Package Contents
The following contents should be found in your box:
¾One PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter
¾Quick Installation Guide
¾One Resource CD for PW-DN481D, including:
•AR52 Wireless Lite-N Client Utility (AWCU) and Drivers
•User Guide
•Other Helpful Information
)Note:
Make sure that the package contains the above items. If any of the listed items are damaged or
missing, please contact with your distributor.
Conventions:
The ‘Adapter’ mentioned in this user guide stands for PW-DN481D 150Mbps Wireless Lite-N
PCI-E Adapter without any explanations.
1

PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter
2
Chapter 1 Introduction
Thank you for choosing PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter.
1.1 Overview of the product
The adapter is designed to provide a high-speed and unrivaled wireless performance for your PC.
With a faster wireless connection, you can get a better Internet experience, such as downloading,
gaming, video streaming and so on.
The PW-DN481D’s auto-sensing capability allows high packet transfer rate of up to 150Mbps for
maximum throughput. It has good capability on anti-jamming; it can also interoperate with other
wireless (802.11n/g/b) products. The adapter supports WEP, WPA and WPA2 encryption to
prevent outside intrusion and protect your personal information from being exposed.
The Quick Setup Wizard guides you step by step through the installation process; the AR52
Wireless Lite-N Client Utility helps you create a wireless connection immediately.
With unmatched wireless performance, reception, and security protection, the PW-DN481D is the
best choice for easily adding or upgrading wireless connectivity.
1.2 Features
¾IEEE 802.11n, IEEE 802.11g, IEEE 802.11b standards
¾Supports WPA/WPA2 data security, IEEE 802.1x authentication, TKIP/AES encryption, WEP
encryption
¾Make use of IEEE 802.11n wireless technology to provide a wireless data rate of up to
150Mbps
¾supports automatically adjust to lower speeds due to distance or other operating limitations
¾Provides PCI-E interface
¾Supports Ad-Hoc and Infrastructure modes
¾Good capability on anti-jamming
¾Supports roaming between access points when configured in Infrastructure mode
¾Easy to configure and provides monitoring information
¾Supports Windows 2000/XP/Vista/7

PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter
3
)Note:
This device leverages some 802.11n features to provide improved performance and coverage
compared to 802.11a/g devices, and fully interoperates with 802.11n products if they are Wi-Fi
CERTIFIED, but it does not conform to all of the requirements in the IEEE specification and is not
classified as "n" in the Wi-Fi CERTIFIED program.
1.3 LED Status
Status Working Status
Off The driver has not been installed.
Flashing Slowly The driver has been installed but there is no data being transmitted
or received.
Flashing Quickly There is data being transmitted or received.

PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter
4
Chapter 2 Installation Guide
2.1 Hardware Installation
To install the adapter, follow these steps listed below:
1. Turn off your desktop PC and disconnect the power.
2. Remove your PC case and locate an available PCI-E slot on the mianboard. Remove the
metal slot cover on the back of the PC. Check with your computer manufacturer for
instructions if needed.
3. Slide the PCI-E Adapter into the PCI-E slot. Make sure that all of its pins are touching the
slot's contacts. Once the adapter is firmly in place, secure its fastening tab to your PC's
chassis with a mounting screw. Then, close your PC case.
4. Reconnect your PC’s power and turn on your desktop PC.
2.2 Software Installation
2.2.1 Overview
The Adapter’s Setup Wizard will guide you through the Installation procedure for Windows XP.
The Setup Wizard will install the AR52 Wireless Lite-N Client Utility (AWCU) and drivers.
When you install the hardware prior to before installing the software, the system will prompt
“Found New Hardware Wizard”, click Cancel, and run the Setup Wizard program on the CD-ROM.
The Setup steps for Windows 2000 and XP are similar with each other. This user guide takes
Windows XP for example.
2.2.2 Software Installation for Windows XP
1. Insert the Resource CD into your CD-ROM drive. To continue, find the CD/DVD drive where
the installation CD was placed. Open PW-DN481D folder, and double-click Setup.exe. Then
the following screen for preparing setup will appear.

PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter
5
Figure 2-1
2. Soon, Figure 2-2 will display after a moment. Click Next to continue.
Figure 2-2
3. After that, you should choose a Setup type. It is recommended that you select Install Client
Utilities and Driver. Select Install Driver Only to install driver only, select Make Driver
Installation Diskette(s) to make the diskette(s) as the installation driver (shown in Figure
2-3). Click Next to continue.

PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter
6
Figure 2-3
4. Click Browse to change the destination location for the software, then click Next in the screen
below (shown in Figure 2-4).
Figure 2-4
5. After that, select the program folder, you should create a new folder name or select one from
the Existing Folders list. It is recommended that you keep the default setting. Click Next to
continue the installation.

PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter
7
Figure 2-5
6. Choose configuration tool, if you are not sure, please leave it default. Then click Next to
continue.
Figure 2-6

PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter
8
7. Click OK to continue the Installation. Wait a while for the setup as shown in Figure 2-7 .
Figure 2-7
)Note:
For Windows XP, the Setup Wizard will notify you of how to proceed with the installation during
these steps (shown in Figure 2-8). Our drivers have been tested thoroughly, and are able to work
with the operating system. Click Continue Anyway to continue the Installation.
Figure 2-8

PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter
9
8. After all the steps above, you will see the screen below, click Finish to reboot the system.
Figure 2-9
2.2.3 Software Installation for Windows Vista
1. Insert the Resource CD into your CD-ROM drive. To continue, find the CD/DVD drive where
the installation CD was placed. Open PW-DN481D folder, and double-click Setup.exe. Then
the following screen for preparing setup will appear.

PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter
10
Figure 2-10
2. Soon, Figure 2-11 will display after a moment. Click Next to continue.
Figure 2-11
3. Click Yes to continue.

PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter
11
Figure 2-12
4. The following page will display and please wait a moment.
Figure 2-13
)Note:
For Windows Vista, the Setup Wizard will notify you of how to proceed with the installation during
these steps (shown in Figure 2-14). Our drivers have been tested thoroughly, and are able to work
with the operating system. Click Install this driver software anyway to continue the Installation.

PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter
12
Figure 2-14
5. Click Finish to complete the installation.
Figure 2-15
2.2.4 Software Installation for Windows 7
1. Insert the Resource CD into your CD-ROM drive. To continue, find the CD/DVD drive where
the installation CD was placed. Open PW-DN481D folder, and double-click Setup.exe. Then
the following screen for preparing setup will appear.

PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter
13
Figure 2-16
2. Soon, Figure 2-17 will display after a moment. Click Next to continue.
Figure 2-17
3. Wait a while for the setup as shown in Figure 2-18.

PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter
14
Figure 2-18
)Note:
For Windows 7, the Setup Wizard will notify you about the Windows Security with the installation
during these steps (shown in Figure 2-19). Our drivers have been tested thoroughly, and are able
to work with the operating system. Click Installation this driver software anyway to continue the
installation.
Figure 2-19
4. Then you will see Figure 2-20. Click Finish to complete.

PW-DN481D 150Mbps Wireless Lite-N PCI-E Adapter
15
Figure 2-20
