Wireless Barricade
Plus
Data Sheet
SMC7004WFW
11 Mbps Wireless Cable/DSL Broadband Router
The Barricade™ Plus Wireless Cable/DSL Broadband Router (SMC7004WFW) is
the ideal networking solution for both the home and business user.This platform
independent multi-functional router combines a 3-port 10/100 Mbps dual-speed
switch, an 802.11b wireless access point, and a robust Stateful Packet Inspection
(SPI) firewall into one convenient device.
The Barricade Plus Wireless Cable/DSL Broadband Router (SMC7004WFW)
provides a 10/100 Mbps WAN port for high-speed integration into your network.
Supporting Network Address Translation (NAT), the Barricade Plus can provide
simultaneous Internet access for up to 253 PCs. It allows the connection of
multiple users to the Internet using a single purchased IP address.This router has
a built-in DHCP server to auto-assign IP addresses to devices on your network.
By using the built-in web-based interface, you can configure this router to handle
IP routing and port forwarding through the Virtual Server option. For added
management, the router also has a full-featured Access Control option. This
integrated feature allows you to filter traffic through your network based on a
scheduled time, IP address, or MAC Address.
For wireless connectivity, the Barricade Plus supports 802.11b communication
at data ranges of 1, 2, 5.5, and 11Mbps. To secure this wireless connection, the
Barricade supports MAC address filtering and both 64- and 128- bit Wired
Equivalent Privacy (WEP). This integrated wireless technology allows you to
connect to your network up to 1000 feet away. Furthermore, this latest Barricade
Plus has two detachable antennas that can be replaced with SMC high gain
antennas for added performance and coverage.
The Barricade Plus Wireless Cable/DSL Broadband Router (SMC7004WFW) has
an integrated Stateful Packet Inspection (SPI) Firewall to provide a high level of
security against Denial of Service (DoS) attacks. This highly efficient SPI firewall
analyzes individual data packets as they pass through the Barricade Plus and
ensures that only authorized packets are allowed access to your network.
Features and Benefits
High Performance & Functionality
• Robust Stateful Packet Inspection (SPI) firewall security
• Access Control based on pre-defined scheduled time, IP address filtering and MAC
address filtering
•URL blocking to limit access to certain websites by entering a full URL address or a
keyword of the website.
•Hacker prevention and logging capability prevents DoS and common hacker attacks
•Built-in VPN (IPSec/PPTP Client and Server) support
•3-port 10/100 Mbps switch versatility plus 1 10/100 Mbps port for WAN connection
•Wireless operation at 11, 5.5, 2, 1 Mbps
•2 Detachable Antennas
•64-bit/128-bit WEP encryption and MAC address filtering
•Platform independent – works with PC or Mac
Product Model No Description
SMC7004WFW 11Mbps Wireless Cable/DSL Broadband Router with
integrated Access Point and VPN support
Wireless Barricade Plus

Specifications
Ports
•Three 10Base-T/100Base-TX RJ-45 LAN
Ports with Automatic-MDI/MDIX feature
•One 10Base-T/100Base-TX Broadband WAN
Port
Internet Sharing Methods
•Static IP
•Dynamic IP
•PPPoE
Protocols
•TCP/IP, PPTP/L2TP/IPSec Passthrough
(VPN)
•IPSec/PPTP Client &Server (VPN)
•MD5, SHA1
•DES, 3DES
•DNS
•SNTP
•NAT
•DHCP
•HTTP
•HTML
•PPP Internet Control Protocol
•PPP Authentication Protocol
•Point-to-Point Protocol
•SNMP
Cabling Type
•10Base-T: UTP/STP Category 3 or 5
•100Base-TX: UTP/STP Category 5 or better
Speed
•WAN Router: 10/100 Mbps (10Base-T/
100Base-TX)
•LAN: 10Mbps (10Base-T) or 100Mbps
(100Base-TX)
LEDs
•Power
•WAN
•WLAN
•Link
•Activity
NAT Router – Ethernet Interface
•IP, PPPoE
Wireless
•IEEE 802.11b for Wireless LAN
•11, 5.5, 2,1 Mbps data rate per channel, Auto
Fallback
•2.4-2.4835 GHz, Direct Sequence Spread
Spectrum
•Operating Range: up to 1000 feet
•2 Detachable Antennas
Encryption
•64-bit/128-bit WEP
Frequency
•2.4-2.4835 GHz for US, Canada and ETSI
•2.471-2.497GHz for Japan
Modulation Type
•CCK, BPSK,QPSK
Operating Channels
•11 Channels (US, Canada)
•13 Channels (ETSI)
•14 Channels (Japan)
Output Power
•>+15dBm
Receive sensitivity
•Min. -76dBm for 11Mbps;
•Min. -80dBm for 5.5/2/1 Mbps;
(@BER 10E-5)
Configuration and Management
•Web-based
Maximum Users
•NAT: 253 PCs
Features
•DHCP Client/Server, Stateful Packet
Inspection Firewall, One IPSec/PPTP
VPN Tunnel,NAT, Hacker Attack Prevention
and Logging
Upgrade Method
•Web
Standards
•802.11b
•802.3
•802.3u
•RFC
Certification
•FCC Class B
•VCCI Class B
•Industry Canada Class B
•EN55022 (CISPR 22) Class B
•C-Tick – AS/NZS 3548 (1995) Class B
•CE Mark
•ETSI 300.328
•MPT RCR STD33
•IEC 1000-4-2/3/4/6
•CSA
•UL
•EN60950 (TUV)
Size
•21.5 x 13.1 x 2.5 cm
Weight
•750g
Power
•9VDC, 1A
Tem perature
•0°C ~ 40°C in operating
•-25°C ~ 60°C in storage
Humidity
•15%~95% (non-condensing)
Warranty
•Limited Lifetime
