1INTRODUCTION
The SMC-1310 Panel Display is a reliable and cost effective way to process, log and display data from
Motion Reference Units and/or Weather sensors.
The SMC-1310 can receive data on multiple serial RS232, RS422, RS485 ports and over ethernet. The
panel display accepts data in NMEA formats and many proprietary formats.
Data can be transmitted from the display to another receiving device, via serial or ethernet using the
external output.
The data received can be displayed in one of the SMCs Monitoring System applications for graphical
presentation and data logging.
The SMC-1310 is intended to be used in indoor applications.
1.1 RECEIVING THE DISPLAY
Unpack the equipment and remove all the packaging materials and shipping carton.
The SMC-1310 Display is delivered in a cardboard box designed to protect it from damage during
transit.
When the Panel Display has been received, it must be inspected for damage during shipment. If
damage has occurred during transit, all the shipping cartons and packaging materials should be
stored for further investigation. If damage is visible, a claim for shipping damage must be filed
immediately.
Standard Delivered Items
•Display Panel
•USB memory
•Cable Connectors
Optional Items
•VESA mount
•Power adapter

5
SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu
1.2 SMC-1310 DIMENSIONS
All dimensions are in mm

6
SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu
Rear view showing VESA mounting holes.
1.3 INSTALLATION
SMC highly recommend that the SMC-1310 Data Display is attached to a wall or suitable surface
using a VESA compatible mounting.
The VESA spacing is 100 x 100 mm
The Panel PC should not be mounted outside.
1.3.1 INSTALLATION LOCATION RECOMMENDATIONS
Install the SMC-1310 Data Display in an area with free air flow. The SMC-1310 is a fanless device and
the air need to be able to circulate through the ventilation holes in the case.
Avoid positioning the display sensor in direct sunlight. Where possible the display should be mounted
away from heat sources.

7
SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu
1.4 ELECTRICAL & DATA CONNECTION
The underside of the display has several connectors.
2 x 8 pin data connection, phoenix style terminal blocks
1 x RJ45 Ethernet
1 x USB for external devices
1 x USB acting as a service port
1 x 2 pin DC power, terminal block
Starting from left
8 Pin terminal connectors
Pin
Terminal function
Details
1 & 9
Serial
Setting dependable, see below tables
2 & 10
Serial
Setting dependable, see below tables
3 & 11
Serial
Setting dependable, see below tables
4 & 12
Serial
Setting dependable, see below tables
5 & 13
Signal Ground
6 & 14
Signal Ground
7 & 15
VDC - Output
Power output 12…24 VDC for instrument
8 & 16
VDC+ Output
Power output 12…24 VDC for instrument
RJ45 connector
The RJ45 connector is a 10/100mbit type used for system remote access and ethernet
communication with the Panel Display. The RJ45 can be set to static mode or to DHCP
USB Connector
The top USB connector can be used to connect external devices for expansion, as for example USB to
serial ports.
The bottom USB connector is used as a service port and for software updates
2 Pin terminal connector
Pin
Terminal function
Details
7 & 15
VDC - Input
Power Input 12…24 VDC
8 & 16
VDC+ Input
Power Input 12…24 VDC
Refer to the tables in the Connecting a device section below for the position of the power and data
wire connections for each communication protocol operating mode, RS232, RS422 and RS485.

8
SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu
1.5 OPERATING MODES
The SMC-1310 has several serial operating modes.
To access the menu, click on the SMC logo > System > UART > Quad UART RS-232/RS-485 Controller.
Click on Edit to select the mode from the drop down menu shown below.

9
SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu
1.6 SERIAL PORT TERMINALS
The following selections can be made for the serial inputs and outputs, any of
Note:
Each table below has eight columns representing the eight terminals of each physical connector.
RS232 mode (4T/4R RS-232)
Position 1 … 8
COM1
RS232 TxD
COM1
RS232 RxD
COM2
RS232 TxD
COM2
RS232 RxD
Signal GND
Signal GND
VDC-
VDC+
Position 9 … 16
COM3
RS232 TxD
COM3
RS232 RxD
COM4
RS232 TxD
COM4
RS232 RxD
Signal GND
Signal GND
VDC-
VDC+
RS422 full duplex (2T/2R RS-422/RS-485-4w)
Position 1 … 8
COM1
RS422 Tx+
COM1
RS422 Rx+
COM1
RS422 Tx-
COM1
RS422 Rx-
Signal GND
Signal GND
VDC-
VDC+
Position 9 … 16
COM3
RS422 Tx+
COM3
RS422 Rx+
COM3
RS422 Tx-
COM3
RS422 Rx-
Signal GND
Signal GND
VDC-
VDC+
RS485 half duplex (2T/2R RS-485 & 2R RS-232)
Position 1 … 8
COM1
485 Data+
COM1
485 Data-
COM2
RS232Rx
Signal GND
Signal GND
VDC-
VDC+
Position 9 … 16
COM3
485 Data+
COM3
485 Data-
COM4
RS232 Rx
Signal GND
Signal GND
VDC-
VDC+
Mixed Protocol Full Duplex (2T/2R RS-232 & 1T/1R RS422/RS485-4w)
Position 1 … 8
COM1
RS232 TxD
COM1
RS232 RxD
COM2
RS232 TxD
COM2
RS232 RxD
Signal GND
Signal GND
VDC-
VDC+
Position 9 … 16
COM3
RS422 Tx+
COM3
RS422 Rx+
COM3
RS422 Tx-
COM3
RS422 Rx-
Signal GND
Signal GND
VDC-
VDC+
Mixed Protocol half Duplex (2T/3R RS-232 & 1T/1R RS485)
Position 1 … 8
COM1
RS232 TxD
COM1
RS232 RxD
COM2
RS232 TxD
COM2
RS232 RxD
Signal GND
Signal GND
VDC-
VDC+
Position 9 … 16
COM3
485 Data+
COM3
485 Data-
COM4
RS232 Rx
Signal GND
Signal GND
VDC-
VDC+

10
SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu
The attached device can also take its operating power from the terminal if required.
The operating power matches the input voltage. If the Panel Display operating power is 12VDC, the
voltage output supplied at the device connectors will be 12VDC.
1.6.1 DATA OUTPUT FORMATS
The SMC-1310 supports data output over serial and ethernet TCP or UDP, Modbus, SNMP and TCP.
The Serial and Ethernet string output can be formatted using predefined NMEA style data sentences
as below examples. Or by the user defining its own output strings
MWV Wind speed and angle
HDM Heading magnetic
HDT Heading true
XDR Transducer measurement
XDR Weather station message
GLL Geographic position, latitude / longitude
Note, each of the above has a two letter identifier than can be user defined, for example
WIXDR.

11
SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu
2MAINTENANCE
Cleaning
Clean the display with a soft cloth, any chemical cleaner may damage the display and void any
warranty.
3SERVICE AND WARRANTY
All products are inspected prior to shipment and SMC manufactured products are guaranteed against
defective material or workmanship for a period of two (2) calendar years after delivery date of
purchase.
SMC liabilities are limited to repair, replacement, or refund of the factory quoted price (SMC’s
option). SMC must be notified and provided with sufficient time to remedy any product deficiencies
that require factory attention. This time period may include but is not limited to standard production
lead times, travel time and raw material lead times. SMC will not be responsible for any charges
related to repair, installation, removal, re-installation, or any actual, incidental, liquidated, or
consequential damages. All claims by the buyer must be made in writing. All orders returned to SMC
must have an issued RMA number supplied by the SMC prior to shipment. Only SMC shall have the
authority to issue RMA numbers.
Any products manufactured by others supplied with and/or installed with SMC’s products are
covered by the original manufacturers’ warranty and are excluded from SMC’s warranty
SMC manufactured product must be sent to SMC for repair or replacement.
Please read the SMC Ship Motion Control terms and conditions for complete information.
3.1.1 LIABILITY
SMC shall have no liability under the warranties in respect of any defect in the Products arising from:
specifications or materials supplied by the Buyer; fair wear and tear; wilful damage or negligence of
the Buyer or its employees or agents; abnormal working conditions at the Buyer’s premises; failure to
follow SMC’s instructions (whether oral or in writing); misuse or alteration or repair of the Products
without SMC’s approval; or if the total price for the Products has not been paid.
SMC shall in no event be liable for any indirect or consequential, or punitive damages or cost of any
kind from any cause arising out of the sale, use or inability to use any product, including without
limitation, loss of profits, goodwill or business interruption. In case of failure in the product the

12
SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu
company is not liable to compensate the buyer with anything exceeding the cost of the product sold
by SMC.
The exclusion of liability in these Terms & Conditions shall not apply in respect of death or personal
injury caused by SMC’s negligence.
SMC shall not be bound by any representations or statements on the part of its employees or agents,
whether oral or in writing, including errors made in catalogues and other promotional materials.
Please read the SMC Ship Motion Control terms and conditions for complete information.
3.1.2 RESTRICTION OF WARRANTY
The warranty does not cover malfunction of the sensor generated from
-If the sensor case has been opened by the customer in an attempt to carry out repair work
-If the sensor has been fed with an over voltage in the power supply wires or the signal wires
The sensor electronics are shielded in a case of UV protected ABS plastic with O ring seals to prevent
damage from moisture.
The sensor should not be opened as this could affect the warranty on the unit. All operations inside
the sensor must be carried out by SMC personnel.

13
SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu
3.2 TECHNICAL SUPPORT
If you experience any problem, or you have a question regarding your sensor please contact your
local agents or SMC directly.
Refer to the SMC website at https://www.shipmotion.eu/
Please have the following information available
•Equipment Model Number
•Equipment Serial Number
•Fault Description
Worldwide Service contact
Telephone: [phone] (CET 8am –5pm)
E-mail: [email protected]
Return Procedure
If this is not possible to solve the problem a Ship Motion Control technician will issue a Return
Material Authorization Number (RMA#). Please be ready to provide the following information.
•Name
•Address
•Telephone, E-mail
•Equipment Model Number
•Equipment Serial Number
•Installation Date
If the Sensor is under warranty, repairs are free.
Pack the sensor in its original packaging, or suitable heavy packaging.
Mark the RMA# on the outside of the package
Return the Sensor, prepaid carrier to SMC

14
SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu
4TECHNICAL SPECIFICATIONS SMC-1310
System
Processor ARM based processor
Operating System Linux
Storage 8 GB
RAM 2 GB
Display size 10.1 inch
Brightness 800 cd/m2
Aspect Ratio 16:10
Resolution 1280x800
Viewing angle 89 degrees
Touch Type Capacitive
Mounting VESA 75x75mm
Communication
User configurable serial inputs.
2xRS232 or 2x RS422/RS485
USB A for data export
Ethernet
External output
Serial, Ethernet, SNMP, MODBUS TCP/RTU
Physical
Housing Material UV resistant ABS plastic
Dimensions (W x H x D) 260 x 178 x 42mm
Weight 1.2 kg
Terminal and PSU connectors included
Environmental
Operating Temperature 0° to +50° Celsius
MTBF (computed) 50 000 hours
IP22
Electrical
Power requirements 12 - 36 VDC
Power consumption 20W
Complies with the IEC 60945
Warranty & Support
2-year Limited Hardware & Software Warranty
Free Technical & Hardware support

15
SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu
5FAQ AND SUPPORT
If no communication is seen or bad data is displayed, please refer to the FAQs below which cover the
most common configuration problems.
Is the attached device sending data over RS232, RS422 or RS485?
Check which serial mode your sensor has been designed or configured for, RS422, RS232 or RS485.
The receiving comport on the SMC Display must match the sending data.
Check the wiring as per the Manufacturers guide to see which output is being used.
Data is being received but is either seen as bad data or wrong data.
Verify that there is a signal ground connected for RS232, if not the data would not be readable.
Are the cables connected correctly, Note: RS422 uses a cross over Tx+ to Rx+, Tx- to Rx- etc.
Check the wiring continuity through to the sensor.
