SMC Networks PFGV301 User manual

No.PF※※-OMZ0005
PRODUCT NAME
Digital Flow Monitor
MODEL / Series / Product Number
PFGV301
(For PFMV5 series)

-1-
No.PF※※-OMZ0005
Table of Contents
Safety Instructions 2
Model Indication and How to Order 8
Summary of Product parts 9
Definition and terminology 10
Mounting and Installation 12
Installation 12
Wiring 14
Flow Setting 19
Outline of Settings 20
Initial Setting 21
3 Step Setting Mode 24
Simple Setting Mode 26
Function Selection Mode 27
Function selection mode 27
Default setting 27
F0 Voltage orflowrange,display unitsandswitchoutput specificationsswitchfunction 29
F1 Setting of OUT1 33
F2 Setting of OUT2 36
F3 Digital filter setting 38
F4 Auto-preset function 39
F5 FUNC terminal function setting 41
F10 Sub display setting 46
F14 Display with zero cut-off setting 48
F80 Power saving mode 50
F81 Security code 51
F90 Setting of all functions 53
F96 Sensor input/External input signal status display 55
F97 Copy setting 56
F98 Output check 59
F99 Reset to default settings 61
Other Settings 62
Maintenance 66
Forgotten the security code 66
Troubleshooting 67
Specification 74
Characteristics data 76
Dimensions 78

-2-
No.PF※※-OMZ0005
Safety Instructions
These safety instructions are intended to prevent hazardous situations and/or equipment damage. These
instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are
all important notes for safety and must be followed in addition to International Standards (ISO/IEC)*1), and other
safety regulations.
1) ISO 4414: Pneumatic fluid power - General rules and safety requirements for systems and their components
ISO 4413: Hydraulic fluid power - General rules and safety requirements for systems and their components
IEC 60204-1: Safety of machinery - Electrical equipment of machines - Part 1: General requirements
ISO 10218-1: Robots and robotic devices - Safety requirements for industrial robots - Part 1:Robots
etc.
Danger
Danger indicates a hazard with a high level of risk which, if not avoided, will result
in death or serious injury.
Warning
Warning indicates a hazard with a medium level of risk which, if not avoided, could
result in death or serious injury.
Caution
Caution indicates a hazard with a low level of risk which, if not avoided, could result
in minor or moderate injury.
Warning
1. The compatibility of the product is the responsibility of the person who designs the equipment or
decides its specifications.
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
necessary analysis and test results. The expected performance and safety assurance of the equipment will be
the responsibility of the person who has determined its compatibility with the product. This person should also
continuously review all specifications of the product referring to its latest catalog information, with a view to
giving due consideration to any possibility of equipment failure when configuring the equipment.
2. Only personnel with appropriate training should operate machinery and equipment.
The product specified here may become unsafe if handled incorrectly. The assembly, operation and
maintenance of machines or equipment including our products must be performed by an operator who is
appropriately trained and experienced.
3. Do not service or attempt to remove product and machinery/equipment until safety is confirmed.
1. The inspection and maintenance of machinery/equipment should only be performed after measures to
prevent falling or runaway of the driven objects have been confirmed.
2. When the product is to be removed, confirm that the safety measures as mentioned above are implemented
and the power from any appropriate source is cut, and read and understand the specific product precautions
of all relevant products carefully.
3. Before machinery/equipment is restarted, take measures to prevent unexpected operation and malfunction.
4. Our products cannot be used beyond their specifications. Our products are not developed,
designed, and manufactured to be used under the following conditions or environments. Use
under such conditions or environments is not covered.
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
direct sunlight.
2. Use for nuclear power, railways, aviation, space equipment, ships, vehicles, military application, equipment
affecting human life, body, and property, fuel equipment, entertainment equipment, emergency shut-off
circuits, press clutches, brake circuits, safety equipment, etc., and use for applications that do not conform
to standard specifications such as catalogs and operation manuals.
3. Use for interlock circuits, except for use with double interlock such as installing a mechanical protection
function in case of failure. Please periodically inspect the product to confirm that the product is operating
properly.

-3-
No.PF※※-OMZ0005
Safety Instructions
Caution
We develop, design, and manufacture our products to be used for automatic control equipment, and
provide them for peaceful use in manufacturing business.
Use in non-manufacturing business is not covered.
Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the
Measurement Act.
The new Measurement Act prohibits use of any unit other than SI units in Japan.
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
Requirements”.
Read and accept them before using the product.
Limited warranty and Disclaimer
1. The warranty period of the product is 1 year in service or 1.5 years after the product is delivered, whichever is
first.∗2)
Also, the product may have specified durability, running distance or replacement parts. Please consult your
nearest sales branch.
2. For any failure or damage reported within the warranty period which is clearly our responsibility, a replacement
product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage incurred due to
the failure of the product.
3. Prior to using SMC products, please read and understand the warranty terms and disclaimers noted in the
specified catalog for the particular products.
*2) Vacuum pads are excluded from this 1 year warranty.
A vacuum pad is a consumable part, so it is warranted for a year after it is delivered.
Also, even within the warranty period, the wear of a product due to the use of the vacuum pad or failure due to
the deterioration of rubber material are not covered by the limited warranty
Compliance Requirements
1. The use of SMC products with production equipment for the manufacture of weapons of mass destruction
(WMD) or any other weapon is strictly prohibited.
2. The exports of SMC products or technology from one country to another are governed by the relevant security
laws and regulations of the countries involved in the transaction. Prior to the shipment of a SMC product to
another country, assure that all local rules governing that export are known and followed.

-4-
No.PF※※-OMZ0005
Operator
This operation manual is intended for those who have knowledge of machinery using pneumatic
equipment, and have sufficient knowledge of assembly, operation and maintenance of such
equipment. Only those persons are allowed to perform assembly, operation and maintenance.
Read and understand this operation manual carefully before assembling, operating or providing
maintenance to the product.
■Safety Instructions
Warning
■Do not disassemble, modify (including changing the printed circuit board) or repair.
An injury or failure can result.
■Do not operate the product outside of the specifications.
Do not use for flammable or harmful fluids.
Fire, malfunction, or damage to the product can result.
Verify the specifications before use.
■Do not operate in an atmosphere containing flammable or explosive gases.
Fire or an explosion can result.
This product is not designed to be explosion proof.
■Do not use the product in a place where static electricity is a problem.
Otherwise it can cause failure or malfunction of the system.
■If using the product in an interlocking circuit:
•Provide a double interlocking system, for example a mechanical system
•Check the product regularly for proper operation
Otherwise malfunction can result, causing an accident.
■The following instructions must be followed during maintenance:
•Turn off the power supply
•Stop the air supply, exhaust the residual pressure and verify that the air is released before performing
maintenance
Otherwise an injury can result.

-5-
No.PF※※-OMZ0005
Caution
■Do not touch the terminals and connectors while the power is on.
Otherwise electric shock, malfunction or damage to the product can result.
■After maintenance is complete, perform appropriate functional inspections and leak tests.
Stop operation if the equipment does not function properly or there is a leakage of fluid.
When leakage occurs from parts other than the piping, the product might be faulty.
Disconnect the power supply and stop the fluid supply.
Do not apply fluid under leaking conditions.
Safety cannot be assured in the case of unexpected malfunction.
■NOTE
○Follow the instructions given below when designing, selecting and handling the product.
●The instructions on design and selection (installation, wiring, environment, adjustment, operation,
maintenance, etc.) described below must also be followed.
Product specifications
•Use the specified voltage.
Otherwise failure or malfunction can result.
•Use the specified flow sensor.
Otherwise the product may be broken and it will not be able to perform proper measurement.
•Do not exceed the specified maximum allowable load.
Otherwise it can cause damage or shorten the lifetime of the product.
•Design the product to prevent reverse current when the circuit is opened or the product is forced to operate for
operational check.
Reverse current can cause malfunction or damage to the product.
•Input data to the product is not deleted, even if the power supply is cut off.
(Writing time: 1,500,000 cycles)
•Reserve a space for maintenance.
Allow sufficient space for maintenance when designing the system.

-6-
No.PF※※-OMZ0005
●Product handling
Installation
•Tighten to the specified tightening torque.
If the tightening torque is exceeded the mounting screws and brackets may be broken.
If the tightening torque is insufficient, the product can be displaced and loosen the mounting screws.
•Be sure to ground terminal FG when using a commercially available switch-mode power supply.
•Do not drop, hit or apply shock to the product.
Otherwise damage to the internal parts can result, causing malfunction.
•Do not pull the lead wire forcefully, not lift the product by pulling the lead wire.
(Tensile force 50 N or less)
Hold the body when handling to avoid the damage of the product which lead to cause the failure and malfunction.
Wiring
•Do not pull the lead wires. In particular, do not lift or carry the product by holding the cables once they
are connected to the product.
Otherwise damage to the internal parts can result, causing malfunction or to be off the connector.
•Avoid repeatedly bending or stretching the lead wire, or placing heavy load on them.
If the lead wire can move, fix it near the body of the product.
The recommended bend radius of the lead wire is 6 times the outside diameter of the sheath, or 33 times the
outside diameter of the insulation material, whichever is larger.
Replace the damaged lead wire with a new one.
•Wire correctly.
Incorrect wiring can break the product.
•Do not perform wiring while the power is on.
Otherwise damage to the internal parts can result, causing malfunction.
•Do not route wires and cables together with power or high voltage cables.
Otherwise the product can malfunction due to interference of noise and surge voltage from power and high voltage
cables to the signal line. Route the wires (piping) of the product separately from power or high voltage cables.
•Confirm proper insulation of wiring.
Poor insulation (interference from another circuit, poor insulation between terminals, etc.) can lead to excess
voltage or current being applied to the product, causing damage.
•Design the system to prevent reverse current when the product is forced to operate for operational check.
Depending on the circuit used, insulation may not be maintained when operation is forced, allowing reverse current
to flow, which can cause malfunction and damage the product.
•Keep wiring as short as possible to prevent interference from electromagnetic noise and surge voltage.
Do not use a cable longer than 30 m.
Wire the DC(-) line(blue) as close as possible to the power supply.
Environment
•Do not use the product in area that is exposed to corrosive gases, chemicals, sea water, water or steam.
Otherwise failure or malfunction can result.
•Do not use the product in an environment where the product is constantly exposed to water or oil
splashes.
If the product is to be used in an environment containing oils or chemicals such as coolant or cleaning solvent, it
may be adversely affected (damage, malfunction, or hardening of the lead wires).
•Do not use in an area where surges are generated.
If there is equipment which generates a large amount of surge (solenoid type lifter, high frequency induction
furnace, motor, etc.) close to the product, this may cause deterioration or breakage of the internal circuit of the
product. Avoid sources of surge generation and crossed lines.

-7-
No.PF※※-OMZ0005
•Do not use a load which generates surge voltage.
When a surge-generating load such as a relay or solenoid is driven directly, use a product with a built-in surge
absorbing element.
•The product is CE marked, but not immune to lightning strikes. Take measures against lightning strikes
in the system.
•Mount the product in a place that is not exposed to vibration or impact.
Otherwise failure or malfunction can result.
•Prevent foreign matter such as remnant of wires from entering the product.
Take proper measures for the remnant not to enter the product in order to prevent failure or malfunction.
•Do not use the product in an environment that is exposed to temperature cycle.
Heat cycles other than ordinary changes in temperature can adversely affect the inside of the product.
•Do not expose the product to direct sunlight.
If using in a location directly exposed to sunlight, shade the product from the sunlight.
Otherwise failure or malfunction can result.
•Keep within the specified ambient temperature range.
The ambient temperature range is 0 to 50 oC. Operation at low temperature (5 oC or less) may cause damage or
operation failure due to frozen moisture in the air.
Protection against freezing is necessary.
Avoid sudden temperature change even within specified temperature.
•Do not operate close to a heat source, or in a location exposed to radiant heat.
Otherwise malfunction can result.
Adjustment and Operation
•Turn the power on after connecting a load.
Otherwise it can cause excess current causing instantaneous breakage of the product.
•Do not short-circuit the load.
Although error is displayed when the load at the output part has a short circuit, generated over current may lead to the
damage of the product.
•Do not press the setting buttons with a sharp pointed object.
It may damage the setting buttons.
•If using the product to detect very small pressure rates, warm up the product for 10 to 15 minutes first.
There will be a drift on the display or the analogue output of approximate 1% immediately after the power supply
is turned on, within 10 minutes.
•Perform settings suitable for the operating conditions.
Incorrect setting can cause operation failure.
For details of each setting, refer to page 19 to 65 of this manual.
•Do not touch the LCD during operation.
The display can vary due to static electricity.
Maintenance
•Turn OFF the power supply before maintenance.
There is a risk of unexpected malfunction.
•Perform regular maintenance and inspections.
There is a risk of unexpected malfunction.
•Do not use solvents such as benzene, thinner etc. to clean the product.
They could damage the surface of the body and erase the markings on the body.
Use a soft cloth to remove stains. For heavy stains, use a cloth soaked with diluted neutral detergent and fully
squeezed, then wipe up the stains again with a dry cloth.

-8-
No.PF※※-OMZ0005
Model Indication and How to Order
○Accessories/Part numbers
If an option is required independently, order with the following part numbers.
Items
Part No.
Remarks
Sensor connector (For PFMV5)
ZS-28-C
Bracket A
ZS-46-A1
Self tapping screws: Nominal size 3 x 8L (2 pcs.)
Bracket B
ZS-46-A2
Self tapping screws: Nominal size 3 x 8L (2 pcs.)
Panel mount adapter
ZS-46-B
Panel mount adapter + Front protective cover
ZS-46-D
Lead wire with connector
ZS-46-5L
5 cores, 2 m
Front protective cover
ZS-27-01

-9-
No.PF※※-OMZ0005
Summary of Product parts
○Names of individual parts
Operation light: Displays the switch operating condition.
LCD display: Displays the current status of flow, setting mode, selected display units and error code.
4 types of display can be selected for the main display: Single colour of constant red or green;
or switching from red to green or green to red corresponding to the output.
The indication for the sub display is orange.
UP button: Increases mode and ON/OFF set values.
DOWN button: Decreases mode and ON/OFF set values.
SET button: Press this button to change mode and to confirm settings.
Unit display: Indicates the units currently selected.

-10-
No.PF※※-OMZ0005
■Definition and terminology
Term
Definition
A
Analogue output
An Output value proportional to the flow rate. When the analogue output is in
the range of 1 to 5 V, it will vary between 1 to 5 V according to the flow rate
change. The same occurs for analogue output of 0 to 10 V and 4 to 20 mA.
Auto-shift
Function where the switch output state is determined by the change in
instantaneous flow rate, relative to a reference value set when an external
input signal is received.
Auto-shift zero
The same as auto-shift, but in addition the display is set to zero when the
external input signal is received, and therefore the display indicates the change
of instantaneous flow from the reference value.
Auto-preset
This function calculates and sets the flow values automatically based on the
ongoing operation.
B
Bottom value display (mode)
The minimum flow recorded from when the power was supplied to the present time.
C
Chattering
The problem of the switch output turning ON and OFF repeatedly around the set
value at high frequency due to the effect of pulsation.
Copy function
Function to copy the set values of the copy source to a copy destination.
D
Delay time
The setting time from when the connected flow sensor signal reaches the set
value, to when the ON-OFF output actually operates.Adjusting the delay time
can prevent the output from chattering.
Digit
(smallest settable increment)
How precisely the pressure can be displayed or set. When 1 digit = 1 L/min, the
value is displayed in increments of 1 L/min, e.g., 1, 2, 3, …, 99, 100.
Digital filter
Function to add digital filtering to any fluctuation in the input signal.
Smooth the fluctuation of the displayed value for sharp start up or fall of the flow.
When the function is used, digital filtering is reflected in the switch output
ON/OFF or analogue output. Output chattering or display flicker in
measurement mode can be reduced by setting the digital filter.
The response time indicates when the set value is 90% in relation to the step input.
Display accuracy
The maximum deviation between the displayed flow rate and the actual flow rate.
Display colour
Indicates the colour of the digital display.
Always green, always red, green (switch OFF) changing to red (switch ON), or
red (switch OFF) changing to green (switch ON) are available in window
comparator mode.
Display flow (voltage) range
The range of flow that can be displayed.
Display resolution
Indicates into how many units the rated flow range can be divided.
(Example: When the value can be displayed down to 0.01 L/min for a product
with a rated flow range of 1.0 L/min, the resolution is 1/100).
E
Energy saving mode
Operating mode in which the digital display turns off to reduce power consumption.
Error display
A code number displayed to identify the error code detected by the
self-diagnostic function of the product.
Refer to "Error indication function" on page 73 for details of the errors.
Error output
Switches the switch output to ON/OFF when an error is displayed.
F
F.S.
(full span/full scale)
This means "full span" or "full scale", and indicates a varied analogue output
range at a rated value.
For example, when the analogue output is 1 to 5 V, F.S. = 5 [V] - 1 [V] = 4 [V].
(Reference: 1%F.S. = 4 [V] x 1% = 0.04 [V])
Function selection mode
The mode in which setting of functions is performed. It is a separate menu from
the display setting. If any function settings need to be changed from the factory
default, each setting can be selected with "F". The setting items are: display
colour, display range, display units, operation mode, output type, delay time,
digital filter, power saving mode, security code, etc.

-11-
No.PF※※-OMZ0005
Term
Definition
H
Hysteresis
The difference between ON and OFF points used to prevent chattering.
Hysteresis can be effective in avoiding the effects of pulsation.
Hysteresis mode
Mode where the switch output will turn ON when the flow is greater than the set
value, and will turn OFF when the flow falls below the set value by the amount of
hysteresis or more.
I
Insulation resistance
The insulation resistance between the electrical circuit and the case.
K
Key-lock function
Function that prevents changes to the settings (disables button operation).
M
Maximum applied voltage
The maximum voltage that can be connected to the output of an NPN device.
Maximum load current
The maximum current that can flow to the switch output.
Measurement mode
Operating condition in which pressure is being detected and displayed, and the
switch function is working.
Minimum resolution
Refer to "digit".
N
Normal output
One of the switch output types. In hysteresis mode the switch output is turned
ON when flow equal to or greater than the switch output set value is detected. In
window comparator mode, the switch output is turned ON when flow between
the switch output set values (P1L to P1H) is detected.
O
Operation LED
An LED that turns on when the switch output is ON.
Operation mode
Operation selected from Hysteresis mode/ Window comparator mode/
Accumulated output mode/Accumulated pulse mode/ Error detection mode/
Output OFF mode.
Output
The operation principle of the switch output. Normal output and reverse output
can be selected.
P
Peak value display (mode)
The maximum flow rate recorded from when the power was supplied to the
present time.
R
Rated flow (voltage) range
The flow range within which the product will meet all published specifications.
Repeatability
The repeatability of the display or analogue output value, when the measured
flow quantity is repeatedly increased and decreased.
Resolution
Refer to "Display resolution".
Reversed output
One of the switch output types. In hysteresis mode the switch output is turned
ON when a flow less than or equal to the switch output set value is detected. In
window comparator mode, the switch output is turned ON when flow outside of
the switch output set values (n1L to n1H) is detected.
Ripple
A type of chattering.
S
Set point range
The flow range that can be set for the switch output.
Switch output
Output type that only has 2 possible states, ON or OFF. Sometimes referred to
as "ON-OFF output".
U
Units selection function
A function to select the display units other than the international units (SI units)
specified in Japanese measurement law. The product for use in Japan is not
equipped with this function.
W
Window comparator mode
An operating mode in which the switch output is turned on and off depending on
whether the flow is inside or outside a range of two set values.
Withstand voltage
A measure of the product’s resistance to a voltage applied between the
electrical circuit and case. The product may be damaged if a voltage above this
value is applied.
(The withstand voltage is not the supply voltage used to power the product).

-12-
No.PF※※-OMZ0005
Mounting and Installation
■Installation
○Mounting with bracket
●Mount the bracket to the body with mounting screws (Self tapping screws: Nominal size 3 x 8L (2 pcs.)),
then set the body to the specified position.
: Tighten the bracket mounting screws to a torque of 0.5±0.05 N•m.
Self tapping screws are used, and should not be re-used several times.
•Bracket A (Part No.: ZS-46-A1)
•Bracket B (Part No.: ZS-46-A2)

-13-
No.PF※※-OMZ0005
○Mounting with panel mount adapter
●Mount part (a) to the front of the body and fix it. Then insert the body with (a) into the panel until (a)
comes into contact with the panel front surface. Next, mount part (b) to the body from the rear and insert
it until (b) comes into contact with the panel for fixing.
•Panel mount adapter (Part No.: ZS-46-B)
Panel mount adapter + Front protective cover (Part No.: ZS-46-D)
: The panel mount adapter can be rotated through 90 degrees for mounting.
How to remove the panel mount adapter
●When removing the digital flow switch with panel mount adapter from the installation, pull it
forward while expanding the hooks on each side as shown below.
If the panel mount adapter is pulled forward with the hook caught, the product and the
adapter may be damaged.

-14-
No.PF※※-OMZ0005
■Wiring
○Wiring connections
●Connections should be made with the power supply turned off.
●Use a separate route for the product wiring and any power or high voltage wiring. Otherwise, malfunction
may result due to noise.
●If a commercially available switching power supply is used, be sure to ground the frame ground (FG)
terminal. If the switching power supply is connected for use, switching noise will be superimposed and it
will not be able to meet the product specifications. In that case, insert a noise filter such as a line noise
filter/ferrite between the switching power supplies or change the switching power supply to the series
power supply.
○How to use connector
Connector attachment/detachment
●When connecting the connector, insert it straight onto the pins, holding the lever and connector body, and
lock the connector by pushing the lever hook into the concave groove on the housing.
●To detach the connector, remove the hook from the groove by pressing the lever downward, and pull the
connector straight out.
Connector pin out

-15-
No.PF※※-OMZ0005
Attaching the connector to the sensor wire
•Strip the sensor wire as shown.
•Do not cut the insulator.
•Insert the corresponding wire colour shown in the table into the pin
number printed on the sensor connector, to the bottom.
Pin no.
Wire colour 
Description
1
Brown
DC(+)
2
NC
-
3
Blue
DC(-)
4
White
IN
: The wire colours shown is for the PFMV5 series cables.
•Check that the above preparation has been performed correctly, then part Ashown should be pressed in by
hand to make temporary connection.
•Part A should then be pressed in using a suitable tool, such as pliers.
•The sensor connector cannot be re-used once it has been fully crimped.
In cases of connection failure such as incorrect order of wires or incomplete insertion, please use a new
connector.
•If the sensor is not connected correctly "LLL" or "HHH" will be displayed.

-16-
No.PF※※-OMZ0005
○Internal circuit and wiring examples
PFGV301- - -
Output specification
RT/SV
•NPN open collector 2 output + Analogue output
Max.30 V, 80 mA
Residual voltage: 1 V or less
RT: Analogue output 1 to 5 V, 0 to 10 V
Output impedance 1 kΩ
SV: Analogue output 4 to 20 mA
Max. load impedance
Power supply voltage 12 V: 300 Ω
Power supply voltage 24 V: 600 Ω
RT/SV
•NPN open collector 2 output + External input
Max. 30 V, 80 mA
Residual voltage: 1 V or less
External input: Input voltage 0.4 V or less (reed or solid state), 30 msec or more

-17-
No.PF※※-OMZ0005
RT/SV/XY
•NPN open collector 2 output + Copy function
Max. 30 V, 80 mA
Residual voltage: 1 V or less
RT/SV
•PNP open collector 2 output + Analogue output
Max. 80 mA
Residual voltage: 1.5 V or less
RT: Analogue output 1 to 5 V, 0 to 10 V
Output impedance 1 kΩ
SV: Analogue output 4 to 20 mA
Max. load impedance
Power supply voltage 12 V: 300 Ω
Power supply voltage 24 V: 600 Ω

-18-
No.PF※※-OMZ0005
RT/SV
•PNP open collector 2 output + External input
Max. 80 mA
Residual voltage: 1.5 V or less
External input: Input voltage 0.4 V or less (reed or solid state), 30 msec or more
RT/SV/XY
•PNP open collector 2 output + Copy function
Max.30 V, 80 mA
Residual voltage: 1.5 V or less

-19-
No.PF※※-OMZ0005
Flow Setting
Default settings
When the flow exceeds the set value, the switch will be turned on.
When the flow falls below the set value by the amount of hysteresis or more, the switch will be turned off.
The default setting is that the output is turned ON at 3.00 [V] for the connected sensor range voltage.
Perform initial settings while referring to the "Outline of Settings" section (page 20).
