Snapper XD Series User manual
82V CORDLESS CHAIN SAW
Read all safety rules and instructions carefully before operating this tool.
Owner’s Manual
TOLL-FREE HELPLINE: 1-800-317-7833
www.snapper.com
(SXDCS82)
1696773
Not for Reproduction
2
CONTENTS
Contents .............................................................................................................................. 2
Product specications.......................................................................................................... 2
Important safety instructions ............................................................................................... 3
Symbols............................................................................................................................... 9
Know your chainsaw ...........................................................................................................11
Assembly .......................................................................................................................... 12
Operation............................................................................................................................16
Battery&Charger.............................................................................................................. 26
Maintenance...........................................................................................................................28
Environmentally safe battery disposal...................................................................................37
Troubleshooting......................................................................................................................38
Limited warranty..................................................................................................................... 39
Exploded View.........................................................................................................................41
Part List...................................................................................................................................42
PRODUCT SPECIFICATIONS
82V CORDLESS CHAIN SAW
Type .............................................................................................Cordless, battery-powered
Motor .............................................................................................................. 82V Brushless
Bar length ......................................................................................................... 18” (458 mm)
Chain pitch.................................................................................................... 3/8 in. (9.5 mm)
Chain gauge...................................................................................................0.05 in. (1.27 mm)
Chain type....................................................................................................................91P062X
Guide bar type.......................................................................................................180SDEA041
Chain oil tank capacity.. .................................................................................7 oz (200 ml)
Weight(Without battery) .. ................................................................................11.6 lbs (5.4 kg)
Disclaimer:* Maximum initial battery voltage ( measured without a workload) is 82volts.
Normal voltage is 72.
Not for Reproduction
3
IMPORTANT SAFETY INSTRUCTIONS
WARNING
Read and understand all instructions before using this product. Failure to follow all
instructions listed below may result in electric shock, re, and/or serious personal injury. Save all
warnings and instructions for future reference.
WORK AREA SAFETY
• Keep work area clean and well lit. Cluttered or dark areas invite accidents.
• Do not operate Power tool in explosive atmospheres, such as in the presence of
ammableliquids,gases,ordust.Power tools create sparks which may ignite the dust or
fumes.
• Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
ELECTRICAL SAFETY
• Avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is earthed
or grounded.
• Do not expose the power tool to rain or wet locations. Water entering a chaisaw will
increase the risk of electric shock.
• If operating a power tool in a damp location is unavoidable, use a residual current
device protected supply. Use of an RCD reduce the risk of electric shock.
• A battery-operated tool with internal batteries or a separate battery pack must be
rechargedonlywiththespeciedchargerforthebattery.A charger that may be suitable
for one type of battery may create a risk of re when used with another battery.
PERSONAL SAFETY
• Stay alert, watch what you are doing and use common sense when operating a power
tool.Donotuseachaisawwhileyouaretiredorundertheinuenceofdrugs,alcoholor
medication. A moment of inattention while operating chaisaws may result in serious personal
injury.
• Usepersonalprotectiveequipment.Alwaysweareyeprotection. Safety equipment such
as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
• Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch or plugging in power tools that have the
switch on invites accidents.
• Remove any adjusting key or wrenches before turning the power tool on. A wrench or a
key left attached to a rotating part of the chaisaw may result in personal injury.
• Do not overreach. Keep proper footing and balance at all times. This enables better
control of the chainsaw in unexpected situation.
• Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
• If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of these devices can reduce dust-
related hazards.
Not for Reproduction
4
IMPORTANT SAFETY INSTRUCTIONS
POWER TOOL USE AND CARE
• Do not force the Power tool. Use the correct chainsaw for your application. The correct
chainsaw will do the job better and safer at the rate for which it was designed.
• Do not use the chainsaw if the switch does not turn it on and off. Any chainsaw that
cannot be controlled with the switch is dangerous and must be repaired.
• Disconnect the battery pack from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
• Store idle chainsaws out of the reach of children and do not allow persons unfamiliar
with the chainsaw or these instructions to operate the chainsaw. Chainsaws are
dangerous in the hands of untrained users.
• Maintain chainsaws. Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the chainsaw’s operation. If damaged,
have the chainsaw repaired before use. Many accidents are caused by poorly maintained
chainsaws.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
• Use the chainsaw, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the
chainsaw for operations different from those intended could result in a hazardous situation.
BATTERY USE AND CARE
• Ensure the switch is in the off position before inserting battery pack. Inserting the
battery pack into power tools that have the switch on invites accidents.
• Rechargeonlywiththechargerspeciedbythemanufacturer. A charger that is suitable
for one type of battery pack may create a risk of re when used with another battery pack.
• Usepowertoolsonlywithspecicallydesignatedbatterypacks. Use of any other battery
packs may create a risk of injury and re.
• When battery pack is not in use, keep it away from other metal objects, like paper clips,
coins, keys, nails, screws, or other small metal objects, that can make a connection
from one terminal to another. Shorting the battery terminals together may cause burns or a
re.
• Underabusiveconditions,liquidmaybeejectedfromthebattery;avoidcontact.If
contactaccidentallyoccurs,ushwithwater.If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause irritation or burns.
SERVICE
• Haveyourchainsawservicedbyaqualiedrepairpersonusingonlyidentical
replacement parts. This will ensure that the safety of the chainsaw is maintained.
Not for Reproduction
5
IMPORTANT SAFETY INSTRUCTIONS
CHAIN SAW SAFETY WARNINGS
• Keep all parts of the body away from the saw chain when the chain saw is operation.
Before you start the chain saw, make sure the saw chain is not contacting anything. A
moment of inattention while operating chain saws may cause entanglement of your clothing or
body with the saw chain.
• Always hold the chain saw with your right hand on the rear handle and your left hand
on the front handle. Holding the chain saw with a reversed hand conguration increases the
risk of personal injury and should never be done.
• Hold the power tool by insulated gripping surfaces only, because the saw chain may
contact hidden wiring. Saw chains contacting a “live” wire may make exposed metal parts of
the chainsaw “live” and could give the operator an electric shock.
• Always use two hands when operating the chainsaw.
• Contact of the guide-bar tip with any object should be avoided.
• Tip contact may cause the guide bar to move suddenly upward and backward, which
may cause serious injury.
• Wearsafetyglassesandhearingprotection.Furtherprotectiveequipmentforhead,
hands, legs and feet is recommended. Adequate protective clothing will reduce personal
injury by ying debris or accidental contact with the saw chain.
• Do not operate a chain saw in a tree. Operation of a chain saw while up in a tree may result
in personal injury.
• Alwayskeepproperfootingandoperatethechainsawonlywhenstandingonxed,
secure and level surface. Slippery or unstable surfaces such as ladders may cause a loss of
balance or control of the chain saw.
• When cutting a limb that is under tension be alert for spring back. When the tension in
the wood bres is released the spring loaded limb may strike the operator and/or throw the
chain saw out of control.
• Use extreme caution when cutting brush and saplings. The slender material may catch
the saw chain and be whipped toward you or pull you off balance.
• Carry the chain saw by the front handle with the chain saw switched off and away from
yourbody.Whentransportingorstoringthechainsawalwaysttheguidebarcover.
Proper handling of the chain saw will reduce the likelihood of accidental contact with the
moving saw chain.
• Follow instructions for lubricating, chain tensioning and changing accessories.
Improperly tensioned or lubricated chain may either break or increase the chance for kickback.
• Keep handles dry, clean, and free from oil and grease. Greasy, oily handles are slippery
causing loss of control.
• Cut wood only. Do not use chain saw for purposes not intended. For example: do not
use chain saw for cutting plastic, masonry or non-wood building materials. Use of the
chain saw for operations different than intended could result in a hazardous situation.
Not for Reproduction
6
IMPORTANT SAFETY INSTRUCTIONS
W A R N I N G (PROPOSITION 65)
This product contains a chemical known to the state of California to cause cancer, birth defectsor
other reproductive harm.
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities
contains chemicals known to cause cancer, birth defects or other reproductive harm. Some
examples of these chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement and other masonry products, and
• Arsenic and chromium from chemically treated lumber.
Your risk of exposure to these chemicals varies depending on how often you do this type of work.
To reduce your exposure to these chemicals, work inven a well-ventilated area, and work with
approved safety equipment, such as dust masks that are specially designed to lter out microscopic
particles.
WARNING
When using an cordless chainsaw, basic safety precaution should always be followed to reduce the
risk of re, electric shock, and injury to persons.
CHILD SAFETY
Tragic accidents can occur if the operator is not aware of the presence of children.
• Keep children out of the working area and under the watchful care of a responsible adult.
• Do not allow children under the age of 14 to operate this blower. Children who are 14
years of age and older must read and understand the operating instructions and safety
rules in this manual and must be trained and supervised by a parent.
• Stay alert, and turn the blower off if a child or any other person enters the working area.
• Use extreme care when approaching blind corners, doorways, shrubs, trees, or other
objects that may obscure your view of a child who may run into the wrong area.
Not for Reproduction
7
IMPORTANT SAFETY INSTRUCTIONS
WARNING
Kickback may occur when the moving chain contacts an object at the upper portion of the tip of the
guide bar or when the wood closes in and pinches the saw chain in the cut. Contact at the upper
portion of the tip of the guide bar can cause the chain to dig into the object and stop the chain for
an instant. The result is a lightning fast reverse reaction which kicks the guide bar up and back
toward the operator. If the saw chain is pinched along the top of the guide bar, the guide bar can
be driven rapidly back toward the operator. Either of these reactions can cause loss of saw control
which can result in serious injury. Do not rely exclusively upon the safety devices built into the saw.
As a chainsaw user, you should take several steps to keep your cutting jobs free from accident or
injury.
CAUSES AND OPERATOR PREVENTION OF KICKBACK
1.Maintainarmgrip,withthumbsandngersencirclingthechainsawhandles,withboth
hands on the saw and position your body and arm to allow you to resist kickback forces.
Kickback forces can be controlled by the operator, if proper precautions are taken. Do not let go of
the chain saw.
2. Do not overreach and do not cut above shoulder height. This helps prevent unintended tip
contact and enables better control of the chain saw in unexpected situations.
3.Onlyusereplacementbarsandchainsspeciedbythemanufacturer. Incorrect
replacement bars and chains may cause chain breakage and/or kickback.
4. Follow the manufacturer’s sharpening and maintenance instructions for the saw chain.
Decreasing the depth gauge height can lead to increased kickback.
Rotational
Kickback Kickback
Danger Zone
Not for Reproduction
8
IMPORTANT SAFETY INSTRUCTIONS
LOW-KICKBACK SAW CHAIN
The rakers (depth gauges) ahead of each cutter can minimize the force of a kickback reaction
by preventing the cutters from digging in too deeply at the kickback zone. Only use replacement
chain that is equivalent to original chain or has been certied as low kickback chain per ANSI
B175.1. Low-kickback/skip tooth saw chain is a chain that has met the kickback performance
requirements of ANSI B175.1 - 1991. When tested on the representative sample of chainsaws
below 3.8 c.i.d. specied in ANSI B175.1 - 1991. As saw chains are sharpened during their
useful life, they lose some of the low-kickback qualities and extra caution should be used.
Push and pull - This reaction force is always opposite to the direction the chain is moving where
wood contact is made. Thus, the operator must be ready to control the PULL when cutting on the
bottom edge of the bar, and PUSH when cutting along the top edge.
UNDERSTANDING YOUR CHAINSAW SAFETY DEVICES
P
ULL PUSH
Not for Reproduction
9
SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their
meaning. Proper interpretation of these symbols will allow you to operate the product better and safer.
SYMBOLES DESIGNATION EXPLANATION
VVolts Voltage.
AAmperes Current.
Hz Hertz Frequency(cycles per second)
WWatts Power
hrs Hours Time.
n
o
No Load Speed Rotational speed, at no load
/ min Per minute Revolutions, strokes, surface speed, orbits etc., per minute
Lithium-ion Battery
Recyling
Designates that this tool is in compliance with
Lithium-ion battery recylcing program requirements
Safety Alert Symbol Precautions that involve your safety
Read the instruction
Manual
To reduce the risk of injury, user must read and understand
the instruction manual before using this product
Eye Protection Wear eye protection when operating this equipment.
Wear Ear Protection Wear ear protection when operating this equipment.
Gloves Wear non-slip, heavy-duty protective gloves when handling
the chainsaw and the blade
Kickback DANGER! Beware of kickback
Operate With Two
Hands Hold and operate the saw properly with both hands
One Handed Do not operate the saw using only one hand
Bar Nose Contact Avoid bar nose contact
Keep Bystanders
Away Keep all bystanders at least 50'(15m) away
Class II Construction
Wet Conditions Alert
Double-insulated construction
Do not expose to rain or use in damp locations
Not for Reproduction
SYMBOLS
10
The following signal words and meanings are intended to explain the levels of risk associated
with this product.
SERVICE
Servicing requires extreme care and knowledge and should be performed only by a qualied
service technician. For service we suggest you return the product to your nearest AUTHORIZED
SERVICE CENTER for repair. When servicing, use only identical replacement parts.
DANGER Indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
CAUTION Indicates a potentially hazardous situation, which, if not avoided,
may result in minor or moderate injury.
CAUTION (Without Safety Alert Symbol) Indicates a situation that may
result in property damage.
SAVE THESE INSTRUCTIONS
SYMBOL SIGNAL MEANING
• Do not use for wet materials.
• Disconnect before cleaning or changing accessories.
To avoid serious personal injury, do not attempt to use this product until you have read this Owner’s
Manual thoroughly and understand it completely. If you do not understand the warnings and
instructions in this Owner’s Manual, do not use this product. Call the Toll-free Helpline ( 1-800-317-
7833) for assistance.
WARNING
The operation of any power tool can result in foreign objects being thrown into your
eyes, which can result in severe eye damage. Before beginning power tool operation,
always wear safety goggles or safety glasses with side shields or a full face shield.
We recommend Wide Vision Safety Mask for use over eyeglasses or standard safety
glasses with side shields. Always use eye protection which is marked to comply with
ANSI Z87.1.
WARNING
WARNING
Not for Reproduction
11
KNOW YOUR CHAIN SAW
KNOW YOUR CHAIN SAW
The safe use of this product requires an understanding of the information on the product and in
this operator’s manual as well as a knowledge of the project you are attempting. Before use of
this product, familiarize yourself with all operating features and safety rules.
Front hand guard / Chain Brake
Guard Bar
Adjustment Screw
Chain Cover Lock Nuts
Chain Cover
Rear Handle
Scabbard
Wrench
On/Off Buttom
Low Kickback
Saw Chain
Front Handle
Oil Reservior Cap
Safety Lock
Quick View
Oil Indicator
Not for Reproduction
12
ASSEMBLY
UNPACKING
This product has been shipped completely assembled.
• Carefully remove the product and any accessories from the box. Make sure that all items
listed in the package contents section are included.
• Inspect the product carefully to make sure no breakage or damage occurred during
shipping.
• Do not discard the packing material until you have carefully inspected and satisfactorily
operated the product.
• If any parts are damaged or missing, please call 1-800-317-7833 for assistance.
PART NAME FIGURE QTY
Chainsaw 1
Scabbard 1
Wrench - 13mm (located inside
rear handle) 1
18'' Bar and Chain 1
Operator’s
manual 1
PACKING LIST
WARNING
If any parts are damaged or missing, do not operate this product until the parts are replaced.
Using a product with damaged or missing parts could result in serious personal injury.
WARNING
Do not attempt to modify this product or create accessories not recommended for use with this
product. Any such alteration or modication is mis use and could result in a hazardous condition
leading to possible serious personal injury.
Read all safety rules and instructions carefully before operating this tool.
Owner’s Manual
TOLL-FREE HELPLINE:
1-800-317-7833
www.snapper.com
SXDCS82
1696773
82V CORDLESS CHAIN SAW
Not for Reproduction
13
ASSEMBLY
ADDING BAR AND CHAIN LUBRICANT
Use a bar and chain lubricant with this product. It is designed for chains and chain oilers, and is
formulated to perform over a wide temperature range with no dilution required.
• Remove oil cap.
• Carefully pour the bar and chain oil into the tank.
• Wipe off excess oil and replace cap.
• Check and ll the oil tank when quick view oil indicator is below the MIN. line.
• Repeat as needed.
NOTE: Chain saw comes from the factory with no bar and chain oil added. The level should also
be checked after every 20 minutes of use and relled as needed.
NOTE:
• Do not use dirty, used or otherwise contaminated oils. Damage may occur to the bar or
chain.
• It is normal for oil to seep from the saw when not in use. To prevent seepage, empty the
oil tank after each use then run for one minute. When storing the unit for a long period of
time (three months or longer) be sure the chain is lightly lubricated; this will prevent rust
on the chain and bar sprocket.
Quick view oil indiacator
WARNING
Do not insert the battery until assembly is complete. Failure to comply could result in accidental
starting and possible serious personal injury.
Oil Reservoir
Cap
CHAIN
LUBRICANT
Not for Reproduction
14
ASSEMBLY
The battery pack is not charged when it is purchased. Before using the chain saw for the rst time,
place the battery pack in the battery charger and charge it fully. Be sure to read all safety
precautions, and follow the instructions in the section entitled Charging Procedure. With regular
use, the battery will require shorter charging times. When storing the chain saw for a prolonged
period of time, remove the battery. When the chain saw is going to be used again, charge the
battery pack for at least a full charging period. This product has no memory effect.
IMPORTANT
TO INSTALL THE BATTERY:
1. Align the battery pack (3) with the battery compartment on the chain saw.
2. Grasp the chain saw (2) rmly.
3. Push the battery pack into the battery compartment until the latch locks into place.
4. You should hear a "click" once the battery is installed.
BATTERY
IMPORTANT
This Lithium-ion battery pack is equipped with an internal circuit breaker which will automatically
shut off the power to the tool if overloaded.
If this occurs, release the trigger to reset the internal circuit breaker.
IMPORTANT
• Make sure the chain brake is not engaged;
• Pull back on chain brake guard;
• Press the O/I button to turn the unit on;
Not for Reproduction
ASSEMBLY
15
WARNING
Follow these instructions in order to avoid injury and to reduce the risk of electric shock or re:
• Replace the battery or the charger immediately if the battery case or charger cord is
damaged.
• Read, understand, and follow the instructions contained in the charger manual.
TO REMOVE THE BATTERY:
1. Press the battery release button on the chain saw. This will cause the battery to raise out
of the tool slightly.
2. Grasp the chain saw rmly and pull the battery out of the handle.
Not for Reproduction
16
OPERATION
STARTING AND STOPPING THE CHAIN SAW
A. To start the chain saw:
• Make sure chain tension is at desired setting. Refer to adjusting the chain tension in the Care
and Maintenance section of this manual.
• Make sure the chain cover lock knob is tight to the chain cover.
• Make sure no objects or obstructions are in the immediate vicinity which could come in contact
with the bar and chain.
• Fit the battery into the chain saw.
• Press the power button on the left of the rear handle. You will hear two beeps signalling the
chain saw is active.
• Press in the safety lock. This makes the trigger switch operational.
• Press and hold the trigger switch and keep it pressed for continued operation.
B. To stop the chain saw:
• Release the switch trigger to stop the chain saw.
• Upon release of the trigger switch, the safety lock will be automatically reset to the lock
position.
NOTE: It is normal for the chain to coast to a stop once the trigger switch is released.
On/Off Button
Switch Trigger
Safety Lock Buttom
Not for Reproduction
17
OPERATION
OPERATING THE CHAIN BRAKE
Check the operating condition of the chain brake prior to each use.
• Engage the chain brake by rotating your left wrist towards the guard, allowing the back of your
hand to engage the brake while the chain is rotating. Be sure to maintain both hands on the
saw handles at all times.
WARNING
If the chain brake does not stop the chain immediately, or if the chain brake will not stay in the run
position without assistance, take the saw to an authorized service center for repair prior to use.
BRAKE OFF BRAKE ON
Not for Reproduction
18
OPERATION
PREPARING FOR CUTTING
PROPER GRIP ON HANDLES
See General Safety Rules for appropriate safety equipment.
• Wear non-slip gloves for maximum grip and protection.
• Hold the saw rmly with both hands. Always keep your left hand on the front handle and
your right hand on the rear handle so that your body is to the left of the chain line.
• Maintain a proper grip on the saw whenever the motor is running. The ngers should
encircle the handle and the thumb should be wrapped under the handlebar. This grip is
least likely to be broken by a kickback or other sudden reaction of the saw. Any grip in
which the thumb and ngers are on the same side of the handle is dangerous because a
slight kick of the saw can cause loss of control.
WA RNIN G
DO NOT operate the
switch trigger with your
left hand and hold the
front handle with your
right hand. Never allow
any part of your body
to be in the chain line
while operating a saw.
Proper grip
Proper hand grip position
Chain line
Improper grip
Not for Reproduction
19
OPERATION
PROPER CUTTING STANCE
• Balance your weight with both feet on solid ground.
• Keep left arm with elbow locked in a “straight arm” position to withstand any kickback force.
• Keep your body to the left of the chain line.
• Keep your thumb on underside of front handle.
BASIC OPERATING/CUTTING PROCEDURES
Practice cutting a few small logs using the following technique to get the “feel” of using the saw
before you begin a major sawing operation.
• Take the proper stance in front of the wood.
• Press the safety lock and squeeze the trigger switch then release the safety lock and let the
chain accelerate to full speed before entering the cut.
• Begin cutting with the saw against the log.
• Keep the unit running the entire time you are cutting, maintain a steady speed.
• Allow the chain to cut for you; exert only light downward pressure. Forcing the cut could result
in damage to the bar, chain, or motor.
• Release the trigger switch as soon as the cut is completed, allowing the chain to stop. If you
run the saw without a cutting load, unnecessary wear can occur to the chain, bar, and unit.
• Do not put pressure on the saw at the end of the cut.
Chain Line Straight Arm
THUMB ON
UNDERSIDE OF
HANDLE BAR
Not for Reproduction
20
OPERATION
REMOVING BUTTRESS ROOTS
A buttress root is a large root extending from the trunk of the tree above the ground. Remove
large buttress roots prior to felling. Make the horizontal cut into the buttress rst, followed by the
vertical cut. Remove the resulting loose section from the work area. Follow the correct tree felling
procedure as stated in Proper Procedure For Tree Felling after you have removed the large
buttress roots.
PROPER PROCEDURE FOR TREE FELLING
• Felling a tree — When bucking and felling operations are being performed by two or
more persons at the same time, the felling operation should be separated from the
bucking operation by a distance of at least twice the height of the tree being felled. Trees
should not be felled in a manner that would endanger any person, strike any utility line or
cause any property damage. If the tree does make contact with any utility line, the utility
company should be notied immediately.
• Operator should keep on the uphill side of terrain as the tree is likely to roll or slide after
it is felled.
• Pick your escape route (or routes in case the intended route is blocked). Clear the
immediate area around the tree and make sure there are no obstructions in your planned
path of retreat. Clear the path of safe retreat approximately 135° from the planned line of
fall.
• Consider the force and direction of the wind, the lean and balance of the tree, and the
location of large limbs. These things inuence the direction in which the tree will fall. Do
not try to fell a tree along a line different from its natural line of fall.
• Remove dirt, stones, loose bark, nails, staples, and wire from the tree where felling cuts
are to be made.
• Notched Undercut. Cut a notch about 1/3 the diameter of the trunk on the side of the
tree. Make the notch cuts so they intersect at a right angle to the line of fall. This notch
should be cleaned out to leave a straight line. To keep the weight of the wood off the
saw, always make the lower cut of the notch before the upper cut.
Vertical Cut
Loose section
Horizontal
Cut
Planned Line o
f
f
all
Path of safe retreat
135°from planned
line of fall
Not for Reproduction
