Smeg FC336XPNE User manual

NO-FROST Combi Refrigerator
Fridge-Freezer
Instruction booklet
a Froid Ventile
Guide d’utilisation
NO-FROST Kühl-Gefrierkombi
Réfrigérateur
Réfrigérateur - Congélateur
Bedienungsanleitung
FC336XPNE

EN -1-
Index
BEFOREUSINGYOURREFRIGERATOR ..............................................................2
Information onNo-Frosttechnology ............................................................................ 2
SafetyInformation......................................................................................................... 3
Securitywarnings ......................................................................................................... 4
InstallationandOperationof yourRefrigerator ........................................................... 5
Before StartingtoOperateYour Refrigerator ............................................................... 5
USAGEINFORMATION ..........................................................................................6
Displayandcontrolpanel............................................................................................. 6
OperatingyourFridge................................................................................................... 6
Use ofcontrolpanel .............................................................................................................. 6
SuperFreezeMode............................................................................................................... 7
SuperCoolMode ................................................................................................................... 8
EconomyMode ...................................................................................................................... 8
HolidayMode ......................................................................................................................... 9
DrinkCoolMode................................................................................................................... 10
ScreenSaverMode ............................................................................................................ 10
Functionof ChildLock ..........................................................................................................11
LightCancellingMode...........................................................................................................11
CoolerTemperatureSettings..................................................................................... 12
FreezerTemperatureSettings ................................................................................... 12
Warningsabout temperatureadjustments ............................................................... 13
Accessories ................................................................................................................ 14
Icebox................................................................................................................................. 14
Freezerbox......................................................................................................................... 14
FOODPLACEMENT .............................................................................................15
Cooling Compartment................................................................................................ 15
DeepFreezeCompartment........................................................................................ 15
CLEANINGANDMAINTENANCE .........................................................................20
Defrosting ................................................................................................................... 21
Replacingthe Bulb ..................................................................................................... 21
SHIPMENTANDREPOSITIONING ......................................................................22
Repositioning the Door .............................................................................................. 22
BEFORECALLINGTHESERVICE.......................................................................22
TipsForSavingEnergy .............................................................................................. 24
THEPARTSOF THEAPPLIANCEAND THE COMPARTMENTS........................25

EN -2-
PART- 1. BEFOREUSING YOUR REFRIGERATOR
InformationonNo-Frosttechnology
No-frostrefrigeratorsdifferfromotherstatic
refrigerators intheiroperatingprinciple.
Innormalfridges,thehumidityenteringthefridgedue
todooropeningsand thehumidityinherentinthe food
causesfreezinginthefreezerdepartment. To defrost
thefrostandiceinthefreezercompartment,youare
periodicallyrequiredtoturnoffthefridge,placethefood
thatneedstobekeptfrozeninaseparatelycooled
container,andremovetheicegathered inthefreezer
department.
Thesituationis completelydifferent inno-frostfridges.
Dryand coldairisblowninto the fridgeandfreezer
compartmentshomogeneouslyand evenlyfrom
several pointsvia ablowerfan. Cold airdispersed
homogeneously andevenlybetweentheshelvescools
allof yourfoodequallyand uniformly,thuspreventing
humidityandfreezing.
Thereforeyourno-frostfridgeallowsyoueaseof use,
inaddition toitshugecapacityand stylish appearance.

EN -3-
SafetyInformation
•Whilecarrying andpositioningthefridge, donot givedamage to the cooler
gas circuit.
•Ifyourold fridge hasalock,breakorremovethe lock beforediscardingit,
becausechildren maygettrappedinside itandmaycausean accident.
•OldfridgesandfreezerscontainisolationmaterialandrefrigerantwithCFC. Therefore,
takecarenotto harmenvironment when youarediscardingyouroldfridges.
IMPORTANTNOTES:
•IfyourapplianceusesR600asarefrigerant–youcanlearnthisinformation
fromthelabelonthecooler-youshouldbecarefulduringshipmentandmontage
topreventyourappliance’s coolerelementsfrombeingdamaged. Although
R600aisa environmental friendlyand naturalgas,asitisexplosive,incaseof
aleakagetobeoccurreddueto adamagein thecoolerelementsmoveyour
fridge fromopen flameorheatsourcesandventilatethe roomwherethe
applianceislocatedforafewminutes.
•Pleasereadthe instructionmanualcarefullybeforeinstallingandusingyour
appliance. Ourcompanyisnotresponsible ofthe damageoccurred due tomisuse.
•Followall instructionsonyourapplianceandinstructionmanual,andkeepthis
manual inasafe placetoresolvetheproblems that mayoccurinthefuture.
•This applianceisproducedtobe used athousesanditcanonlybeusedinhouse
andforthe specified purposes.Itisnotsuitable forcommercial orcommon use.
Suchusewillcausetheguaranteeof theappliancetobe cancelled andour company
willnotbe responsibleforthelossestobe occurred.
•This applianceisproducedtobe used inhousesanditis onlysuitableforcooling/
storingfoods.Itisnotsuitable forcommercial orcommonuseand/orforstoring
substancesexceptforfood.Ourcompanyisnotresponsibleforthelossestobe
occurred inthe contrarycase.
ConformityInformation
•TropicalClass isdefinedfortheenvironmenttemperaturesbetween16°Cand 43°C
inaccordancewiththeTSENISO15502Standards.
•The applianceis designed in compliance with the EN15502, IEC60335-1/
IEC60335-2-24, 2004/108/ECstandards.
PleaseaskyourmunicipalauthorityaboutthedisposaloftheWEEEfor
thereuse,recycleandrecoverypurposes.

EN -4-
Securitywarnings
Warning: Donotusemechanicaldevicesorothermeansto acceleratethe
defrostingprocess,otherthanthoserecommendedbythemanufacturer.Do
notuseelectricalappliancesinsidethe food storagecompartmentsofthe
appliance, unless theyareof the type recommended bythe manufacturer.
Keepventilation openings,intheapplianceenclosureorinthe built-instructure,
clearofobstruction.Donot damagetherefrigerantcircuit.
•Pleasedo notuseamulti-waysocketoranextensioncable.
•Pleasedo notinsertaplugwhosecable isdamaged,tornor
worn-out into thesocket.
•Pleaseneverpull,bendordamagethecable.
•This producthasbeendesignedfor utilizationbyadults;please
donot letchildrenplaywiththe deviceanddangletheirbodyby
hangingonthedoor.
•Neverevertakeout theplugfromthe socketwithwethandsin
ordernottocauseanyelectricalshock!
•Pleasedo notever placeacidicdrinksinglassbottlesand cans
inthe deep-freezecompartmentofyourrefrigerator.Bottlesand
cansmayburstout.
•Foryoursafety,pleasedo notplaceanyexplosiveand flammable
materialsintherefrigerator.Placethedrinkswithhighalcohol
contentintothe coolingcompartment ofthedevicewiththeir
lidstightlyclosed andinavertical position.
•Avoidanymanualcontactasyoutakeouttheicemadeinthe
deepfreezecompartment;theicemaycauseburnsand/orcuts.
• Neverevertouchthefrozenfoodwithbarehands!Donoteattheicecreamandice
cubesimmediatelyafteryoutakenthemoutofthe deep freezecompartment!
• Pleasedonotrefreezethe frozenfoodoncetheyarethawed.Itmayposeadanger
foryourhealthsinceitmightcauseproblemssuchasfoodpoisoning.
• Pleasedonotcover thebodyand\ortopof therefrigeratorwithcloth, tablecoveretc.
Thiswillnegatively affectthe performanceof therefrigerator.
• Securetheaccessoriesinsidethe applianceinordertopreventthemgetdamaged
while moving.
•Theapplianceisnotintended forusebypeople(includingchildren)withreduced
physical,sensoryormentalcapabilities,orlackofexperienceandknowledge, unless
theyhavebeengivensupervisionorinstructionconcerninguseofthe appliance by
apersonresponsiblefortheirsafety.Childrenshouldbesupervised toensurethat
theydon’t playwith theappliance.
•Ifthesupply cordisdamageditmustbereplacedbythemanufacturerorservice
agentorsimilaryqualifiedpeople inordertoavoid ahazard.

EN -5-
InstallationandOperationofyourRefrigerator
•The operationvoltageof yourrefrigeratoris220-240Vand50Hz.
•Aspecially groundedplughasbeenconnectedtothe powercable ofyour refrigerator.
Thisplugshould beusedwithaspeciallygroundedsocketof16amperes.Ifthere
isnosuchsocketinyourhouse,pleasehaveitinstalledbyanauthorized electrician.
•Ourcompanyshallnot beheldresponsible fordamagesthat
mayariseduetoutilization with nogroundinginstallation.
•Placeyourrefrigeratorin asuitablespotthatitwillnotbe exposed
todirectsunlight.
•Itshould beatleast50cmawayfromheatsourcessuchas
cookers,ovens,wingradiatorsand stovesandatleast5cm
awayfromelectricalovens.
•Your refrigeratorshouldnotbe used intheopen airandshould
notremainundertherain.
•If yourrefrigeratoris juxtaposed with adeep freeze, itis
necessary toleaveaspaceofat least2cmbetweenthemin
ordertopreventcondensation ontheoutersurfaces.
•Pleasedo notplaceanyheavy objectsonyourrefrigeratorand
placeyourrefrigeratorinasuitablespotinsuchawaythatthere
willbeafreespaceofminimum15 cmonthe top.
•Ifyouraregoingtoplacetherefrigeratorbesideyourkitchen
cabinetsthenyoushouldkeepaclearanceofatleast2cm’s
between them.
• Topreventthecondenser(theblackbackside component with
fins) fromtouchingthewall,puton the plasticdistanceguidein
itsplacerotating 90°.
• Toensuresmooth andvibration-freeoperationofyourrefrigerator,theadjustable
frontfeetmustbesetatthesuitableheightandmutuallybalanced. Youcanensure
thisbyturningtheadjustable feetclockwise(orcounter-clockwise). Thisprocess
should beperformedbeforethefoodisplacedintherefrigerator.
•Beforeusingyourrefrigerator,wipeallitspartswithwarmwaterinwhichyoushall
addoneteaspoon offoodsoda,thenrinseitwithcleanwateranddryit. Afterthe
cleaningprocess iscompleted,placeallthepartsback.
BeforeStarting toOperateYourRefrigerator
•Duringthefirstoperationortoensuretheefficientoperationof
thedevicefollowingthe relocationprocesses,allowyour
refrigerator toremain idle for3hours(in avertical position),
theninsert theplugtothesocket. Otherwise, youmaydamage
thecompressor.
•Thefirsttimeyouoperateyourrefrigerator,anodormightbe smelt.Thisodorshall
disappearonceyourrefrigeratorstartscooling.

EN -6-
PART- 2. USAGE INFORMATION
Displayand control panel
Operating yourFridge
Aftertheapplianceisplugged,allsymbols will appearfor2seconds,andthenthestart-
upvalueswillappearas-18°Confreezersettingindicatorand+5°Con coolersetting
indicator.
Allbuttonsonthecontrol panelaretouch-operated. (Only presstoactivate thebuttonyou
wanttooperate.)
1
3
10
5
2
4
7
8
9
11
6
Useofcontrolpanel
1.IndicatorandbarofSuperFreeze mode
2.IndicatorandbarofSuperCoolmode
3.Adjustmentindicatorsandbarsoffreezer.
Theactivesettingvaluewillbeilluminated.
Allbarsfromminimumuptotherelative
settingvaluewillbeilluminated.
4.Adjustmentindicatorsand barsofcooler.
Theactivesettingvaluewillbeilluminated.
Allbarsfromminimumuptotherelative
settingvaluewillbeilluminated.
5.Itenables thesettingvalue offreezerto
bemodifiedandSuperFreezemodetobe
activatedifdesired.
Freezermaybesetto-16,-18,-20,-22,
-24°C.
6.Itenablesthesettingvalueofcoolertobe
modified and SuperCoolmode tobe
activatedifdesired.
Coolermaybesetto+2,+4,+5,+6,+8°C.
7.ItactivatesDrinkCoolmode.The
expressionwill be illuminatedwhen it is
active.
8.Itactivatesholidaymode.Theexpression
willbeilluminatedwhenitisactive.
9.Itactivates economicalmode.The
expressionwill be illuminatedwhen it is
active.
10.AlarmandSRwilllightredandaudible
alarmwillbereleasedwhenany problem
occursinthefridge.Audiblealarmwill be
deactivatedwhenpressedonalarmbutton.
Redwarninglightswill continue tolightup
untiltheproblemiscorrected/eliminated.
11.Incase the mains voltage islow,Alarm
andLVwilllight redandaudiblealarmis
released.Audiblealarmwillbedeactivated
whenpressedon alarmbutton.Red
warninglightswill gooffwhenmains
voltageraisesthe appropriatelevel.

EN -7-
SuperFreezeMode
Whenwoulditbeused?
•For freezinga largeamountoffood(toolarge tobe fittedin the Superfreezer).
•Tofreezefastfood.
•Tofreezefoodquickly.
•Tostoreseasonalfoodforalongtime.
Howwoulditbeused?
•Pressbutton Funtilletters"SF"and relativebar
graphiclightup.
•Ifpressedonnobuttonin1second,SFandbar
graphicswillflash3timesandabeepsound will
be released.
•SFand relativebargraphicswill be displayed
duringthismode.
During thismode:
•Maximumamount offreshfood (inkg) that canbe frozenin24hoursisindicated on
theappliancelabel.
•Foroptimumapplianceperformancetoreach maximumfreezingcapacity,setactive
SFmode3hoursbeforeplacingfreshfoodin thefreezer.
•3hoursafterbeing activated,yourrefrigeratorstartsgivingsignals.Thissignaltells
thatthequickfreezercompartmentis readyfor the foodstobe placedin it. Your
refrigeratorwillgiveintermittentbeep soundsfor1minuteinevery5minutes;provided
thatthe doorsarenotopened,thissignalgivingwilllast1hour.Whenthissoundis
heard,foodstobefrozenmustbe placed awayfromthe alreadyfrozen ones.Whenthe
doorof the freezerorcooleris opened,thissignal stops.When yourfoodsare
cooled enough,yourrefrigeratorwillautomaticallygooutof thequick freezingmode.
•Afteraperiodofmaximum24hoursafterthefunction isactivated,thefreezingprocess
willbecompleted.
•Freezermaybe adjusted,SuperFreezewill becancelledandtheselectedsetting
valueswillproceed.
•Temperatureof supercoolandcoolermaybeadjusted.Inthiscase,superfreeze
mode continues.
•EconomicalandHolidaymodescanbeselected.SuperFreezeModewillbecancelled
andtheselectedmodeisenabled.
•When "Super Freeze" isactive,SF canbe re-selectedand cancelled bypressingon
button F.
Note: “SuperFreeze”mode will beautomatically cancelledafter24hoursor
freezersensortemperatureislowerthan-32 oC.

EN -8-
SuperCoolMode
Whenwoulditbeused?
•Tocoolfastfood before eating.
•Tocoolandstoreandlotsoffood.
•Tocooldrinksquickly.
Howwoulditbeused?
•Pressbutton Runtilletters"SC"and relativebar
graphiclightup.
•Ifpressedonnobuttonin1second,SCandbar
graphicswillflash3timesandabeepsound will
be released.
•SCandrelativebargraphicswillbedisplayedduringthismode.
•When youusesupercool mode,existing freshfoodinrefrigeratorcompartmentcan
reachtomuchmorecooling forabriefperiod.Afterthismode, thefreshfood will turn
backtonormal temperature.
•Andifneededyoucanusethismodeagain.
During thismode:
•Coolermaybeadjusted,SuperCoolwillbecancelledandtheselectedsetting
valueswillproceed.
•Temperatureof superfreezeandfreezermaybe adjusted. Inthiscase,supercool
mode continues.
•Economicaland Holidaymodescanbeselected.Super CoolModewillbe cancelled
andtheselectedmodeisenabled.
•When "SuperCool"isactive,SCcanbere-selectedand cancelled bypressingon
button R.
Note: “SuperCool”mode will be automatically cancelledafter12 hoursor
coolersensortemperatureislowerthan 0°C.
EconomyMode
FreezerandCooleroperate in theeconomical
conditionsthataredeterminedinthecontrolunit.
Whenwoulditbeused?
•Whenyouwantyourfridgetooperateeconomically.
Howwoulditbeused?
•Touchbutton ECO.
•ECOwillstartflashing
•Ifpressedonnobuttonin1second,thesymbol
will flash 3timesand abeep sound will be
released.
•When this mode isactive,ECOsymbol stays on.
•-18andrelativegraphic barwillbedisplayedonFreezer
•+4andrelativegraphicbarwill bedisplayed onCooler
