Smeg SA611XC-1 Instruction Manual

INSTRUCTION OF USE
SA611XC-1

2
Dear customers,
Thank you for having chosen our ceramic hob.
In order to make the best use of your appliance, we would advise you to read carefully the
following notes and to keep them for later consulting.
SUMMARY
SAFETY.......................................................................................................................................3
PRECAUTIONS BEFORE USING......................................................................................................3
USING THE APPLIANCE................................................................................................................3
PRECAUTIONS NOT TO DAMAGE THE APPLIANCE ............................................................................4
PRECAUTIONS IN CASE OF APPLIANCE FAILURE..............................................................................4
OTHER PROTECTIONS.................................................................................................................4
DESCRIPTION OF THE APPLIANCE.........................................................................................5
TECHNICAL DATA........................................................................................................................5
CONTROL PANEL ........................................................................................................................5
USE..............................................................................................................................................5
SENSITIVE TOUCHES...................................................................................................................5
DISPLAY ....................................................................................................................................5
STARTING UP THE APPLIANCE...............................................................................................6
BEFORE USING YOUR NEW HOB....................................................................................................6
STARTING-UP.............................................................................................................................6
RESIDUAL HEAT INDICATION ........................................................................................................6
AUTOMATIC COOKING .................................................................................................................6
CONTROL PANEL LOCKING...........................................................................................................7
COOKING ADVICES...................................................................................................................7
EXAMPLES OF POWER SETTING:...................................................................................................7
MAINTENANCE AND CLEANING..............................................................................................7
WHAT TO DO IN CASE OF A PROBLEM..................................................................................8
ENVIRONMENT PROTECTION..................................................................................................8
INSTALLATION INSTRUCTIONS...............................................................................................9
ELECTRICAL CONNECTION ...................................................................................................11

3
Safety
Precautions before using
Unpack all the materials.
The installation and connecting of the appliance have to be done by approved
specialists. The manufacturer cannot be responsible for damage caused by installation or
connecting errors.
To be used, the appliance must be well-equipped and installed in a kitchen unit and an
adapted and approved work surface.
This domestic appliance is exclusively for the cooking of food, to the exclusion of any
other domestic, commercial or industrial use.
Remove all labels and self-adhesives from the ceramic glass.
Do not change or alter the appliance.
The cooking plate cannot be used as freestanding or as working surface.
The appliance must be grounded and connected conforming to local standards.
Do not use any extension cable to connect it.
The appliance cannot be used above a dishwasher or a tumble-dryer: as steam may
cause damage.
Using the appliance
Switch the heating zones off after using.
Keep an eye on the hob whilst cooking using grease or oils that may quickly ignite.
Be careful not to burn yourself while or after using the appliance.
Make sure no cable of any fixed or moving appliance contacts with the glass or the hot
saucepan.
Magnetically objects (credit cards, floppy disks, calculators) should not be placed near to
the engaged appliance.
Do not place any metallic object on the hob except for pans or cooking utensils. In case
of untimely engaging or residual heat, this one may heat, melt or even burn.
Never cover the appliance with a cloth or a protection sheet. This could become very hot
and catch fire.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Metallic objects such as knives, forks, spoons and lids should not be placed on the hob
surface since they can get hot.

4
Precautions not to damage the appliance
Raw pan bottoms or damaged saucepans (not enamelled cast iron pots,) may damage
the ceramic glass.
Sand or other abrasive materials may damage ceramic glass.
Avoid dropping objects, even little ones, on the vitroceramic.
Do not hit the edges of the glass with saucepans.
Make sure that the ventilation of the appliance works according to the manufacturer’s
instructions.
Do not put or leave empty saucepans on the vitroceramic hobs.
Sugar, synthetic materials or aluminium sheets must not contact with the heating zones.
These may cause breaks or other alterations of the vitroceramic glass by cooling: switch
on the appliance and take them immediately out of the hot heating zone (be careful: do
not burn yourself).
Never place any hot container over the control panel.
If a drawer is situated under the embedded appliance, make sure the space between the
content of the drawer and the underside of the appliance is large enough (2cm). This is
essential to guarantee correct ventilation.
Never put any inflammable object (ex. sprays) into the drawer situated under the
vitroceramic hob. All cutlery drawers must be resistant to heat.
Precautions in case of appliance failure
If a defect is noticed, switch off the appliance and turn off at the main electrical supply.
If the ceramic glass is cracked or fissured, you must unplug the appliance and contact
the after sales service.
Repairing has to be done by specialists. Do not open the appliance by yourself.
WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of
electric shock.
If the supply cor dis damaged, it must be replaced by a cable or special set available by
the manufacturer or his after sale service.
Other protections
Note sure that the container pan is always centred on the cooking zone. The bottom of
the pan must have to cover as much as possible the cooking zone.
For the users of pacemaker, the magnetic field could influence its operating. We
recommend getting information from the retailer or from the doctor.
Do not to use aluminium or synthetic material containers: they could melt on still hot
cooking zones.

5
DESCRIPTION OF THE APPLIANCE
Technical data
Type Total power Heating zone location Power Diameter
SA611XC-1 6000 W
Front left
Rear left
Rear right
Front right
1800 W
1200 W
1800 W
1200 W
190 mm
155 mm
190 mm
155 mm
Control panel
USE
Sensitive touches
Your ceramic hob is equipped with electronic controls with sensitive touch keys. When your
finger touches the key, the corresponding command is activated. This activation is validated by
a control light, a letter or a number in the display and/or a “beep” sound.
Touch only one key on the same time.
Display
Display Designation Function
0 Zero The heating zone is activated
1…9 Power level Selection of the cooking level
A Heat accelerator Automatic cooking
E Error message Electronic failure
H Residual heat The heating zone is hot
L Locking The control panel is locked
[ - ] key for all 4
heating zones
[ + ] key
Power display
On/Off key

6
STARTING UP THE APPLIANCE
Before using your new hob
Clean your hob with a damp cloth, and then dry the surface thoroughly. Do not use detergent
which risks causing blue-tinted colour on the glass surface.
Starting-up
Start-up/ switch off the hob
Action Control panel Display
To start press key [ 0/I ] 4 x [ 0 ]
To stop press key [ 0/I ] nothing or [ H ]
Start-up/ switch off a heating zone
Action Control panel Display
Increase power press key [ + ] [ 1 ] to [ 9 ]
Decrease power press key [ - ] [ 9 ] to [ 1 ]
Stop press simultaneous [ + ] and [ - ] [ 0 ] or [ H ]
or press key [ - ] [ 0 ] or [ H ]
Residual heat indication
After the switch-off of the hob, the heating zone is still hot and indicates [ H ] on the display.
The symbol [ H ] disappears when the heating zone may be touched safely.
When the residual heat indicator light is on,don’t touch the heating zone and don’t put any heat
sensitive object on them. There are risks of burn and fire.
Automatic cooking
All the cooking zones are equipped with an automatic “go and stop” cooking device. The
cooking zone starts at full power during a certain time, then reduces automatically its power on
the preselected level.
Start-up :
Action Control panel Display
Zone selection press key [ + ] from the zone [ 0 ]
Full power setting repress key [ + ] [ 1 ] to [ 9 ]
Automatic cooking repress key [ + ] [ 9 ] is blinking with [A]
Power level selection press key [ - ] [ 9 ] wents to [ 8 ] [ 7 ]
(for example « 7 ») [ 7 ] is blinking with [A]
Switching off the automatic cooking :
Action Control panel Display
Zone selection press key [ + ] from the zone [ 7 ] is blinking with [A]
(for example « 7 »)
Power level selection press key [ - ] or [ + ] Level selected

7
Control panel locking
To avoid modifying a setting of cooking zones, in particular with within the framework of
cleaning the control panel can be locked (with exception to the On/Off key [ 0/I ]).
Locking
Action Control panel Display
Start Press key [ 0/I ] [ 0 ] or [ H ] on 4 displays
Hob locking Press simultaneously [ - ]
and [ + ] at left No modification
Press key [ + ] [ L ] on 4 displays
Unlocking
Action Control panel Display
Start Press key [ 0/I ] [ L ] on 4 displays
In the 5 seconds after start:
Unlocking the hob Press simultaneously [ - ]
and [ + ] at left [ 0 ] or [ H ] on 4 displays
Press key [ - ] No light on the displays
COOKING ADVICES
Examples of power setting:
(The values below are indicative)
1 to 2 Melting, Reheating Sauces, butter, chocolate, gelatine
Dishes prepared beforehand
2 to 3 Simmering, Defrosting Rice, pudding, sugar syrup
Dried vegetables, fish, frozen products
3 to 4 Steam Vegetables, fish, meat
4 to 5 Water Steamed potatoes, soups, pasta, fresh vegetables
6 to 7 Medium cooking, Simmering Meat, liver, eggs, sausages,
7 to 8 Cooking Potatoes, fritters, waffles
9 Frying, roasting, Boiling water Steaks, omelettes, fried dishes, water
MAINTENANCE AND CLEANING
Switch-off the appliance before cleaning.
Do not clean the hob if the glass is too hot because they are risk of burn.
Remove light marks with a damp cloth with washing up liquid diluted in a little water.
Then rinse with cold water and dry the surface thoroughly.
Highly corrosive or abrasive detergents and cleaning equipment likely to cause scratches
must be absolutely avoided.
Do not ever use any steam-driven or pressure appliance.
Do not use any object that may scratch the ceramic glass.
Ensure that the pan is dry and clean. Ensure that there are no grains of dust on your
ceramic hob or on the pan. Sliding rough saucepans will scratch the surface.
Spillages of sugar, jam, jelly, etc. must be removed immediately. You will thus prevent
the surface being damaged.

8
WHAT TO DO IN CASE OF A PROBLEM
The hob or the cooking zone doesn’t start-up:
The hob is badly connected to the electrical system.
The protection fuse has blown.
The locking function is activated
The sensitive keys are covered by grease or water.
An object is covering the control panel.
The symbol [ E ] displays :
Call the After-sales Service.
One or all cooking zones cut-off:
The safety system has engaged
You forgot to cut-off the cooking zone for a long time.
One or more sensitive keys are covered.
The pan is empty and its bottom overheated.
The hob also has an automatic reduction of power level and breaking automatic
overheating.
ENVIRONMENT PROTECTION
The packaging material is ecological and can be recycled.
The worn appliances contain certain noble metals. Apply to the local government about
the possibilities of recycling.

Don't dispose of your appliance with general household
waste
Get in touch with the waste collection centre of your local
council that control the recycling of household appliances.

9
INSTALLATION INSTRUCTIONS
The installation comes under the exclusive responsibility of specialists.
The installer is held to respect the legislation and the standards enforce in his home country.
How to stick the gasket:
The gasket supplied with the hob avoids all infiltration of liquids in the cabinet.
His installation has to be done carefully, in conformity of the following drawing.
Stick the gasket (2) two millimeters
from the external edge of the glass,
after removing the protection sheet (3).
Over empty kitchen unit or drawers
If there are other pieces of furniture (lateral
wails, drawers, etc.) under the hob, a double-
layer wooden base must be installed at least
30 mm from the bottom of the hob to avoid
any accidental contact. It must only be
possible to remove the double-layer base
using suitable equipment.

10
Fitting - installing:
The cut out sizes are:
Reference Cut-size
SA611XC-1 560 x 490 mm
Ensure that there is a distance of 50 mm between the hob and the wall or sides.
The hobs are classified as “Y” class for heat protection. Ideally the hob should be
installed with plenty of space on either side. There may be a wall at the rear and tall units
or a wall at one side. On the other side, however, no unit or divider must stand
higher than the hob.
The piece of furniture or the support in which the hob is to be fitted, as well as the edges
of furniture, the laminate coatings and the glue used to fix them, must be able to resist
temperatures of up to 100 °C.
The mural rods of edge must be heat-resisting.
Not to install the hob to the top of a not ventilated oven or a dishwasher.
To guarantee under the bottom of the hob casing a space of 30 mm to ensure a good air
circulation of the electronic device.
If a drawer is placed under the work, avoid to put into this drawer flammable objects
(for example: sprays) or not heat-resistant objects.
Materials which are often used to make worktops expand on contact with water. To
protect the cut out edge, apply a coat of varnish or special sealant. Particular care must
be given to applying the adhesive joint supplied with the hob to prevent any leakage into
the supporting furniture. This gasket guaranties a correct seal when used in conjunction
with smooth work top surfaces.
The safety gap between the hob and the cooker hood placed above must respect the
indications of the hood manufacturer. In case of absence of instructions respect a
distance minimum of 760 mm.
The connection cord should be subjected, after building, with no mechanical constraint,
such for example of the fact of the drawer.

11
ELECTRICAL CONNECTION
The installation of this appliance and the connection to the electrical system should be
entrusted only to a qualified electrician.
Protection against the parts under tension must be ensured after instalation
The data of connection necessary are on the stickers place on the hob casing near the
connection box.
The connection to the mains must be made using an earthed plug or via an omnipolar
circuit breaking device with a contact opening of at least 3 mm.
The electrical circuit must be separated from the network by adapted devices, for
example: circuit breakers, fuses or contactors.
If the appliance is not fitted with an accessible plug, disconnecting means must be
incorporated in the fixed installation, in accordance with the installation regulations.
The inlet hose must be positioned so that it does not touch any of the hot parts of the hob
or even.
Caution!
This appliance has only to be connected to a network 230 V~ 50/60 Hz
Always connect the earth wire.
Respect the connection diagram.
The connection box is located underneath at the back of the hob casing. To open the cover, use
a medium screwdriver. Place it in the slits and open the cover.
( * ) calculated with the simultaneous factor following standard EN 60 335-2-6/1990
Connection of the hob
The ceramic hob can be connected in different ways (230V~ 1P+N or 400V~ 2P+N), use the
brass links which are in the box next to the terminal block.
Monophase 230V~1P+N
Put the link bar between terminal 1 and 2
Attach the earth to the terminal “earth”, the neutral N to terminal 4, the Phase L to one of the
terminals 1 or 2.
Biphase 400V~2P+N
Attach the earth to the terminal “earth”, the neutral N to terminal 4, the Phase L1 to the
terminals 1 and the Phase L2 to the terminal 2.
Caution! Frequent loosening and screwing of the screws on the connection box risks
damaging the efficiency of the tightness once screwed. It is therefore
advisable to keep screwing and unscrewing to a minimum.
Ensure that the cables are correctly inserted and tightly screwed down.
We cannot be held responsible for any accident resulting from incorrect connection or
which could arise from the use of an appliance which has not been earthed or has been
equipped with a faulty earth connection
This appliance is not intended to be operated by means of external timer or separate remote
control system.
Mains
Connection
Cable diameter
Cable
Protection calibre
230V~ 50/60Hz 1 Phase + N 3 x 2,5 mm² H 05 VV - F
H 05 RR - F
25 A *
400V~ 50/60Hz 2 Phases + N 4 x 1.5 mm² H 05 VV - F
H 05 RR - F
16 A *

17344/0
