Snapper S27JB User manual

769-12458 / 00 09/17
Operator’s Manual
SAVE THESE NSTRUCT ONS
MPORTANT: Read this manual thoroughly before using this product. Follow all instructions.
S27JB
Electric Start Capable 2-Cycle Handheld Blower
Briggs & Stratton Corporation • Post Office Box 702 • Milwaukee • W 53201

SAFETY
2
SPARK ARRESTOR NOTE
NOTE: For users on U.S. Forest Land and in the states of
California, Maine, Oregon and Washington. All U.S. Forest Land
and the state of California (Public Resources Codes 4442 and
4443), Oregon and Washington require, by law that certain internal
combustion engines operated on forest brush and/or grass-covered
areas be equipped with a spark arrestor, maintained in effective
working order, or the engine be constructed, equipped and
maintained for the prevention of fire. Check with your state or local
authorities for regulations pertaining to these requirements. Failure
to follow these requirements could subject you to liability or a fine.
This unit is factory equipped with a spark arrestor. If it requires
replacement, contact your local service dealer to install the
appropriate muffler assembly.
Read the operator’s manual and follow all warnings and safety
instructions. Failure to do so can result in serious injury to the
operator and/or bystanders.
SYMBOL MEAN NG
WARN NG:Signals a SERIOUS hazard.
Failure to obey a safety WARN NG signal CAN result in
serious injury to yourself or to others.
CAUT ON:Signals a MODERATE hazard.
Failure to obey a safety CAUT ON signal MAY result in
property damage or injury to yourself or to others.
The purpose of safety symbols is to attract your attention to
possible dangers. The safety symbols, and their explanations,
deserve your careful attention and understanding. The safety
warnings do not by themselves eliminate any danger. The
instructions or warnings they give are not substitutes for proper
accident prevention measures.
NOTE: Advises you of information or instructions vital to the
operation or maintenance of the equipment.
DANGER:Signals an EXTREME hazard.
Failure to obey a safety DANGER signal W LL result in
serious injury or death to yourself or to others.
CAL FORN A PROPOS T ON 65
WARN NG:This product contains a
chemical known to the State of California to cause cancer,
birth defects or other reproductive harm.
TABLE OF CONTENTS
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Know Your Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Oil and Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Starting and Stopping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Cleaning and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
SERV CE
Please do NOT return the machine to the retailer or dealer
without first contacting the Customer Support Department.
If you have difficulty assembling this product or have any questions
regarding the controls, operation, or maintenance of this machine,
you can seek help from the experts. Choose from the options below:
• Visit us on the web at www.snapper.com
• Call a Customer Support Representative at [phone]
• Write to Briggs & Stratton Corporation • Post Office Box 702 •
Milwaukee • WI 53201
All information, illustrations, and specifications in this manual are based
on the latest product information available at the time of printing. We
reserve the right to make changes at any time without notice.
The product may vary slightly from the illustrations contained in this
manual.

3
WH LE OPERAT NG
• Wear safety glasses or goggles that meet current ANSI / ISEA
Z87.1 standards and are marked as such. Wear ear/hearing
protection when operating this unit. Wear a face mask or dust
mask if the operation is dusty.
• Wear heavy long pants, boots, gloves and a long sleeve shirt. Do
not wear loose clothing, jewelry, short pants, sandals or go
barefoot. Secure hair above shoulder level.
• Use the unit only in daylight or good artificial light.
• Avoid accidental starting. Be in the starting position whenever
pulling the starter rope. The operator and unit must be in a stable
position while starting. Refer to Starting and Stopping.
• Use the right tool. Only use this tool for its intended purpose.
Only use the unit as described in this manual.
• Always hold the unit with a firm grip when operating.
• Do not overreach. Always keep proper footing and balance. Take
extra care when working on stairs, steep slopes or inclines. To avoid
serious injury, do not operate the unit while on a ladder or a roof.
• Keep hands, face, and feet away from all moving parts. Do not
touch or try to stop moving parts.
• Do not touch the engine or muffler. These parts get extremely
hot from operation, even after the unit is turned off.
• Do not operate the unit faster than the speed needed to do the job.
Do not run the unit at high speed when not in use.
• Do not force the unit. It will do a better, safer job when used at
the intended rate.
• Always turn the unit off when operation is delayed or when
carrying the unit from one location to another. Make sure all
moving parts come to a complete stop.
• Before setting the unit down, always make sure the engine is off
and all moving parts have stopped.
• MPORTANT SAFETY NSTRUCT ONS •
READ ALL NSTRUCT ONS BEFORE OPERAT NG
• Read the instructions carefully. Be familiar with the controls and
proper use of the unit. Know how to stop the unit and disengage
the controls quickly.
• Stay alert. Do not operate this unit when tired, ill or under the
influence of alcohol, drugs or medication.
• Never allow children to operate the unit. Teens must be trained,
accompanied and supervised by an adult. Never allow adults to
operate the unit without proper instruction.
• All guards and safety attachments must be installed properly
before operating the unit.
• Inspect the unit before use. Check for damaged parts. Check for
fuel leaks. Make sure all parts operate properly. Make sure all
fasteners are in place and secure. Make sure all moving parts are
properly aligned and are not bound. Replace parts that are cracked,
chipped, or damaged in any way. ave all damaged or improperly
working parts repaired or replaced by an authorized service
center. Do not operate the unit with loose or damaged parts.
• Be aware of risk of injury to the head, hands and feet.
• Carefully inspect the area before starting the unit. Remove
rocks, broken glass, nails, wire, string and other objects that
may be thrown or become entangled with the unit.
• Clear the area of children, bystanders and pets; keep them
outside a 50-foot (15 m) radius, at a minimum. Even then, they are
still at risk from thrown objects. Encourage bystanders to wear
eye protection. If you are approached, stop the unit immediately.
• Squeeze the throttle control and check that it returns
automatically to the idle position. Make all adjustments or
repairs before using the unit.
• Do not change the engine governor settings or overspeed the
engine.
• This unit is intended for occasional, household use only.
WARN NG:When using the unit, all safety
instructions must be followed. Please read these
instructions before operating the unit in order to ensure the
safety of the operator and any bystanders. Please keep
these instructions for later use.
SAFETY WARN NGS FOR GAS UN TS
• Store fuel only in containers specifically designed and approved
for the storage of such materials.
• Always stop the engine and allow it to cool before filling the
tank. Never remove the fuel tank cap or add fuel when the
engine is hot. Always loosen the fuel tank cap slowly to relieve
any pressure in the tank before fueling.
• Always mix and add fuel in a clean, well-ventilated outdoor area
where there are no sparks or flames. DO NOT smoke.
• Never operate the unit without the fuel cap securely in place.
• Avoid creating a source of ignition for spilled fuel. Wipe up any
spilled fuel from the unit immediately, before starting the unit.
Move the unit at least 30 ft. (9.1 m) from the fueling source and
site before starting the engine. DO NOT smoke.
• Never start or run the unit inside a closed room or building.
Breathing exhaust fumes can kill. Operate this unit only in a well
ventilated outdoor area.
WARN NG:Gasoline is highly flammable and
its vapors can explode if ignited. Take the following
precautions:

4
OTHER SAFETY WARN NGS
• Maintain the unit with care. Follow all maintenance instructions
in this manual.
• Do not perform maintenance procedures other than those
described in this manual. All service, other than the maintenance
procedures described in this manual, should be performed by an
authorized service dealer.
• Before inspecting, maintaining, cleaning, storing, transporting or
replacing any parts on the unit:
1. Stop the unit. Refer to Starting and Stopping.
2. Make sure all moving parts have stopped.
3. Allow the unit to cool.
4. Disconnect the spark plug wire.
•Secure the unit while transporting.
• Never store the unit with fuel in the tank, inside a building where
fumes may reach an open flame (pilot lights, etc.) or sparks
(switches, electrical motors, etc.).
• Store the unit in a dry place, secured or at a height to prevent
unauthorized use or damage. Keep the unit out of the reach of
children.
• Never douse or squirt the unit with water or any other liquid.
Keep handles dry and clean (free from debris, oil and grease).
Clean the unit after each use. Refer to Cleaning and Storage. Do
not use solvents or strong detergents.
• Keep these instructions. Refer to them often and use them to
instruct other users. If you loan this unit to others, also loan
them these instructions.
SAVE THESE NSTRUCT ONS
BLOWER SAFETY
• Do not insert anything into the air openings or blower tubes. Do
not operate the unit if any of the air openings or tubes are
blocked. Keep the air openings free from dust, lint, hair and
anything else that may reduce airflow.
• Do not operate the unit without the blower tubes securely attached.
• Do not use the unit to spray liquids, especially flammable or
combustible liquids, such as gasoline. Do not use the unit in
areas where such liquids are present.
• Do not use the unit for spreading chemicals, fertilizer or any
other substance that may contain toxic materials.
• Do not set the unit down on any surface while the unit is
running. Debris can be picked up by the air intake and thrown
out the discharge opening, resulting in damage to the unit or
property or causing serious injury to bystanders or the operator.
• During operation, never point the unit in the direction of people,
animals, windows or automobiles. Always direct blowing debris
away from people, animals, windows or automobiles.
• Use extra caution when blowing debris near solid objects, such
trees, walls, fences, etc. When possible, blow away from such
objects, not toward them.
• Take care when working near valuable plants. The force of the
blown air could damage tender plants.
• Never attempt to clear a clogged air intake opening while the
unit is running.
• Keep hair, fingers and all other body parts away from moving
parts and openings.
• If the unit strikes or becomes entangled with a foreign object,
stop the unit immediately. Check for damage. If damaged, do
not restart or operate the unit until it is repaired. Do not operate
the unit with loose or damaged parts.
• Turn the engine off and disconnect the spark plug for
maintenance or repair.
• Use only original equipment manufacturer (OEM) replacement
parts and accessories for this unit. These are available from your
authorized service dealer. Use of any other parts or accessories
could lead to serious injury to the user, or damage to the unit,
and void the warranty.
• Keep the unit clean. Carefully remove vegetation and other
debris that could block moving parts.
• To reduce fire hazard, replace a faulty muffler and spark arrestor.
Keep the engine and muffler free from grass, leaves, excessive
grease or carbon build up.
• If the unit starts to vibrate abnormally, stop the unit immediately.
Inspect the unit for the cause of the vibration. Vibration is
generally an indicator of trouble.

5
• SAFETY & NTERNAT ONAL SYMBOLS •
This operator's manual describes safety and international symbols and pictographs that may appear on this product. Read the operator's
manual for complete safety, assembly, operating and maintenance and repair information.
SYMBOL MEAN NG SYMBOL MEAN NG
•SAFETY ALERT SYMBOL
Indicates danger, warning or caution. May be used in
conjunction with other symbols or pictographs.
• READ OPERATOR'S MANUAL
WARN NG: Read the operator’s
manual(s) and follow all warnings and safety
instructions. Failure to do so can result in serious
injury to the operator and/or bystanders.
• WEAR EYE AND HEAR NG PROTECT ON
WARN NG:Thrown objects and loud
noise can cause severe eye injury and hearing loss.
Wear eye protection meeting current ANSI / ISEA
Z87.1 standards and ear protection when operating
this unit. Use a full face shield when needed.
• UNLEADED FUEL
Always use clean, fresh unleaded fuel.
• O L
Refer to operator’s manual for the proper type of oil.
• DO NOT USE E85 FUEL N TH S UN T
WARN NG:It has been proven that fuel
containing greater than 10% ethanol will likely
damage this engine and void the warranty.
•ON/OFF STOP CONTROL
ON / START / RUN
• ON/OFF STOP CONTROL
OFF or STOP
• PR MER BULB
Push primer bulb, fully and slowly, 10 times.
• THROWN OBJECTS CAN CAUSE SEVERE NJURY
WARN NG:Small objects can be
propelled at high speed, causing injury.
• KEEP BYSTANDERS AWAY
WARN NG:Keep all bystanders,
especially children and pets, at least 50 feet (15 m)
from the operating area.
• HOT SURFACE
WARN NG:Do not touch a hot muffler
or cylinder. You may get burned. These parts get
extremely hot from operation. When turned off, they
remain hot for a short time.
• BLOWERS – ROTAT NG MPELLER BLADES CAN
CAUSE SEVERE NJURY
WARN NG:Stop the engine and allow
the impeller to stop before changing tubes, cleaning
or performing any maintenance.

Fuel Cap
Starter Rope Grip
Throttle
Control
Spark Plug Cover
Muffler
On/Off Switch
Primer Bulb
Choke Lever
Air Filter
Cover
Handle
Cruise Control
Lower Blower
Tube
Upper Blower
Tube
Electric Start
Port
6
KNOW YOUR UN T
APPL CAT ONS
•Cleaning yards, garages, driveways, porches, patios, around
walls, fences and more
SPEC F CAT ONS*
* All specifications are based on the latest product information available at the time of printing. We reserve the right to make changes at any
time without notice.
NO ASSEMBLY TOOLS REQU RED
Engine Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Air-Cooled, 2-Cycle
Displacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 cc (1.64 cu. in.)
Spark Plug Gap. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.025 in. (0.635 mm)
Spark Plug. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Champion® RDJ7J or equivalent plug
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fuel/Oil Mixture
Fuel/Oil Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40:1
Fuel Tank Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 oz. (414 ml)
Approximate Unit Weight (No fuel) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9.5 - 10.5 lbs. (4.3 - 4.8 kg)
Air Volume** (measured at: outlet / upper tube / lower tube) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 650 / 500 / 350 cfm (18 / 14 / 10 m3/min)
Air Speed (Peak)** (measured at: outlet / upper tube / lower tube) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 / 80 / 135 mph (64 / 129 / 217 km/h)
Air Speed (Average)** (measured at: outlet / upper tube / lower tube). . . . . . . . . . . . . . . . . . . . . . . . . . . 30 / 65 / 110 mph (48 / 105 / 177 km/h)
** Per ANSI B175.2.

ASSEMBLY
7
NSTALL NG THE BLOWER TUBES
nstalling the Upper Blower Tube
1. Set the unit on a flat, level surface.
2. Rotate the upper blower tube so that the TOP lock tab is facing
up (Fig. 1).
3. Align the TOP lock tab on the upper blower tube with the groove
on the blower outlet (Fig. 2).
4. Push the upper blower tube onto the blower outlet (Fig. 3).
5. While holding the handle firmly, turn the upper blower tube
clockwise until it locks into place (Fig. 3). The tab on the upper
blower tube should align with the tab on the blower outlet (Fig.
3).
nstalling the Lower Blower Tube
1. Align the tab on the lower blower tube with the groove on the
upper blower tube (Fig. 4).
2. Push the lower blower tube onto the upper blower tube (Fig. 4).
3. While holding the handle firmly, turn the lower blower tube
clockwise until it locks into place (Fig. 4). The tab on the lower
blower tube should align with the tab on the upper blower tube.
Fig. 1
TOP Lock Tab
Fig. 2
WARN NG: To avoid serious personal injury and
damage to the unit, shut the unit off before removing or
installing blower tubes.
Upper Blower
Tube
TOP Lock Tab
Groove
Fig. 4
Upper
Blower Tube
Lower
Blower Tube
Tab
Groove
Blower Outlet
Tab
Fig. 3
Upper Blower Tube
Tab
Blower Outlet
Upper Blower
Tube

8
Fig. 5
TOP
Lock Tab
Lock Tab
REMOV NG THE BLOWER TUBES
Removing the Lower Blower Tube
1. Set the unit on a flat, level surface.
2. While holding the handle firmly, turn the lower blower tube
counterclockwise until it unlocks from the upper blower tube
(Fig. 4).
3. Remove the lower blower tube from the upper blower tube.
Removing the Upper Blower Tube
1. While holding the upper blower tube firmly, carefully insert a flat-
head screwdriver under the TOP lock tab (Fig. 5).
2. Gently twist the screwdriver to lift the lock tab away from the
blower outlet. Repeat this step with a second lock tab (Fig. 5).
3. Remove the upper blower tube from the blower outlet.

9
O L AND FUEL
FUEL NG THE UN T
1. Position the unit with the fuel cap facing up.
2. Slowly remove the fuel cap.
3. Place the fuel container spout into the fuel tank fill hole and fill
the tank.
NOTE: Do not overfill the tank.
4. Wipe up any fuel that may have spilled.
5. Reinstall the fuel cap.
6. Move the unit at least 30 ft. (9.1 m) from the fuel container and
the fueling site before starting the engine.
O L AND FUEL M X NG NSTRUCT ONS
The use of old and/or improperly mixed fuel is the most common cause
of performance problems. Use only fresh, clean unleaded gasoline.
Follow the instructions carefully for the proper gasoline/oil mixture.
Definition of Blended Fuels
Today's fuels are often a blend of gasoline and oxygenates such as
ethanol, methanol or MTBE (ether). Alcohol-blended fuel absorbs
water. As little as 1% water in the fuel can make fuel and oil
separate, forming acids when stored. ALWAYS use fresh fuel (less
than 30 days old).
NOTE: Dispose of old fuel according to federal, state and local
regulations.
Using Blended Fuels
If using a blended fuel:
• Always use the fresh fuel mix explained in this operator's manual
• Use Briggs & Stratton Advanced Formula Fuel Treatment and
Stabilizer or an equivalent
• Always agitate the fuel mix before fueling the unit
Using Fuel Additives
The container of 2-cycle oil provided with this unit includes a fuel
additive to help inhibit corrosion and minimize gum deposits.
Always use the brand of 2-cycle oil that came with this unit. If this is
unavailable, use a 2-cycle oil designed for air-cooled engines and
mix it with a fuel additive, such as Briggs & Stratton Advanced
Formula Fuel Treatment and Stabilizer or an equivalent. Add 0.8 oz.
(23 ml) of fuel additive per gallon of fuel, according to the
instructions on the container. NEVER add fuel additives directly to
the unit's fuel tank.
Mixing the Fuel
NOTE: This unit comes with a 3.2 oz. (95 ml) container of 2-cycle
oil. To obtain the correct fuel mixture described below, pour the
entire container into one gallon of unleaded gasoline.
Thoroughly mix the proper ratio of unleaded gasoline with 2-cycle
engine oil. Do not mix them directly in the unit’s fuel tank. Use a
separate fuel can. Use a 40:1 gasoline/oil ratio. See the table below
for specific gasoline and oil mixing ratios.
Unleaded gasoline 2-cycle oil
1 gallon U.S.
(3.8 liters)
3.2 fl. oz.
(95 ml)
1 liter 25 ml
M X NG RAT O - 40:1
CAUT ON: For proper engine operation and maximum
reliability, pay strict attention to the gasoline and oil mixing
instructions on the 2-cycle oil container. Using improperly
mixed fuel can severely damage the engine.
WARN NG: Gasoline is extremely flammable. Ignited
vapors may explode. Always stop the engine and allow it
to cool before filling the fuel tank. Do not smoke while
filling the tank. Keep sparks and open flames at a distance
from the area.
WARN NG: Remove the fuel cap slowly to avoid injury
from fuel spray. Never operate the unit without the fuel cap
securely in place.
WARN NG: Add fuel in a clean, well-ventilated outdoor
area. Wipe up any spilled fuel immediately. Avoid creating
a source of ignition for spilled fuel. Do not start the engine
until fuel vapors dissipate.
CAUT ON: DO NOT USE E85 FUEL N TH S UN T. It
has been proven that fuel containing greater than 10%
ethanol will likely damage this engine and void the warranty.

10
START NG AND STOPP NG
WARN NG: Operate this unit only in a well-ventilated
outdoor area. Carbon monoxide exhaust fumes can be
lethal in a confined area.
WARN NG: Avoid accidentally starting the unit. To avoid
serious injury, the operator and the unit must be in a stable
position when pulling the starter rope (Fig. 8).
START NG NSTRUCT ONS
NOTE: There is no need to turn the unit on. The On/Off switch is in
the On ( ) position at all times (Fig. 6).
Before Starting the Unit
1. Mix gasoline with oil. Refer to Oil and F el Mixing Instr ctions.
2. Fill the fuel tank. Refer to F eling the Unit.
Starting the Unit
1. Slowly press and release the primer bulb 10 times (Fig. 7).
2. Move the cruise control to the LO (slow) position (Fig. 6).
NOTE: Keep the cruise control in the LO (slow) position and
DO NOT squeeze the throttle control until step 7 (Fig. 6).
3. Flip the choke lever clockwise until it clicks (Fig. 7).
4. Crouch in the starting position (Fig. 8).
5. Pull the starter rope with a controlled and steady motion until the
unit starts.
6. Idle the engine for 30 seconds.
NOTE: If the unit stops during this time, squeeze and hold the
throttle control or move the cruise control to the H (fast)
position (Fig. 6), then pull the starter rope in a controlled and
steady motion until the unit starts.
7. Squeeze and hold the throttle control or move the cruise control
to the H (fast) position (Fig. 6). Allow the engine to warm up for
30 to 60 seconds. The unit may be used during this time.
NOTE: The engine is properly warmed up when it accelerates
without hesitation.
NOTE: Once the engine is properly warmed, the cruise control may
be adjusted and the throttle control can be used normally.
F... the engine does not start, repeat the starting procedure.
F... the unit is hot and fails to start within 3 pulls of the starter rope,
squeeze and hold the throttle control or move the cruise control
to the H (fast) position, then pull the starter rope with a
controlled and steady motion until the unit starts.
STOPP NG NSTRUCT ONS
1. Release the throttle control, or move the cruise control to the
LO (slow) position, and allow the engine to idle.
2. Press and hold the On/Off switch in the Off (O) position until the
engine comes to a complete stop (Fig. 6).
Fig. 6
Fig. 8
Throttle Control
Starting
Position
Starter Rope Grip
Fig. 7
Primer Bulb
Choke Lever
Cruise Control
WARN NG: When starting the unit, make sure it is not
directed toward people, animals, windows, automobiles or
loose debris.
On/Off Switch
( = On / O = Off)
LO (slow)
H (fast)

11
START NG NSTRUCT ONS
NOTE: There is no need to turn the unit on. The On/Off switch is in
the On ( ) position at all times (Fig. 6).
Before Starting the Unit
1. Mix gasoline with oil. Refer to Oil and F el Mixing Instr ctions.
2. Fill the fuel tank. Refer to F eling the Unit.
Starting the Unit
Read the Operator's Man al that came with the electric start
accessory before attempting these instructions.
1 Slowly press and release the primer bulb 10 times (Fig. 7).
2. Move the cruise control to the LO (slow) position (Fig. 6).
NOTE: Keep the cruise control in the LO (slow) position and
DO NOT squeeze the throttle control until step 9 (Fig. 6).
3. Flip the choke lever clockwise until it clicks (Fig. 7).
4. Crouch in the starting position (Fig. 8).
5. Insert the electric start accessory into the electric start port (Fig. 9).
6. Run the electric start accessory in intervals no longer than 2
seconds each until the unit starts.
7. Idle the engine for 30 seconds.
NOTE: If the unit stops during this time, squeeze and hold the
throttle control or move the cruise control to the H (fast)
position (Fig. 6), then run the electric start accessory in intervals
no longer than 2 seconds each until the unit starts.
8. Remove the electric start accessory from the unit, unless specified
otherwise in the electric start accessory Operator's Man al.
9. Squeeze and hold the throttle control or move the cruise control
to the H (fast) position (Fig. 6). Allow the engine to warm up for
30 to 60 seconds.The unit may be used during this time.
NOTE: The engine is properly warmed up when it accelerates
without hesitation.
NOTE: Once the engine is properly warmed, the cruise control may
be adjusted and the throttle control can be used normally.
F... the engine does not start, repeat the starting procedure.
F... the unit is hot and fails to start after running the electric start
accessory for 3 sets of 2-second intervals: squeeze and hold the
throttle control or move the cruise control to the H (fast)
position, then run the electric start accessory in intervals no
longer than 2 seconds each until the unit starts. Remove the
electric start accessory from the unit, unless specified otherwise
in the electric start accessory Operator's Man al.
STOPP NG NSTRUCT ONS
1. Release the throttle control, or move the cruise control to the
LO (slow) position, and allow the engine to idle.
2. Press and hold the On/Off switch in the Off (O) position until the
engine comes to a complete stop (Fig. 6).
US NG THE ELECTR C START ACCESSORY
This unit can be started with an optional electric start accessory
(items sold separately). Refer to the electric start accessory
operator’s manual for the proper use of this feature.
Please contact your local retailer, call the Customer Support
Department or visit our website for more information.
Fig. 9
Electric Start
Port

12
OPERAT ON
HOLD NG THE UN T
•Stand in the operating position (Fig. 10). Stand up straight. Do
not bend over.
•Keep feet apart and firmly planted.
• old the handle firmly with either hand (Fig. 10).
WARN NG: Always wear eye, hearing, hand, foot and body
protection to reduce the risk of injury when operating this unit.
Wear a face mask or dust mask if the operation is dusty.
Fig. 10
T PS FOR BEST RESULTS
• Conserve water by using the blower instead of a hose to
perform many outdoor cleaning actions.
• Operate the unit only at reasonable hours, not early in the
morning or late at night when people might be disturbed. Comply
with times listed in local ordinances. Usual recommendations are
9:00 a.m. to 5:00 p.m., Monday through Saturday.
• To reduce noise levels, operate the unit at the lowest speed
needed to do the job. Limit the number of pieces of power
equipment used at any one time.
• Use rakes or brooms to loosen debris before operation.
• In dusty conditions, slightly dampen surfaces.
• Use the cruise control to make continuous operation easier (Fig. 6).
• Watch out for children, pets, open windows and freshly washed
cars. Blow debris safely away. Never direct the unit toward
anyone while the unit is in operation.
• Sweep the unit from side to side with the blower tube several
inches above the ground. Slowly advance, keeping the
accumulated debris in front of the operator.
• Clean up after operation. Dispose of debris appropriately.
WARN NG: To prevent serious personal injury, never
operate the unit without the blower tubes securely attached.

13
MA NTENANCE
MA NTENANCE SCHEDULE
Perform these required maintenance procedures at the frequency
stated in the table. These procedures should also be a part of any
seasonal tune-up.
NOTE: Some maintenance procedures may require special tools or
skills. If you are unsure about these procedures, take the unit to
an authorized service dealer.
NOTE: Maintenance, replacement, or repair of the emission control
devices and system may be performed by an authorized service
dealer.
NOTE: Please read the California/EPA statement that came with the
unit for a complete listing of terms and coverage for the emissions
control devices, such as the spark arrestor, muffler, carburetor, etc.
FREQUENCY MA NTENANCE REQU RED
Every 10 hours • Clean and re-oil the air filter. Refer to
Maintaining the Air Filter.
Every 25 hours • Check the spark plug condition and gap.
Refer to Maintaining the Spark Pl g.
MA NTA N NG THE A R F LTER
Failure to maintain the air filter can result in poor performance or can
cause permanent damage to the engine. Engine failure due to
improper air filter maintenance is not covered by the product warranty.
Cleaning the Air Filter
1. Open the air filter cover: press in the lock tab and swing the air
filter cover to the right (Fig. 11).
2. Remove the air filter from inside the air filter cover (Fig. 11).
3. Wash the air filter in detergent and water. Rinse the air filter
thoroughly and allow it to dry.
4. Lightly coat the air filter with clean SAE 30 oil.
5. Squeeze the air filter to spread and remove excess oil.
6. Reinstall the air filter inside the air filter cover (Fig. 11).
NOTE: Operating the unit without the air filter and air filter cover will
VOID the warranty.
7. Close the air filter cover: swing the air filter cover to the left and
press it closed until the lock tab snaps into place (Fig. 11).
Fig. 11
Air Filter
Air Filter Cover
Lock Tab
WARN NG: To avoid serious personal injury, always stop
the engine and allow it to cool before cleaning or maintaining
the unit. Never perform cleaning or maintenance while the
unit is running. Disconnect the spark plug wire to prevent
the unit from starting accidentally.
WARN NG: Wear protective clothing and observe all
safety instructions to prevent serious personal injury.

14
Fig. 13
Spark Plug Cover
MA NTA N NG THE SPARK PLUG
1. Stop the engine and allow it to cool.
2. Open the spark plug cover (Fig. 13). Grasp the spark plug boot
firmly and pull it from the spark plug.
3. Clean around the spark plug. Remove the spark plug from the
cylinder head with a 5/8-inch socket, turning counterclockwise.
4. Inspect the spark plug. If the spark plug is cracked, fouled or
dirty, replace it with a replacement part #753-06193, a
Champion RDJ7J or an equivalent spark plug.
5. Use a feeler gauge to set the air gap at 0.025 in. (0.635 mm)
(Fig. 14).
6. Install the spark plug in the cylinder head. Tighten the spark plug
with a 5/8-inch socket, turning it clockwise until snug.
NOTE: If using a torque wrench, torque to:
110-120 in.•lb. (12.3-13.5 N•m). Do not over tighten.
7. Reattach the spark plug boot. Close the spark plug cover.
WARN NG: Do not sand blast, scrape or clean spark plug
electrodes. Grit in the engine could damage the cylinder.
Fig. 12
dle Speed Screw
Fig. 14
0.025 in.
(0.635 mm)
ADJUST NG THE DLE SPEED
If the engine will not idle properly:
1. Start the engine. Refer to Starting and Stopping.
2. Move the cruise control to the LO (slow) position and let the
engine idle.
NOTE: Make sure the choke lever is NOT engaged while adjusting
the idle speed.
• If the engine stops, increase the idle speed. Use a small
Phillips screwdriver to turn the idle speed screw clockwise,
1/8 of a turn at a time, until the engine idles smoothly (Fig. 12).

15
CLEAN NG AND STORAGE
CLEAN NG
Use a small brush to clean the outside of the unit. Do not use strong
detergents. ousehold cleaners that contain aromatic oils such as
pine and lemon, and solvents such as kerosene, can damage plastic.
Wipe off any moisture with a soft cloth.
WARN NG: To avoid serious personal injury, always stop
the engine and allow it to cool before cleaning or maintaining
the unit.
STORAGE
• Never store a fueled unit where fumes may reach an open flame
or spark.
• Allow the engine to cool before storing.
• Lock up the unit to prevent unauthorized use or damage.
• Store the unit in a dry, well-ventilated area.
• Store the unit out of the reach of children.
Long-term Storage
1. Remove the fuel cap, tip the unit and drain the fuel into an
approved container. Reinstall the fuel cap.
2. Start the engine and allow it to run until it stalls. This ensures
that all fuel has been drained from the carburetor.
3. Allow the engine to cool. Remove the spark plug and put 5
drops of any high-quality motor oil or 2-cycle oil into the
cylinder. Pull the starter rope slowly to distribute the oil. Reinstall
the spark plug.
4. Thoroughly clean the unit and inspect it for any loose or
damaged parts. Repair or replace damaged parts and tighten
loose screws, nuts or bolts.
Preparing the Unit for Use after Long-term Storage
1. Remove the spark plug. Tip the unit and drain all of the oil from
the cylinder into an approved container. Reinstall the spark plug.
NOTE: Do not use fuel that has been stored for more than 30 days.
Dispose of old fuel and oil according to federal, state and local
regulations.

16
The fuel tank is empty Fill the fuel tank with properly-mixed fuel
The primer bulb was not pressed enough Press the primer bulb 10 times
The engine is flooded Squeeze the throttle control and pull the starter rope until the
engine starts
The fuel is old (over 30 days) and/or improperly mixed Drain the fuel tank and add fresh, properly-mixed fuel
The spark plug is fouled Replace the spark plug
The choke lever was not flipped Refer to Starting Instr ctions in the Starting and Stopping section
TROUBLESHOOT NG
The fuel is old (over 30 days) and/or improperly mixed Drain the fuel tank and add fresh, properly-mixed fuel
The air filter is dirty Clean or replace the air filter
PROBLEM SOLUT ON
The air filter is dirty Clean or replace the air filter
The fuel is old (over 30 days) and/or improperly mixed Drain the fuel tank and add fresh, properly-mixed fuel
The idle speed is incorrect Adjust the idle speed
The fuel is old (over 30 days) and/or improperly mixed Drain the fuel tank and add fresh, properly-mixed fuel
The air filter is dirty Clean or replace the air filter
The spark plug is fouled Replace the spark plug
THE ENG NE W LL NOT START
THE ENG NE W LL NOT DLE
THE ENG NE W LL NOT ACCELERATE
THE ENG NE LACKS POWER OR STALLS
f further assistance is required, contact an authorized service center.

17
NOTES

18
NOTES

19
NOTES

20
BR GGS & STRATTON PRODUCTS WARRANTY POL CY
WARRANTY PER OD
ABOUT YOUR WARRANTY
Equipment 36 months 3 months
L M TED WARRANTY
Briggs & Stratton warrants that, during the warranty period specified below, it will repair or replace, free of charge, any part that is
defective in material or workmanship or both. Transportation charges on product submitted for repair or replacement under this warranty
must be borne by purchaser. This warranty is effective for and is subject to the time periods and conditions stated below. For warranty
service, find the nearest Authorized Service Dealer in our dealer locator map at www.snapper.com. The purchaser must contact the
Authorized Service Dealer, and then make the product available to the Authorized Service Dealer for inspection and testing.
There is no other express warranty. mplied warranties, including those of merchantability and fitness for a particular purpose,
are limited to one year from purchase, or to the extent permitted by law. All other implied warranties are excluded. Liability for
incidental or consequential damages are excluded to the extent exclusion is permitted by law. Some states or countries do not
allow limitations on how long an implied warranty lasts, and some states or countries do not allow the exclusion or limitation of incidental
or consequential damages, so the above limitation and exclusion may not apply to you. This warranty gives you specific legal rights and
you may also have other rights which vary from state to state or country to country.**
** In Australia - Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. For
warranty service, find the nearest Authorized Service Dealer in our dealer locator map at BRIGGSandSTRATTON.COM, or by calling 1300
274 447, or by emailing or writing to [email protected], Briggs & Stratton Australia Pty Ltd, 1 Moorebank Avenue,
NSW, Australia, 2170.
The warranty period begins on the date of purchase by the first retail consumer or commercial end user, and continues for the period of time
stated in the table above.
“Consumer use” means personal residential household use by a retail consumer. “Commercial use” means all other uses, including use for
commercial, income producing or rental purposes. Once a product has experienced commercial use, it shall thereafter be considered as a
commercial use product for purposes of this warranty.
No warranty registration is necessary to obtain warranty on Briggs & Stratton products. Save your proof of purchase receipt. f you
do not provide proof of the initial purchase date at the time warranty service is requested, the manufacturing date of the product will
be used to determine the warranty period.
Warranty service is available only through Snapper Authorized Service Dealers. Most warranty repairs are handled routinely, but sometimes
requests for warranty service may not be appropriate. This warranty only covers defects in materials or workmanship. It does not cover
damage caused by improper use or abuse, improper maintenance or repair, or normal wear and tear, or stale or unapproved fuel.
mproper Use and Abuse - The proper, intended use of this product is described in the Operator’s Manual. Using the product in a way not
described in the Operator’s Manual or using the product after it has been damaged will void your warranty. Warranty is not allowed if the
serial number on the product has been removed or the product has been altered or modified in any way, or if the product has evidence of
abuse such as impact damage, or water/chemical corrosion damage.
mproper Maintenance or Repair - This product must be maintained according to the procedures and schedules provided in the Operator’s
Manual, and serviced or repaired using genuine Briggs & Stratton parts or equivalent. Damage caused by lack of maintenance or use of non-
original parts is not covered by warranty.
Normal Wear - Like all mechanical devices, your unit is subject to wear even when properly maintained. This warranty does not cover repairs
when normal use has exhausted the life of a part or the equipment. Maintenance and wear items such as filters, belts, cutting blades, and
brake pads (except engine brake pads) are not covered by warranty due to wear characteristics alone, unless the cause is due to defects in
material or workmanship.
Stale Fuel - In order to function correctly, this product requires fresh fuel that conforms to the criteria specified in the Operator’s Manual.
Damage caused by stale fuel (carburetor leaks, clogged fuel tubes, sticking valves, etc) is not covered by warranty.
Other Exclusions - This warranty excludes damage due to accident, abuse, modifications, alterations, improper servicing, freezing or
chemical deterioration. Attachments or accessories that were not originally packaged with the product are also excluded. There is no
warranty coverage on equipment used for primary power in place of utility power or on equipment used in life support applications. This
warranty also excludes failures due to acts of God and other force majeure events beyond the manufacturer’s control.
80021536EN Rev A
tem Consumer Use Commercial Use
August 2016
