Smeg Linear SAP112-8 User manual

VOLUME 2
LINEAR

The new Linear range unifies exceptional design and style with superior
technology. Elegant linearity is balanced perfectly with satin stainless steel and
supersilver glass to produce a timeless look that is clean, streamlined and smart.
The entire range offers the latest features and works beautifully, both as stand-
alone appliances or alongside other Linear products.

4
Passion and entrepreneurial vision are the elements
that have always guided Smeg. In over 60 years of
history, Smeg has evolved, creating distinctive domestic
products that are becoming an international reference
for quality products.
Linear style exudes light, balance and ergonomics
that maximise the space: products with a modern and
minimal style that respond to the latest design trends.

5
technology 6–9
cooking functions 10–11
Linear 60cm single ovens 12–15
Linear 70cm single oven 16
optional accessories 17
Linear compact steam oven 18
Linear compact microwave oven with grill 19
Linear compact microwave convection oven with grill 20
Linear coffee machine 21
Linear warming drawer 22
Linear gas cooktops 24–29
complementing the Linear range 30
contact Smeg 31

6
Thermoseal
Smeg has spent many decades developing
thermoseal — a unique system for cooking that
produces consistently better results. Thermoseal
is a combination of technologies which creates
a controlled cooking environment. The system
includes a Venturi valve that releases excess
moisture into the cooling system. Ideal cooking
conditions for perfect results are maintained at
all times. Simultaneously cooked, crispy baked
potatoes and succulent roasts can be assured.
A Smeg Thermoseal oven is energy efficient
because it reaches cooking temperature more
quickly and uses less energy to maintain
cooking temperatures. A Smeg kitchen is
cleaner because oven-hot air laden with
moisture, oils and food particles is not
continually released.
Cool Door
Smeg has one of the safest, coolest
oven doors available. Smeg Cool
Door technology keeps wandering
hands safe from burning and helps
stop radiant heat from raising the
temperature in your kitchen. During
standard cooking functions, our triple
and quadruple-glazed doors never
reach more than 10°C above the
ambient room temperature. Even when
using the pyrolytic cleaning function
– at oven-cavity temperatures of up to
500°C – the door temperature never
rises to more than 15°C above the
ambient room temperature. This is a
very credible and unique 31°C below
Australian Standards limit.
Smeg tangential cooling fan system
1. Sheet metal outer carcase
2. Cool air-well
3. Thermo-reflective foil
4. 20mm-thick rockwool blanketing
5. 1.2mm thick oven wall
6. Ever Clean Enamel — thermo-reflective
3
1
4
5
6
2
2
Smeg Linear oven model Temperature rise
measured C° allowed C°
SA112-8 metal 6 30
glass 10 40
SAP112-8
normal function
metal 4 30
glass 5 40
SAP112-8 pyrolytic
function over 3 hours
handle 7 35
glass 14 45
The above figures are as tested and reported by NATA
Technology

7
Temperature, time, cooking functions, Smeg’s fully-automatic
Smart Chef program – all are displayed on the electronic LED
display. Smeg’s engineers and designers have delivered a
distinctive and easy visual format that mimics human logic.
Intuitive Display
Smeg’s Smart Chef menu options give you nine pre-set recipes
from which to choose and the interactive capacity to modify
functions as much or as little as you require. It will even tell you
which shelf to use. You can also store your favourite recipes to
memory, to personalise your oven.
Smart Chef
Our telescopic shelving guides ensure Smeg shelves are
stable and safe. Each shelf can be telescoped forward,
providing a flat plane and easy access. Standard or optional
depending on model selection.
Capacity
Smeg has applied innovative engineering and smart
design to develop 60cm ovens with an incredible
70-litre true-cooking capacity. Now, you can stack
the oven, fit two cake tins side-by-side and enjoy the
added benefits of five shelves. You can even cook on
the oven floor. Perfect for entertaining!
Telescopic Shelving
Guides

8
Ever Clean Enamel
Pyrolytic Cleaning
Vapour Clean
Formulation, application, firing – our
exclusive Ever Clean Enamel creates
a flawless finish on oven interiors
and baking trays alike, making oven
surfaces incredibly easy to maintain.
The same superior Ever Clean Enamel
is used in all new Smeg ovens.
In just ninety minutes, Smeg’s pyrolytic
cleaning function can assist to rid your
oven of grease and waste. Pyrolytic
cleaning sends the oven interior to
between 475°C and 500°C and
literally carbonises food residue
to a fine ash. At such an extreme
temperature, the door automatically
locks for safety, while radiant heat is
reduced to no more than 15°C above
ambient using an independent cooling
fan and quadruple door glazing.
To help take the hard work out of
cleaning your non-pyrolytic oven,
Smeg has developed Vapour Clean.
Just add a little water to the cavity
on the oven floor, some water and
detergent to the oven cavity walls,
select Vapour Clean and allow the
vapour to soften any residue.
Technology

9
Precise Temperature Control
An electronic thermostat is positioned within the
oven cavity. This delivers the ultimate in responsive
and precision temperature control, enhancing
cooking results.
Illumination
Twin halogen lights are positioned asymmetrically
on the side walls of the new 79-litre oven cavity
for optimum internal radiance.

10
FAN FORCED This versatile function is ideal for roasting meats, baking, heating
dishes and so much more. It allows you to use the entire oven,
including the oven floor.
SUPER FAN
FORCED Choose Super Fan Forced for large-capacity cooking, including
roasts. It is also suitable for cooking bases. The floor of the oven
is perfect for pizza.
SUPERCOOK Supercook is the use of three elements and the fan at once,
enabling foods to be cooked, quickly and efficiently, with minimal
smell and flavour transference.
FAN ASSISTED Very even cooking throughout the middle zones of the oven.
Also, the highest to lowest levels when used, favour browning
and crisping.
CONVECTION This function supplies heat from above and below and suits long,
slow cooking and dishes requiring a lower temperature. Best
positions are shelves 2 and 3.
FAN GRILL Enjoy full-width, high-power grilling. This function is great for
baking chips, pastries, scones and any type of meat, including
fish. Door must be closed while grilling.
HALF FAN GRILL The centre element gives generous coverage of the grill tray, all
the way from the rear to the front. Use to cook smaller amounts
of food. Door must be closed while grilling.
STATIC GRILL Radiant heat is directed straight onto the top of your food. Use
this function for great toast, cheese melts, focaccia and so on.
Door must be closed while grilling.
HALF STATIC
GRILL All the benefits of the Static Grill but for small quantities of food.
Place food from front to back, down the centre of the tray. Door
must be closed while grilling.
ROTISSERIE Works with the grill element to cook and brown food to
perfection. A tray of vegetables beneath the rotisserie, basted by
delicious juices from above, is a meal not to be missed.
HALF
ROTISSERIE Slightly less powerful than the Full Rotisserie function, the Half
Rotisserie nevertheless delivers mouth-watering results.
PIZZA Establishing a hot residual and even heat into the pizza stone
directly from the concealed floor element ensures crispy evenly
cooked bases and perfect toppings.
fan + perimeter
roof element + floor
element + circular
rear element
fan + circular rear
element
+ floor element
fan + circular rear
element
fan + perimeter
roof element
+ floor element
perimeter roof
element
+ floor element
fan + perimeter roof
element
+ inner roof element
fan + inner
roof element
perimeter roof
element
+ inner roof element
inner roof
element
rotisserie + perimeter
roof element
+ inner roof element
rotisserie + inner
roof element
concealed floor
element only
Cooking Functions

11
BAKERS
FUNCTION Sensational for dishes with a pastry base. Produce
wonderfully crisped pies, tarts and quiches, every time.
BASE HEAT Choose Base Heat for crisp pastry or any dish needing a
higher base temperature. Base Heat will also keep a full oven
hot without over-cooking.
PROOFING
Heat from the top of the oven cavity makes it easier to proof
all types of dough and guarantees perfect results, quickly.
GAS
CONVECTION People with a gas-only oven will love the even heat
afforded by this function. Please note, a gas oven cannot
be Thermosealed.
DEFROST
Defrost your frozen food with the help of this convenient,
fan-assisted function.
VAPOUR CLEAN Add a little water to the cavity on the oven floor, and some
water and detergent to the oven cavity walls. Select Vapour
Clean and allow the vapour to soften any residue for easy
wipe-over.
PYROLYTIC
CLEANING From ninety minutes to a maximum of three hours for heavily
soiled ovens, this function sends the oven interior to between
475°C and 500°C and literally carbonises food residue to a
fine ash. The door automatically locks for safety.
ECO PYROLYTIC This 90-minute, preset function sends the oven interior to more
than 500°C and carbonises food residue to a fine ash. It is
a great choice for cleaning a slightly soiled oven. The door
automatically locks for safety.
MICROWAVE Great for cooking, thawing and heating – quickly and
easily – the microwave function can also be combined with
conventional functions, if available.
MICROWAVE
WITH GRILL Combine traditional microwave functions with the
convenience of a grill.
STEAM Whether you want to cook, re-heat, defrost or sterilise, the
steam function is your gentle, healthy and regenerative
alternative.
MICROWAVE &
FAN FORCED Classic even fan forced cooking overlaid with microwave
sequencing can speed up the cooking for particular dishes.
gas only
microwave
only
fan only +
floor element
concealed floor
element only
concealed floor
element only
fan only
steam only
fan + rear +
perimeter roof +
floor element
fan + circular rear
+ perimeter roof +
floor elements
fan + circular rear
+ perimeter roof +
floor elements
both roof
elements

12
bakers function convection eco
fan assisted fan grill fan forced
supercook static grill base heat
defrost eco pyrolytic pyrolytic
SAP112-8
60cm pyrolytic electric oven
finish glass and satin stainless steel
size 592mmH x 597mmW x 566mmD
capacity 79 litre
installation flush fitment, underbench or wallmount
cooking levels five shelf heights plus recessed floor for
pizza stone
multifunction eight cooking functions, two pyrolytic
cleaning selections
programmability three LED displays with intuitive prompting,
full auto cooking, semi-auto cooking,
minute minder, manual override
menu memories smeg Smart Chef — nine preprogrammed
cooking memories, three blank memories,
all amendable
cleaning two pyrolytic self-clean selections,
smeg ever-clean enamelling
lighting automatic, two, opposite sides, staggered
heights, 40-watt halogen
furniture smeg Ever-Clean enamel —
• 2 x 40mmH grill-bake-roast tray
• removable roof liner
• chromed grill insert
• one shelf
• pair safety-grip tray handles
• GT1P set, partial 70% telescopic shelf
guides
options GT1P sets, maximum five sets
GT1T sets, total 110% telescopic shelf
guide, maximum five sets
PRTX 35cm diameter pizza stone
PAL stainless steel/timber pizza shovel
rotisserie attachment
Linear 60cm single ovens — pyrolytic
beef pork poultry lamb fish veg pizza cake biscuits R1 R2 R3
z
STORED MEMORIES

13
SAP109-9
60cm pyrolytic electric oven
finish glass and satin stainless steel
size 592mmH x 597mmW x 566mmD
capacity 70 litre
installation flush fitment, underbench or
wallmount
cooking levels four shelf heights plus recessed floor
for pizza stone
multifunction six cooking functions, two pyrolytic
cleaning selections
programmability LED display, digital clock, full auto
cooking, semi-auto cooking, minute
minder, manual override
cleaning two pyrolytic self-clean selections,
smeg ever-clean enamelling
lighting automatic, one side wall recess,
25 watt incandescent
furniture smeg Ever-Clean enamel —
• 40mmH
grill-bake-roast tray
• removable roof liner
• chromed grill insert
• two shelves
• pair safety-grip tray handles
options PRTX 35cm diameter pizza stone
PAL stainless steel/timber pizza
shovel
GT1P set, partial 70% telescopic
shelf guides
GT1T set, 110% telescopic shelf
guides
warranty two years parts and labour
supercook convection eco
fan forced fan grill static grill
eco pyrolytic pyrolytic
NB: THE LINEAR RANGE OF APPLIANCES IS BEST DISPLAYED
WHEN FLUSHMOUNTED WITH CABINET FASCIAS.
THE ACCOMPANYING DRAWINGS SHOW THE ACTUAL
OVERALL DIMENSIONS OF THE APPLIANCE AND THE CABINET
CARCASE DIMENSIONS TO SUIT THE APPLIANCE.

14
SA112-8
60cm electric oven
finish glass and satin stainless steel
size 592mmH x 597mmW x 566mmD
capacity 79 litre
installation flush fitment, underbench or wallmount
cooking levels five shelf heights plus recessed floor for pizza
stone
multifunction nine cooking functions, proofing selection, defrost
selection, vapour clean selection
programmability three LED displays with intuitive prompting, full
auto cooking, semi-auto cooking, minute minder,
manual override
menu memories smeg Smart Chef — nine preprogrammed
cooking memories, three blank memories, all
amendable
cleaning smeg Vapour Clean selection
smeg ever-clean enamelling
lighting automatic, two, opposite sides, staggered
heights, 40-watt halogen
furniture smeg Ever-Clean enamel —
• 2 x 40mmH grill-bake-roast tray
• removable roof liner
• chromed grill insert
• one shelf
• pair safety-grip tray handles
• GT1P set, partial 70% telescopic shelf
guides
options GT1P sets, maximum five sets
GT1T sets, total 110% telescopic shelf guide,
maximum five sets
PRTX 35cm diameter pizza stone
PAL stainless steel/timber pizza shovel
bakers function convection eco
fan assisted fan grill fan forced
supercook static grill base heat
defrost proofing vapour clean
Linear 60cm single ovens
beef pork poultry lamb fish veg pizza cake biscuits R1 R2 R3
z
STORED MEMORIES

15
SA109-8
60cm electric oven
finish glass and satin stainless steel
size 592mmH x 597mmW x 566mmD
capacity 70 litre
installation flush fitment, underbench or wallmount
cooking levels four shelf heights plus recessed floor for
pizza stone
multifunction seven cooking functions
defrost selection
programmability LED display with intuitive prompting, full
auto cooking, semi-auto cooking, minute
minder, manual override
lighting automatic, one recessed side wall,
25 watt incandescent
furniture smeg Ever-Clean enamel —
• 40mmH grill-bake-roast tray
• removable roof liner
• chromed grill insert
• two shelves
• pair safety-grip tray handles
options GT1P set, 70% partial telescopic shelf
guide, maximum four sets
GT1T set 110% total telescopic shelf
guide,max four sets
PRTX 35cm diameter pizza stone
PAL stainless steel/timber pizza shovel
warranty two years parts and labour
supercook fan forced fan assisted
convection fan grill static grill
eco vapour clean
NB: THE LINEAR RANGE OF APPLIANCES IS BEST DISPLAYED
WHEN FLUSHMOUNTED WITH CABINET FASCIAS.
THE ACCOMPANYING DRAWINGS SHOW THE ACTUAL
OVERALL DIMENSIONS OF THE APPLIANCE AND THE CABINET
CARCASE DIMENSIONS TO SUIT THE APPLIANCE.

16
SCA712-3
70cm electric oven
colour satin stainless steel/mirrored glass
size 597mmH x 698mmW x 566mmD
capacity 90 litre
installation built-in underbench or wallmount,
flushmount
cooking levels three shelf heights with fitted
GT379 telescopic shelf guides
thermostat variable 50–250°C
multifunction 10 cooking functions plus defrost
plus proofing
fully automatic 24-hour digital — time of day, fully
automatic, semi automatic, minute
minder, manual override
cavity cooling independent self-cooling carcase
fan
furniture 2 x 20mm grill/baking tray, grill
insert, 2 x chrome wire shelves,
two non-stick flat trays, removable
roof liner, 2 x safety-grip handles,
1 x set GT379 telescopic shelf
guides
interior enamel smeg Ever-Clean enamel
safety thermal overload protection
safety-notched furniture
triple-glazed door
forced-air door cooling
warranty two years parts and labour
bakers function convection eco
fan assisted fan grill fan forced
supercook static grill base heat
defrost proofing super fan
forced
beef pork poultry lamb fish veg pizza cake biscuits R1 R2 R3
z
Linear 70cm single oven
STORED MEMORIES
GT379 telescopic shelf guides
for SCA712-3 (supplied)

17
GT1P partial telescopic shelf
guides
SSDLID to suit SSDPLUSSSDPLUS heavy-duty full-width
baking dish (fits 60cm oven
racking, suits any oven)
SD1 heady-duty baking dish
with lid
GIRAR60 rotisserie assemblyPALPZ pizza paddlePPR2 rectangular terracotta
pizza stone
PRTX round terracotta pizza
stone
GT1T 110% telescopic shelf
guides
optional accessories
700
600
50 50
STLINEAR
2 x vertical sidetrims for integration of Linear compact
microwave oven, convection microwave, steam or
coffee units above 70cm-wide Linear electric oven.

18
SCA45V2 compact steam oven
finish glass and satin stainless steel,
stainless steel interior
size 455mmH x 595mmW x 562mmD
capacity 37 litres
water tank 1.2 litres
installation flush fitment, underbench or
wallmount
cooking levels four shelf heights
multifunction four cooking functions
reheating and/or sterilising function
defrost function
programmability LED display, electronic timer with
end-cooking alarm
lighting automatic, 25 watt incandescent
power connection 10 amp, 3-pin plug
1.5 kW power consumption
safety child lock
furniture • 1 x 40mm perforated steam tray
• 1 x 20mm non-perforated tray
• 1 x wire rack
warranty two years parts and labour
Linear compact steam oven
reheat/sterilise steam
chicken fish
vegetables defrost
450 min
460 min
450 min
455
22
22

19
Linear microwave oven with grill
microwave microwave &
grill
static grill defrost by time
defrost by
weight pizza
SCA45M2 microwave oven + grill
finish glass and satin stainless steel, double-
glazed door
size 455mmH x 595mmW x 562mmD
capacity 37 litres
installation flush fitment, underbench or wallmount
cooking levels two shelf heights
multifunction six functions
defrost by weight or time
programmability LED display, electronic timer with end-
cooking alarm
lighting automatic, 10 watt halogen
power supply 15 amp, 3-pin plug
furniture glass tray
wire shelf
warranty two years parts and labour
450 min
460 min
450 min
455
22
22
NB: THE LINEAR RANGE OF APPLIANCES IS BEST DISPLAYED
WHEN FLUSHMOUNTED WITH CABINET FASCIAS.
THE ACCOMPANYING DRAWINGS SHOW THE ACTUAL
OVERALL DIMENSIONS OF THE APPLIANCE AND THE CABINET
CARCASE DIMENSIONS TO SUIT THE APPLIANCE.

20
Linear microwave convection oven
fan forced fan forced +
grill fan grill
static grill microwave microwave +
grill
microwave +
fan forced defrost by time defrost by weight
pizza
SCA45MC2 microwave convection
oven + grill
finish glass and satin stainless steel,
size 595W x 455H x 562D
capacity 37 litres
installation flush fitment, underbench or wallmount
cooking levels two shelf heights
multifunction ten functions
defrost by weight or time
programmability LED display, electronic timer with end-cooking
alarm
lighting automatic, 10 watt halogen
power supply 15 amp, 3-pin plug
240V, 14.8 amps
microwave power
output
1000W
furniture glass tray
wire shelf
warranty two years parts and labour
450 min
460 min
450 min
455
22
22
NB: THE LINEAR RANGE OF APPLIANCES IS BEST DISPLAYED
WHEN FLUSHMOUNTED WITH CABINET FASCIAS.
THE ACCOMPANYING DRAWINGS SHOW THE ACTUAL
OVERALL DIMENSIONS OF THE APPLIANCE AND THE CABINET
CARCASE DIMENSIONS TO SUIT THE APPLIANCE.
