Smeg Dolce Stil Novo PM6954R User manual

PRECAUTIONS - 3391477A185/C
e
PRECAUTIONS 33
General safety instructions 33
Installation 37
Appliance purpose 38
This user manual 38
Manufacturer’s liability 39
Identification plate 39
Disposal 39
Energy efficiency information 39
To save energy 39
How to read the user manual 39
DESCRIPTION 40
General description 40
Control panel 41
Accessories 42
USE 42
Precautions 42
Preliminary operations 43
Using the accessories 43
Basic functions 43
Using the hob 43
Additional functions 46
Special functions 48
User menu 49
Safety features 50
Error notifications 51
CLEANING AND MAINTENANCE 51
Cleaning the hob 51
Cleaning the glass ceramic hob 52
What to do if... 52
INSTALLATION 53
Gas connection 53
Gas types and Countries 56
Burner and nozzle characteristics tables 56
Electrical connection 57
Power limitation procedure 58
Section cut from the countertop 58
Mounting 59
Fastening to the built-in cabinet 59
Instructions for the installer 60
We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com
These instructions apply only to the destination countries listed on the appliance's data plate.
This is a class 3 built-in hob.
PRECAUTIONS
General safety instructions
Risk of personal injury
• During use the appliance and
its accessible parts become
very hot. Keep children well
away from the appliance.
• Protect hands with heat resistant
gloves during use.
• Never try to put out a fire or
flames with water: Turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
• This appliance may only be
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
mental capacity, or lacking in
experience in the use of
electrical appliances, provided
that they are supervised or
have been given instructions on
the safe use of the appliance
and of the hazards associated
with it.
• Children must not play with the
appliance.
• Keep children under the age of
eight at a safe distance unless

34 - PRECAUTIONS 91477A185/C
they are constantly supervised.
• Keep children under the age of
8 away from the appliance
when it is in use.
• Cleaning and maintenance
must not be carried out by
unsupervised children.
• Make sure that the flame-
spreader crowns are correctly
positioned in their housings with
their respective burner caps.
• Be aware of how rapidly the
cooking zones heat up. Do not
place empty pans on the heat.
Danger of overheating.
• Activate the controls lock when
you have children or pets which
could reach the hob.
• Do not touch or clean the hob
surface during operation or
when the residual heat
indicator lights are still on.
• After use, switch off the plates.
Never rely solely on the
cookware detector.
• Supervise children carefully as
they cannot readily see the
residual heat indication. After
use the cooking zones remain
hot for a certain period of time
even if they have been turned
off. Keep children away from
the cooking zones.
• The cooking process must
always kept under control. A
short cooking process must be
continuously monitored.
• WARNING: Cooking foods
containing fat and/or oil
without monitoring them can be
dangerous and can cause a
fire.
• Fats and oils can catch fire if
they overheat. Do not leave the
appliance unattended while
preparing foods containing oils
or fats. If fats or oils catch fire,
never put water on them. Place
the lid on the pan and turn off
the relevant cooking zone.
• Do not use the Booster and/or
the Double Booster functions (if
present) to heat fats or oils. Fire
hazard.
• Do not place metal objects,
such as dishes or cutlery, on the
surface of the hob during
cooking as they may overheat.
• WARNING: leaving food
unattended when cooking
using fat or oil can be
dangerous and can cause a
fire. DO NOT attempt to
extinguish a fire with water. Turn
off the appliance and smother
the flames, for example with a
lid or a blanket.
• Do not cook foods in closed
tins or containers or plastic
containers.
• Do not use magnetic tins.
• Do not use trivets or other items
between the bottom of the pan
and the glass ceramic surface.
Danger of burns.
• Do not insert pointed metal
objects (cutlery or utensils) into
the slots in the appliance.

PRECAUTIONS - 3591477A185/C
e
• Do not use or store flammable
materials near the appliance or
directly underneath the hob.
• Switch off the appliance
immediately after use.
• Do not pull the cable to unplug
the appliance (if present).
•DONOTUSEAEROSOLSIN
THE VICINITY OF THIS
APPLIANCE WHILST IT IS IN
USE.
• DO NOT MODIFY THIS
APPLIANCE.
• Always wear personal
protective equipment (PPE)
before carrying out any work
on the appliance (installation,
maintenance, positioning or
moving).
• Do not clean the appliance if it
is still hot or in operation.
• After use the cooking zones
remain hot for a certain period
of time after they have been
turned off. Do not touch the hob
surfaces.
• Before performing any work on
the appliance, switch off the
power supply.
• Do not try to repair the
appliance yourself or without
the assistance of a qualified
technician.
• If the power cable becomes
damaged, contact technical
support immediately to arrange
for it to be replaced in order to
avoid possible hazards.
• If cracks or fissures form, or if
the glass ceramic cooking
surface breaks, turn off the
appliance immediately.
Disconnect the power supply
and call Technical Support.
• People who have pacemakers
or other similar devices fitted
must make sure that the
operation of these devices is
not affected by the induction
field, the frequency range of
which is between 20 and 50
kHz.
• In conformity with the provisions
regarding electromagnetic
compatibility, the
electromagnetic induction
cooking hob comes under
group 2 and class B (EN
55011).
• WARNING: A gas cooking
appliance produces heat,
humidity and combustion
products in the room where it is
installed. Make sure there is
good ventilation, especially
when the appliance is in use:
keep the natural ventilation
openings open or install a
mechanical ventilation device.
• Intensive and prolonged use of
the appliance may require
additional ventilation, for
example opening a window or
more effective ventilation; for
example by increasing the
power of any mechanical
suction devices.

36 - PRECAUTIONS 91477A185/C
Risk of damaging the appliance
• Do not use abrasive or
corrosive detergents (e.g.
scouring powders, stain
removers and metallic
sponges) on glass parts.
• Use wooden or plastic utensils.
• Do not sit on the appliance.
• Do not use the glass ceramic
cooking surface as a support
surface.
• Do not use the appliance as a
support surface.
• Do not obstruct ventilation
openings and heat dispersal
slots.
• Do not use the hob if the
pyrolytic cycle is taking place
inside any oven installed
below.
• Do not use steam jets to clean
the appliance.
• Never leave the appliance
unattended during cooking
operations where fats or oils
could be released, as these
could then heat up and catch
fire. Be very careful.
• Fire hazard: Never leave
objects on the cooking
surfaces.
• DO NOT FOR ANY REASON
USE THE APPLIANCE AS A
SPACE HEATER.
• Cooking vessels or griddle
plates should be placed inside
the perimeter of the hob.
• All pans must have smooth, flat
bottoms.
• If any liquid does boil over or
spill, remove the excess from
the hob.
• Take care not to spill acid
substances such as lemon juice
or vinegar on the hob.
• Do not spill sugar or sweet
mixtures on the hob during
cooking.
• Do not place materials or
substances that could melt or
catch fire (paper, plastic or
aluminium foil) on the
appliance while it is in use.
• Place the cookware directly on
the glass ceramic surface and
on the burners.
• Do not put empty pans or frying
pans cooking zones or burners
that are switched on.
• Do not use rough or abrasive
materials or sharp metal
scrapers.
• The glass ceramic surface is
highly resistant to impact.
However, prevent hard, solid
objects from falling on the
cooking surface as they may
cause it to break.
• Do not use cleaning products
containing chlorine, ammonia
or bleach on parts made of
steel or that have metallic
surface finishes (e.g. anodizing,
nickel- or chromium-plating).
• Do not wash removable parts
such as the hob pan support
grids, flame-spreader crowns
and burner caps in the

PRECAUTIONS - 3791477A185/C
e
dishwasher.
• This appliance is not designed
to operate with external timers
or with remote-control systems.
Installation
• THIS APPLIANCE MUST NOT
BE INSTALLED IN BOATS OR
CARAVANS.
• This appliance must not be
installed on a dishwasher.
• Position the appliance into the
cabinet cut-out with the help of
a second person.
• Before installation, make sure
that the local distribution
conditions (type and pressure
of the gas) and the regulation
of the appliance are
compatible.
• This appliance is not connected
to a system for extracting
combustion products. It should
be installed and connected in
compliance with current
installation regulations. Pay
particular attention to the
requirements regarding
ventilation.
• The settings for this appliance
are shown on the gas settings
label.
• Have the gas connection
performed by authorised
personnel.
• Have the electrical connection
performed by authorised
technical personnel.
• Installation using a hose must
be carried out so that the length
of the hose does not exceed 2
metres when fully extended for
steel hoses and 1.5 metres for
rubber hoses.
• The gas connection hoses must
not come into contact with
moving parts of the built-in
module (for example a drawer)
and must not be routed through
a space that could cause it to
be pinched.
• If required, use a pressure
regulator that complies with
current regulations.
• After carrying out any
operation, check that the
tightening torque of gas
connections is between 10 Nm
and 15 Nm.
• At the end of the installation,
check for any leaks with a
soapy solution, never with a
flame.
• Check that the carcase has the
required openings.
• Check that the carcase material
is heat resistant.
• Installation and servicing should
be carried out by qualified
personnel in accordance with
current standards.
• The appliance must be
connected to earth in
compliance with electrical
system safety standards.
• Use cables that can withstand
temperatures of at least 90°C.
• Run the power cable in the rear
part of the unit. Make sure that

38 - PRECAUTIONS 91477A185/C
it does not come into contact
with the lower part of the hob
or a built-in oven below it.
• Be careful when connecting
additional electrical
appliances. Connection cables
must not come into contact with
hot cooking zones.
• The tightening torque of the
screws of the terminal supply
wires must be 1.5 - 2 Nm.
• Do not attach the appliance
too tightly to the unit as this
could cause damage during
use or partially obstruct the heat
dispersal slots.
• The power cable must only be
installed or replaced by a
qualified technician.
• If the power cable becomes
damaged, contact technical
support immediately to arrange
for it to be replaced in order to
avoid possible hazards.
• Always use any necessary/
required personal protective
equipment (PPE) before
performing any work on the
appliance (installation,
maintenance, positioning or
movement).
• Before performing any work on
the appliance, switch off the
power supply.
• Allow the appliance to be
disconnected after installation,
via an accessible plug or a
switch in the case of a fixed
connection.
• Fit the power line with an all-
pole circuit breaker with a
contact separation distance
sufficient to provide complete
disconnection in category III
overvoltage conditions,
pursuant to installation
regulations.
• This appliance can be used up
to a maximum altitude of 2,000
metres above sea level.
For this appliance
• The induction cooking zones
are independent from the gas
burners. The gas burners can
be used while the induction
zones are switched off and vice
versa.
Appliance purpose
This appliance is intended for
cooking food in the home
environment. Every other use is
considered inappropriate. It
cannot be used:
• in employee kitchens, shops,
offices and other working
environments.
• in farms/farmhouses.
• by guests in hotels, motels and
residential environments.
• In bed and breakfast
accommodation.
This user manual
• This user manual is an integral part of the
appliance and must therefore be kept in its
entirety and within the user's reach for the
whole working life of the appliance.
• Read this user manual carefully before using
the appliance.

PRECAUTIONS - 3991477A185/C
e
• The explanations in this manual include
images, which describe all that regularly
appears on the display. However, it should
be kept in mind that the appliance may be
equipped with an updated version of the
system, and as such, all that appears on the
display may differ from those in the manual.
Manufacturer’s liability
The manufacturer declines all liability for
damage to persons or property caused by:
• use of the appliance other than that
specified;
• failure to comply with the instructions in the
user manual;
• tampering with any part of the appliance;
• use of non-original spare parts.
Identification plate
The identification plate bears the technical data,
serial number and brand name of the
appliance. Do not remove the identification
plate for any reason.
Disposal
This appliance conforms to the WEEE
European directive (2012/19/EU) and
must be disposed of separately from
other waste at the end of its service life.
The appliance does not contain substances in
quantities sufficient to be considered hazardous
to health and the environment, in accordance
with current European directives.
To dispose of the appliance:
• Cut the power cable and remove it.
• Deliver the appliance to the appropriate
recycling centre for electrical and electronic
equipment waste, or return it to the retailer
when purchasing an equivalent product, on
a one for one basis.
Our appliances are packaged in non-polluting
and recyclable materials.
• Deliver the packing materials to the
appropriate recycling centre.
Energy efficiency information
The information according to the European
ecodesign directive can be found in a separate
document together with the product instructions.
This information can be found in the "Product
information sheet" that can be downloaded
from the page for the specific product on the
website.
To save energy
• The diameter of the base of the pan must not
extend beyond the lines printed on the glass
ceramic surface.
• Pans must not be placed outside the
perimeter of the hob or on the display.
• When buying a pan, check whether the
diameter indicated is that of the base or the
top of the pan, as the top is almost always
larger than the base.
• When preparing dishes with long cooking
times, you can save time and energy by
using a pressure cooker, which also helps to
retain vitamins contained in the food.
• Make sure that the pressure cooker contains
enough liquid as, if there is not enough and
it overheats, this may cause damage to both
the pressure cooker and the cooking zone.
• If possible, always cover pans with a
suitable lid.
• Choose a pan suitable for the quantity of
food to be cooked. A large, half-empty
saucepan leads to a waste of energy.
How to read the user manual
This user manual uses the following reading
conventions:
Power voltage
Danger of electrocution
• Disconnect the mains power supply.
• Unplug the appliance.
Plastic packaging
Danger of suffocation
• Do not leave the packaging or any part of it
unattended.
• Do not let children play with the plastic
bags.
Under certain circumstances, if the hob
and the oven are used at the same time,
the maximum power limit of the
electrical system might be exceeded.
Warning/Caution

40 - DESCRIPTION 91477A185/C
DESCRIPTION
General description
• 1, 2: Induction cooking zones
• 3: Control panel
• AUX: Auxiliary burner
• R: Rapid burner
• UR-3c: Ultra-rapid triple crown burner
• UR: Ultra-rapid burner
• A: 65 cm models.
•B:75cmmodels.
•C:90cmmodels.
*Power levels are approximate and may vary according to the pan used or the settings made.
Information/Advice
Zone Dimensions H x L
(mm)
Max. power draw
(W)*
Power draw in
booster function (W)
*
Power draw in Dou-
ble Booster function
(W)*
1 - 2
Single zones 182 x 218 2100 2500 3000
1 - 2
Bridge function 365 x 218 1500 1850 -

DESCRIPTION - 4191477A185/C
e
Control panel
Cooking zones area
List of buttons
Scroll bar: increases or decreases the power
level of a cooking zone.
Warming function button: activates the
keep warm function.
List of icons
Scroll bar and cooking: zone display: indicate
the power level that has been selected for a
cooking zone.
Warming function icon: indicates the
activation of the keep warm function.
Key icon: indicates the activation of the
controls lock function.
Clock icon: indicates the timing of a
cooking zone.
, Bridge function icons: indicate the
activation of the Bridge function.
Main controls area
On/Off button: turns the hob on or off.
Auto-Vent 2.0 function button: activates
communication between the hob and the
extractor hood (on some models only).
Grill function button: activates the Grill
function.
, Increase and decrease buttons.
Minute minder timer icon: indicates the
activation of the independent minute minder
timer.
Timer display.
Gas cooking zone
Rear zone
Front zone
Burner knobs
For lighting and adjusting the hob burners. Press
and turn the knobs anti-clockwise to in
If there is no symbol, it means that
the appliance is not designed for
wireless communication with the hood.

42 - USE 91477A185/C
order to light the relative burners. Turn the knobs
to the zone between the maximum and
minimum setting to adjust the flame. Return
the knobs to the position to turn off the
burners.
Advantages of induction cooking
• Energy saving thanks to the direct
transmission of energy to the pan (suitable
magnetisable cookware is required)
compared to traditional electric cooking.
• Improved safety as the energy is only
transmitted to the pan placed on the hob.
• High level of energy transmitted from the
induction cooking zone to the base of the
pan.
• Rapid heating speed.
• Reduced danger of burns as the cooking
surface is only heated under the base of the
pan; foods which overflow do not stick.
Power control
The hob is fitted with a power control module
that optimises/limits consumption. If the overall
set power level exceeds the maximum limit
permitted, the electronic circuit board will
automatically manage the power supplied by
the hot plates. The module tries to maintain the
maximum deliverable power levels. Levels set by
the automatic control will appear on the display.
Accessories
• Not all accessories are available on some
models.
• The accessories intended to come into
contact with food are made of materials that
comply with the provisions of current
legislation.
• Original supplied and optional accessories
can be requested to Authorised Assistance
Centres. Use only original accessories
supplied by the manufacturer.
Wok support
Useful when using a wok.
USE
Precautions
A gas leak can cause an explosion.
If you smell gas or there are faults in the gas
system:
• Immediately turn off the gas supply or close
the valve on the gas cylinder.
• Extinguish all naked flames and cigarettes.
• Do not turn on power switches or
appliances and do not remove plugs from
power sockets. Do not use phones or
mobile phones inside the building.
• Open the window in order to ventilate the
room.
• Call customer assistance services or your
gas supplier.
Malfunctions
Any of the following indicate a malfunction and
you should contact a service centre.
• The burners do not ignite properly.
• It is difficult to keep the burners lit.
• The burners go out when the appliance is in
use.
• It is difficult to turn the gas cocks.
The appliance is equipped with an
induction generator for each cooking
zone. Each generator located under the
glass ceramic cooking surface creates
an electromagnetic field which induces
a thermal current in the base of the pan.
This means the heat is no longer
transmitted from the hob to the pan but
created directly inside the pan by the
inductive current.
Priority is given to the last zone set.
The power control module does not
affect the total power consumption of
the appliance.
See General safety instructions.

USE - 4391477A185/C
e
Preliminary operations
To remove any moisture that may have
accumulated during the manufacturing process
in order for the electronic circuits and the
controls area to work correctly:
• Remove any protective film from the outside
or inside of the appliance, including any
accessories (if present).
• Remove any labels (apart from the technical
data plate).
Using the accessories
Trivet
The trivets and reduction pan supports must be
placed on the hob pan supports. Make sure
they are placed properly.
The trivet should only be used on the UR burner.
Cookware suitable for use in induction
cooking
Cookware used on the induction cooking
surface must be made of metal, with magnetic
properties and a sufficiently large base.
Suitable cookware:
• Enamelled steel cookware with thick bases.
• Cast iron cookware with an enamelled
base.
• Cookware in multilayer stainless steel, ferritic
stainless steel and aluminium with a special
base.
Unsuitable cookware:
• Copper, stainless steel, aluminium, fireproof
glass, wood, ceramic and terracotta
cookware.
Cookware diameters
To ensure that the appliance detects the
containers correctly and for best results, use the
pan sizes indicated in the following table.
Bear in mind the following:
• Pans should not extend beyond the lines
marked on the surface of the appliance.
• Do not place pans near to the edges of the
glass ceramic surface or close to the control
panel.
• If you use a griddle, it must have a maximum
size of and 36 x 20 cm for zones 1 - 2.
Practical tips for using the hob
For better burner efficiency and to minimise gas
consumption, use pans with lids and of suitable
size for the burner, so that the flames do not
reach up the sides of the pan. Once the contents
come to the boil, turn down the flame far
enough to ensure that the liquid does not boil
over.
Basic functions
First power connection
When connected to the power supply for the
first time, or after power has been switched
back on after a power failure, an automatic
check is carried out that control turns on the
indicator lights and the displays for a few
seconds. Afterwards, the appliance can be
used normally.
Switching on and off
Press and hold the button for at least one
second to switch on the appliance. To turn off
the appliance, press the button until a sound
is emitted. The appliance will switch off
automatically after about 10 seconds of
inactivity.
Using the hob
All the appliance’s control and monitoring
devices are located together on the front panel.
See General safety instructions. Cooking zones Minimum diam-
eter (mm)
Recommended
diameter (mm)
1 - 2 (Single) 90 - 110 170 - 190
1 - 2 (Bridge) 190 - 230 240
Burner Pan diameter
AUX 8 - 18 cm
R 20 - 26 cm
UR 20 - 30 cm
UR-3c 20 - 30 cm

44 - USE 91477A185/C
The burner controlled by each knob is shown
next to the knob. The appliance is equipped
with an electronic ignition device. Simply press
the knob and turn it anti-clockwise to the
maximum flame symbol, until the burner ignites. If
the burner does not light in the first 15 seconds,
turn the knob to and wait 60 seconds
before trying again. After lighting, keep the knob
pressed in for a few seconds to allow the
thermocouple to heat up. The burner may go out
when the knob is released: In this case, the
thermocouple has not heated up sufficiently.
Wait a few moments and repeat the operation.
Keep the knob pressed in longer.
Correct positioning of the flame-spreader
crowns and burner caps
Before lighting the hob burners, make sure that
the flame-spreader crowns are correctly
positioned in their housings with their respective
burner caps. Make sure that the holes 1 in the
flame-spreader crowns are aligned with the
igniters 3 and thermocouples 2. Also ensure that
the flame-spreader crowns are correctly
engaged in the burner holes.
Correct positioning of the pan supports
Under the pan supports there are silicone rests
with a hole that must be centred onto the
matching fixing pins on the surface.
Make sure that the pan supports are simply
centred on their respective burners, without
forcing them to be raised or tilted. If they are,
repeat the positioning procedure.
If you find that a pan is particularly unstable,
make sure that the grids have not been
positioned incorrectly.
Switching on the cooking zones
After switching on the display:
1. Position a pan (suitable for induction
cooking and not empty) on the cooking
zone you wish to use.
2. The display corresponding to the zone on
which the container has been placed turns
on automatically and displays .
Adjusting cooking zones
After having placed a pan on the cooking zone
and made sure that the zone has been
activated:
1. Place a finger on the left-hand side of the
scroll bar of the cooking zone to be used.
The power level is now .
2. Move your finger to the left or right to select
the power level from 1 to 9 or enable the
In case of an accidental switching off, a
safety device will be tripped, cutting off
the gas supply, even if the gas cock is
open. Return the knob to and wait
at least 60 seconds before lighting it
again.
The appliance is fitted with an automatic
pan sensing system.

USE - 4591477A185/C
e
Booster or Double Booster function (see
specific sections).
The display of the zone being used will indicate
the selected power level.
Switching off the cooking zones
1. Move your finger to the far left of the scroll
bar of the cooking zone you wish to turn off.
1. The display of the zone selected indicates
.
Power level table
The power in the cooking zones can be
adjusted to various levels. In the table below
you will find instructions for the different types of
cooking.
Booster function
The Booster function allows you to heat a pan at
maximum power for a limited amount of time. It
can be used to bring a large amount of water to
the boil rapidly.
After switching on the hob and having selected
a zone:
1. Swipe your finger from the far left to the far
right of the scroll bar.
2. The Booster function will be activated and
the symbol appears on the cooking
zone display.
To deactivate the Booster function, simply
decrease the power level of the cooking zone
or switch off the appliance.
Double Booster Function
The Double Booster function allows more
power to be supplied compared to the Booster
function.
After having activated the Booster function for a
cooking zone, press the far right of the scroll bar
again. The symbols , and will be
displayed in sequence to indicate that the
Double Booster function is on.
To deactivate the function, simply select any
other power level or switch off the appliance.
The power level can also be selected
by pressing the scroll bar at the point
that corresponds to the required power
level.
To switch off more than one cooking
zone at the same time, simply switch off
the appliance using the button.
Power level Suitable for:
0 OFF setting
from 1 to 2 Cooking small amounts of food
(minimum power)
from 3 to 4 Cooking
from 5 to 6 Cooking large quantities of food,
roasting larger portions
from 7 to 8 Roasting, slow frying with flour
9 Roasting
, ,
Bring a large amount of water to
the boil (maximum power, see
"Booster Function” and “Double
Booster Function")
See General safety instructions.
The Booster function can also be
activated by a pressing the right end of
the scroll bar once.
The Booster function remains active for
a maximum of 5 minutes, after which the
power level of the zone returns to 9.
See General safety instructions.

46 - USE 91477A185/C
Bridge function (on some zones only)
This function allows you to operate two cooking
zones (front and rear) at the same time when
using pans such as fish kettles or long pans.
After switching on the hob:
1. Place two small pans or one long pan on
the vertically connected zones.
2. The displays of the cooking zones involved
indicate .
3. The flashing and symbols appear
at the side of the displays. These symbols
indicate that the Bridge function can be
activated.
To activate the Bridge function:
1. Touch the scroll bars of the relevant zones at
the same time. The and symbols
stop flashing.
2. Once the function has been activated, only
the left hand side zone display remains
active.
3. Use the left-hand side scroll bar to set the
required cooking power for both zones.
If a large, oval or oblong pan is being used,
make sure that it is placed in the centre of the
cooking zone.
Correct pan position
INCORRECT pan position
Examples of griddle position
Additional functions
Independent minute minder timer
This function is used to set a timer that will emit a
sound at the end of the set time. It does not stop
the operation of the cooking zones but informs
the user when the set minutes have elapsed.
After having switched on the hob, without
having activated a cooking zone:
1. Press the and buttons at the same
time. The icon will appear between
them.
2. The timer display shows .
3. Use the and buttons to select the
required time; hold the buttons down to
advance more quickly.
4. After a few seconds, the timer will start the
countdown and the dot between the first
and second digit will start to flash.
5. When the time elapses, a series of beeps
will sound. Press the or button to
deactivate the buzzer.
This function automatically divides the
power equally between both zones that
are in use.
After having arranged the pans (when
switching on or with the hob already
on), if you wish to use two zones
independently, wait 5 seconds until the
and symbols disappear.
It is not possible to activate the Double
Booster function for the cooking zones
on which the Bridge function is active.
A maximum of 1 hour and 59 minutes
can be set.

USE - 4791477A185/C
e
Modifying and deactivating the minute
minder timer
To modify or deactivate the timer during the
countdown:
1. Press the button to activate the hob (if it
is off or in stand-by).
2. Press the and buttons together.
3. Use the and buttons to modify the
countdown or reset the timer. The timer has
to be turned off in order to reset it.
Increasing and decreasing the minute minder
timer (touch by touch)
Increasing and decreasing the minute minder
timer (fast advance).
Timed cooking
This function is used to program the automatic
switch-off of each cooking zone at the end of a
period of time set by the user.
1. Place a pan on a cooking zone and select
a power level.
2. Press the and buttons at the same
time. The icon appears next to the
cooking zone display.
3. Use the and buttons to select the
required time; press and hold to advance
more quickly.
4. Timed cooking will start a few seconds after
the last selection.
5. When the time elapses, a series of beeps
will sound. Press the or button to
deactivate the buzzer.
Modifying or deactivating timed cooking
To modify or reset timed cooking, simply follow
the same instructions for modifying or resetting
the minute minder timer. If several timed cooking
functions have been set, press the and
buttons at the same time to move between the
timers of each zone and modify them one by
one.
Each selected timer is indicated by the icon
at full brightness, while the other icons are
partially dimmed.
Rapid heating
This function heats a cooking zone to the
maximum and allows it to reach the heat
corresponding to the selected power level more
quickly.
After selecting a cooking zone:
1. Press and hold the scroll bar at the required
power level (1 to 9) for at least 3 seconds.
2. The symbol appears on the display of
the zone alternating with the selected power
level.
3. After the heating time has elapsed, the
cooking zone reverts to the previously
selected power level.
- +
from 0 to 5 min-
utes 10 sec. 1 minute
from 5 to 9 min-
utes 30 sec. 1 minute
9 minutes and
upwards 1 minute 1 minute
- +
from 0 to 10 min-
utes 1 minute 1 minute
from 10 min. to 1
hour 5 minutes 5 minutes
from 1 hour to 1
hour and 59 min-
utes
5 minutes 5 minutes
With a time of 10 minutes or more, the
icon appears below the timer
display.
A maximum of 1 hour and 59 minutes
can be set.
• This function can be activated on
multiple cooking zones at the same
time.
• When the timer of another cooking
zone is activated, the icon of
the previously selected zone will
dim slightly.
An independent timer can always be
set during one or several timed cooking
functions.
This function is not available for power
the Warming, Booster and Double
Booster functions.

48 - USE 91477A185/C
This function can be deactivated by selecting
and a different power level or by switching the
appliance off.
Pause function (on some models only)
This function allows you to pause the operation
of all the cooking zones.
To activate the Pause function:
1. With at least one cooking zone active, press
the and buttons at the same time.
2. appears on the displays of all the
cooking zones.
To deactivate the Pause function:
1. Press the and buttons together. An
animation appears on the rear right zone
scroll bar.
2. Move your finger from left to right on the
scroll bar.
3. The Pause function has now been
deactivated and the previously set functions
are restored.
Recall Function (on some models only)
This is used to restore some functions that have
already been started after the appliance has
been switched off unintentionally.
In this case, carry out the following procedure
within 6 seconds:
1. Switch on the appliance.
• The LEDs above the and buttons
start to flash.
2. Press the and buttons at the same
time to restore the functions that were
previously active.
The Recall function only allows the following
functions to be restored:
1 Functions and power levels of the cooking
zones.
2 Timed cooking.
3 Bridge Function.
4 Rapid heating.
5 Booster and Double Booster Functions.
6 Controls lock.
Special functions
Warming Function
To activate the Warming function, first turn on the
hob, then:
1. Place a pan on a cooking zone.
2. Press the button to activate the function.
The symbol appears on the display of
the selected cooking zone and the icon
will appear next to the scroll bar.
To turn off the Warming function, simply press
the button of the relative zone again.
Grill Function
To activate the Grill function:
1. Place a griddle or a long pan on the right
zones.
2. Press the button. The LED above it will
flash.
The symbol appears on the front zone
display and the symbol appears on the rear
zone display. The electronics will automatically
set the power level to 9 (preheating phase).
After 3 minutes of operation, the power will be
lowered to level 7 and the LED above the Grill
function button becomes steady.
Use the scroll bar to modify the power level at
any time.
Press the button to deactivate the Grill
The Pause function can be maintained
for a maximum of 10 minutes, after
which the appliance switches off.
The cooking time limitation, the residual
heat indicators and the Controls Lock
function remain enabled during the
Pause function.
This function can only be used if at least
one cooking zone was active at the
time of the unintentional switch-off.
Any functions not listed will not be
restored.
This function allows you to keep cooked
food warm or to keep water on the boil.
This function is used to activate the
Bridge function automatically for the
right zones only. It is used when using a
griddle or cooking with long pans.

USE - 4991477A185/C
e
function.
Auto-Vent 2.0 function (on some models
only)
The Auto-Vent 2.0 function is disabled by
default, but can be enabled from the user menu.
This function has an automatic and a manual
mode:
• Automatic mode adjusts the hood extractor
fan speed according to the total power of
the appliance (see “User menu - option U2).
• Manual mode allows you to adjust the
extractor fan speed by pressing the
button.
After switching on the hob, to activate manual
mode:
1. Press the button.
2. Each subsequent press of the button
increases the hood fan speed according to
a cyclic sequence with 5 levels of
adjustment, from 0 (off) to 4 (maximum
speed).
To go back to automatic mode, the appliance
has to be switched off and on again.
User menu
The user menu allows you to modify some
operating characteristics of the appliance. There
are 4 options are available. Each option is
marked with the letter “U” together with a
progressive number on the timer display.
Accessing the user menu
1. If the hob is off, switch it on using the
button.
2. Press again within 3 seconds to switch it
off; the icon starts to flash.
3. Press the and buttons at the same
time until the graph bars appear above the
scroll bars of the right zones.
4. Press the centre of both scroll bars at the
same time to complete the access
procedure.
User options
Once you have accessed the user menu, the first
option that appears is the power limitation
option (option U0), which should only be
modified by the installer (see "Power limitation
procedure").
Use the and buttons to move between
the options.
To select the values for each option, press the
left half of the scroll bar to scroll backwards and
the right half to scroll forwards.
Option U1 (on some models only) allows you to
activate or deactivate the Auto-Vent 2.0
function:
• 0: function off.
• 1: function on.
Option U2 (on some models only) allows you to
• This function allows you to control
the speed of the hood extractor fan
via a wireless connection.
• The hood must be designed to use
the Auto-Vent 2.0 function.
• The connection is always one way,
from the hob to the hood. It is not
possible to control the hob via the
hood.
Refer to the hood manual for more
detailed information.
Option Description
Power limitation (kW) - Modifica-
tion restricted to the installer
Activation and deactivation of the
Auto-Vent 2.0 function (on some
models only)
Auto-Vent 2.0 configuration in auto-
matic mode (on some models only)
Option restricted

50 - USE 91477A185/C
configure the Auto-Vent 2.0 function in
automatic mode. 8 values can be selected. The
following table shows a summary of the possible
settings:
Refer to the table below to select the most
suitable value according to the power limitation
of the appliance:
Exiting the user menu
There are two ways to exit from the user menu:
1 Press the and buttons at the same
time for at least two seconds. All
modifications will be saved and the hob will
be switched off. It will then have to be turned
back on.
Or
2 Press the button for at least two
seconds. Changes will not be saved and the
hob will restart, but it will still be powered.
Safety features
Limiting the cooking duration
The appliance has an automatic device that
limits the duration of use.
If the cooking settings for a pan are not
changed, the maximum operation time for each
zone depends on the power level selected.
Heating is switched off when the device for
limiting the duration of use is activated.
Residual heat indicators
After the cooking zone has been switched off, a
symbol appears on each display to indicate
whether the zone is still hot and indicates the
approximate temperature:
Protection from overheating
If the hob is used on full power for a long
period, the electronics will have trouble cooling
down if the room temperature is high.
When certain safety thresholds are reached, on
or more cooking zones are deactivated. At the
Hardness level Hood lighting Hood fan speed
Delicate cooking Medium cooking Intense cooking
0 Off Off
1On Off
2 - 4 - 6 On Off speed 1 speed 2
3 - 5 - 7 On speed 1 Speed 2 Speed 3
Hardness level Power limitation
2 - 3 up to 4 kW
4 - 5 from 4 to 5 kW
6 - 7 5 kW upwards
If the appliance is set to a lower power
level lower than the one indicated in the
table above, it may not be possible to
select some of the fan speeds.
For models that are not provided with a
wireless connection, options U1 and
U2 in the user menu will be visible, but
not accessible.
See General safety instructions.
Power level Maximum cooking duration in
hours
Warming 2
19
27
35½
44½
53½
63
72½
82
91½
Booster /
DBooster 10 minutes
Symbol Temperature
> 60°C
> 80°C
> 100°C

CLEANING AND MAINTENANCE - 5191477A185/C
e
end, if the internal temperature is very high, the
appliance is switched off automatically.
Controls lock (on some models only)
This is useful when cleaning the appliance and
to prevent functions being modified by mistake.
To activate the controls lock function, at least
one cooking zone has to be active:
• press the and buttons at the same
time for at least one second.
The Controls lock is active and the symbol is
shown for each cooking zone.
To deactivate the controls lock, press the
and buttons at the same time for at least one
second; the symbols disappear.
Controls lock (child safety)
To activate the controls lock function, the
appliance must be switched on, the cooking
zones must not be active and no timer must be
enabled:
• Press the and buttons at the same
time for at least 3 seconds.
The symbol will appear on the displays of
all the cooking zones and on the timer display.
To disable child lock, press buttons and
at the same time for at least 3 seconds.
Error notifications
If the appliance malfunctions or operates
incorrectly, the associated error code appears
on the display.
The error codes always begin with the letter “E”
or “Er” followed by a series of digits (e.g. “Er47-
30”).
Errors coded as:
• “E02”
•“E2”
• “Er21”
Indicate that the appliance or part of it is
overheating. If this occurs, you should switch off
the appliance immediately, remove all pans and
let it cool down.
If these errors persist or if other errors appear,
make a note of the code and contact Technical
Support.
CLEANING AND MAINTENANCE
Cleaning the hob
Cooking hob pan support grids
Remove the pan support grids and clean them in
lukewarm water and non-abrasive detergent.
Make sure to remove any encrustations. Dry
them thoroughly and return them to the hob.
Flame-spreader crown and burner caps
For easier cleaning, the flame-spreader crowns
and the burner caps can be removed. Wash
them in hot water and non-abrasive detergent.
Carefully remove any encrustation, then wait
until they are perfectly dry. Replace the flame-
spreader crowns, making sure that they are
correctly positioned in their housings with their
respective burner caps.
Igniters and thermocouples
For correct operation the igniters and
thermocouples must always be perfectly clean.
Check them frequently and clean them with a
damp cloth if necessary. Remove any dry
This feature is designed to lock all the
hob controls during operation, except
for the button.
This function prevents the appliance
from being switched on unintentionally,
for example by children.
The continuous contact between the
pan supports and the flame can cause
modifications to the enamel over time in
those parts exposed to heat. This is a
completely natural phenomenon which
has no effect on the operation of this
component.

52 - CLEANING AND MAINTENANCE 91477A185/C
residues with a wooden toothpick or a needle.
Cleaning the glass ceramic hob
Cleaning the surfaces
To keep the surfaces in good condition, they
should be cleaned regularly after use. Let them
cool first.
Ordinary daily cleaning
Always and only use specific products that do
not contain abrasives or chlorine-based acids.
Pour the product onto a damp cloth and wipe
the surface, rinse thoroughly and dry with a soft
cloth or a microfibre cloth.
Weekly cleaning
Clean and maintain the hob once a week using
an ordinary glass ceramic cleaning product.
Always follow the manufacturer’s instructions.
The silicon in these products creates a
protective, water-repellent membrane which
also resists dirt. All marks stay on the membrane
and can therefore be removed easily. After
cleaning, dry the surface with a clean cloth.
Make sure that there is no detergent left on the
cooking surface as it might undergo an
aggressive reaction when heated up and could
modify the structure of the cooking surface.
Food stains or residues
Light coloured marks from pans with aluminium
bases can be easily cleaned off with a cloth
moistened in vinegar. Remove any burnt-on
residues after cooking; then rinse with water and
dry thoroughly with a clean cloth. Dirt, which
may have fallen on the hob while cleaning
lettuce or potatoes, can scratch the hob when
moving pans. Consequently, remove any dirt
from the cooking surface immediately. Changes
in colour do not affect the operation and
stability of the glass. These are not alterations to
the material of the hob but just residues which
have not been removed and have then
carbonised. Shiny surfaces can form due to the
bases of pans, especially aluminium ones,
rubbing on the surface, and due to the use of
unsuitable detergents. They are difficult to
remove using conventional cleaning products. It
may be necessary to repeat the cleaning
process several times. Use of corrosive
detergents or rubbing of pan bases can wear
away the decoration on the hob over time and
contribute to the formation of stains.
What to do if...
The hob does not work:
• Make sure that the hob is connected and
that the main switch is turned on.
• Make sure that there is no power failure.
• Make sure that the fuse has not blown. In
this case replace the fuse.
• Make sure that the circuit breaker of the
residential electrical system has not tripped.
In this case, reset the circuit breaker.
The cooking results are unsatisfactory:
• Make sure that the cooking temperature is
not too high or too low.
• Make sure that the hob is properly
ventilated and that the air inlets are
unobstructed.
• Use cookware that is certified and tested for
induction cooking.
The hob smokes:
• Let the hob cool down and clean it once
cooking is complete.
• Make sure that the food has not spilled out
of the pan and use a larger cooking vessel,
if needed.
The fuses blow or the circuit breaker of the
residential electrical system trips repeatedly.
• Call Technical Support or an electrician.
There are cracks or fissures in the hob:
See General safety instructions.
We recommend the use of cleaning
products distributed by the
manufacturer.
After cleaning, dry the appliance
thoroughly to prevent any water or
detergent from interfering with its
operation or creating unsightly marks.
