Smeg sfp109 Guide

www.smeguk.com
ADDITIONAL FEATURES & SECONDARY MENU OF SMEG OVENS
FOR MODELS: SF109 / SFP109 / SFP125 / SFP390 / SF390 / SF485 / SC45MC / SC45M / SC45VC / MP122 / DOSP38X /
S45MC / S45M / S45VC / MP322 / SFP6925 / SF6922 / SF4920 / MP422
HOW TO:
SUPER START GUIDE
SET THE CLOCK
• When the oven is on standby position, turn the far left control knob to the right or left for 5 seconds- or
until the time fl ashes.
• Set the hours by turning the left control knob to the right or left to go up or down.
• Once you have the correct hour repress the left control knob. Repeat this process for setting the minutes.
• Leave for 5 seconds and the time will now be saved.
SET THE MINUTE MINDER
This function activates the buzzer without stopping the cooking. Great to use as an egg timer or to alert the
user to add other dishes to the oven.
• Press the left control once (twice if cooking is already in progress). The display will show 00.00 and the
timer indicator fl ashes.
• Turn the left control to set the duration from 1 minute to 4 hours.
• After 5 seconds the indicator light stops fl ashes and the time starts to count down.
• A buzzer will indicate when the time has fi nished.
SET TIMED COOKING
This function allows the cooking to start and then end after a specifi c duration of time set by a user. Great for
everyday cooking, so that the oven alerts the user when the cooking has fi nished.
• After selecting a cooking function and temperature, press the left control knob 3 times. The display will
show 00.00 and the indicator light fl ashes.
• Turn the left control knob to set the cooking duration from 00:00 to 13:00.
• After 5 seconds the duration is set and the indicator will stop fl ashing.
• Press the right control knob to start timed cooking.
• At the end of cooking STOP fl ashes on the display and a buzzer will sound.

www.smeguk.com
ADDITIONAL FEATURES & SECONDARY MENU OF SMEG OVENS
FOR MODELS: SF109 / SFP109 / SFP125 / SFP390 / SF390 / SC45MC / SC45M / SC45VC / MP122 / DOSP38X /
S45MC / S45M / S45VC / MP322 / SFP6925 / SF6922 / SF4920 / MP422
HOW TO:
SUPER START GUIDE
SET PROGRAMMED COOKING
This function allows the oven to be stopped automatically at an established clock time set by a user. Great for
setting to come on during the day, and it will automatically turn off after cooking.
• After selecting a cooking function and temperature, press the left control knob 3 times. The display will
show 00.00 and the indicator light fl ashes.
• Turn the left control knob to set the cooking duration from 00:00 to 13:00.
• Press the left control a 4th time and the indicator light fl ashes, turn the left control to set the clock
cooking end time.
• After 5 seconds the duration is set and the and indicators will stop fl ashing.
• At the end of cooking STOP fl ashes on the display and a buzzer will sound.
SET THE CLOCK (FOR MODELS DOSC36X,DUSC36X & OPERA COOKERS)
• Press and hold the button for 2 seconds. A fl ashing dot will be seen between
2 and 3 on the clock.
• Press the or button to increase or decrease the time.
• Press or wait 5 seconds to exit the time setting mode.
HOW TO SET THE MINUTE MINDER
This function activates the buzzer without stopping the cooking. Great to use as an egg timer or to alert the
user to add other dishes to the oven.
• Press the button for 2 seconds. A symbol will appear between 9 and 10 on the clock.
• Press the or button to increase or decrease the time. Each line represents 1 minute, if going over 1
hour a ring around the desired hour will appear. The example to the right shows 1 hour 10 minute.
• Press or wait 5 seconds to exit the time setting mode.
• A buzzer will indicate when the time has fi nished.
HOW TO SET DURATION COOKING
This function allows the cooking to start and then end after a specifi c duration of time set by a user. Great for
everyday cooking, so that the oven alerts the user when the cooking has fi nished.
• After selecting a cooking function and temperature, press the button and symbol will appear
fl ashing on the clock between 11 and 12.
• Press the or button to increase or decrease the time- for every 12 minutes a new line will appear.
The example to the right shows 1 hour 12 minutes.
• Wait 5 seconds to exit the time setting mode.
• A fi xed symbol will appear between 11 and 12 on the clock.
• A buzzer will indicate when the time has fi nished and the oven will automatically turn off.

www.smeguk.com
ADDITIONAL FEATURES & SECONDARY MENU OF SMEG OVENS
HOW TO:
SUPER START GUIDE
SET AN END COOKING TIME
This allows the user to set a cooking duration as well as and end cooking time- this can be delayed up to 12
hours from when it was set.
• After selecting the cooking function and temperature proceed as previous section in ‘How to set duration
cooking’.
• Once the desired cooking duration has been set press button, then the symbol will appear between
10 and 11.
• Press the or button to increase or decrease the time, each line represents 1 minute.
• Wait 5 seconds and the time will be set.
• The example to the right shows the current time as 07:06 and cooking is programmed to start at 8:06 and
to fi nish at 9:06.
• Once the current time coincides with the cooking start time the internal segments begin to fl ash to show
it has starting cooking.
• Once the cooking duration has ended the buzzer will sound and the oven will automatically turn off.
SET THE CLOCK (SFP378X & SF372X)
• Press and hold for 2 seconds. A fl ashing dot will be seen between 2 and 3 and the time can now be set.
• Press the or buttons to increase or decrease the setting by one minute for each pressure until
reaching the desired time.
• Press or wait 5 seconds to exit the time setting mode.
USING THE TIMER
• Press the button, the display will show 00:00 and the symbol will fl ash on the display.
• Press the or buttons to set the time.
• Press or wait 5 seconds to exit the time setting mode. The symbol will appear on the display.
SET THE COOKING DURATION
• After selecting a cooking function and temperature press button and the display will show 00:00.
• Press the or buttons to increase or decrease the time.
• Wait 5 seconds and the time will be set.
• The A symbol and the symbol will appear on the display.
• After the cooking duration has ended a buzzer will sound and the user will have to manually switch
off the oven.

www.smeguk.com
HOW TO:
SET AN END COOKING TIME
• After selecting the cooking function and temperature proceed as previous section in ‘How to set duration
cooking’.
• Once the desired cooking duration has been set press button and the sum of the current time and the
cooking time will appear.
• Press the or button to increase or decrease the time, each line represents 1 minute.
• The current time and the A symbol will show on the display panel.
• At the end of the cooking time the buzzer will sound and the oven will automatically switch off.
SET THE CLOCK
(FOR MODELS: VICTORIA RANGE COOKERS/SYMPHONY RANGE COOKERS/ CONCERT RANGE COOKERS)
• Press and hold the and buttons at the same time for 2 seconds. A fl ashing dot will appear
in-between the hours and minutes.
• The time can be set using the or buttons.
• Press or wait 5 seconds to exit the time setting mode.
• The symbol will appear on the display to highlight that the appliance is ready to start cooking.
THE TIMER
• Press the button, the display will show 00:00 and the symbol will fl ash on the display.
• Press the or buttons to set the time.
• Press or wait 5 seconds to exit the time setting mode. The symbol will appear on the display.
SET DURATION COOKING
• After selecting a cooking function and temperature press button and the symbol will come up in-
between 00:00 on the display.
• Press the or buttons to increase or decrease the time.
• Wait 5 seconds and the time will be set.
• The A symbol and the symbol will appear on the display.
• After the cooking duration has ended a buzzer will sound and the oven will be automatically switched off.
ADDITIONAL FEATURES & SECONDARY MENU OF SMEG OVENS
SUPER START GUIDE

www.smeguk.com
HOW TO:
SECONDARY MENU:
SET AN END COOKING TIME
• After selecting the cooking function and temperature proceed as previous section in ‘How to set duration cooking’.
• Once the desired cooking duration has been set press button and the sum of the current time and the
cooking time will appear.
• Press the or button to increase or decrease the time, each line represents 1 minute.
• The current time and the A and symbols will appear on the display panel.
• At the end of the cooking time the buzzer will sound and the oven will automatically switch off.
Selected models have a secondary menu that allows you to modify some of the ovens settings. These include
child lock, showroom mode, Eco logic and Eco light modes.
CHILD LOCK will stop a child from accidently switching the oven on. The appliance will lock the controls
automatically after 1 minute. The oven will not heat up suffi ciently to cause injury.
When this mode is active this symbol will appear on the display panel . This will become on bloc or off bloc
on the menu.
SHOWROOM MODE is used for demonstrating the products in Showrooms. The elements are not heated,
but the display panel can be set for cooking. When this mode is activated this symbol will appear on the display
panel . This will become Off Show or On Show on the menu.
THE ECO LOGIC MODE uses less power, to reduce energy bills. This is useful if other appliances in the
cooking area require more power than is available. Cooking times will be lengthened. This logo will be
highlighted in the display panel when this mode is activated. This will become High power or Low Power on the
menu.
KEEP WARM MODE keeps the oven on for a period of time after the oven has fi nished cooking at a low
temperature. This will become Off hold or On hold on the menu.
THESE MODELS HAVE A SECONDARY MENU: SF109 / SFP109 / SFP125 / SFP390 / SF390 /
SC45MC / SC45M / SC45VC / MP122 / DOSP38X / S45MC / S45M / S45VC / MP322 / MP422
HOW TO ENTER THE SECONDARY MENU
• When the oven is on standby turn the far left control knob, to activate the light.
• Press and hold down the control for at least 5 seconds
• Options for the secondary menu will appear and can be changed by moving the dial to the right.
• Once the desired option is found, press in the dial to select this option. Turn the dial right or left
to turn the option on or off.
SUPER START GUIDE
