Snapper 63151 User manual

Parts Manual fo
r
Revision 1,
SUNSHADE KIT (UTILITY VEHICLE)
COPYRIGHT
©
2005
McDonough, GA, 30253 U.S.A.
TP 400-5029-1-AT-N
8/5/2005 Manual No. 7063151
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
MODEL
63151
7063151

Table Of Content
s
TP 400-5029-1-AT-N
Manual No. 7063151SUNSHADE KIT (UTILITY VEHICLE)
3
PAGE GROUP
4Grounds Cruiser Sun Shade Kit

Grounds Cruiser Sun Shade Kit
TP 400-5029-1-AT-N
Manual No. 7063151 SUNSHADE KIT (UTILITY VEHICLE)
4

Grounds Cruiser Sun Shade Kit
Footnotes:
TP 400-5029-1-AT-N
Manual No. 7063151SUNSHADE KIT (UTILITY VEHICLE)
5
Part No Descri
p
tionItem Qt
y
Note
1 7073168 1 SUNSHADE
2 7073301 4 CLAMP BRACKET, Upper
3 7073302 4 CLAMP BRACKET, Lower
4 7073303 2 CLAMP, ROPS Side Tube
5 7073304 2 CLAMP, Round Sunshade Tube
6 7045297 6 STRIP, Sponge Rubber
7 7027230 12 SCREW, 1/4-20 x 1” Hex Head Cap, GR5 Was 91059
8 7090639 8 SCREW, 1/4-20 x 1-1/2” Hex Head Cap w/Nylon Patch, GR5
9 7076978 20 NUT, 1/4-20 Nyloc
10 7073169 1 TUBE, 7/8” O.D. Sunshade Frame
11 7072365 2 BRACE, Sunshade Side Tube
-- 7073813 1 INSTRUCTION SHEET, Sunshade Kit
The Sunshade is not a work platform.
DO NOT stand or sit on Sunshade.
DO NOT haul or suspend items on Sunshade.
DO NOT carry passengers on Sunshade.

Parts Manual fo
r
SUNSHADE KIT (UTILITY VEHICLE)
IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS
WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE
RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS
AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE
SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.
