About This Guide
Purpose
This guide details the hardware features of the wireless AP/Router, including its physical
and performance-related characteristics, and how to install the device and use its
configuration software.
Audience
This guide is for PC users with a working knowledge of computers. You should be familiar
with Windows operating system concepts.
Conventions
The following conventions are used throughout this guide to show information:
Note: Emphasizes important information or calls your attention to related features or
instructions.
Caution: Alerts you to a potential hazard that could cause loss of data, or damage the
system or equipment.
Warning: Alerts you to a potential hazard that could cause personal injury.
Related Publications
The following publication gives basic information on how to install and use the wireless
AP/Router.
Quick Installation Guide
Also, as part of the wireless AP/Router’s software, there is online help that describes all
configuration related features.
Revision History
This section summarizes the changes in each revision of this guide.
September 2009 Revision
This is the first revision of this guide. This guide is valid for software release v1.0.1.0.

xi
Table of Contents
Chapter 1: Introduction 1-1
Package Checklist 1-1
Hardware Description 1-2
Antennas 1-2
LED Indicators 1-3
Ethernet RJ-45 Ports 1-4
Power Socket 1-4
Reset Button 1-4
WPS Button 1-4
Hardware Installation 1-5
Chapter 2: Installation 2-1
Gateway Mode 2-1
Bridge Mode 2-2
Chapter 3: Network Planning 3-1
Internet Gateway Router 3-1
LAN Access Point 3-2
Wireless Bridge 3-3
Chapter 4: Initial Configuration 4-1
Using the Setup Wizard 4-2
DHCP 4-3
Static IP 4-4
PPPoE 4-5
L2TP 4-6
PPTP 4-7
Chapter 5: System Configuration 5-1
Operation Mode configuration 5-4
Network Settings 5-4
WAN Setting 5-4
DHCP 5-5
Static IP 5-6
PPPoE 5-7

xii
Contents
L2TP 5-8
PPTP 5-9
LAN Setting 5-11
Advanced Routing 5-13
QoS Setting 5-15
ALG 5-16
Wireless Settings 5-16
Basic Settings 5-17
Advanced Wireless Settings 5-23
WLAN Security 5-28
Wi-Fi Protected Setup (WPS) 5-35
Station List 5-37
Firewall 5-37
MAC/IP/Port Filtering 5-38
Virtual Server Settings (Port Forwarding) 5-40
DMZ 5-41
System Security 5-42
Content Filtering 5-43
Administration Settings 5-44
System Management 5-44
Upgrade Firmware 5-47
Configuration Settings 5-48
System Status 5-49
Statistics 5-51
DHCP Clients 5-52
System Log 5-52
Reboot 5-53
Appendix A: Troubleshooting A-1
Appendix B: Specifications B-1
Appendix C: License Information C-1
The GNU General Public License C-1
Glossary
Index

1-1
Chapter 1: Introduction
The SMCWBR14S-N3 wireless AP/Router is an IEEE 802.11n wireless gateway
router that connects your Internet access device (cable or ADSL modem) to your PC
or local area network, or to its own secure wireless network.
The wireless AP/Router can be automatically configured with other Wi-Fi Protected
Setup (WPS) devices by simply pressing its WPS button. For more detailed
configuration, the unit can also be set up through its easy-to-use web interface.
Package Checklist
The wireless AP/Router package includes:
• 802.11b/g/n wireless AP/Router (
SMCWBR14S-N3 )
• RJ-45 Category 5 network cable
• AC power adapter
• Quick Installation Guide
• EZ Installation and Documentation CD
• Warranty Information Card
Inform your dealer if there are any incorrect, missing or damaged parts. If possible,
retain the carton, including the original packing materials. Use them again to repack
the product in case there is a need to return it.

Introduction
1-2
1
Hardware Description
Figure 1-1. Rear Panel
Antennas
The access point includes integrated MIMO antennas for wireless communications.
A MIMO antenna system uses two or more identical antennas to receive and
transmit signals, helping to increase data throughput and range. The antennas
transmit the outgoing signal as a toroidal sphere (doughnut shaped), with the
coverage extending most in a direction perpendicular to the antenna. The antenna
should be adjusted to an angle that provides the appropriate coverage for the
service area.
Antennas
WPS Button
Ethernet WAN
RJ-45 Port
Ethernet LAN
RJ-45 Ports
Power Socket
Reset Button

Hardware Description
1-3
1
LED Indicators
The wireless AP/Router includes eight status LED indicators, as described in the
following figure and table.
Figure 1-2. LED Indicators
*Slow blinking is an on-off cycle of once every 2 seconds.
**Fast blinking is an on-off cycle of once of every 0.5 seconds.
LED Status Description
POWER On Blue Indicates that the system is working normally.
WLAN On Blue Indicates the 802.11n radio is enabled.
Blinking
Blue Indicates the AP/Router has an established connection and is
transmitting and receiving data.
Off Indicates the 802.11n radio is disabled.
WPS On Indicates the WPS authentication of a device has been successfully
completed.
Fast Blinking
Blue** Indicates the WPS authentication of a client device is in progress.
If the WPS authentication of a device does not complete after 120
seconds, the LED changes to Slow Blinking.
Slow Blinking Blue* Indicates the WPS authentication of a device did not complete after
120 seconds. The LED status does not change until the user restarts
or disables the WPS connection.
Off Indicates that WPS is not in progress.
WAN On Blue Indicates a valid link on the WAN Ethernet port.
Blinking
Blue Indicates the data is being transmitting or receiving.
Off The Ethernet port has no valid link.
LAN (4 LEDs) On
Blue Indicates a valid link on the LAN Ethernet port.
Blinking
Blue Indicates the Ethernet port is connected and is transmitting or receiving.
Off The Ethernet port has no valid link.
Power
802.11n Link/Activity
WPS Authentication
WAN Link/Activity
LAN Link/Activity

Introduction
1-4
1
Ethernet RJ-45 Ports
The wireless AP/Router has the following RJ-45 ports:
• The four RJ-45 LAN ports are for connections to PCs or to a 10/100 Mbps network
switch.
• The RJ-45 WAN port is for connection to a DSL or cable modem, or to a LAN or
other device that provides your Internet access.
All RJ-45 ports auto-negotiate the operating speed to 10/100 Mbps, the mode to
half/full duplex, and the pin signals to MDI/MDI-X. Automatic MDI/MDI-X support
enables you to use straight-through cables for all network connections to PCs,
switches, or hubs.
Power Socket
The wireless AP/Router does not have a power switch. It is powered on when
connected to the AC power adapter, and the power adapter is connected to a power
source. The power adapter automatically adjusts to any voltage between 100-240
volts at 50 or 60 Hz. No voltage range settings are required.
Reset Button
The Reset button can be used to restart the wireless AP/Router or restore the
factory default configuration. If you press the button for less than 5 seconds, the
wireless AP/Router will restart. If you press and hold down the button for 5 seconds
or more, any configuration changes you may have made are removed and the
wireless AP/Router is restored to its factory default configuration.
WPS Button
Use the WPS button on the wireless AP/Router to automatically connect devices to
the network. Within two minutes, press the physical or virtual button on a single
wireless client device to enable it to join the WLAN.
The WPS configuration process may be initiated on any device. Only one client
device can connect with the wireless AP/Router after the WPS button is pressed.
There is no restriction to the order in which buttons are pressed.
Note: Any WPS-compatible devices could unintentionally join the WLAN if they are
within range during the two-minute set up period after the WPS button is pressed.
Note that only one device at a time can join the network when using the WPS
button.

Hardware Installation
1-5
1
Hardware Installation
1. Select a Site – Choose a proper place for the wireless AP/Router . In general,
the best location is at the center of your wireless coverage area, within line of
sight of all wireless devices. For optimum performance, consider these points:
• Mount the
wireless AP/Router as high as possible above any obstructions in
the coverage area.
• Avoid mounting next to or near building support columns or other
obstructions that may cause reduced signal or null zones in parts of the
coverage area.
• Mount away from any signal absorbing or reflecting structures (such as those
containing metal).
Note: When choosing a site for mounting the router on a wall, consider the accessibility
for network cabling.
2. Mount the Wireless AP/Router – The wireless AP/Router can be mounted on
any horizontal surface.
Mounting on a wall or wood surface – The access point should be mounted
only to a wall or wood surface that is at least 1/2-inch plywood or its
equivalent.
• For wall or wood surface mounting, use a cross-head screwdriver and the
20-mm M4 tap screws (not included). Or, drill two holes and insert two hooks.
• Mount the access point to the screws or hooks.
Note: Mount the router with the front panel facing upward so that the status LED
indicators are clearly visible.

Introduction
1-6
1

2-1
Chapter 2: Installation
The wireless AP/Router has two basic operating modes that can be set through the
web-based management interface. For information on setting the mode suitable for
your network environment, see “Operation Mode configuration” on page 5-4.
•Gateway Mode — A gateway mode that connects a wired LAN and wireless clients
to an Internet access device, such as a cable or DSL modem. This is the factory
set default mode.
•Bridge Mode — An access point mode that extends a wired LAN to wireless
clients.
In addition to these basic operating modes, the wireless interface supports a
Wireless Distribution System (WDS) link to another wireless AP/Router. These
advanced configurations are not described in this section. See “Network Planning”
on page 3-1 for more information.
In a basic configuration, how the wireless AP/Router is connected depends on the
operating mode. The following sections describe connections for basic Gateway
Mode and Bridge Mode operation.
Gateway Mode
In its default Gateway Mode, the wireless AP/Router forwards traffic between an
Internet connected cable or ADSL modem, and wired or wireless PCs or notebooks.
The basic connections are illustrated in the figure below.
Figure 2-1. Gateway Mode Connection
4.Set up wireless
devices
Notebook PC
3.Connect AC power
adapter to
power source
2.Connect LAN port
to PC
Cable/DSL Modem
1.Connect WAN port to
cable/DSL modem
Internet

Installation
2-2
2
To connect the wireless AP/Router in Gateway Mode for use as an Internet gateway,
follow these steps:
1. Connect an Ethernet cable from the wireless AP/Router’s WAN port to your
Internet connected cable or ADSL modem.
2. Connect an Ethernet cable from the wireless AP/Router’s LAN port to your PC.
Alternatively, you can connect to a workgroup switch to support multiple users.
The wireless AP/Router can support up to 253 wired and wireless users.
3. Power on the wireless AP/Router by connecting the AC power adapter and
plugging it into a power source.
Caution: Use ONLY the power adapter supplied with the wireless AP/Router. Otherwise,
the product may be damaged.
When you power on the wireless AP/Router, verify that the Power LED turns on
and that the other LED indicators start functioning as described under “LED
Indicators” on page 1-3.
4. Set up wireless devices by pressing the WPS button on the wireless AP/Router
or by using the web interface. See “Initial Configuration” on page 4-1 for more
information on accessing the web interface.
Bridge Mode
In Bridge Mode, the wireless AP/Router operates as a wireless access point,
extending a local wired network to associated wireless clients (PCs or notebooks
with wireless capability). From any nearby location, you can then make a wireless
connection to the wireless AP/Router and access the wired network resources,
including local servers and the Internet.
In Bridge Mode, the wireless AP/Router does not support gateway functions on its
WAN port. Both the LAN port and the WAN ports can be connected to a local
Ethernet LAN.
Note: Bridge Mode is not the factory default mode and must be manually set using the
web management interface.
