(Figure C)
6) Aach hexagon shaped end of Stainless Steel Bidet Hose to remaining opening on Shut Off
T-Valve Adapter, making sure rubber washer is lying flat at end of hose. (Figure D)
7) Aach other end (conical shaped) of Stainless Steel Bidet Hose to Brass Bidet Sprayer
Head, making sure rubber washer is lying flat at end of hose. (Figure E)
8) Locate Bidet Hook Holder and affix to convenient locaon on toilet tank and place Bidet
Sprayer Head inside Bidet Hook Holder, dropping in over the top of the holder. (Figure F)
9) Alternavely, wall mount the holder by disassembling the hook holder. With screwdriver,
remove screws from backside of hook. Use provided long screws and anchors to aach
holder to wall through two holes on front side of holder. Two sets of anchors provided for
different mounng surfaces.
IMPORTANT: When the Shut Off T-Valve lever is facing straight down, the water supply is off.
Using your thumb to push the lever upwards toward the wall will open the valve.
10) Turn on water supply at the wall to check for leaks. Open the Shut Off T-Valve allowing
water to flow to the Bidet Sprayer Head. You will hear sound of water making way through
valve into hose. If leaks occur, turn off water supply and connue to Troubleshoong
secon.
A
B
C
D
E

Contact us for installaon instrucons or quesons at [email protected]om.
Do NOT return product to retail store or online before contacng us.
www.SmarterFresh.com
OPERATION AND USAGE:
Direct the hand held sprayer in appropriate direcon and press the Bidet Sprayer Head
lever to release flow of water. Water spray is adjustable and will spray with high or low
force (jet spray vs gentle rinsing) based on how much depression is placed on the Bidet
Sprayer Head lever. You can further adjust the spray by adjusng the Shut Off T-Valve
lever up and down.
The Shut Off T-valve lever does not need to be turned upwards at 100% to receive a
reasonable flow of water from the sprayer. Test this by starng to turn the
valve lever 25% of the distance, assessing the sprayer flow, and increasing unl th e
perfect water flow speed is reached.
F
TROUBLESHOOTING:
If leaking occurs at Shut Off T-Valve Adapter and Toilet Tank, the Shut Off T-Valve Adapter is either cross-threaded or
Ÿ
not ghtened enough. Tighten the leaking area with a ¼ to ½ turn by hand, using rubber jar opener, or with large
pliers. Turn water supply back on to test. Connue paern unl leaking stops. If leaking connues, unscrew the Shut
Off T-Valve Adapter completely and make sure rubber washer exists and is seated flat and even at boom of the Shut
Off T-Valve Adapter.
If leaking occurs at Bidet Sprayer Head, disconnect sprayer from Stainless Steel Bidet Hose, and check for existence
Ÿ
of rubber washer or that the washer is lying flat and deep in hose. Tighten hose to sprayer head.
If leaking occurs under Shut Off T-Valve Adapter from flexible toilet connector, turn the toilet connector ¼ to ½ turn
Ÿ
by hand and turn water supply back on to test.
Please do not hesitate contacng us at with any installaon or troubleshoong quesons. [e-mail]
We are here to help!
WARNING MESSAGE:
Turn off Shut Off T-Valve Adapter lever aer each use to close the water supply to the Bidet Sprayer Head. If you choose
to not turn off the valve lever, you risk weakening the internal components of the sprayer and hose, or exposing your
home to water damage or flooding.
The valve lever is conveniently located on the Shut Off T-Valve Adapter and takes only a moment to shut off.
Manufacturer is not responsible for damage which may have been caused by failure to follow this recommendaon.
You may also want to flush out the remaining water from the hose aer every use by depressing the Bidet Sprayer Head
handle. The hose will lay beer when no water is inside.
The hand held bidet has many uses including female and male hygiene, cleaning toilets, sinks, or tub shower, cloth
diaper cleaning, washing pets, etc.
