EN -2-
CHAPTER-1: BEFORE USING THE APPLIANCE
•Correct Usage 6-7
•  Generalwarnings 8-9-10-11
•  Safetywarnings   12-13-14-15-16-17
•  PackagingandEnvironment  18
•  SavingsInformation   19
CHAPTER-2: OVERVIEW OF YOUR DEVICE
•  GeneralAppearance   20-21
•  Specications    22
CHAPTER-3: INSTALLATION
•  Removingtransportationsafetyscrews 23-24
•  AdjustingAdjustableStays  25-26-27
•  Electricalconnection   28
•  Waterinlethoseconnection 29-30
•  Waterdischargeconnection  31
CHAPTER-4: INTRODUCTION OF CONTROL PANEL 32
•  Detergentdrawer   33-34
•  Programmeknob   35
•  Electronicdisplay   36-37
CHAPTER-5 PRELIMINARY PREPARATION FOR LAUNDERING
•  Separatinglaundries   38-39
CONTENTS

EN-3-
•  Puttinglaundriesinthemachine  40
•  Addingdetergentintomachine  41 
•  Operatingyourmachine   42-43-44
•  AuxiliaryFunctions   45-46-47-48-49-50-51-52
•  Childlock    53
•  Cancellingprogramme   54
•  Finishingprogramme   55
CHAPTER-6: PROGRAM TABLE   56-57-58-59-60-61-62-63
CHAPTER-7: MAINTENANCE AND CLEANING OF YOUR MACHINE
•  Warning    64
•  Waterinletlters    65
•  Pumplter    66-67
•  Detergentdrawer   68
•  Liquiddetergentapparatus  68
CHAPTER-8: FLUSH STOPPER / BODY / DRUM 69
CHAPTER-9: TROUBLE SHOOTING   70-71-72-73-77
CHAPTER-10: AUTOMATIC FAULT WARNINGS AND
WHAT TO BE DONE 75
CHAPTER-11: PRACTICAL INFORMATION 76-77-78-79
• How to read the energy label and saving energy 80-81
• Disposal of your old machine 82
CONTENTS

EN-4-
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)
Operatingvoltage/frequency:
(V/Hz)(220-240)V~/50Hz;
Totalcurrent(A):10
Waterpressure(Mpa)
Maximum:1Mpa/Minimum:0.1Mpa
Totalpower(W):2200
Maximumdrylaundrycapacity(kg):7
Donotinstallyourmachineonacarpet
orsuchgroundsthatwouldpreventthe
ventilationofitsbase.
Theapplianceisnotintendedforuseby
people(includingchildren)withreduced
physical,sensoryormentalcapabilities,or
lackofexperienceandknowledgeunlessthey
havebeengivensupervisionorinstruction
concerninguseoftheappliancebyaperson
responsiblefortheirsafety.
Childrenshouldbesupervisedtoensurethat
theydonotplaywiththeappliance.
Callthenearestauthorizedservicefora
replacementifthepowercordmalfunctions.

EN-5-
Useonlythenewwaterinlethosecoming
withyourmachinewhilemakingwaterinlet
connectionsofyourmachine.Neveruseold,
usedordamagedwaterinlethoses.
Thisappliancecanbeusedbychildren
agedfrom8yearsandaboveand
personswithreducedphysical,sensoryor
mentalcapabilitiesorlackofexperience
andknowledgeiftheyhavebeengiven
supervisionorinstructionconcerninguseof
theapplianceinasafewayandunderstand
thehazardsinvolved.
Childrenshallnotplaywiththeappliance.
Cleaningandusermaintenanceshallnotbe
madebychildrenwithoutsupervision.
Note:Forsoftcopyofthisusermanual,
pleasecontactfollowingaddress:
“[email protected]”.Inyour
e-mail,pleaseprovidethemodelnameand
serialnumber(20digits)whichyoucannd
ontheappliancedoor.
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)

EN -6-
CHAPTER -1: BEFORE USING THE APPLIANCE
(CORRECT USAGE)
• Denitely read the user’s manual.
• Your machine is designed to be used
domestically. Commercial use will
cause your warranty to be cancelled.
•Keepyourpetsawayfromyourmachine.
•Pleasecheckthepackagingofyourmachine
beforeinstallation,andtheoutersurfaceaf-
terthepackageisopened.Donotoperate
damagedmachinesormachineswithopened
package.
•Haveyourmachineinstalledonlybyauthor-
izedservice.Anyinterferencetoyourmachine
byanyoneotherthanauthorizedservices
shallcauseyourwarrantytobevoid.
•Theapplianceisnotintendedforuseby
people(includingchildren)withreducedphys-
ical,sensoryormentalcapabilities,orlackof
experienceandknowledgeunlesstheyhave
beengivensupervisionorinstructionconcern-
inguseoftheappliancebyapersonresponsi-
blefortheirsafety.Childrenshouldbesuper-
visedtoensurethattheydonotplaywiththe
appliance.

EN -7-
CHAPTER -1: BEFORE USING THE APPLIANCE
(CORRECT USAGE)
•Useyourmachineonlyforlaundriesthathave
beenspeciedassuitableforwashingbythe
manufacturer.
• Before operating the washing machine, re-
move the 4 transportation screws and rubber
spacers from the back of the machine. If the
screws are not removed, it may cause heavy
vibration, noise and product malfunction,
(voiding the guarantee).
•Yourmachineisnotcoveredunderwarranty
forfaultscausedbyanykindofexternalfactors
(pesticides,re,etc.).
•Pleasedonotthrowawaythisusermanual;
keepitforfuturereference.Youorsomebody
elsemightneeditinthefuture.
Note:Machineryspecicationsmayvaryde-
pendingontheproductpurchased.

EN -8-
•Thenecessaryambienttemperatureforyour
machine’sidealoperationis15-25°.
•Frozenhosescantearandexplode.Inregions
wheretemperatureisbelowzero,ambienttem-
peraturemightendangerthesafeoperationof
electroniccard.
•Pleaseensurethattheclothesyouwillplace
inyourmachinedonotcontainanyforeignsub-
stances(nail,needle,coins,lighter,matches,clip
etc.)intheirpockets.Theseforeignsubstances
candamageyourmachine.
•Beforestartingtouseyourmachine,youmay
callthenearestauthorizedserviceandrequest
free-of-chargehelpforinstallation,operationand
useofyourmachine.
• It is recommended to perform the rst
washing operation in 90˚ Cotton programme
and without laundry by inserting ½ scale
of detergent in 2nd compartment of the
detergent drawer.
CHAPTER -1: BEFORE USING THE APPLIANCE
(GENERAL WARNINGS)

EN -9-
•Asdetergentorsoftenerexposedtoairfora
longtimemaycauseresidues,putyourdeter-
gentorsoftenerinthedetergentdraweratthe
beginningofeverywashing.
•Itisadvisedthatyouunplugyourmachine
andclosethewaterinlettapifyouwillnotuse
yourmachineforalongtime.Also,leavingthe
doorofyourmachinewillpreventtheforma-
tionofbadodorsduetohumidity.
•Somewatermightbeleftinyourmachine
afterthetrialsandtestsconducteddueto
QualityControlprocedures.Thiswillnotdam-
ageyourmachine.
•Rememberthatpackagingmaterialsofyour
machinemaybedangerousforchildren.
•Keepthepackagingmaterialsinaplace
wherechildrencannotreachordisposeof
themappropriately.
•Usepre-washprogramsonlyforverydirty
laundry.
CHAPTER -1: BEFORE USING THE APPLIANCE
(GENERAL WARNINGS)

EN -10-
•Neveropenthedetergentdrawer
whentheapplianceisrunning.
•Incaseofanybreakdown,unplug
theappliancerstandthenturn
thetapoff.Donotattempttorepair
byyourself,alwayscontactforau-
thorizedserviceadvice.
•Theamountoflaundryyouputin
yourwashingmachineshouldnot
exceedthemaximumamountindi-
cated.
•Neverforcethedoortoopen
whenthemachineisrunning.
•Washingouryclothesinyour
machinedamagesthemachine.
Donotwashouryclothesinyour
machine.
CHAPTER -1: BEFORE USING THE APPLIANCE
(GENERAL WARNINGS)

EN -11-
CHAPTER -1: BEFORE USING THE APPLIANCE
(GENERAL WARNINGS)
•Pleaseadheretodetergent/fabriccondition-
ermanufacturers’theuseoffabriccondition-
erorsimilarproductsinyourmachine.
•Setupyourmachineinaplacewhereits
doorcanbecompletelyopened.(Donotset
upyourmachineinplaceswhereitsdoorcan-
notbefullyopened.)
•Setupyourmachineatlocationsthatcan
befullyventilatedandcouldhaveconstantair
circulation.

EN -12-
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)
You must read these warnings. You can
thus protect yourself and your beloved
ones against fatal injuries and risks.
DANGER OF GETTING BURNT!
Donottouchdischarginghoseandwater
duringdischargingastheappliancemay
reachhightemperatureswhenrunning.

EN-13-
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)
DEATH RISK DUE TO
ELECTRICAL CURRENT!
•Donotusemultiplereceptacles
orextensioncord.
•Donotplugindamagedplug
sockets
•Neverpullthecablewhenun-
plugging–alwaysgriptheplug
itself.
•Donotplug-inorouttheplug
fromthereceptaclewithwethands
topreventelectrocution!
•Nevertouchthemachinewithwet
handsorfeet.
•Callthenearestauthorizedser-
viceforareplacementifthepower
cordmalfunctions.

EN-14-
Flooding risk!
•Checkwhetherthewaterrunsfastornotbe-
foreplacingthedischargehoseonthesink.
•Takenecessarymeasurestopreventthe
slippingofyourhose.
•Thebackringforceofahosethatisnot
placedappropriatelycandisplacethehose.
Preventthestopperinsideyoursinkfrom
blockingthesinkhole.     
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)

EN-15-
Danger of Fire!
•Donotkeepinammableliquidsnearyour
machine.
•Thesulphurecontentofpaintremovers
mightcausecorrosion.Forthisreason,
neverusepaint-removingmaterialsinyour
machine.
•Neveruseproductsthatcontainsolvent
material(likewashinggas)inyourma-
chine.
•Removealltheobjectsinthepocketsof
yourlaundries(needle,paperclip,lighter,
matchesetc.)whenplacingthemyourma-
chine.
Fire and Explosion risk may occur.
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)

EN -16-
Fall and injury hazard!
•Donotclimbonyourmachine.Theupperta-
bleofyourmachinemaybreakandyoumight
getinjured.
•Tidythehose,cableandpackagingofyour
machineduringinstallation.Youmighttrip
overandfall.
•Donotturnyourmachineupsidedown,or
onitsside.
•Donotliftyourmachinebyholdingitfrom
extrudingparts(detergentdrawer,door).
Thesepartsmightbreakandcauseyoutoget
injured.
•There’stheriskoftrippingandinjuryifthe
materialslikehoseandcablesarenotprop-
erlystoredafteryourmachineisinstalled. 
Machine must be carried by
2 people or more.
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)

EN -17-
Child safety!
•Donotleavechildrenunattendednearthe
machine.Childrenmightlockthemselvesup
intothemachineanddeathriskmightoccur.
•Doorglassandsurfacemightbe 
extremelyhotwhileyourmachine
operates.Thus,especiallytouchingthe
machinemightgivedamagetothe
skinsofchildren.
•Keeppackagingmaterialawayfromchildren.
•Poisoningmightoccurifthedetergentand
maintenancematerialsareconsumed,and
eyesortheskinmightbeirritatediftheycome
intocontactwiththeskin.Keepthecleaning
materialsawayfromthereachofchildren.
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)

EN -18-
Removal of packaging materials
Packagingmaterialsprotectyourmachine
fromanydamagethatmightoccurduring
transportation.Packagingmaterialsareen-
vironmentfriendlyastheyarerecyclable.
Recyclingmaterialprovidesbothrawmate-
rialsavingsanddecreaseswasteproduc-
tion.
Disposal of old machine
Electricalorelectronicalolddevices
mightstillcontainsalvagableparts.
So,neverthrowawayyourolddevices
thatyoudonotuseintothewaste.
Ensurethatthepartsofyouroldelectronic
orelectricaldevicesarereusedbygiving
themtothegatheringcentresforeseenby
relatedauthorities.
Please ensure your old appliances are
kept in an appropriate place for the safe-
ty of children until they are taken outside
the house.
CHAPTER -1: BEFORE USING THE APPLIANCE
PACKAGING AND ENVIRONMENT

EN -19-
CHAPTER -1: BEFORE USING THE APPLIANCE
SAVINGS INFORMATION
Someimportantinformationtogetmoreef-
ciencyoutofyourmachine:
•Theamountoflaundryyouputinyourwash-
ingmachineshouldnotexceedthemaximum
amountindicated.
Bythisway,yourmachineshallruninsaving
mode.
•Notusingthepre-washfeatureforlittleand
normal-dirtylaundryshallsaveelectricityand
water.

EN -20-
CHAPTER -2: OVERVIEW OF YOUR DEVICE
GENERAL APPEARANCE
Electronicdisplay
Programmeknob
UpperTray
Detergentdrawer
Container
Coverofpumplter
