SMITH SYSTEM ACROBAT Rectangle User manual

ASSEMBLY
INSTRUCTIONS
For assistance in assembling product, missing or damaged parts,
or to place an order, please contact Customer Service at 800-328-1061.
Form# 179856A www.smithsystem.com 08.21.2015
ACROBAT™
BULLET, RECTANGLE, PENINSULA & CONTOUR
Rectangle Workstations
26443 Rectangle Instructor Desk 30” x 48”
26453 Rectangle Instructor Desk 30” x 60”
26526 Rectangle Instructor Desk 30” x 72”
26528 Rectangle Instructor Desk 30” x 60” w/ BBF Pedestal
Peninsula Workstations
26213 Peninsula Instructor Desk 36” x 72”
26233 Peninsula Instructor Desk 36” x 60”
Bullet Workstations
26515 Bullet Workstation 24” x 45”
26512 Bullet Workstation 30” x 45”
26516 Bullet Workstation 30” x 60”
26522 Bullet Workstation 30” x 72”
26536 Bullet Instructor Desk 30” x 60” (w/ BBF Ped + Lectern)
26538 Bullet Instructor Desk 30” x 72” (w/ BBF Ped + Lectern)
Contour Workstations
26203 Contour Instructor Desk 36” x 72”
26223 Contour Instructor Desk 36” x 60”
For Assistance in assembling product, missing or damaged parts,
or to place an order, please contact customer service at 800-328-1061
You may also place your order online at
www.smithsystem.com
Form# 179856A 04/2014
For Assistance in assembling product, missing or damaged parts,
or to place an order, please contact customer service at 800-328-1061
You may also place your order online at
www.smithsystem.com
Form# 179856A 04/2014
Replacement pack 69755 includes:
77471 (Qty. 16) 1/4-20X1/2” Combo Drive Machine Screw
70226 (Qty. 8) 10-32X1/2” Machine Screw
77482 (Qty. 2) Tinnerman Clip
70054 (Qty. 16) SM Screw #10X3/4 HI/LO PTH
Shapes and Sizes
Assembly Instructions
Step 1: Flip the top upside down on a clean dry surface. Align the leg sets with the predrilled holes on
the top.
Step 2: Adjust the legs to the desired height by taking out the (4) ¼-20X1/2” Machine screws per leg and
reinserting them at the desired height.
Install (1) Tinnerman Clip per leg in the square hole located inside of the leg.
*NOTE: The Tinnerman Clip is only used if the desk is raised to a high range, when set to a low
range, threaded holes in the lower leg will be used instead of the Tinnerman Clip.

[ 1 ] 69755 HARDWARE PACK, ACROBAT WORKSTATIONS
QTY 16 #77471 - 1/4 - 20 X 1/2” COMBO DRIVE MACHINE SCREW
QTY 8 #70226 - 10 - 32 X 1/2” MACHINE SCREW
QTY 2 #77482 - TINNERMAN CLIP
QTY 16 #70054 - #10 X 3/4” WOOD SCREW HI/LO PTH
ACROBAT™ WORKSTATION
REPLACEMENT HARDWARE PACK
HARDWARE AND COMPONENTS
Form# 179856A www.smithsystem.com 08.21.2015
For Assistance in assembling product, missing or damaged parts,
or to place an order, please contact customer service at 800-328-1061
You may also place your order online at
www.smithsystem.com
Form# 179856A 04/2014
Special Notes:
1. Check that all components are accounted for and undamaged before assembling.
2. Please assemble product in a clean and dry area.
3. For larger units, you may need another person to help assemble the product.
4. Clean the product with a mild cleaner and a damp cloth.
Tools
You will need a Phillips Head Screwdriver.
Hardware and Components
*Our Acrobat Workstations come in different lengths and shapes, so hardware and screw hole
placement will vary. If you feel you have not received all of the necessary hardware, please call us at
800-328-1061.
#10 Wood Screw
(Qty. 16)*
P/N-70054
10-32X1/2” Machine Screw
(Qty. 8)*
P/N-70226
1/4-20X1/2” Machine Screw
(Qty. 12)*
P/N-77471
Leg Sets (Qty. 1)
(2 legs per set)
Table Top (Qty.1)
Tinnerman Clips (Qty. 2)
P/N-77482
Cross Brace (Qty. 1)
Modesty Panel (Qty. 1)
* a phillips head screw driver will be needed for assembly.
* the Acrobat Workstations come in different lengths and shapes; so hardware and screw hole placement will vary. If you feel you have not received all of
the necessary hardware, please contact Customer Service.

STEP 1: Flip the top upside down on a clean dry surface. Align the leg sets with the predrilled
holes on the top.
ASSEMBLY INSTRUCTIONS
Form# 179856A www.smithsystem.com 08.21.2015
For Assistance in assembling product, missing or damaged parts,
or to place an order, please contact customer service at 800-328-1061
You may also place your order online at
www.smithsystem.com
Form# 179856A 04/2014
Replacement pack 69755 includes:
77471 (Qty. 16) 1/4-20X1/2” Combo Drive Machine Screw
70226 (Qty. 8) 10-32X1/2” Machine Screw
77482 (Qty. 2) Tinnerman Clip
70054 (Qty. 16) SM Screw #10X3/4 HI/LO PTH
Shapes and Sizes
Assembly Instructions
Step 1: Flip the top upside down on a clean dry surface. Align the leg sets with the predrilled holes on
the top.
Step 2: Adjust the legs to the desired height by taking out the (4) ¼-20X1/2” Machine screws per leg and
reinserting them at the desired height.
Install (1) Tinnerman Clip per leg in the square hole located inside of the leg.
*NOTE: The Tinnerman Clip is only used if the desk is raised to a high range, when set to a low
range, threaded holes in the lower leg will be used instead of the Tinnerman Clip.
STEP 2: Adjust the legs to the desired height by taking out the (4) 1/4 - 20 x 1/2” machine
screws per leg and reinserting them at the desired height.
2A: Install (1) Tinnerman clip per leg in the square hole located inside the leg.
NOTE: The tinnerman clip is
only used if the desk is raised
to a high range; when set to
a low range, threaded holes
in the lower leg will be used
instead of the tinnerman clip.

STEP 4: Attach the cross brace to the foot using the (4) 10 - 32 x 1/2” machine screws.
STEP 3: Attach the modesty panel to the legs using (4) 1/4 - 20 x 1/2” machine screws.
(The 1/4 - 20 screws for the height of the leg set may need to be loosened to realign
holes to attach the modesty panel).
ASSEMBLY INSTRUCTIONS
Form# 179856A www.smithsystem.com 08.21.2015
For Assistance in assembling product, missing or damaged parts,
or to place an order, please contact customer service at 800-328-1061
You may also place your order online at
www.smithsystem.com
Form# 179856A 04/2014
Step 3: Attach the Modesty Panel to the legs using (4) ¼-20X1/2” Machine Screws. The ¼-20 screws for
the height of the leg set may need to be loosened to realign holes to attach the modesty panel.
Step 4: Attach the Cross Brace to the foot using (4) 10-32X1/2” Machine Screws.
For Assistance in assembling product, missing or damaged parts,
or to place an order, please contact customer service at 800-328-1061
You may also place your order online at
www.smithsystem.com
Form# 179856A 04/2014
Step 3: Attach the Modesty Panel to the legs using (4) ¼-20X1/2” Machine Screws. The ¼-20 screws for
the height of the leg set may need to be loosened to realign holes to attach the modesty panel.
Step 4: Attach the Cross Brace to the foot using (4) 10-32X1/2” Machine Screws.

STEP 5: Attach the brackets to the top using (8) #10 wood screws, by first aligning the brackets
with the predrilled holes in the top.
ASSEMBLY INSTRUCTIONS
Form# 179856A www.smithsystem.com 08.21.2015
For Assistance in assembling product, missing or damaged parts,
or to place an order, please contact customer service at 800-328-1061
You may also place your order online at
www.smithsystem.com
Form# 179856A 04/2014
Step 5: Attach the brackets to the top using (8) #10 wood screws, by first aligning the brackets with the
predrilled holes.
Step 6: With help, flip the desk back into its upright position. Your desk is now ready for use. Enjoy!
STEP 6: With the help of another person, flip the desk back into it’s upright position. Your desk is
now ready for use. Enjoy!
