Snapper NP216012 User manual

Parts Manual fo
r
Revision 7,
21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
COPYRIGHT
©
2005
McDonough, GA, 30253 U.S.A.
TP 400-5137-7-WB-N
11/14/2005 Manual No. 7006059
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
PUSH MODELS PROPELLED
MODELS
215012 EFRP216012TV
215014 EFRP216512TV
215015 EFRP216516BV
216015 EFRP216516TV
216515BV EP216012
FR215014 FRP216012
N21501
2
FRP216012TV
NR215012 FRP216016
R21501
2
FRP216512TV
NP216012
NRP215012
P216012
P216012
E
P216012TV
P216512BV
P216512TV
RP215012
RP215012T2
RP216012
WP216512BV

Table Of Content
s
TP 400-5137-7-WB-N
Manual No. 700605921" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16 3
PAGE GROUP
4Handles & Controls
10 Cutting Deck, Blades
14 Front Wheel Bracket
16 Rear Wheel Brackets, Latches
18 Front Wheels
20 Rear Wheels
22 Drive System Self-Propelled
26 Transmission (Differential)
28 Throttle Controls (1997 Thru 2001 Models)
30 Decals (Part 1)
32 Decals (Part 2)
34 Decals (Part 3)
36 Decals (Part 4)
38 Side Chute, Adapter
40 Accessory - Grass Bag
42 Accessory - Snapperizer
44 Accessory - Recycling Kits
46 Thatcherizer - Accessory
48 Electric Start

Handles & Controls
TP 400-5137-7-WB-N
Manual No. 7006059 21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
4

Handles & Controls
Footnotes:
TP 400-5137-7-WB-N
Manual No. 700605921" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16 5
Part No Descri
p
tionItem Qt
y
Note
1 7046914 HANDLE, Upper Was 24889
7035252 HANDLE, Upper NRP215012, RP215012
7074384 HANDLE, Upper Was 33473, Note #2
7074254 HANDLE, Upper 215015, 216015, 216515BV
7046914 HANDLE, Upper Used on P216012E
2 7024890 HANDLE, Middle Note #1
7036350 HANDLE, Middle Note #3
3 7033985 HANDLE, Lower Left Hand Note #1
7046502 HANDLE, Lower Left Hand Was 35343, Note #3
7046502 HANDLE, Lower Left Hand 215015, 216015, 216515BV
4 7033986 HANDLE, Lower Right Hand Note #1
7035342 HANDLE, Lower Right Hand Note #4
5 7017072 CONTROL, Blade Note #3
7047011 CONTROL, Blade 215015, 216015, 216515BV
6 7033904 CLIP, Blade Control Used on All Except 215015
7034872 CLIP, Blade Control 215015, 216015, 216515BV
7 7025036 CABLE, Blade Control (50-1/2" Long) Note #1
7026136 CABLE, Blade Control (74-1/16" Long) Used on RP215012T2
7035808 CABLE, Blade Control (46-1/16" Long) Note #3
7035840 CABLE, Blade Control (60" Long) P216012TV, FRP216012TV,
EFRP216012TV
7072933 CABLE, Blade Control (49-1/4" Long) 215015, 216015, 216515BV
8 7032826 HANDLE, Wheel Drive Self-Propelled Models
9 7014307 GRIP, Wheel Drive Handle Self-Propelled Models
7029775 GRIP, Wheel Drive Handle European Models
10 7025013 CABLE, Clutch Pull (Z-BEND) (41-7/16" Long) Note #1
7023134 CABLE, Clutch Pull (Z-BEND) (36-1/16" Long) NRP215012, RP215012
11 7012121 COVER, Vinyl Self-Propelled Models
12 7012122 SPRING, Clutch Self-Propelled Models
13 7038478 SECTOR, Speed Self-Propelled Models
14 7024641 TIE, Wire (3) Self-Propelled Models
15 7012093 SPRING, Speed Control Self-Propelled Models
16 7090188 WASHER, 3/8" Flat Self-Propelled Models
17 7023801 GRIP, Speed Control Handle Note #1
7023801 GRIP, Speed Control Handle NRP215012, RP215012
18 7034892 ANCHOR, Speed Control Self-Propelled Models
19 7032408 GUIDE, Lower V-Belt Self-Propelled Models
20 7023790 ROD, Transfer American models
Note 1: RP215012T2, RP216012, NP216012, EP216012, P216012, P216012E, P216012TV, P216512BV, FRP216012TV,
EFRP216012TV, FRP216012, FRP216016, EFRP216512TV, EFRP216516TV & EFRP216516BV.
Note 2: N215012, 215012, 216015, NR215012, 8215012.

Handles & Controls
TP 400-5137-7-WB-N
Manual No. 7006059 21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
6

Handles & Controls
Footnotes:
TP 400-5137-7-WB-N
Manual No. 700605921" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16 7
Part No Descri
p
tionItem Qt
y
Note
20A 7051698 ASSEMBLY, Transfer Rod European models
21 7010937 CLIP, Transfer Rod Self-Propelled Models
22 7090895 TEE-NUT, 5/16-18 Self-Propelled Models
23 7012114 BUSHING, Differential Self-Propelled Models
24 7090595 BOLT, 5/16-18 x 3/4" Flange Lock, Grade 5
25 7090238 SCREW, 5/16-24 x 1" Hex Cap, Grade 5
26 7090799 BOLT, 5/16-18 x 5/8" Carriage, Grade 5 Was 91026 (Used on All Models)
27 7091601 NUT, 5/16-18 Hex Flange Lock, Grade 5 Was 91070 (Used on All Models)
28 7091606 NUT, 5/16-24 Center Lock, Grade 5 Was 91074 (Used on All Models)
28 7091606 NUT, 5/16-24 Center Lock, Grade 5 Was 91074 (Used on All Models)
29 7023813 CLIP, Cable/Wiring
30 7091740 4 SCREW, 5/16-18 x 1-7/8 Curved Head, Grade 2 Was 91189 (Used on All Models)
31 7035744 T-KNOB, 5/16-18
32 7079577 SCREW, 1/4-20 x 1-1/2 Hex Cap, Grade 5
33 7090053 WASHER, 1/4 Internal Tooth Lock Was 91023 (Used on All Models)
34 7091576 NUT, 1/4-20 Hex, Grade 5 or B Was 91100 (Used on All Models)
35 7090505 SCREW, 1/4-20 x 2" Hex Cap, Grade 5
36 7014343 4 BUSHING
37 7023792 PIN, 1/4" X 1-1/2"
38 7091020 PUSH-NUT, 1/4"
39 7024211 DECAL, Blade Control (L.H. Side) Used on All (Except European)
7029782 DECAL, Operator's Presence Control Used on European Models
7029785 DECAL, Handle International Warning Used on European Models
40 7026141 GUIDE, Rope
41 7075634 GRIP, Foam Was 73115, Note #1
7022460 GRIP, Foam Used on P216012E &
P216512BV
42 7024087 DECAL, Speed Select Except European
7029783 DECAL, Speed Select European Models
43 7023153 CLAMP, Casing
44 7090391 WASHER, 5/16 Internal Tooth Lock
45 7090545 SCREW, 5/16-24 x 1-1/2" Machine, Grade 5
46 7022779 GUIDE, Rope Used on Grass Bag Models
47 7029217 ASSEMBLY, Speed Control Lever (Includes Items 48 thru 51),
Note #1
47A 7029233 ASSEMBLY, Speed Control Lever Includes Items 48A, 49A, 50A &
51
48 7029217 ROD, Upper Was 29153, Note #1
48A 7029189 ROD, Upper NRP215012, RP215012
49 7029217 ROD, Intermediate Was 29154, Note #1
49A 7029190 ROD, Intermediate NRP215012, RP215012
Note 1: RP215012T2, RP216012, NP216012, EP216012, P216012, P216012E, P216012TV, P216512BV, FRP216012TV,
EFRP216012TV, FRP216012, FRP216016, EFRP216512TV, EFRP216516TV & EFRP216516BV.
Note 2: N215012, 215012, 216015, NR215012, 8215012.

Handles & Controls
TP 400-5137-7-WB-N
Manual No. 7006059 21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
8

Handles & Controls
Footnotes:
TP 400-5137-7-WB-N
Manual No. 700605921" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16 9
Part No Descri
p
tionItem Qt
y
Note
50 7029217 ROD, Lower Was 29155, Note #1
50A 7029191 ROD, Lower NRP215012, RP215012
51 7029161 2 NUT, 1/4-20 Wing Used on Item 47 & 47A
52 7023154 SCREW, #10-32 x 5/8" Self-Tapping Used on All Models
53 7024669 TIE, Wire Self-Propelled Models
54 7026219 CLAMP Self-Propelled Models
55 7046465 GUIDE, Rope Used on: 215014.
56 7076978 NUT, 1/4-20 Nyloc Used on: 215014.
57 7012080 CABLE-TIE, 7" Used on: 215014.
58 7079577 SCREW, 1/4-20 x 1-1/2" Hex Head Cap, Grade 5 Used on: 215014.
-- Note 3: NRP215012, RP215012, N215012, 215012, 216015,
NR215012, 8215012.
-- Note 4: NRP215012, RP2150122, N215012, 215012, 216015,
NR215012, 8215012, 215015, 216015, 216515BV.
Note 1: RP215012T2, RP216012, NP216012, EP216012, P216012, P216012E, P216012TV, P216512BV, FRP216012TV,
EFRP216012TV, FRP216012, FRP216016, EFRP216512TV, EFRP216516TV & EFRP216516BV.
Note 2: N215012, 215012, 216015, NR215012, 8215012.

Cutting Deck, Blades
TP 400-5137-7-WB-N
Manual No. 7006059 21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
10

Cutting Deck, Blades
Footnotes:
TP 400-5137-7-WB-N
Manual No. 700605921" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16 11
Part No Descri
p
tionItem Qt
y
Note
1 7057663 DECK, Mower Painted deck with decals
1
A&
B
7058540 DECK, Mower FR & EFR Models; Painted
Baffle Type Deck w/Decals
2 7091601 10 NUT, 5/16-18 Hex Flange Lock, Grade 5 Was 90585
3 7090731 10 BOLT, 5/16-18 x 1/2" Short Neck Carriage (Gr. 5)
4 7091169 BOLT, Bolt 5/16-18 x 1-1/8" Short Neck Carriage, Grade 5
5 7090324 3 SCREW, 3/8-16 x 1" Self-Tapping (Engine Mounting)
7 7090534 SCREW, 5/16-18 x 1/2" Hex Head Cap, Grade 5
8 7090702 BOLT, 5/16-18 x 2-1/4" Hex Flange Lock
9 7013320 BUSHING
10 7033863 COVER, Belt (European Models)
11 7031961 2 WASHER, 7/16 Flat
12 7090483 SCREW, 3/8-24 x 1-3/4" Hex Head Cap, Grade 5
13 7012063 WASHER, Cone (2)
14 7019795 BLADE, Cutter (European)
14A 7017168 BLADE, Cutter (Mulching)
14B 7026691 BLADE, Cutter (Standard Lift)
14C 7026407 BLADE, Cutter (Quad Edge - Ninja)
15 7015626 HUB, Blade Drive 25mm
16 7015894 KEY, Woodruff #506 (Briggs)
17 7090201 SCREW, 5/16-18 x 5/16" Hex Socket Set
18 7015780 PULLEY, Engine (25mm I.D. x 2-1/8" O.D.)
19 7031968 SHIELD, Belt Opening Cover (Push Models Only)
20 7041400 STRUCTURE, Fender (European Models)
21 7091508 2 BOLT, 5/16-18 x 3/4" Short Neck Carriage, Grade 5 Was 90001
22 7011791 RETAINER, 5/16 Bolt
23 7091601 3 NUT, 5/16-18 Hex Flange Lock, Grade 5 Was 91070
7060785 KIT, Air Lift (Includes items 24 thru 27)
24 7032558 2 LIFT, Air
25 7090391 6 WASHER, 5/16 Internal Tooth Lock
26 7091297 4 NUT, 5/16-24 Hex, Grade 5 Was 90223
27 7090228 4 SCREW, 5/16-24 x 21/32" Machine
28 7054494 ASSEMBLY, Front Baffle Used on FRP216012,
FRP216012TV, Includes decal
29 7029193 DECAL, Front Baffle
30 7054493 ASSEMBLY, Front Baffle Used on EFRP216012TV,
EFRP216512TV,Includes decal
31 7036463 DECAL, Front Baffle

Cutting Deck, Blades
TP 400-5137-7-WB-N
Manual No. 7006059 21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
12

Cutting Deck, Blades
Footnotes:
TP 400-5137-7-WB-N
Manual No. 700605921" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16 13
Part No Descri
p
tionItem Qt
y
Note
32 7090316 2 BOLT, 5/16-18 x 3/4" Carriage, Grade 5
33 7090189 2 WASHER, 5/16 Internal/External Lock
34 7024085 2 WINGNUT, 5/16-18 Nylok
35 7091076 WASHER, 5/16 Flat
36 7029000 3/16" THICK SPACER, Blade Hub ("FRP" & "EFRP" Models)
7044770 1/16" THICK SPACER, Blade Hub
37 7046446 BAFFLE, Belt
38 7046471 PLUG, 5/16" Square Hole (Qty. 3 on Push)
39 7045264 PLUG, 5/16" Round Hole (Qty. 3 on Push; Qty. 2 on Self-
Propelled)
40 7091122 4 SCREW, 1/4-20 X 1/2" Hex Self-Tapping Was 90539
41 7046720 DECAL, Warning Chute/Deflector
42 7046780 2 PLUG, Hole
43 7072426 BAFFLE, Front (FRP216016, EFRP216516TV
and EFRP216516BV Models
Only)
44 7090951 2 NUT, 5/16-18 Hex Center Lock

Front Wheel Bracket
TP 400-5137-7-WB-N
Manual No. 7006059 21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
14

Front Wheel Bracket
Footnotes:
TP 400-5137-7-WB-N
Manual No. 700605921" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16 15
Part No Descri
p
tionItem Qt
y
Note
1 7051886 ASSEMBLY, Arm Right Wheel (Consists of Items 2,3,4,5A,6)
7051885 ASSEMBLY, Arm Left Wheel (Consists of Items 2,3,4,5B,6)
2 7015761 BOLT, 5/16-18 x 3/4" Shoulder
3 7012325 LATCH, Height
4 7027702 GRIP, Latch
5A 7031017 ARM, Right Wheel (Round Hole)
5B 7031016 ARM, Left Wheel (Square Hole) (Not shown)
6 7011791 RETAINER, 5/16 Bolt
7 7091601 NUT, 5/16-18 Hex Flange Lock, Grade 5 Was 91070
8 7074702 BRACKET, Front Wheel Was 41770
9 7021119 AXLE

Rear Wheel Brackets, Latches
TP 400-5137-7-WB-N
Manual No. 7006059 21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
16

Rear Wheel Brackets, Latches
Footnotes:
TP 400-5137-7-WB-N
Manual No. 700605921" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16 17
Part No Descri
p
tionItem Qt
y
Note
1 7012312 BEARING, 9/16
2 7091012 3 SCREW, #10-32 x 3/8" Self-Tapping (Torx)
3 7035717 LATCH, Height Adjusting (Long)
4 7091576 NUT, 1/4-20 Hex, Grade 5 Was 90063
5 7091601 6 NUT, 5/16-18 Hex Flange Lock, Grade 5 Was 91070
6 7054228 ASSEMBLY, Wheel Arm (Right Rear) (Push Models); (Round
Opening - Includes Items 3, 10,
14, 15, 16)
7 7054229 ASSEMBLY, Wheel Arm (Left Rear) (Push Models); (Square
Opening - Includes Items 3, 11,
14, 15, 16)
8 7054230 ASSEMBLY, Wheel Arm (Right Rear) Was 54230 (Self-Propelled
models)(Incl. 1, 2, 3, 12, 14, 15
& 16)
9 7054247 ASSEMBLY, Wheel Arm (Left Rear) Was 54231 (Self-Propelled
Models)(Includes 1, 2, 3, 13, 15,
& 16)
10 7033776 ARM, Round Axle End (Round Opening) (Right Rear) (Push Models)
11 7033775 ARM, Square Axle End (Square Opening) (Left Rear) (Push Models)
12 7032722 ARM, Wheel Right Rear (Self Propelled Models)
13 7032723 ARM, Wheel Left Rear (Self Propelled Models)
14 7011078 BOLT, 5/16-18 x 1" Shoulder
15 7011791 RETAINER, 5/16 Bolt
16 7027702 GRIP, Latch
17 7033494 BRACKET, Right Rear Wheel
18 7033495 BRACKET, Left Rear Wheel
19 7021119 AXLE (Rear on Push Models - Also
Front on All)
20 7035741 GUARD, Rear Foot (Push Models)
21 7029008 GUARD, Rear Foot (Self-Propelled Models); (Except
European)
7017010 GUARD, Rear Foot (European Models)
22 7023791 RING
23 7012616 SUPPORT, Foot Guard
24 7091604 BOLT, 1/4-20 x 1/2" Short Neck Carriage, Grade 5 Was 90005
25 7090053 WASHER, 1/4 Internal Tooth Lock Was 91023
26 7090731 BOLT, 5/16-18 x 1/2" Short Neck Carriage, Grade 5

Front Wheels
TP 400-5137-7-WB-N
Manual No. 7006059 21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
18

Front Wheels
Footnotes:
TP 400-5137-7-WB-N
Manual No. 700605921" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16 19
Part No Descri
p
tionItem Qt
y
Note
1 7022374 WHEEL, 8 x 1.75 Plastic (Push & RP215012 &
NRP215012 Models)
7046990 WHEEL, 8 x 1.75, .442 Bore (215014, 215015, 216015 &
216515BV Models.)
2 7029010 WHEEL, 8 x 1.75 Plastic (Self-Propelled Except
RP215012 & NRP215012)
3 7017829 PLUG, Wheel
4 7090377 NUT, 7/16-20 Hex (Thin)
5 7012309 BUSHING, Axle (All Models except 215014 &
215015)
6 7031961 WASHER, 7/16 x 1" O.D. Flat

Rear Wheels
TP 400-5137-7-WB-N
Manual No. 7006059 21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
20
