Smeg SCP750AX8 User manual

43
Contents
INSTRUCTIONS FOR THE USER: these instructions contain user
recommendations, a description of the controls and the correct
procedures for cleaning and maintenance of the appliance.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualified
technician who must install the appliance, set it functioning and carry out
an inspection test.
Further information about the products can be found at www.smeg.com
@
1. INSTRUCTIONS FOR USE ......................................................................... 44
2. SAFETY PRECAUTIONS ............................................................................ 46
3. ENVIRONMENTAL CARE .......................................................................... 48
4. GET TO KNOW YOUR OVEN ..................................................................... 49
5. AVAILABLE ACCESSORIES....................................................................... 50
6. USING THE OVEN ...................................................................................... 55
7. COOKING WITH THE OVEN....................................................................... 60
8. CLEANING AND MAINTENANCE .............................................................. 68
9. EXTRAORDINARY MAINTENANCE ........................................................... 75
10. INSTALLING THE APPLIANCE................................................................... 79

General instructions
44
1. INSTRUCTIONS FOR USE
THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. IT MUST BE KEPT IN ITS
ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF
THE APPLIANCE.
CAREFUL READING OF THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN
BEFORE USING THE APPLIANCE IS ESSENTIAL. INSTALLATION MUST BE CARRIED
OUT BY COMPETENT PERSONS IN ACCORDANCE WITH THE REGULATIONS IN
FORCE. THIS APPLIANCE IS INTENDED FOR HOUSEHOLD USE AND COMPLIES
WITH THE EEC DIRECTIVES CURRENTLY IN FORCE. THE APPLIANCE HAS BEEN
BUILT TO CARRY OUT THE FOLLOWING FUNCTION: COOKING FOOD; ALL OTHER
USES ARE CONSIDERED UNSUITABLE.
THE MANUFACTURER CANNOT BE HELD LIABLE FOR USES OTHER THAN THOSE
INDICATED.
THIS APPLIANCE HAS BEEN MANUFACTURED TO COOK FOOD, DO NOT USE THE
APPLIANCE TO HEAT ROOMS.
THIS APPLIANCE IS MARKED ACCORDING TO EUROPEAN DIRECTIVE 2002/96/EC
ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE).
THIS DIRECTIVE DEFINES THE STANDARDS FOR THE COLLECTION AND
RECYCLING OF WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT APPLICABLE
THROUGHOUT THE EUROPEAN UNION.
NEVER OBSTRUCT THE OPENINGS AND SLITS PROVIDED FOR VENTILATION AND
HEAT DISPERSAL.
DO NOT REST ANY WEIGHT OR SIT ON THE OPEN DOOR OF THE APPLIANCE.
THE IDENTIFICATION PLATE WITH THE TECHNICAL DATA, SERIAL NUMBER AND
BRAND NAME HAS BEEN VISIBLY AFFIXED TO THE APPLIANCE.
DO NOT REMOVE THIS PLATE FOR ANY REASON.
BEFORE THE APPLIANCE IS PUT INTO OPERATION, ALL THE PROTECTIVE FILMS
APPLIED INSIDE OR OUTSIDE MUST BE REMOVED.
TAKE CARE THAT NO OBJECTS ARE STUCK IN THE DOOR OF THE OVEN.
THE APPLIANCE BECOMES VERY HOT DURING USE. SUITABLE HEAT-PROOF
GLOVES SHOULD BE WORN FOR ALL OPERATIONS.

General instructions
45
DO NOT USE METALLIC SPONGES OR SHARP SCRAPERS AS THEY
WILL DAMAGE THE SURFACE.
USE NORMAL NON-ABRASIVE PRODUCTS, INCLUDING WOODEN OR
PLASTIC UTENSILS IF NECESSARY. RINSE THOROUGHLY AND DRY
USING A SOFT CLOTH OR CHAMOIS LEATHER.
DO NOT ALLOW RESIDUES OF SUGARY FOODS (SUCH AS JAM) TO SET
INSIDE THE OVEN. IF THEY ARE ALLOWED TO SET FOR TOO LONG,
THEY COULD RUIN THE ENAMEL COVERING THE INSIDE OF THE OVEN.
DO NOT USE PLASTIC KITCHENWARE OR CONTAINERS. THE HIGH
TEMPERATURES INSIDE THE OVEN COULD MELT THE PLASTIC, DAMAGING THE
APPLIANCE.
DO NOT USE SEALED TINS OR CONTAINERS IN THE APPLIANCE.
OVERPRESSURE MAY OCCUR INSIDE THE CONTAINERS DURING COOKING,
CREATING A DANGER OF EXPLOSION.
DO NOT LEAVE THE APPLIANCE UNATTENDED DURING COOKING PROCESSES
WHERE FATS OR OILS COULD BE RELEASED.
FATS AND OILS MAY CATCH FIRE.
DO NOT COVER THE BOTTOM OF THE OVEN WITH ALUMINIUM OR TINFOIL
SHEETS DURING COOKING AND DO NOT PLACE PANS OR TRAYS ON IT TO AVOID
DAMAGE TO THE ENAMELLED SURFACE.
IF THE SURFACES ARE STILL VERY HOT DURING COOKING, DO NOT POUR
WATER DIRECTLY ONTO THE TRAYS. THE STEAM COULD CAUSE SEVERE BURNS
AND DAMAGE TO ENAMELLED SURFACES.
ALL COOKING OPERATIONS MUST TAKE PLACE WITH THE DOOR CLOSED.

General instructions
46
2. SAFETY PRECAUTIONS
CONSULT THE INSTALLATION INSTRUCTIONS FOR SAFETY STANDARDS ON
ELECTRICAL OR GAS APPLIANCES AND FOR VENTILATION FUNCTIONS.
IN YOUR INTERESTS AND FOR YOUR SAFETY THE LAW REQUIRES THAT THE
INSTALLATION AND SERVICING OF ALL ELECTRICAL APPLIANCES IS CARRIED
OUT BY QUALIFIED PERSONNEL IN ACCORDANCE WITH THE REGULATIONS IN
FORCE.
OUR APPROVED INSTALLERS GUARANTEE A SATISFACTORY JOB.
GAS OR ELECTRICAL APPLIANCES MUST ALWAYS BE DISCONNECTED BY
SUITABLY SKILLED PEOPLE.
BEFORE CONNECTING THE APPLIANCE TO THE POWER GRID, CHECK THE DATA
ON THE PLATE AGAINST THE DATA FOR THE GRID ITSELF.
BEFORE CARRYING OUT INSTALLATION/MAINTENANCE WORK, MAKE SURE THAT
THE APPLIANCE IS NOT CONNECTED TO THE POWER GRID.
THE PLUG TO BE CONNECTED TO THE POWER SUPPLY CABLE AND ITS SOCKET
MUST BE OF THE SAME TYPE AND CONFORM TO THE REGULATIONS IN FORCE.
THE SOCKET MUST BE ACCESSIBLE AFTER THE APPLIANCE HAS BEEN BUILT IN.
NEVER UNPLUG BY PULLING ON THE CABLE.
IF THE POWER SUPPLY CABLE IS DAMAGED, CONTACT THE TECHNICAL
SUPPORT SERVICE IMMEDIATELY AND THEY WILL REPLACE IT.
THE APPLIANCE MUST BE CONNECTED TO EARTH IN COMPLIANCE WITH
ELECTRICAL SYSTEM SAFETY REGULATIONS.
IMMEDIATELY AFTER INSTALLATION, CARRY OUT A BRIEF INSPECTION TEST,
FOLLOWING THE INSTRUCTIONS BELOW. SHOULD THE APPLIANCE NOT
FUNCTION, DISCONNECT IT FROM THE POWER SUPPLY AND CALL THE NEAREST
TECHNICAL ASSISTANCE CENTRE.
NEVER ATTEMPT TO REPAIR THE APPLIANCE.
DO NOT USE OR LEAVE FLAMMABLE MATERIALS NEAR THE APPLIANCE OR IN
THE FOOD WARMING COMPARTMENT.
DURING USE THE APPLIANCE BECOMES VERY HOT. TAKE CARE NOT TO TOUCH
THE HEATING ELEMENTS INSIDE THE OVEN.
THE USE OF THIS APPLIANCE IS NOT PERMITTED TO PEOPLE (INCLUDING
CHILDREN) OF REDUCED PHYSICAL AND MENTAL ABILITY, OR LACKING IN
EXPERIENCE IN THE USE OF ELECTRICAL APPLIANCES, UNLESS THEY ARE
SUPERVISED OR INSTRUCTED BY ADULTS OR PEOPLE RESPONSIBLE FOR THEIR
SAFETY.

General instructions
47
DO NOT LET CHILDREN GO NEAR THE APPLIANCE WHEN IT IS IN OPERATION OR
PLAY WITH IT AT ANY TIME.
DO NOT INSERT POINTED METAL OBJECTS (CUTLERY OR UTENSILS) INTO THE
SLITS IN THE APPLIANCE.
IF THE APPLIANCE IS INSTALLED ON CARAVANS OR BOATS, IT MUST NOT BE
USED TO HEAT ROOMS.
DO NOT USE STEAM JETS FOR CLEANING THE APPLIANCE.
THE STEAM COULD REACH THE ELECTRONICS, DAMAGING THEM AND CAUSING
SHORT-CIRCUITS.
DO NOT MODIFY THIS APPLIANCE.
DO NOT SPRAY ANY SPRAY PRODUCTS NEAR THE ELECTRICAL APPLIANCE
WHILE IT IS IN OPERATION.
DO NOT USE SPRAY PRODUCTS WHILE THE PRODUCT IS STILL HOT.
The manufacturer declines all responsibility for damage to persons or things caused
by non-observance of the above prescriptions or by interference with any part of the
appliance or by the use of non-original spares.

Instructions for disposal
48
3. ENVIRONMENTAL CARE
3.1 Our environmental care
Pursuant to Directives 2002/95/EC, 2002/96/EC, 2003/108/EC, relating to the
reduction of the use of hazardous substances in electrical and electronic
appliances, as well as to the disposal of refuse, the crossed out bin symbol on
the appliance indicates that the product, at the end of its useful life, must be
collected separately from other refuse. Therefore, the user must consign the
product that has reached the end of its working life to the appropriate selective
collection centres for electrical and electronic refuse, or deliver it back to the
retailer when purchasing an equivalent product, on a one for one basis.
Adequate selective collection for the subsequent forwarding of the
decommissioned product to recycling, treatment and ecologically compatible
disposal contributes to avoiding possible negative effects on the environment
and on health and promotes the recycling of the materials of which the
appliance consists. The illicit disposal of the product by the user results in the
application of administrative sanctions.
The product does not contain substances in quantities sufficient to be
considered hazardous to health and the environment, in accordance with
current European directives.
3.2 Your environmental care
Our product's packing is made of non-polluting materials, therefore compatible
with the environment and recyclable. Please help by disposing of the packing
correctly. You can obtain the addresses of collection, recycling and disposal
centres from your retailer or from the competent local organisations.
Do not discard the packaging or any part of it, or leave it unattended. It can
constitute a suffocation hazard for children, especially the plastic bags.
Your old appliance also needs to be disposed of correctly.
Important: hand over your appliance to the local agency authorised for the
collection of household appliances no longer in use. Correct disposal enables
intelligent recovery of valuable materials.
Before disposing of your appliance it is important to remove doors and leave
shelves in the same position as for use, to ensure that children cannot
accidentally become trapped inside during play. It is also necessary to cut the
connecting cable to the power grid, removing it along with the plug.

Instructions for the user
49
4. GET TO KNOW YOUR OVEN
CONTROL PANEL
ROOF LINER
INSIDE LIGHTS
RACK AND TRAY SUPPORT FRAMES
INSERT FOR THE ROTISSERIE ROD
OVEN FAN
BOTTOM PLATE (on some models only)
PIZZA PLATE OR COVER RECESS (on some models only)

Instructions for the user
50
5. AVAILABLE ACCESSORIES
NOTE: Some models are not provided with all accessories.
Rack: useful for holding cooking containers.
Rack: useful for holding cooking containers.
Ideal for use on the removable guides.
Tray rack: to be placed over the top of the oven
tray; for cooking foods which may drip.
Oven tray: useful for collecting fat from foods
placed on the rack above.
Deep oven tray: for baking cakes, pizza and
oven-baked desserts.

Instructions for the user
51
Pizza plate: specially designed for cooking
pizza and similar dishes.
Pizza spatula: for easy placement of the pizza
on the pizza plate.
Pizza plate cover: for covering the pizza plate
when it is not in use.
Rotisserie frame: supports the rotisserie rod.
Rotisserie rod: for cooking chicken and all
foods which require uniform cooking over their
entire surface.
• The oven accessories intended to come into contact with food are made of
materials that comply with the provisions of Directive 89/109/EEC, dated 21/
12/88, and of Legislative Decree 108, dated 25/01/92.
• Accessories available on request:
Original supplied and optional accessories may be ordered from any
Authorised Support Centre.
• Use original accessories only.

Instructions for the user
52
5.1 Using the rack
The racks are equipped with a mechanical
safety lock which prevents them from being
taken out accidentally. To insert the rack
correctly, check that the lock is facing
downwards (as shown in the figure below).
To take it out, lift the front edge of the rack
slightly while sliding it out on the side runners.
The mechanical lock (or the skirt where
present) must always face the back of the
oven.
Insert racks and trays fully into the oven until they come to a stop.
5.2 Using the support rack
The support rack is inserted into the tray (as
shown in the figure).
Using this, foods can be cooked and the fat can
be collected separately from the food which is
being cooked.

Instructions for the user
53
5.3 Using the rotisserie rod
When cooking with the rotisserie, position the
frame on the third runner (see 6.2.1 Oven
runners). Once the frame is inserted, the
shaped part must sit facing outwards (as shown
in the figure).
Then prepare the rotisserie rod with the food,
using the clip forks provided.
So that you can handle the rod with the food on
it readily, screw on the handle provided.
Having prepared the rotisserie rod with the
food, position it on the guide frame as shown in
the figure.
Insert the rod into the hole (detail B) so that it
connects with the rotisserie motor.
Make sure that the pin is placed correctly on the
guide frame (detail A).

Instructions for the user
54
5.4 Using the pizza plate (on some models only)
With the oven cold, remove the circular cover
from the bottom (as shown in the figure) and
insert the pizza plate.
Make sure that the plate is inserted correctly in
the recess provided.
For cooking use the special pizza function
.
Do not use the pizza plate other than as described, for example do not use it on
gas or glass ceramic hobs or in ovens which are not designed for this purpose.
If you wish to add oil to your pizza, it is best to add it after removing it from the
oven since oil stains on the pizza plate are unsightly and may reduce its
efficiency.
In models where it is provided, if the pizza plate is not in use, cover the bottom
of the oven with the cover provided.
5.5 Using the pizza spatula (on some models only)
Always grip the pizza spatula on the wooden
handle to put food in and take it out of the oven.
You are advised to dust the steel surface
lightly with flour to make it easier to slide fresh
products on and off, as they could stick to the
steel due to their moisture content.

Instructions for the user
55
6. USING THE OVEN
6.1 Before using the appliance
• Remove any labels (apart from the technical data plate) from trays, dripping
pans and the cooking compartment.
• Remove any protective film from the outside or inside of the appliance,
including from accessories such as trays, dripping pans, the pizza plate or
the base cover.
• Before using the appliance for the first time, remove all accessories from the
oven compartment and wash them as indicated in “8. CLEANING AND
MAINTENANCE”.
Heat the empty appliance to the maximum temperature in order to remove
any manufacturing residues which could affect the food with unpleasant odours.
6.2 General Description
6.2.1 Oven runners
The oven features 5 runners for positioning
trays and racks at different heights. The
insertion heights are indicated from the bottom
upwards (see figure).
6.2.2 Cooling system
The appliance is equipped with a cooling
system which comes into operation as soon as
a cooking function starts. The fan causes a
steady outflow of air from above the door which
may continue for a brief period of time even
after the oven has been turned off.
6.2.3 Internal oven lights
The oven lights come on when the door is opened (depending on model) or any
function is selected.

Instructions for the user
56
6.3 Warnings and general advice for usage
All cooking operations must be carried out with the door closed.
During cooking, do not cover the bottom of the oven with aluminium or tin foil
and do not place pans or oven trays on it as this may damage the enamel
coating. If you wish to use greaseproof paper, place it so that it will not interfere
with the hot air circulation inside the oven.
For the best cooking results, we recommend
placing cookware in the centre of the rack.
To prevent any steam in the oven from causing
problems, open the door in two stages: keep it
half open (5 cm approx.) for 4-5 seconds and
then fully open. If you need to access the food,
always leave the door open for as short a time
as possible to prevent the temperature in the
oven from falling and ruining the food.
To prevent excessive amounts of condensation from forming on the internal
glass, hot food should not be left inside the oven for too long after cooking.

Instructions for the user
57
6.4 Description of the controls on the front panel
All the appliance's control and monitoring devices are located together on the
front panel.
OVEN THERMOSTAT KNOB
This knob can be used to select the cooking
temperature.
Turn the knob clockwise to the desired value,
between 50°C and 280°C.
THERMOSTAT LIGHT
When this is flashing, it indicates that the oven
is heating up to the temperature set using the
thermostat knob. Once the oven has reached
the selected temperature, the light stops
flashing and remains lit steadily until the oven is
switched off. Moreover, the light switches on
when the automatic cleaning cycle (pyrolysis)
starts and remains lit until the cycle is complete.

Instructions for the user
58
PROGRAMMING CLOCK
The programming clock can be used to display
the current time or to set a cooking programme.
DOOR LOCK
This light only comes on when the automatic
cleaning cycle is activated.
FUNCTION KNOB
Turn the knob clockwise or anti-clockwise to
select a function from the following options:
(see 7. COOKING WITH THE OVEN).

Instructions for the user
59
6.5 Programming clock
AManual or timed cooking
pointer
BHour - minute pointers
CRegulation knob
DCooking starting hand
The programmer enables manual cooking or the timer to be selected, or the
cooking time to be set.
Select the desired function and cooking temperature before setting the cooking
time.
6.5.1 Setting the time
To set the correct time, pull out and rotate the knob Cclockwise.
6.5.2 Semi-automatic cooking
This function only switches the oven off automatically at the end of the cooking
time. Turn knob Canti-clockwise to set the cooking time in window A.
6.5.3 Automatic cooking
This function switches the oven on and off in fully automatic mode. Turn knob C
anti-clockwise to set the cooking time in window A.
Pull out and rotate knob Canti-clockwise until the pointer Dis aligned with the
desired cooking start time.
6.5.4 End of cooking
At the end of the cooking time the oven will switch off automatically and
simultaneously a buzzer will start to sound intermittently.
6.5.5 Stopping the buzzer
The buzzer can be switched off manually by turning knob A anti-clockwise until
the symbol appears in window B.
In order to use the oven manually, turn knob Cat the end of a programming until
the symbol appears in window A.

Instructions for the user
60
7. COOKING WITH THE OVEN
ECO:
Using the grill and the lower heating element in combination is
particularly suitable for cooking on a single runner only, as it
provides low energy consumption.
STATIC:
As the heat comes from above and below at the same time, this
system is particularly suitable for certain types of food.
Traditional cooking, also known as static or thermal radiation
cooking, is suitable for cooking just one dish at a time. Perfect
for all types of roasts, bread and cakes and in any case
particularly suitable for fatty meats such as goose and duck.
GRILL:
The heat coming from the grill element gives perfect grilling
results, especially for thin and medium thickness meat and, in
combination with the rotisserie (when present), it allows the
food to be browned evenly at the end of cooking. Perfect for
sausages, ribs and bacon. This function enables large
quantities of food, particularly meat, to be grilled evenly. (3rd or
4th runner).
ROTISSERIE GRILL:
The rotisserie functions in combination with the grill element
allowing to perfectly brown food.
FAN-ASSISTED STATIC:
The operation of the fan, combined with traditional cooking,
ensures uniform cooking even with complex recipes. Perfect for
biscuits and cakes, even when simultaneously cooked on
several levels. (For multiple-level cooking, you are advised to
use the 2nd and 4th runners.)
FAN-ASSISTED GRILL:
The air produced by the fan softens the strong heatwave
generated by the grill, giving perfect grilling results even with
very thick foods. Perfect for large cuts of meat (e.g. shin of
pork).

Instructions for the user
61
FAN-ASSISTED BOTTOM:
The combination of the fan with just the lower heating element
allows cooking to be completed more rapidly. This system is
recommended for finishing off the cooking of foods which are
already well-cooked on the surface, but not inside, which
therefore need a little more heat. Perfect for any type of food.
CIRCULAR:
The combination of the fan and the circular element
(incorporated in the rear of the oven) enables different foods to
be cooked on several levels, as long as they need the same
temperature and cooking time. Hot air circulation ensures
instant and uniform distribution of heat. It will be possible, for
instance, to cook fish, vegetables and biscuits simultaneously (on different
levels) without mixing smells and flavours.
(For multiple-level cooking, you are advised to use the 2nd and 4th runners.)
TURBO:
The combination of fan-assisted cooking and traditional cooking
enables different foods to be cooked on several levels
extremely quickly and efficiently, without any transfer of smells
and flavours.
Perfect for large volumes that call for intense cooking.
(For multiple-level cooking, you are advised to use the 2nd and 4th runners.)
PYROLYSIS:
When this function is set, the oven reaches temperatures of up to 500°C,
destroying all the grease which forms on the internal walls.
PIZZA (on some models only):
The operation of the fan, combined with the grill and the lower
heating element, ensures uniform cooking even with complex
recipes. Perfect not just for pizzas, but also for biscuits and
cakes.

Instructions for the user
62
7.1 Cooking advice and instructions
7.1.1 General advice
We recommend preheating the oven before putting the food in.
• For cooking on several levels, we recommend using a fan-assisted function
(,, ) to achieve uniform cooking at all heights.
• In general, it is not possible to shorten the cooking times by increasing the
temperature (the food could be well-cooked on the outside and undercooked
on the inside).
• While cooking desserts or vegetables, excessive condensation may form on
the glass. In order to avoid this, open the door very carefully a couple of
times while cooking.
7.1.2 Advice for cooking meat
• Cooking times, especially for meat, vary according to the thickness and
quality of the food and to consumer taste.
• We recommend using a meat thermometer for meat when roasting it.
Alternatively, simply press on the roast with a spoon: if it is hard it is ready, if
not, it needs another few minutes cooking.
7.1.3 Advice for cooking desserts and biscuits
• Use dark metal moulds for desserts: they help to absorb the heat better.
• The temperature and the cooking duration depend on the quality and
consistency of the dough.
• Check whether the dessert is cooked right through: at the end of the cooking
time, put a toothpick into the highest point of the dessert. If the dough does
not stick to the toothpick, the dessert is cooked.
• If the dessert collapses when it comes out of the oven, on the next occasion
reduce the set temperature by about 10°C, selecting a longer cooking time if
necessary.
